PolarFire MPF300T FPGA Video Kit
June 2019

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0
Contents
1 Revision History ............................................................................................................................. 1
1.1 Revision 1.0 ........................................................................................................................................ 1
2 Introduction ................................................................................................................................... 2
2.1 Kit Contents ........................................................................................................................................ 2
2.2 Block Diagram ..................................................................................................................................... 2
2.3 Board Overview .................................................................................................................................. 3
3 Hardware Settings ......................................................................................................................... 6
3.1 Jumper Settings .................................................................................................................................. 6
3.2 LEDs .................................................................................................................................................... 6
3.3 Power Sources .................................................................................................................................... 7
4 Board Components and Operations .............................................................................................. 9
4.1 Memory Interface ............................................................................................................................... 9
4.2 SPI Serial Flash .................................................................................................................................... 9
4.3 HDMI1.4 Interface ............................................................................................................................ 10
4.4 MIPI-RX Connector (CSI-2 Application) ............................................................................................. 10
4.5 MIPI-TX Connector (DSI Application) ................................................................................................ 11
4.6 MIPI-TX Connector (CSI-2 Application) ............................................................................................. 11
4.7 MIPI-TX and RX PCB Loopback .......................................................................................................... 12
4.8 Transceivers ...................................................................................................................................... 12
4.8.1 XCVR0 Block .......................................................................................................................................... 12
4.8.2 XCVR1 and XCVR3 Blocks ...................................................................................................................... 13
4.8.3 XCVR2 Block .......................................................................................................................................... 14
4.8.4 XCVR Reference Clock ........................................................................................................................... 15
4.9 Programming .................................................................................................................................... 15
4.9.1 FTDI and JTAG Header Scheme ............................................................................................................. 15
4.10 50 MHz Oscillator ........................................................................................................................... 16
4.11 Device Reset ................................................................................................................................... 17
4.12 User Reset ...................................................................................................................................... 17
4.13 User Interface ................................................................................................................................. 17
4.13.1 User LEDs ............................................................................................................................................. 18
4.13.2 Push-Button Switches ......................................................................................................................... 18
4.13.3 Slide Switches (DPDT) .......................................................................................................................... 19
4.13.4 DIP Switches (SPST) ............................................................................................................................. 19
4.13.5 FMC HPC Connector (J14) ................................................................................................................... 20
4.14 Board Components Placement ....................................................................................................... 20

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 1
1 Revision History
The revision history describes the changes that were implemented in the document. The changes are
listed by revision, starting with the most current publication.
1.1 Revision 1.0
Revision 1.0 was the first publication of this document

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 2
2 Introduction
The Microsemi PolarFire® FPGA Video Kit (POLARFIRE VIDEO KIT), which is RoHS-compliant, enables you
to evaluate the PolarFire FPGA for the following interfaces:MPF300T-1FCG1152E
MIPI CSI-2 RX interface
HDMI2.0
HDMI1.4
DDR4 memory
FMC HPC with 8 Transceiver lanes
UART Interface to the FTDI device
SPI Interface to the SPI Flash device
2.1 Kit Contents
The following table lists the contents of the PolarFire Video Kit.
Table 1 • Kit Contents
Item Quantity
Dual Camera Sensor Module 1
PolarFire Video Board featuring the device with 300K logic elementsMPF300T-1FCG1152E 1
12 V, 5 A AC power adapter and cord 1
USB 2.0 A-male to mini-B cable programming 1
Quickstart card 1
Free one-year Libero Gold software license 1
2.2 Block Diagram
The following figure shows the block diagram of the video kit.

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 3
Figure 1 • Block Diagram
2.3 Board Overview
The following figure shows a labeled image of the video board highlighting its components.
Figure 2 • Board Callout

