Michell Instruments Easidew I.S. User manual

Easidew I.S.
Dew-Point Transmitter
User Manual
97099 Issue 16.2
July 2021
E
a
s
i
d
e
w
I
.
S
.
D
e
w
-
P
o
i
n
t
0
9
0
6
R
a
n
g
e
:
-
1
0
0
/
+
2
0
4
8
L
a
n
c
a
s
t
e
r
W
a
y
B
E
l
y
,
C
a
m
b
r
i
d
g
e
s
C
B
6
3
N
U
n
i
t
e
d
K
i
n
g
M
I
C
H
E
I
n
s
t
r
u
m
e
n

Please ll out the form(s) below for each instrument that has been purchased.
Use this information when contacting Michell Instruments for service purposes.
Transmitter
Code
Serial Number
Invoice Date
Location of Instrument
Tag Number
Transmitter
Code
Serial Number
Invoice Date
Location of Instrument
Tag Number
Transmitter
Code
Serial Number
Invoice Date
Location of Instrument
Tag Number

© 2021 Michell Instruments
This document is the property of Michell Instruments Ltd and may not be copied or
otherwise reproduced, communicated in any way to third parties, nor stored in any Data
Processing System without the express written authorization of Michell Instruments Ltd.
Easidew I.S.
For Michell Instruments' contact information please go to
www.michell.com

Easidew I.S. User Manual
iv 97099 Issue 16.2, July 2021
Contents
Safety ................................................................................................................................vi
Electrical Safety ...........................................................................................................vi
Pressure Safety ............................................................................................................vi
Toxic Materials .............................................................................................................vi
Repair and Maintenance ...............................................................................................vi
Calibration ...................................................................................................................vi
Safety Conformity ........................................................................................................vi
Abbreviations .....................................................................................................................vii
Warnings ...........................................................................................................................vii
1 INTRODUCTION ............................................................................................VIII
1.1 Features .......................................................................................................... viii
2 INSTALLATION ..................................................................................................1
2.1 Unpacking the Instrument ................................................................................... 1
2.2 Preparation of the Sensor Cable .......................................................................... 2
2.3 Cable Connection ............................................................................................... 4
2.4 Electrical Schematic ............................................................................................ 4
2.4.1 Electrical Boundaries ..................................................................................... 5
2.5 Transmitter Mounting .......................................................................................... 5
2.5.1 Transmitter Mounting - Sample Block (Optional) .............................................. 6
2.5.2 Transmitter Mounting - Direct Pipeline Connection ........................................... 7
2.5.3 Transmitter Mounting - With Additional Process Connection Adapter ................ 8
3 OPERATION ......................................................................................................9
4 GOOD MEASUREMENT PRACTICE .....................................................................10
5 MAINTENANCE ................................................................................................13
5.1 O-Ring Replacement ......................................................................................... 14

Easidew I.S. User Manual
Michell Instruments v
Figures
Figure 1 DIN43650 Transmitter Unpacking Method ....................................................2
Figure 2 Connector Terminal Block Removal ..............................................................3
Figure 3 Bare Wires .................................................................................................3
Figure 4 Crimped Wires ...........................................................................................3
Figure 5 Cut to 5mm ...............................................................................................4
Figure 6 Connection to Connector Terminal Block .......................................................4
Figure 7 Wiring Connections .....................................................................................4
Figure 8 Connector Installation .................................................................................5
Figure 9 Electrical Connections .................................................................................5
Figure 10 Transmitter Mounting ..................................................................................7
Figure 11 Transmitter Mounting - Pipe or Duct.............................................................8
Figure 12 Transmitter Mounting with Adapter .............................................................9
Figure 13 Installation Location .................................................................................10
Figure 14 Indication of Dead Space ..........................................................................10
Figure 15 Material Permeability Comparison ..............................................................11
Figure 16 Replacement of HDPE Guard .....................................................................14
Figure 17 Dimensions .............................................................................................18

