Microchip Technology MPLAB ICE User manual

2001 Microchip Technology Inc. DS51159C
MPLAB®ICE
EMULATOR
USER’S GUIDE
M

DS51159C - page ii 2001 Microchip Technology Inc.
Information contained in this publication regarding device
applications and the like is intended through suggestion only
and may be superseded by updates. It is your responsibility to
ensure that your application meets with your specifications.
No representation or warranty is given and no liability is
assumed by Microchip Technology Incorporated with respect
to the accuracy or use of such information, or infringement of
patents or other intellectual property rights arising from such
use or otherwise. Use of Microchip’s products as critical com-
ponents in life support systems is not authorized except with
express written approval by Microchip. No licenses are con-
veyed, implicitly or otherwise, under any intellectual property
rights.
Trademarks
The Microchip name and logo, the Microchip logo, PIC, PICmicro,
PICMASTER, PICSTART, PRO MATE, KEELOQ, SEEVAL,
MPLAB and The Embedded Control Solutions Company are reg-
istered trademarks of Microchip Technology Incorporated in the
U.S.A. and other countries.
Total Endurance, ICSP, In-Circuit Serial Programming, Filter-
Lab, MXDEV, microID, FlexROM, fuzzyLAB, MPASM,
MPLINK, MPLIB, PICC, PICDEM, PICDEM.net, ICEPIC,
Migratable Memory, FanSense, ECONOMONITOR, Select
Mode and microPort are trademarks of Microchip Technology
Incorporated in the U.S.A.
Serialized Quick Term Programming (SQTP) is a service mark
of Microchip Technology Incorporated in the U.S.A.
All other trademarks mentioned herein are property of their
respective companies.
© 2001, Microchip Technology Incorporated, Printed in the
U.S.A., All Rights Reserved.
Printed on recycled paper.
Microchip received QS-9000 quality system
certification for its worldwide headquarters,
design and wafer fabrication facilities in
ChandlerandTempe,ArizonainJuly 1999.The
Company’s quality system processes and
procedures are QS-9000 compliant for its
PICmicro®8-bit MCUs, KEELOQ®code hopping
devices, Serial EEPROMs and microperipheral
products. In addition, Microchip’s quality
system for the design and manufacture of
development systems is ISO 9001 certified.
Note the following details of the code protection feature on PICmicro®MCUs.
•The PICmicro family meets the specifications contained in the Microchip Data Sheet.
•Microchip believes that its family of PICmicro microcontrollers is one of the most secure products of its kind on the market today,
when used in the intended manner and under normal conditions.
•There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our knowl-
edge, require using the PICmicro microcontroller in a manner outside the operating specifications contained in the data sheet.
The person doing so may be engaged in theft of intellectual property.
•Microchip is willing to work with the customer who is concerned about the integrity of their code.
•Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not
mean that we are guaranteeing the product as “unbreakable”.
•Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of
our product.
If you have any further questions about this matter, please contact the local sales office nearest to you.

12 MPLAB®ICE USER’S GUIDE
Table of Contents
2001 Microchip Technology Inc. DS51159B-page iii
Quick Start
Introduction ................................................................................................ 9
Highlights ...................................................................................................9
MPLAB ICE System Components ............................................................. 9
Installing MPLAB ICE ..............................................................................10
Setting Up MPLAB ICE ...........................................................................12
Using MPLAB ICE ................................................................................... 14
General Information
Introduction .............................................................................................. 19
Highlights .................................................................................................19
About This Guide .....................................................................................19
Warranty Registration ..............................................................................21
Recommended Reading ..........................................................................22
Troubleshooting ....................................................................................... 22
The Microchip Internet Web Site .............................................................23
Development Systems Customer Notification Service ............................24
Customer Support ................................................................................... 26
Chapter 1. Overview and Installation
1.1 Introduction ................................................................................... 27
1.2 Highlights ...................................................................................... 27
1.3 What MPLAB ICE Is ..................................................................... 27
1.4 MPLAB ICE System Components ................................................28
1.5 How MPLAB ICE Helps You ......................................................... 29
1.6 MPLAB ICE Kit Components ........................................................30
1.7 Installing MPLAB ICE Hardware ...................................................31
1.8 Applying Power to the System Components ................................32
1.9 Installing MPLAB IDE Software .................................................... 35