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 4
The following table lists the components of the video board.
Table 2 • Board Components
Component Label on
Board
Description
Featured Device
PolarFire FPGA FPGAMPF300T-1FCG1152E
Power Supply
12 V power supply J20 The board is powered by a 12 V power source using an external +12 V/5 A DC jack
ON/OFF switch SW4 Power ON/OFF switch from +12 V external DC jack
Clocks
On-board 50 MHz
clock oscillator
X3 50 MHz clock oscillator with single-ended output
XCVR reference clock Y5 148.5 MHz oscillator (differential LVDS output) that provides reference clock
(REFCLK) via PolarFire device pins AF29 and AF30. These pins are connected to the
XCVR
Clock Synthesizer U15 CDCEL913PWR Clock Synthesizer for HDMI1.4 clocks and programmable through
the I2C
FPGA Programming and Debugging
FT4232H U70 USB-to-quad serial ports in various configurations
JTAG programming
header
J18 This header is used to program and debug the PolarFire device using FlashPro4 or
FlashPro5. In the FlashPro software, the appropriate programmer (FlashPro4
orFlashPro5) must be selected.
SPI flash U30 One 1 Gb SPI Flash from Micron MT25QL01GBBB8ESF-0SIT (P/N) connected to SPI
pins on bank 3 of the PolarFire device
Memory Chips
DDR4 Memory U1,U2,
U3 and
U4
Four 4 Gb (MT40A256M16GE-083E:B) chips are connected in Fly-by topology with a
64-bit data bus for storing data bits
FMC HPC connector J14 FMC connector with eight XCVR lanes and 13 Differential pairs HPC[HA0:12] and LPC
[0:33])
Video Interfaces
CSI-2 RX connector J5 MIPI data and clock signals are received from Camera sensor board
DSI TX connector J26 MIPI data and clock signals are transmitted to Display daughter board through the
connector
CS-2 TX connector J4 MIPI data and clock signals are transmitted to Display daughter board through the
connector
General Purpose I/O
Switches SW1 and
SW2
Push-button switches for user-interface debugging applications
DIP Switches SW6 Four DIP switches for testing
Light-emitting diodes
(LEDs)
Four active-high LEDs connected to some of the user I/Os for debugging, and
twelve active high LEDs used for indicating power supply

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 5
Component Label on
Board
Description
USER Reset switch SW3 Push-button system reset for the PolarFire device Users must program this HSIO for
PolarFire logic reset function
Device reset SW5 Device reset

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 6
3 Hardware Settings
This section provides information about jumper settings, switches, LEDs, and DIP switches on the
PolarFire video board.
3.1 Jumper Settings
Connect the jumpers according to the settings specified in the following table.
Table 3 • Jumper Settings
Jumper Description Pin(s) Default
J15 SPI Slave and Master mode selection. By Default
SPI master
1-2 Closed
J19 XCVR_VREF is connected to GND 1-2 Closed
J28 Close pin 1-2 to program through the FTDI Open
pin 1-2 to program the external Flash pro5
1-2 Closed
J24 Jumper to select the PolarFire VDDAUX4 for
Bank4 voltage
Close pin2-4 for 3V3
Close pin2-4 for 2V5
Closed
Open
J25 Jumper to select the PolarFire VCCIO voltage
(VCCIO_HPC_VADJ)
Close pin 1 and 2 for 3.3 V
Close pin 3 and 4 for 2.5 V
Close pin 5 and 6 for 1.8 V
Close pin 7 and 8 for 1.5 V
Close pin 9 and 10 for 1.2 V
Open
Open
Closed
Open
Open
J36 Jumper to select the SW3 input or the
ENABLE_FT4 232 signal from the FT4232H chip
Close pin 1 and 2 for manual power switching
using SW3
Close pin 2 and 3 for remote power switching
using the GPIO capability of the FT4232 chip
Close
Open
3.2 LEDs
The following table lists the power supply LEDs.
Table 4 • LEDs
LED Description
DS14-Green 12 V voltage rail
DS20-Green 5 V voltage rail
DS21-Green 3.3V voltage rail
DS5-Green 1.0V voltage rail
DS4-Green 1.8V voltage rail
DS3-Green VDD25 Voltage rail
DS2-Green VDDAUX2_5 Voltage rail

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 7
LED Description
DS9-Green VDDA(1V05) Voltage rail
DS8-Green VDDAUX4 Voltage rail
DS7-Green 1.2V voltage rail
DS6-Green VCCIO_HPC_VADJ voltage rail
DS12-Green 1.8V HDMI1V4 voltage rail
DS13-Green 0.6V VTT voltage rail
3.3 Power Sources
The PolarFire video board uses Microchip power supply devices. For more information about these
power supply devices, see: https://www.microchip.com/design-centers/power-management/dc-dc-
converters-regulators.
The following table lists the key power supplies required for normal operation of the PolarFire video
board.
Table 5 • Voltage Rails in PolarFire Video Board
PolarFire Bank I/O Rail Voltage
Bank 0 1P2V 1.2V
Bank 1 1P8V 1.8V
Bank 2 1P2V_B2 1.2V
Bank 3 VDD25 2.5V
Bank 4 VCCIO_HPC_VADJ 1.8V
Bank 5 VDD25 2.5V
Bank 6 1P8V_HDMI1V4 1.8V
Bank 7 1P2V 1.2V
The following figure shows the power supply scheme used in the PolarFire video board.

