Microchip Technology IS2066B User manual

IS2066B
IS2066B Evaluation Board User's Guide
Introduction
This document provides detailed information about the Microchip IS2066B EVB and its WST (Wireless Stereo
Technology) application.
The IS2066B EVB enables the user to evaluate and demonstrate the functionality of the WST application on an EVB
platform. The IS2066B EVB includes status LEDs and an integrated configuration and programming interface for
plug-and-play capability, which enables rapid prototyping and faster time to market.
In addition to the IS2066B EVB, software tools and applications are provided to demonstrate the Bluetooth® WST
connections to the on-board IS2066B System-on-Chip (SoC) with options for configuring or programming it.
Features
• IS2066B SoC Configured for WST Application, Qualified for Bluetooth v5.0 Specifications
• On-board Audio Amplifier (MAX97220) for Common 4-pin Headphone Connections
• On-board Audio Control Buttons for Playback Operation
• 5V Power Supply Switch for IN-BOX and OUT-BOX Simulation
• MIC-In and Stereo Out Ports
• USB Connector to update IS2066B EEPROM Parameters (over MCP2200 USB to UART converter)
• Li-ion Battery Connector
• On-board SMA Connector for Dipole Antenna
• On-board Thermistor
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 1

Table of Contents
Introduction.....................................................................................................................................................1
Features.................................................................................................................................................. 1
1. Quick References....................................................................................................................................3
1.1. Reference Documentation............................................................................................................3
1.2. Hardware Requirements.............................................................................................................. 3
1.3. Software Requirements................................................................................................................3
2. Kit Overview............................................................................................................................................ 4
2.1. Kit Contents..................................................................................................................................4
3. Hardware.................................................................................................................................................6
3.1. Hardware Features.......................................................................................................................6
4. Application Demonstration.....................................................................................................................11
4.1. Establishing a Connection.......................................................................................................... 11
4.2. Audio Streaming and Auto Role Switch Demonstration............................................................. 12
4.3. Handset Profile (HSP) and Hands Free Profile (HFP) Demonstration....................................... 12
5. Configuring IS2066B EVB.....................................................................................................................14
5.1. UI Tool Configuration..................................................................................................................14
5.2. DSP Tool Configuration.............................................................................................................. 19
5.3. MPET Tool Configuration........................................................................................................... 25
6. Updating EEPROM Parameters............................................................................................................34
7. Appendix A: Schematics....................................................................................................................... 39
7.1. Reference Schematics............................................................................................................... 39
8. Document Revision History...................................................................................................................47
The Microchip Website.................................................................................................................................48
Product Change Notification Service............................................................................................................48
Customer Support........................................................................................................................................ 48
Microchip Devices Code Protection Feature................................................................................................ 48
Legal Notice................................................................................................................................................. 48
Trademarks.................................................................................................................................................. 49
Quality Management System....................................................................................................................... 49
Worldwide Sales and Service.......................................................................................................................50
IS2066B
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 2

1. Quick References
1.1 Reference Documentation
For further study, refer to the following:
•IS2066B Bluetooth® Wireless Stereo Technology ROM SoC Data Sheet (DS70005398)
•IS2066B UI Tools Application Note (AN3100)
1.2 Hardware Requirements
• Two IS2066B Evaluation Boards
• Bluetooth Enabled Smartphone:
– Android™ device running on Android 4.3 or later version
– iOS: iPhone® 4S or later version
• Windows® Host PC with USB Port
• 4-pin Headphone with Microphone
• Micro-B USB Cable
1.3 Software Requirements
Note: For the following software tools and firmware files, refer to https://www.microchip.com/wwwproducts/en/
IS2066.
• UITool (User Interface Tool)
• DSPTool
• MPtool (Mass Production EEPROM Tool - MPET)
• EEPROM Tool
IS2066B
Quick References
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 3

2. Kit Overview
This chapter provides an overview of the IS2066B EVB. The following figure illustrates the top view of the IS2066B
EVB with its components.
Figure 2-1. IS2066B EVB Components
Mode switch (SW301)
IS2066B SoC
Audio amplifier (MAX97220)
Audio jack (P1)
Victoria interface (JP301)
SMA connector (CN301)
Power switch (SW201)
Battery connector (J201)
USB to UART converter (MCP2200)
Micro-B USB connector (J701)
GPIO header (J903)
Two status LEDs (D901, LD901)
Volume up/Forward button
Reset button (SW801)
MFB button
Volume down/Reverse button
Note: For more details on the features, refer to 3. Hardware.
2.1 Kit Contents
The IS2066B EVB kit includes the following:
• Two IS2066B EVB, One for Right and One for Left
• Two Type-A to Micro-B USB Cables
• Two Dipole Antenna
• Two 4-pin Headphones
• Two Batteries:
– The batteries may or may not be available based on the geographic location. In case of no batteries,
contact your Microchip sales office for assistance. A list of Microchip offices for sales and service is
provided on the back page of this document.
IS2066B
Kit Overview
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 4

Figure 2-2. IS2066B Kit Contents
Type-A to Micro-B USB Cable Headphone
Dipole Antenna
IS2066B EVB
Battery
Note: If any part of the IS2066B EVB is missing, contact your Microchip sales office for assistance. A list of
Microchip offices for sales and service is provided on the back page of this document.
IS2066B
Kit Overview
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 5