MPLAB®ICE User’s Guide
DS51159B-page iv 2001 Microchip Technology Inc.
Chapter 2. Tutorial - PIC16CXXX
2.1 Introduction ...................................................................................37
2.2 Highlights ......................................................................................37
2.3 Reviewing the Hardware ...............................................................37
2.4 Running MPLAB ............................................................................38
2.5 Setting Up the Development Mode ...............................................39
2.6 Creating a Project .........................................................................42
2.7 Building the Project .......................................................................48
2.8 Using Software Break Points ........................................................48
2.9 Using Named Software Break Points ............................................50
2.10 Using Hardware Break Points .......................................................51
2.11 Using the Complex Trigger ...........................................................52
2.12 Using Code Coverage ...................................................................55
2.13 Going Forward ..............................................................................57
Chapter 3. Tutorial - PIC18CXXX
3.1 Introduction ...................................................................................59
3.2 Highlights ......................................................................................59
3.3 Reviewing the Hardware ...............................................................59
3.4 Running MPLAB ............................................................................60
3.5 Setting Up the Development Mode ...............................................61
3.6 Creating a Project .........................................................................64
3.7 Building the Project .......................................................................70
3.8 Using Software Break Points ........................................................70
3.9 Using Named Software Break Points ............................................72
3.10 Using Hardware Break Points .......................................................73
3.11 Using the Complex Trigger ...........................................................74
3.12 Using Code Coverage ...................................................................77
3.13 Going Forward ..............................................................................79

Table of Contents
2001 Microchip Technology Inc. DS51159B-page v
Chapter 4. General Set Up
4.1 Introduction ...................................................................................81
4.2 Highlights ......................................................................................81
4.3 Running MPLAB ...........................................................................81
4.4 Configuring the LPT Port ..............................................................82
4.5 Selecting the Development Mode and Processor .........................83
4.6 Selecting Processor Power ...........................................................84
4.7 Setting Up the Processor Clock ....................................................86
4.8 Setting Up Miscellaneous Hardware .............................................87
4.9 Using MPLAB Projects .................................................................89
Chapter 5. Basic Features
5.1 Introduction ...................................................................................91
5.2 Highlights ......................................................................................91
5.3 Resetting the Processor ...............................................................91
5.4 Viewing Processor Memory ..........................................................92
5.5 Viewing Files .................................................................................93
5.6 Using the Status Bar and Tool Bars .............................................93
5.7 Starting and Stopping Emulation ..................................................93
5.8 Using Software Break Points ........................................................94
5.9 Using Hardware Break Points .......................................................95
5.10 Using Trigger In/Out Settings .......................................................96
Chapter 6. Advanced Features
6.1 Introduction ...................................................................................97
6.2 Highlights ......................................................................................97
6.3 Using Complex Triggering ............................................................98
6.4 Using Code Coverage ................................................................118
6.5 Using the Trace Memory Window ...............................................120

MPLAB®ICE User’s Guide
DS51159B-page vi 2001 Microchip Technology Inc.
Chapter 7. Verification
7.1 Introduction .................................................................................127
7.2 Highlights ....................................................................................127
7.3 Running Verify .............................................................................127
7.4 Troubleshooting Verify Failures ..................................................132
Chapter 8. Troubleshooting
8.1 Introduction .................................................................................133
8.2 Highlights ....................................................................................133
8.3 Common Problems .....................................................................133
8.4 Configuring a PC’s Parallel Interface for MPLAB ICE .................135
Appendix A. Debugging Techniques
A.1 Introduction .................................................................................141
A.2 Highlights ....................................................................................141
A.3 Complex Triggering Examples ....................................................141
A.4 Additional Debugging Examples .................................................142
Appendix B. Pod Electrical Specification
B.1 Introduction .................................................................................159
B.2 Highlights ....................................................................................159
B.3 Power ..........................................................................................159
B.4 Parallel Port .................................................................................160
B.5 Indicator Lights ............................................................................161
B.6 Logic Probes ...............................................................................163
Appendix C. Migrating from PICMASTER
C.1 Introduction .................................................................................165
C.2 Highlights ....................................................................................165
C.3 Unchanged Items ........................................................................165
C.4 Hardware Setup ..........................................................................165
C.5 How to Time Events ....................................................................166
C.6 Setting Break Points ....................................................................167
C.7 External Inputs and Outputs ........................................................168

Table of Contents
2001 Microchip Technology Inc. DS51159B-page vii
Glossary
Introduction ............................................................................................169
Highlights ...............................................................................................169
Terms ....................................................................................................169
Index .........................................................................................................................185
Worldwide Sales and Service ..........................................................................192

MPLAB®ICE User’s Guide
DS51159B-page viii 2001 Microchip Technology Inc.