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 8
Figure 3 • Power Supply Scheme
The following table lists the suggested Microchip power regulators for PolarFire FPGA voltage rails.
Table 6 • Power Regulators
Voltage Rail Part Number Description Current
5V MIC24055YJL-TR IC REG BUCK ADJ 12A SYNC 28QFN 12A
1V MIC24055YJL-TR IC REG BUCK ADJ 12A SYNC 28QFN 12A
1V2 MIC24046YFL-TR IC REG BUCK PROG 5A SYNC 20VQFN 5A
VDDAUX2&5 MIC23303YML-T5 IC REG BUCK ADJ 3A SYNC 12DFN 3A
VDDAUX4 MIC23303YML-T5 IC REG BUCK ADJ 3A SYNC 12DFN 3A
VCCIO_HPC_VADJ MIC24046YFL-TR IC REG BUCK PROG 5A SYNC 20VQFN 5A
VREF,VTT MIC5166YML-TR IC PWR SUP 3A HS DDR TERM 10MLF 3A
HDMI1.4 MCP1726T-ADJE/MF IC REG LINEAR POS ADJ 1A 8DFN 1A
VDD25 MIC69502WR IC REG LINEAR POS ADJ 5A SPAK-7 5A
3V3 MIC69502WR IC REG LINEAR POS ADJ 5A SPAK-7 5A
VDD18 MIC69502WR IC REG LINEAR POS ADJ 5A SPAK-7 5A
1V05 MIC69502WR IC REG LINEAR POS ADJ 5A SPAK-7 5A
Note: These regulators are not pin compatible with the existing video kit schematics. Use these
regulators for new board.

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 9
4 Board Components and Operations
This section describes the key components of the PolarFire Video board and important board
operations.
4.1 Memory Interface
The following figure shows the memory interface scheme.
Figure 4 • Memory Interface
As shown in the preceding figure, Four 4 Gb DDR4 SDRAM chips are used as flexible volatile memory for
user applications. The DDR4 interface is implemented in the HSIO Bank 0 and Bank 7.
The DDR4 SDRAM specifications are as follows:
MT40A256M16GE-083E:B
Quantity: Four chips are connected in Fly-by topology
Density: 16 Gb
Data rate: DDR4 64-bit at 166 MHz clock rate
The PolarFire video board design uses the DDR4 and POD12 standards for the DDR4 interface. The
default board assembly for the DDR4 standard uses RC terminations.
4.2 SPI Serial Flash
The following figure shows the SPI Flash and its interface with the PolarFire device.

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 10
Figure 5 • SPI Flash Interface
The SPI flash specifications for the PolarFire device are:
Density: 1 Gb
Voltage: 2.7 V to 3.6 V (MT25QL01GBBB8ESF-0SIT)
Frequency: 90 MHz
Quantity = 1
SPI mode support: Modes 0 and 3
4.3 HDMI1.4 Interface
One HDMI1.4 Transmitter is connected to the PolarFire device to support the HDMI1.4 standard as
shown in the following figure.
Figure 6 • HDMI1.4 Interface
The HDMI interface is implemented in Bank6.
The HDMI1.4 transmitter specifications for the PolarFire device are:
Part Number of the HDMI Transmitter: ADV7511KSTZ
Operating frequency: up to 225 MHz
4.4 MIPI-RX Connector (CSI-2 Application)
The video board supports a dual Camera image sensor daughter card that can be connected using the
CSI-2 RX interface (J5) for CSI-2 RX applications. The daughter card includes two IMX334 cameras. Each
image sensor supports a four-lane MIPI interface. The daughter card is connected to the video board via
the board to board connector as shown in the following figure The MIPI output signals . (see page )
are connected to Bank 2.
The image sensor supports maximum 1782 Mbps.

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 11
Figure 7 • MIPI-RX Connection
4.5 MIPI-TX Connector (DSI Application)
The video board supports the MIPI transmitter X4 lanes and clock for DSI application, as shown in the
following figure. MIPI TX signals are interfaced to the LCD display. An adaptor board for the LCD display
can be connected through the J26 connector on the video board. This adaptor board contains the LCD
mating connector and the auxiliary circuit required for the display. For more information, see the video
.board schematics
Figure 8 • MIPI-TX Connection (DSI Application)
4.6 MIPI-TX Connector (CSI-2 Application)
The video board supports the MIPI X4 lanes and clock for the CSI-2 transmitter application, as shown in
the following figure. For testing, the video board can be can be interfaced with Nvidia’s Jetson TX1\TX2
development board using a mating connector cable.

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 12
Figure 9 • MIPI-TX Connection (CSI-2 Application)`
4.7 MIPI-TX and RX PCB Loopback
The video board supports the on-board PCB trace loopback of MIPI X4 lanes and clock, as shown in the
following figure.
Figure 10 • MIPI-TX and RX Loopback
4.8 Transceivers
The PolarFire FPGA device has 4 XCVR blocks and each block contains 4 MPF300T-1FCG1152E
transceiver lanes. These lanes can be accessed through the HDMI2.0 and FMC connectors on the board.
The following sections describe these blocks and the lanes used.
4.8.1 XCVR0 Block
Lanes 0, 1, and 2 of the XCVR0 block are looped back, as shown in the following figure .