Easidew I.S. User Manual
vi 97099 Issue 16.2, July 2021
Appendices
Appendix A Technical Specications .............................................................................13
A.1 Dimensions .................................................................................14
Appendix B System Drawings .......................................................................................16
B.1 Baseefa Approved System Drawing ...............................................16
B.2 FM Approved System Drawing ...................................................... 17
B.3 CSA Approved System Drawing .....................................................18
Appendix C Hazardous Area Certication ......................................................................20
C.1 Product Standards .......................................................................20
C.2 Product Certication ....................................................................20
C.3 Global Certicates/Approvals ........................................................20
C.4 Terminal Parameters ....................................................................20
C.5 Special Conditions of Use ............................................................. 21
C.6 Maintenance and Installation ........................................................21
Appendix D Quality, Recycling & Warranty Information ...................................................23
Appendix E Return Document & Decontamination Declaration ........................................25

Easidew I.S. User Manual
Michell Instruments vii
Safety
The manufacturer has designed this equipment to be safe when operated using the procedures
detailed in this manual. The user must not use this equipment for any other purpose than that
stated. Do not apply values greater than the maximum value stated.
This manual contains operating and safety instructions, which must be followed to ensure the safe
operation and to maintain the equipment in a safe condition. The safety instructions are either
warnings or cautions issued to protect the user and the equipment from injury or damage. Use
competent personnel using good engineering practice for all procedures in this manual.
Electrical Safety
The instrument is designed to be completely safe when used with options and accessories supplied
by the manufacturer for use with the instrument.
Pressure Safety
DO NOT permit pressures greater than the safe working pressure to be applied to the instrument. The
specied safe working pressure is 45 MPa (450 barg/6500 psig). Refer to the Technical Specications
in Appendix A.
Toxic Materials
The use of hazardous materials in the construction of this instrument has been minimized. During
normal operation it is not possible for the user to come into contact with any hazardous substance
which might be employed in the construction of the instrument. Care should, however, be exercised
during maintenance and the disposal of certain parts.
Repair and Maintenance
The instrument must be maintained either by the manufacturer or an accredited service agent. Refer
to www.michell.com for details of Michell Instruments’ worldwide oces contact information.
Calibration
The recommended calibration interval for this instrument is 12 months unless it is to be used in a
mission-critical application or in a dirty or contaminated environment in which case the calibration
interval should be reduced accordingly. The instrument should be returned to the manufacturer,
Michell Instruments Ltd., or one of their accredited service agents for re-calibration.
Safety Conformity
This product meets the essential protection requirements of the relevant EU and US standards
and directives. Further details of applied standards may be found in the Technical Specications in
Appendix A.

Easidew I.S. User Manual
viii 97099 Issue 16.2, July 2021
Abbreviations
The following abbreviations are used in this manual:
barg pressure unit (=100 kP or 0.987 atm) (bar gauge)
°C degrees Celsius
°F degrees Fahrenheit
DC direct current
dp dew point
fps feet per second
ft-lbs feet per pounds
g grams
lbs/in pounds per inch
µm micrometer
m/sec meters per second
mA milliampere
max maximum
mm millimetres
MPa megapascal
Nl/min normal liters per minute
Nm Newton meter
oz ounces
ppmV parts per million by volume
psig pounds per square inch
RH relative humidity
scfh standard cubic feet per hour
V Volts
Ω Ohms
ø diameter
“ inch(es)
Warnings
The following general warning listed below is applicable to this instrument. It is repeated
in the text in the appropriate locations.
Where this hazard warning symbol appears in the following
sections it is used to indicate areas where potentially hazardous
operations need to be carried out.

Easidew I.S. User Manual
Michell Instruments 1
INTRODUCTION
1 INTRODUCTION
The Easidew I.S. dew-point transmitter has been manufactured, tested and calibrated
to the highest available standards and should be in perfect working order, ready for
installation into a gas measurement application. If, after reading this manual, there
are any questions about the instrument or how to install and operate it, please contact
a Michell representative. Refer to www.michell.com for details of Michell Instruments’
worldwide oces contact information.
This manual covers the following Easidew I.S. (Intrinsically Safe) dew-point products:
Easidew I.S. with G 1/2” BSP thread
Easidew I.S. with 3/4” UNF thread
Easidew I.S. with 5/8” UNF thread
1.1 Features
The Easidew I.S. dew-point transmitter is a continuous, on-line, 4-20 mA transmitter
for the measurement of dew-point temperature or moisture content in air and other
non-corrosive gases. It is designed specically for use within Zone 0, 1 and 2 hazardous
areas.
The key features are:
• IECEx, CSA, FM, ATEX certied transmitter for use in hazardous areas
• G1/2” BSP, 3/4” or 5/8” UNF process connection
• Dew-point or ppmV moisture content
• 2-wire loop powered connection
• Rugged 316 stainless steel IP66 construction
• Measurement ranges -100...+20°Cdp (-148...+68°Fdp)
-110...+20°Cdp (-166...+68°Fdp)
• Accuracy ±2°Cdp
• Calibration Certicate (NPL, NIST)