2001 Microchip Technology Inc. DS51159B-page 9
MPLAB®ICE USER’S GUIDE
12
Quick Start
Introduction
This chapter is designed to get you up and running using the MPLAB ICE
emulator as quickly as possible. It is assumed that you have a working
knowledge of computer hardware terms, of the Windows®operating system,
of MPLAB IDE software and of general emulator operation.
Highlights
This chapter discusses:
•MPLAB ICE System Components
•Installing MPLAB ICE
•Setting Up MPLAB ICE
•Using MPLAB ICE
MPLAB ICE System Components
The MPLAB ICE system consists of these items (Figure 1):
1. Emulator pod
2. Parallel cable to connect the emulator pod to a PC
3. Power supply cable
4. Processor module with cable
5. Device adapter to connect the processor module to the transition socket
6. Transition socket to connect device adapter to target system
7. Logic probe connector

MPLAB®ICE User’s Guide
DS51159B-page 10 2001 Microchip Technology Inc.
Figure 1: MPLAB ICE Emulator System
Installing MPLAB ICE
Hardware Installation
Follow the steps in this section to install the emulator hardware.
•Locate an unused LPT port
•Connect the MPLAB ICE pod to the parallel port using the parallel
cable.
Connect one end of the parallel cable to the parallel connector on the
MPLAB ICE pod and connect the other end to the LPT port on the PC
chassis. Secure both ends with the cable screws.
Parallel Cable (2)
Power Supply
Cable (3)
Emulator Pod (1)
Processor Module
with Cable (4)
Logic Probe
Connector (7)
Device Adapter (5)
Transition Socket (6)
WARNING
Neither the PC nor MPLAB ICE should have power
turned on at this time.
WARNING Using MPLAB ICE in conjunction with a security
key, external disk drive, or other parallel device
(i.e., printer, Zip®drive, scanner) may result in
permanent damage to that device.

2001 Microchip Technology Inc. DS51159B-page 11
Quick Start
•Connect the logic probes.
Plug the logic probes into the logic probe connector found on the front of
the emulator pod.
•Install the processor module.
Insert the processor module firmly into the front of the MPLAB ICE pod.
To remove the processor module, place one finger behind each tab on
the front of the processor module and pull firmly. DO NOT pull on the
cable.
•Attach the power supply.
Make certain that the MPLAB ICE pod on/off switch is in the “O”or “off”
position before completing this step. Plug the appropriate ends of the
power supply into a power outlet and into the back of the MPLAB ICE
pod.
•If using a target board with the MPLAB ICE system, install the
device adapter.
Attach the device adapter to the end of the cable on the processor
module. Then, plug the device adapter into a transition socket on the tar-
get board.
•Turn on the system components.
To prevent damage to any of the subsystem or target application parts,
power up the system components in the following sequence:
1. Turn on the PC.
2. Turn on the emulator assembly by pushing the emulator pod switch
to ‘I’.
3. Apply power to the target application circuit.
Turn the system components off in reverse order.

MPLAB®ICE User’s Guide
DS51159B-page 12 2001 Microchip Technology Inc.
Software Installation
To install the MPLAB IDE software, refer to the installation instructions found
in the MPLAB User’s Guide (DS51025).
Installation Problems
If you have difficulty installing the hardware, please refer to the more detailed
chapter on installation (Chapter 1) or consult the troubleshooting chapter
(Chapter 8). If you have difficulty installing the software, please refer to the
MPLAB User’s Guide (DS51025).
Setting Up MPLAB ICE
Starting MPLAB
After installing MPLAB IDE software, invoke it by executing the file
MPLAB.EXE. For more information on using MPLAB, refer to the MPLAB
User’s Guide (DS51025) and the included file README.LAB.
Setting Up the Development Mode
Open the Development Mode dialog to set up the MPLAB ICE emulator for
use with MPLAB IDE software. Select Options>Development Mode. Set up
the development mode by clicking on each tab of the dialog and setting
options as specified below. Click Apply to accept the setting of each tab. Click
OK to accept the setting and close the Development Mode dialog.
•Ports tab: Displays information about the available LPT ports on the
host PC. Select an available LPT port from the dropdown list. To deter-
mine how this LPT port is configured on your system, click Query Port
Info. The preferred mode of operation for MPLAB ICE is bi-directional
mode (PS/2, EPP, and ECP types).
•Tools tab: Displays development mode and device information. Select
the MPLAB ICE emulator for the development mode and choose a pro-
cessor to emulate from the dropdown list.
Below the Processor is a brief description of any limitations that exist for
emulating this processor on the MPLAB ICE emulator. A more detailed
description of limitations may be viewed by clicking on Details.
WARNING Do not select the MPLAB ICE Emulator mode if
any other device (i.e., printer, Zip drive, scanner) is
installed on the parallel port or permanent
damage to that device may result.