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 13
Figure 11 • XCVR0 Interface
4.8.2 XCVR1 and XCVR3 Blocks
XCVR1 and XCVR3 blocks have four lanes each. These lanes are connected to the FMC HPC connector
and the signals are routed on the PCB as follows:
Lanes 0 to 7 are directly routed to the FMC HPC
TX pad > trace > via (to bottom layer) > trace > FMC HPC connector pad
RX pad > trace > via (to Top layer) > trace > PolarFire device pad
The XCVR1 and XCVR3 reference clock is routed directly from the HPC connector to the PolarFire device.
The following figure shows the XCVR1 and XCVR3 and their interfaces.

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 14
Figure 12 • XCVR1 and XCVR3 Interface
4.8.3 XCVR2 Block
The lanes of the XCVR2 block are connected to HDMI2.0 TX and RX chips via the line drivers chips, as
shown in the following figure. This interface can operate up to 6 Gbps.

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 15
Figure 13 • XCVR2 Interface
4.8.4 XCVR Reference Clock
The following figure shows the clock sources for XCVR blocks.
Figure 14 • XCVR Reference Clocks
XCVR 1A, 3A reference clocks are sources from FMC HPC connector(J14).
XCVR 2B reference clock is sourced from the on-board 148.5 MHz
XCVR 2A reference clock is sourced from the on-board HMDI2.0 TX
4.9 Programming
The PolarFire device is programmed using the on-board FlashPro5 programmer or through the JTAG
Header. For more information about programming, see the .video board schematics
The following section describes the FTDI and JTAG Header programming schemes used on the board.
4.9.1 FTDI and JTAG Header Scheme
The PolarFire device can be programmed using the on-board JTAG Header or FTDI. By default, the FTDI
programming mode is enabled. The programming mode can be changed based on the Jumper settings.
For more information, see .Table 3

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 16
The following figure shows how the JTAG Header interfaces with the PolarFire Device.
Figure 15 • JTAG Header Interface
Note: By default, the FTDI programming mode is enabled. Remove J28 jumper to enable programming
through JTAG header.
4.10 50 MHz Oscillator
A 50 MHz clock oscillator with an accuracy of +/-50 ppm is available on the board. This clock oscillator is
connected to the FPGA fabric to provide a system reference clock. An on-chip PolarFire PLL can be
configured to generate a wide range of high-precision clock frequencies.
The package and pin details of the 50 MHz oscillator are as follows:
Pin Number: AL26
Pin Name: HSIO72PB1/CCC_NE_CLKIN_N_11 shows the 50 MHz clock oscillator interface.
Figure 16 • 50 MHz Oscillator Interface

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 17
4.11 Device Reset
As shown in the following figure, DEVRST_N (SW5 push button) is an input-only reset switch that allows
assertion of a full reset of the chip at any time. The DEVRST_N signal is an active-low signal.
Figure 17 • Device Reset
4.12 User Reset
As shown in the following figure the user reset (SW3 push button) is an input-only reset , (see page )
switch that allows assertion of a reset of the fabric logic.
Figure 18 • User Reset
4.13 User Interface
LEDs and push-button switches are available on the board for the user interface.

PolarFire MPF300T FPGA Video Kit
50200872 UG0872 User Guide Revision 1.0 18
4.13.1 User LEDs
Four active-high LEDs are connected to the PolarFire device. The following table lists the (see page )
on-board label of these switches, the associated PolarFire pin number, name, and Bank.
Table 7 • User LEDs
Label On Board PolarFire Pin Number PolarFire Pin Name PolarFire Bank
LED1 G17 HSIO37NB6 Bank 6
LED2 K23 HSIO54PB6 Bank 6
LED3 L23 HSIO54NB6 Bank 6
LED4 B25 HSIO68NB6/DQS Bank 6
The following figure shows how each user LED interfaces with the PolarFire device. (see page )
Figure 19 • User LED Interface
4.13.2 Push-Button Switches
Two push-button tactile switches are connected to the PolarFire device. The following table lists the on-
board label of these switches, the associated PolarFire pin number, name, and Bank.
Table 8 • Push-Button Switches
Label On Board PolarFire Pin Number PolarFire Pin Name PolarFire Bank
SW1 AK20 HSIO98NB1 Bank 1
SW2 AM27 HSIO73NB1 Bank 1
The following figure shows how these push-button switches interface with the PolarFire Device.