Easidew I.S. User Manual
297099 Issue 16.2, July 2021
INSTALLATION
2 INSTALLATION
2.1 Unpacking the Transmitter
On removing the transmitter from the box, please check that all the following standard
components are included:
• Easidew Transmitter
• Certicate of Calibration
• Electrical Connector (DIN 43650 models only)
E
a
s
i
d
e
w
I
.
S
.
D
e
w
-
P
o
i
n
t
0
9
0
6
R
a
n
g
e
:
-
1
0
0
/
+
2
0
4
8
L
a
n
c
a
s
t
e
r
W
a
y
B
E
l
y
,
C
a
m
b
r
i
d
g
e
s
C
B
6
3
N
U
n
i
t
e
d
K
i
n
g
M
I
C
H
E
I
n
s
t
r
u
m
e
n
Figure 1 DIN43650 Transmitter Unpacking Method
The Transmitter will also be supplied with a process seal, which will be tted to the
unit. Depending on the version, this will either be a bonded seal (5/8” or G1/2” thread
versions) or an o-ring seal (3/4” thread versions).
The transmitter sensing element is protected while in transit by a blue plastic cover
containing a small desiccant capsule. The cover should be removed before operation
but should be retained in case required for return shipping.
Depending on the model, the transmitter may come with the electrical connector tted
to protect the transmitter pins during transit. Keep the connector in a safe place until
ready to wire up the sensor.

Easidew I.S. User Manual
Michell Instruments 3
INSTALLATION
2.2 Preparation of the Sensor Cable
The sensor cable is NOT supplied as standard. A cable can be obtained by contacting
your local distributor or Michell Instruments (see www.michell.com for details).
The crimps supplied must be tted onto any cable installed
into the connector in order to comply with Hazardous Area
Certication of the product.
If making a cable assembly it is important that the cable is correctly terminated. See
Figures 3 to 6 .
Cable connection to the Easidew I.S. transmitter is made via the removable connector.
Removing the central screw enables the connector terminal block to be removed from
the outer housing by using a small screwdriver to prise it clear.

O-ring
and washer
Figure 2 Connector Terminal Block Removal
Caution: When removing the central screw ensure that the
small sealing O-ring and the washer are retained on the screw
and are present during re-installation.
NOTE: Figure 3 to Figure 6 shown below, should be followed in detail. The
crimps should be applied such that there is no possibility of a conductor
strand of a core becoming free (see Figure 4) .
Figure 3
Bare Wires
Figure 4
Crimped Wires

Easidew I.S. User Manual
497099 Issue 16.2, July 2021
INSTALLATION
When the crimp is made it should have a minimum of 2 positions of crimping. After the
crimp is made it should be trimmed to a length of 5mm (see Figure 5) . When the crimps
are installed into the connector terminal block ensure they are fully inserted, as shown
in Figure 6 , before tightening the terminal clamping screw.
10
mm
1
2
3 4
Figure 5 Cut to 5mm
Figure 6 Connection to Connector
Terminal Block
When all wire connections are made, ensure that there is a minimum clearance distance
and a minimum creepage distance in air of 2mm (0.8”) between each terminal.
For the transmitter to work properly, and to achieve maximum performance, the sensor
cable must be connected to the sensor connector as shown in the drawing below.
Note: The drawing below shows the identity of the connector terminals and
wiring connections of the cable manufactured by Michell Instruments.
SCALE 2:1


SHORT
AS POSSIBLE

1
3
24
BLUE
BRAID BRAID
GREEN - 4-20 mA
(SOURCE)
SCREEN
RED
+POWER
GND
VIEW ON REAR
OF CONNECTOR
GREEN
SIGNAL (SOURCE) GREEN
YELLOW
BLUE
RED


BLUE - SCREEN
RED + POWER
GREEN - 4-20 mA
BLUE - SCREEN
RED + POWER
GN
RD
BL
Figure 7 Wiring Connections
Always connect the 4-20 mA return signal to a suitable load
(see Figure 7) before the power is applied. Without this
connection, the transmitter may be damaged if allowed to
operate for prolonged periods.