2001 Microchip Technology Inc. DS51159B-page 13
Quick Start
•Power tab: Displays system power information. Select from where you
want the emulator system to get its power; from its own power source
(From Emulator) or from the target system (From Target Board). Low
Voltage emulation is available when choosing Processor Power From
Target Board.
•Clock tab: Displays oscillator type and frequency information. To use
the on-board clock, select an oscillator type and enter a frequency
between 32 kHz and 40 MHz. To use the target board clock, you must
first set Processor Power to From Target Board on the Power tab. Then
select Use Target Board Clock and the actual frequency will be calcu-
lated and displayed as Actual Frequency.
In addition to the above setting, you may wish to make additional changes
based on your application or device.
•Memory tab: Use this tab to set the memory configuration being used.
This tab is not available for all processors. In order for Off-Chip Memory
to be used, the Processor Mode (Options> Development Mode, Con-
figuration tab) must be set to Microprocessor or Extended Microcon-
troller.
•Configuration tab: Use this tab to set up the Watchdog Timer and/or
Processor Mode, i.e., internal and external memory. Processor mode is
not available for all processors.
•Pins tab: Use this tab to set up pins, such as enable/disable master
clear (MCLR).
•Break Options tab: Use this tab to change the global break and trace
point environment options.
Setting Up a Project
Create a new project by selecting Project > New Project. Find or create a
directory for the new project and then name the project (e.g., newprog.pjt).
For more information on creating and using projects, refer to the MPLAB
User’s Guide (DS51025).
Set Up Problems
If you have difficulty starting MPLAB or setting up a new project, please refer
to the MPLAB User’s Guide (DS51025). If you have difficulty setting up the
development mode, please refer to the more detailed chapter on set up
(Chapter 4) or consult the troubleshooting chapter (Chapter 8).

MPLAB®ICE User’s Guide
DS51159B-page 14 2001 Microchip Technology Inc.
Using MPLAB ICE
MPLAB ICE provides a wide variety of tools to emulate and debug an
application. MPLAB ICE offers a basic set of in-circuit debugging tools,
including the ability to run, halt, reset and single step the processor, plus
additional tools for advanced debugging techniques.
MPLAB ICE Basic Features
MPLAB ICE basic features include the following:
•Downloadable
•Processor Memory
•Status Bar and Tool Bars
•Start and Stop Emulation
•Software Break Points
•Named Software Break Points
•Trigger In/Out
The basic MPLAB ICE emulator features are built in to the MPLAB IDE
software. For more detailed information on each of these features, consult the
MPLAB User’s Guide (DS51025).
MPLAB ICE Advanced Features
MPLAB ICE advanced features include the following:
•Complex Triggering
•Code Coverage
•Trace Window
These features will each be discussed in the following sections. For more
detailed information on each of these features, please refer to Chapter 6.
Using Complex Triggering
MPLAB ICE has a highly flexible and powerful triggering mechanism. A trigger
is a combination of events that can cause:
•a hardware break point, and/or
•a trace memory capture.
An event is a description of the state of the system captured during one cycle.
In addition, an external signal can be generated when the trigger occurs. This
is useful for synchronizing other analyzers or equipment to MPLAB ICE.