3. Hardware
This chapter describes the hardware features of the IS2066B EVB. The IS2066B EVB includes a range of peripheral
components.
Figure 3-1. IS2066B EVB BLOCK DIAGRAM
SYS_PWR
LED2
BAT_IN
Buttons and
Switches
MIC and
Bias Circuit
Audio
Amplifier
Status LEDs
Li-Ion
Battery
16 MHz
Crystal
USB to UART
(MCP2200)
ADAP_IN
Micro-B
USB
12 MHz
Crystal
3V3
LDO
P2_0
Mode
Switch
LED1
GPIO
Header I/O
MIC_BIAS
MIC1_P
MIC1_N
IS2066B SoC
Victoria
Header
Matching
Circuit
Chip Antenna or SMA
Audio
4-pin
Jack
Rx
UART
IS2066B Evaluation Board
RTx
Tx
5V
5V
3.1 Hardware Features
The following sections provide detailed information on the IS2066B EVB components. To locate these components in
the IS2066B EVB, refer to Figure 2-1.
3.1.1 Power Supply
The IS2066B EVB can be powered by the following supplies:
• Li-ion battery (J201) – when using a battery input, mount a jumper on (JP202). Do not mount a jumper on
(JP201). JP201 is a provision for connecting a battery power source with 2.54 mm connector.
• USB (J701) – USB cable is connected to a PC, which provides 5V power for battery charging and testing
purposes.
3.1.2 USB Connectivity
The IS2066B EVB has one USB port (J701) that can be connected to a host PC using a micro-USB cable, where the
USB signals are converted to/from the UART by the serial converter MCP2200.
IS2066B
Hardware
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 6

3.1.3 Switches and Push Buttons
The functions of the switches and push buttons on the IS2066B EVB are:
• SW801 – Reset button for the IS2066B (RST_N)
• SW301 – Mode selection switch for configuring IS2066B into Application mode or Test mode
• SW802 – Multifunction button/Push button to turn on/off the IS2066B EVB (MFB/PWR)
• SW803 – By default, this button is not configured in the EVB, can be configured using the UI tool
• SW804 – By default, this button is not configured in the EVB, can be configured using the UI tool
The following table provides the settings of mode selection switch (SW301) to configure the IS2066B in various
operating modes.
Table 3-1. Mode Selection Switch (SW301) Details
Mode Button Definition
Test mode SW301 is placed in ON (P2_0: Low) position: ON
Application mode SW301 is placed in 1 (P2_0: High) position: OFF
3.1.4 LEDs
The functions of LEDs driven by IS2066B EVB are listed as follows:
• LED1 – Blue (LD901) - Configurable by UITool
• LED2 – Red (D901) - Configurable by UITool
3.1.5 Jumpers and Headers
The following jumpers and headers are available on the IS2066B EVB. GPIO header (J903) provides the GPIO
interface for the IS2066B EVB. The following figure illustrates GPIO header (J903) and the following table provides
the pin details and description.
Figure 3-2. GPIO Header (J903)
Table 3-2. GPIO Header (J903) Pins
Pin Number Pin Name
1 P0_0
2 P2_0
3 P2_7
4 NC
5 P0_2
IS2066B
Hardware
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 7

...........continued
Pin Number Pin Name
6 MFB
7 P0_3
8 HCI_RXD
9 P1_3
10 HCI_TXD
11 P1_5 (AMP_EN)
12 RST_N
13 GND
14 GND
15 NC
16 NC
17 NC
18 NC
19 GND
20 GND
The Victoria interface header (JP301) provides the interface for the IS2066B to connect to the Victoria test board
(production platform). The following figure illustrates the Victoria interface header (JP301) and the following table
provides the pin details and description.
Figure 3-3. Victoria Interface Header (JP301)
Table 3-3. External MCU/DSP Header (JP301) Pins
Pin Number Pin Name Pin Number Pin Name
1 NC 2 NC
3 NC 4 NC
5 NC 6 NC
IS2066B
Hardware
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 8

...........continued
Pin Number Pin Name Pin Number Pin Name
7 MIC_P1 8 AOHPR
9 MCI_N1 10 AOHPL
11 GND 12 GND
13 BK1_OUT 14 CLDO_O
15 HCI_RXD 16 NC
17 HCI_TXD 18 NC
19 VDD_IO 20 CODEC_VO
21 BAT_IN 22 GND
23 BAT_IN 24 GND
25 NC 26 NC
27 5V_VIC 28 NC
29 5V_VIC 30 BK2_OUT
31 MFB 32 NC
33 NC 34 RFLDO_O
35 NC 36 GND
37 P2_0 38 GND
39 GND 40 GND
MIC header (JP601) is used for connecting a microphone to the IS2066B EVB. The following figure illustrates the
MIC header (JP601) and the following table provides the pin details and description.
Figure 3-4. MIC Header (JP601)
1 2 3
Table 3-4. MIC Header (JP601) Pin Details
Pin Number Pin Name
1 MIC_P1
2 AGND
3 MIC_N1
Speaker header (JP602) is used for connecting a speaker to the IS2066B EVB. The following figure illustrates the
(JP602) header and the following table provides the pin details and description.
IS2066B
Hardware
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 9

Figure 3-5. Header (JP602)
1 2 3
Table 3-5. Header (JP602) Pin Details
Pin Number Pin Name
1 AOHPL
2 AOHPR
3 AOHPM
IS2066B
Hardware
© 2019 Microchip Technology Inc. User Guide DS50002946A-page 10