Easidew I.S. User Manual
Michell Instruments 5
INSTALLATION
2.3 Cable Connection
When installing the connector, and to ensure that full ingress protection is achieved, the
securing screw (with the O-ring and washer) must be tightened to a minimum torque
setting of 3.4 Nm (2.5 ft-lbs). The sensor cable used must be a minimum diameter of
4.6mm (0.2”).
O-ring
and washer

Figure 8 Connector Installation
2.4 Electrical Schematic
NOTE: The screen/shield should be connected for maximum performance
and to avoid interference.
DEW-POINT
TRANSMITTER
CERTIFICATION No’s:
Baseefa06ATEX0330X
IECEx BAS 06.0090X
TRANSMITTER VERSION
TERMINAL NUMBER
EASIDEW I.S.
3
1
(+) (+)
(-)
(RETURN)
HAZARDOUS AREA SAFE AREA
GALVANIC ISOLATION INTERFACE
KFD2-STC4-Ex1 H
KFD0-CS-Ex2.50p
KFD2-CR-Ex1.20200
KFD2-CR-Ex1.30200
KFD0-CS-Ex1.50P
MTL5041
MTL5040
MTL5541
+4-20 mA LOAD
+VS (20 - 35 V DC)
VS -
-




Figure 9 Electrical Connections

Easidew I.S. User Manual
697099 Issue 16.2, July 2021
INSTALLATION
2.5 Transmitter Mounting
Prior to installation of the transmitter, unscrew and remove the black, green or blue
plastic cover and retain for future use. Take care to prevent any contamination of
the sensor before installation (handle the transmitter by the main body only,
avoiding contact with the sensor guard).
The Easidew I.S. can be mounted either into a ow-through sensor sampling block
(optional) or directly into a pipe or duct. It can be operated at pressures of up to 45 MPa
(450 barg / 6500 psig) when tted with the bonded seal or O-ring provided.
The recommended gas ow rate, when mounted in the optional sampling block, is 1 to
5 Nl/min (2.1 to 10.6 scfh). However, for direct insertion applications, gas ow can be
from static to 10 m/sec (32.8 fps).
NOTE: Pass the seal over the mounting thread and assemble into the sampling
location, by hand, using the wrench ats only. DO NOT grip and twist the
sensor cover when installing the sensor.
When installed, fully tighten using a wrench until the seal is fully compressed and to the
following torque settings:
• G 1/2” BSP 56 Nm (41.3 ft-lbs)
• 3/4” - 16 UNF 40 Nm (29.5 ft-lbs)
• 5/8” - 18 UNF 30.5 Nm (22.5 ft-lbs)

Easidew I.S. User Manual
Michell Instruments 7
INSTALLATION
2.5.1 Transmitter Mounting - Sample Block (Optional)
The following procedure must be carried out by a qualied
installation engineer.
To mount the transmitter into the sensor block (preferred method), proceed as follows,
refer to Figure 12.
1. Ensure that the green, blue or black protective cover (2), and its
desiccant capsule (2a), have been removed from the tip of the
transmitter.
2. G 1/2” and 5/8” Versions - Ensure that the bonded seal (2) is over the
threaded part of the transmitter body.
3/4” Version - Ensure the O-ring is fully seated in the recess.
Under no circumstances should the sensor guard be handled
with the ngers.
3. Screw the transmitter (1) into the sample block (3) and tighten to the
appropriate torque setting (see Section 2.5). NOTE: Use the ats of
the hexagonal nut and not the sensor body.
4. Fit the transmitter cable/connector assembly to the plug located on the
base of the transmitter and tighten the xing screw (see Section 2.3).
1
2
3
5
7
6
2a
4
4
Figure 10 Transmitter Mounting