2001 Microchip Technology Inc. DS51159B-page 15
Quick Start
Complex triggers can be specified by selecting Debug>Complex Trigger
Settings. The Complex Trigger Settings dialog will look different depending on
your selection of:
1. Memory Access
•Program Memory - If a Program Memory access is specified, the trig-
ger can be generated on an instruction fetch or a table read / table write
operation (on PICmicros that have table read / write capability).
•Data Memory - If a Data Memory access is specified, the trigger can be
generated on a read or a write operation.
2. Events
•Sequential - Select Sequential if each event must occur in sequence
to generate the trigger. Keep in mind that for sequential triggers, the
emulator will wait until Event 1 is satisfied before proceeding to Event
2, and on down to the final Trigger event.
•All Events - Select All Events if each event much occur, in any order,
to generate the trigger. The trigger will be generated when the final
event occurs.
•Any Event - Select Any Event if any single event will generate the trig-
ger.
•Time Between Events - Select Time Between Events to specify a
starting and terminating event. This event selection is used in conjuc-
tion with the trace memory window. Up to two events and the start event
can be specified to occur sequentially before the time stamp generator
starts incrementing.
•Filter Trace - Select Filter Trace to specify the events that will be cap-
tured by the trace memory window. Up to three qualifying events can be
specified to occur sequentially before starting to collect the specified
events.To perform a continuous filter trace, check the Infinite Events
checkbox.
Ignore FNOP Cycles should not be specified when performing a Filter
Trace; otherwise, the trace buffer will capture the cycle that executes
after the cycle that caused the trigger.
Note: Processor modules that do not support data monitoring (12-bit
core processor modules) also do not support triggering on data
memory.
Note: Since Ignore FNOP Cycles should not be specified with a Filter
Trace, prefetches will cause the trigger to fire.

MPLAB®ICE User’s Guide
DS51159B-page 16 2001 Microchip Technology Inc.
Also, performing a Filter Trace on Data Memory access is not recom-
mended, since the traced data will be one cycle after the trigger specifi-
cation.
Click on the Help button to bring up the on-line help file to walk you through
setting up a complex trigger.
In addition, a simple complex trigger break point can be set by using the right
mouse button. In a source window, a listing window, or the program memory
window, select the desired lines by clicking and dragging. Then select
Complex Trigger Break Point on the right mouse button menu. This will set up
and apply a single event sequential trigger with Ignore FNOP Cycles and Halt
on Trigger set. The Complex Trigger dialog does not have to be open.
Using Code Coverage
The code coverage feature provides visibility as to what portions of the code
are being accessed (fetched, written or read). This code is highlighted in the
Program Memory window.
•To enable code coverage, select Debug > Code Coverage and choose
either Enabled/Reset on Run or Enabled/Manual Reset. If Enabled/
Reset on Run is selected, code coverage is reset every time emulation
is started.
•If Enabled/Manual Reset is selected, code coverage is reset only when
a reset (Chapter 6.4) is performed.
•Select Options>Environment Settings>Color and chose a color for
Trace Point Text. This will be the code coverage highlighted text color.
•To disable code coverage, select Debug>Code Coverage and click on
Disabled.
Using the Trace Memory Window
The trace memory window in MPLAB ICE contains information that is
uploaded from MPLAB ICE’s trace buffer. By default, all instruction cycles are
captured by the trace buffer. The Complex Trigger dialog can be used to
control which instruction cycles are captured (see Using Complex Triggering).
Note: When triggering on multiple events, keep in mind that triggers
on data memory accesses are skewed two cycles from the
instructions that caused them.
Note: Code coverage and complex triggering are mutually exclusive.

