1. Connect an IEEE®802.3af/at/bt-compliant
PSE to the PD-USB-DP30’s “PoE IN” RJ45
socket using a standard Cat 5/5e/6 Ethernet
cable. (Note: The maximum allowed length
of the Ethernet cable is 100 meters).
2. Check that the “Power” LED is yellow to
verify that the PD-USB-DP30 is powered on.
3. Connect one side of the supplied USB
Type-C®cable to the PD-USB-DP30’s
USB-C socket. (Note: Any USB-C connec-
tion polarity is allowed.)
4. Connect the other side of the USB Type-C
cable to the USB-C powered device.
5. Verify that the USB-C powered device is
getting power from the PD-USB-DP30.
PoE IN
USB-C®
PD-USB-DP30 Quick Start Guide
LED Indicators
LED Appearance Status
Power
No Light
PD-USB-DP30 is:
powered o or powered
on as a dongle
Yellow On PD-USB-DP30 is powered
on
Link/
Act
No Light No data link
Green On Data link on
Green
Blinking Data activity on
Specicaons
Data
• PoE IN
• 10/100/1000 Mbps
• USB Type-C
• USB 2.0
• USB 3.1 Gen 1
Power
• PoE IN
• Input Voltage: 42-57 VDC
• Input Current: 1.75A max
• USB Type-C
• 5 Vdc/3A
• 9 Vdc/2.61A
• 15 Vdc/1.57A
• 20 Vdc/1.18A
Environmental Informaon:
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Operating Humidity: 90% Max (non-condensing)
• Storage Temperature: −20°C to +70°C (−4°F to +158°F)
• Storage Humidity: 95% Max (non-condensing)
• Dimensions: 22.4 mm (H) x 66.8 mm (W) x 105.2 mm (L)
• Weight: 150g
The Microchip name and logo and the Microchip logo are registered trademarks of Microchip Technology
Incorporated in the U.S.A. and other countries. All other trademarks mentioned herein are property of their
respective companies.
© 2021, Microchip Technology Incorporated. All Rights Reserved. 12/21 DS00003800C
Notes
• If the USB host is running the Windows®operating system, the device driver should be automat-
ically installed (plug and play) after the PD-USB-DP30 is connected. Linux®may require driver
installation in case the LAN7800 Ethernet controller is missing. Apple®requires driver installation.
• If the USB host doesnt recognize the PD-USB-DP30 as a USB device, please go to the LAN7800
product page to download and install the appropriate device driver.
• Powering multiple PD-USB-DP30 from the same PoE multiport midspan may aect data/power
performance to connected USB-C devices if they are sharing common peripheral equipment such as
monitors, projectors, etc.
Technical Support
For technical support please visit the Microchip Technical Support Portal www.microchip.com/support
LAN7800 Driver
To download device drivers for the LAN7800 please visit the LAN7800 WEB page: LAN7800
USA/Canada: +1 877 480 2323