Easidew I.S. User Manual
897099 Issue 16.2, July 2021
INSTALLATION
2.5.2 Transmitter Mounting - Direct Pipeline Connection
The transmitter may be directly mounted into a pipe or duct as shown in Figure 13.
Caution: Do not mount the transmitter too close to the bottom
of a bend where any condensate in the pipeline might collect
and saturate the probe.
The pipe or duct will require a thread to match the transmitter body thread. Fixing
dimensions are shown in Figure 13. For circular pipework, to ensure the integrity of a
gas tight seal, a mounting ange will be required on the pipework in order to provide a
at surface to seal against.
The following procedure must be carried out by competent
personnel.
1. Ensure that the protective cover (and its desiccant capsule) has
been removed from the tip of the transmitter.
WARNING: Under no circumstances should the sensor guard
be handled with the ngers.
2. G 1/2” and 5/8” Versions - Ensure that the bonded seal (2) is over the
threaded part of the transmitter body.
3/4” Version - Ensure the O-ring is fully seated in the recess.
3. Screw the transmitter (3) into the pipe (1). Tighten enough to obtain
a gas tight seal. NOTE: Do not overtighten or the thread on the
pipework may be stripped.
14 15 16 17 18 18 20 21 22 23
2345678910 11
(1.9”)
1
1
2
2
3
3
Optional
display
(available
on request)
Optional
cable
(available
on request)


48mm
Figure 11 Transmitter Mounting - Pipe or Duct

Easidew I.S. User Manual
Michell Instruments 9
INSTALLATION
2.5.3 Transmitter Mounting - With Additional Process Connection Adapter
Applicable to the Easidew I.S. 5/8” Version ONLY
!The following procedure must be carried out by a qualied
installation engineer.
To mount the adapter into the transmitter, proceed as follows (see Figure 14) :
1. Ensure that the protective cover (2), and its desiccant capsule (2a), have
been removed from the tip of the transmitter.
2. Fit the bonded seal (3) over the threaded part of the transmitter body.
3. Screw the adapter (4) onto the threaded part of the transmitter and tighten
to 30.5 Nm (22.5 ft-lbs). NOTE: Use the ats of the hexagonal nut and
not the sensor body.
!WARNING: Under no circumstances should the sensor guard be
handled with the ngers.
4. Screw the transmitter (1) with its seal (3) and adapter (4) into the sample
block (see Section 2.5.1) or pipeline (see Section 2.5.2) and fully tighten
using a wrench until the seal is fully compressed and to the following torque
settings:
G 1/2” BSP 56 Nm (41.3 ft-lbs)
3/4” - 16 UNF ` 40 Nm (29.5 ft-lbs)
1/2” NPT Use a suitable sealant e.g. PTFE tape using
correct taping procedures
NOTE: Use the ats of the hexagonal nut and not the sensor body.
1
2
3
4
2a
Figure 12 Transmitter Mounting with Adapter

Easidew I.S. User Manual
10 97099 Issue 16.2, July 2021
OPERATION
3 OPERATION
Operation is very simple, assuming the following installation techniques are adhered to:
Sampling Hints
Be Sure the Sample is Representative of the Gas Under Test:
The sample point should be as close to the critical measurement point as possible. Also,
never sample from the bottom of a pipe as entrained liquids may be drawn into the
sensing element.


Figure 13 Installation Location
Minimize Dead Space in Sample Lines:
Dead space causes moisture entrapment points, increased system response times and
measurement errors, as a result of the trapped moisture being released into the passing
sample gas and causing an increase in partial vapor pressure.
Deadspace

Figure 14 Indication of Dead Space
Remove Any Particulate Matter or Oil from the Gas Sample:
Particulate matter at high velocity can damage the sensing element and similarly, at
low velocity, they may ‘blind’ the sensing element and reduce its response speed. If
particulate, such as degraded desiccant, pipe scale or rust is present in the sample gas,
use an in-line lter, as a minimum level of protection. For more demanding applications
Michell Instruments oers a range of sampling systems (for more information contact
www.michell.com).
Use High Quality Sample Tube and Fittings:
Michell Instruments recommends that, wherever possible, stainless steel tubing and
ttings should be used. This is particularly important at low dew points since other
materials have hygroscopic characteristics and adsorb moisture on the tube walls,
slowing down response and, in extreme circumstances, giving false readings. For
temporary applications, or where stainless steel tubing is not practical, use high quality
thick walled PTFE tubing.
Position Transmitter away from Heat Source:
It is recommended, as good instrumentation practice, that the transmitter is placed
away from any heat source to avoid adsorption/desorption.