2001 Microchip Technology Inc. DS51159B-page 17
Quick Start
•This trace buffer can be viewed by selecting Window>Trace Memory.
Up to 32767 instruction cycles can be displayed. The trace memory win-
dow contains the following information for each execution cycle:
- Cycle Number –Cycle’s position relative to the trigger or halting
point. The approximate trigger cycle will be highlighted in blue,
and will be numbered as cycle 0.
- Address (Addr) –Address of the instruction being fetched from
program memory.
- Opcode (Op) –Instruction being fetched.
- Label (Label) –Label (if any) associated with the program mem-
ory address.
- Instruction (Instruction) –Disassembled instruction.
- Source Data Address (SA) –Address or symbol of the source
data, if applicable.
- Source Data Value (SD) –Value of the source data, if applicable.
- Destination Data Address (DA) –Address or symbol of the desti-
nation data, if applicable.
- Destination Data Value (DD) –Value of the destination data, if
applicable.
- External Inputs (Ex) –Value of the external inputs.
- Time Stamp (Cycles or Seconds) –Time stamp value.
•Select Data>Reload to force an upload of whatever data has currently
been collected by the trace buffer. This allows you to see where your
program is executing. This is often useful if your trigger is never
reached.
•The column widths can be adjusted manually by dragging the right col-
umn header border with the mouse. Select Options>Configure to further
customize the trace display.
Usage Problems
If you have difficulty using any of the features of MPLAB ICE, please refer to
the more detailed chapters on features (Chapter 5 or Chapter 6) or consult
the troubleshooting chapter (Chapter 8).
Note: Due to the timing of processor signals, the data information will be
skewed by one cycle. Destination data values are actually skewed
by two cycles, but for display purposes, the trace buffer display
compensates for one of the delayed cycles.
Note: Source and destination data addresses and values are not
available when using processor modules based on the 12-bit
PICmicro®core (PIC16C5X and related parts).

MPLAB®ICE User’s Guide
DS51159B-page 18 2001 Microchip Technology Inc.
NOTES:

2001 Microchip Technology Inc. DS51159B-page 19
MPLAB®ICE USER’S GUIDE
12
General Information
Introduction
This first chapter contains general information that will be useful to know
before using the MPLAB ICE emulator.
Highlights
The information you will garner from this chapter:
•About this Guide
•Warranty Registration
•Recommended Reading
•Troubleshooting
•The Microchip Internet Web Site
•Development Systems Customer Notification Service
•Customer Support
About This Guide
Document Layout
This document describes how to use MPLAB ICE as a development tool to
emulate and debug firmware on a target board. The manual layout is as
follows:
•Quick Start –How to get up and running quickly using MPLAB ICE.
•Chapter 1: Overview and Installation –What MPLAB ICE is and how
it can help you. Also, how to install MPLAB ICE hardware and MPLAB
IDE software.
•Chapter 2: Tutorial - PIC16CXXX –A tutorial on using MPLAB ICE to
emulate PIC16CXXX devices.
•Chapter 3: Tutorial - PIC18CXXX –A tutorial on using MPLAB ICE to
emulate PIC18CXXX devices.
•Chapter 4: General Set Up –Setting up MPLAB ICE for use with
MPLAB IDE.
•Chapter 5: Basic Features –A description of the basic features of
MPLAB ICE, (i.e., run, halt, reset, single step, etc).
•Chapter 6: Advanced Features –A description of the advanced fea-
tures of MPLAB ICE, (i.e., complex trigger, code coverage, trace).

MPLAB®ICE User’s Guide
DS51159B-page 20 2001 Microchip Technology Inc.
•Chapter 7: Verification –How to verify MPLAB ICE’s correct opera-
tion.
•Chapter 8: Troubleshooting –How to solve common problems with
MPLAB ICE operation.
•Appendix A: Debugging Techniques –How to debug common prob-
lems in your code by using MPLAB ICE.
•Appendix B: Pod Electrical Specification –The electrical
specifications and description of the emulator pod.
•Appendix C: Migrating from PICMASTER®–How MPLAB ICE differs
from PICMASTER.
•Glossary –A glossary of terms used in this guide.
•Index –Cross-reference listing of terms, features and sections of this
document.
•Worldwide Sales and Service –A listing of Microchip sales and
service locations and telephone numbers worldwide.
Conventions Used in this Guide
This manual uses the following documentation conventions:
Table 1: Documentation Conventions
Description Represents Examples
Code (Courier font):
Plain characters Sample code
Filenames and paths #define START c:\autoexec.bat
Angle brackets: < > Variables <label>, <exp>
Square brackets [ ] Optional arguments MPASMWIN
[main.asm]
Curly brackets and
pipe character: { | } Choice of mutually exclusive arguments
An OR selection
errorlevel {0|1}
Lower case
characters in
quotes
Type of data “filename”
Ellipses... Used to imply (but not show)
additional text that is not rele-
vant to the example
list
[“list_option...
, “list_option”]
0xnnn A hexadecimal number where
n is a hexadecimal digit 0xFFFF, 0x007A
Italic characters A variable argument; it can be
either a type of data (in lower
case characters) or a specific
example (in uppercase
characters).
char isascii
(char, ch);