Easidew I.S. User Manual
Michell Instruments 11
GOOD MEASUREMENT PRACTICE
4 GOOD MEASUREMENT PRACTICE
Ensuring reliable and accurate moisture measurements requires the correct sampling
techniques, and a basic understanding of how water vapor behaves. This section aims
to explain the common mistakes and how to avoid them.
Sampling Materials – Permeation and Diusion
All materials are permeable to water vapor since water molecules are extremely small
compared to the structure of solids, even including the crystalline structure of metals.
The graph above demonstrates this eect by showing the increase in dew point
temperature seen when passing very dry gas through tubing of dierent materials,
where the exterior of the tubing is in the ambient environment.
- 20
- 30
- 40
- 50
- 60
- 70
12345
Time (hours)
Dew point (ºC)
nylon
copper
polyethylene
PTFE
nickel
stainless steel
Figure 15 Material Permeability Comparison
What this demonstrates is the dramatic eect that dierent tubing materials have on
the humidity levels of a gas passed through them. Many materials contain moisture
as part of their structure and when these are used as tubing for a dry gas the gas
will absorb some of the moisture. Always avoid using organic materials (e.g. rubber),
materials containing salts and anything which has small pores which can easily trap
moisture (e.g. nylon).
As well as trapping moisture, porous sampling materials will also allow moisture vapor
to ingress into the sample line from outside. This eect is called diusion and occurs
when the partial water vapor pressure exerted on the outside of a sample tube is
higher than on the inside. Remember that water molecules are very small so in this
case the term ‘porous’ applies to materials that would be considered impermeable in
an everyday sense – such as polyethylene or PTFE. Stainless steel and other metals
can be considered as practically impermeable and it is surface nish of pipework that
becomes the dominant factor. Electropolished stainless steel gives the best results over
the shortest time period.
Take into consideration the gas you are measuring, and then choose materials appropriate
to the results you need. The eects of diusion or moisture trapped in materials are
more signicant when measuring very dry gases than when measuring a sample with a
high level of humidity.

Easidew I.S. User Manual
12 97099 Issue 16.2, July 2021
GOOD MEASUREMENT PRACTICE
Temperature and Pressure eects
As the temperature or pressure of the environment uctuates, water molecules are
adsorbed and desorbed from the internal surfaces of the sample tubing, causing small
uctuations in the measured dew point.
Adsorption is the adhesion of atoms, ions, or molecules from a gas, liquid, or dissolved
solid to the surface of a material, creating a lm. The rate of adsorption is increased at
higher pressures and lower temperatures.
Desorption is the release of a substance from or through the surface of a material. In
constant environmental conditions, an adsorbed substance will remain on a surface
almost indenitely. However, as the temperature rises, so does the likelihood of
desorption occurring.
Ensuring the temperature of the sampling components is kept at consistent levels is
important to prevent temperature uctuation (i.e. through diurnal changes) continually
varying the rates of adsorption and desorption. This eect will manifest through a
measured value which increases during the day (as desorption peaks), then decreasing
at night as more moisture is adsorbed into the sampling equipment.
If temperatures drop below the sample dew point, water may condense in sample
tubing and aect the accuracy of measurements.
Maintaining the temperature of the sample system tubing above the dew point of the
sample is vital to prevent condensation. Any condensation invalidates the sampling
process as it reduces the water vapor content of the gas being measured. Condensed
liquid can also alter the humidity elsewhere by dripping or running to other locations
where it may re-evaporate.
Although ambient pressure does not change drastically in a single location, the gas
sample pressure does need to be kept constant to avoid inconsistencies introduced
by adsorption or desorption. The integrity of all connections is also an important
consideration, especially when sampling low dew points at an elevated pressure. If
a small leak occurs in a high-pressure line, gas will leak out; however, vortices at the
leak point and a negative vapor pressure dierential will also allow water vapor to
contaminate the ow.
Theoretically ow rate has no direct eect on the measured moisture content, but
in practice it can have unanticipated eects on response speed and accuracy. An
inadequate ow rate may:
