Microhard Systems pMDDL5824 User manual

pMDDL5824
2x2 MIMO OEM 5.8 & 2.4 GHz Digital Data Link
Document: pMDDL5824.Operating Manual.v1.1.0.pdf
FW: v1.4.0 Build 1013-13
Operating Manual
150 Country Hills Landing NW
Calgary, Alberta
Canada T3K 5P3
Phone: [phone]
Toll Free: 1-855-353-0028
www.microhardcorp.com

© Microhard 2
Important User Information
Warranty
Microhard Systems Inc. warrants that each product will be free of defects in material and workmanship for a
period of one (1) year for its products. The warranty commences on the date the product is shipped by Micro-
hard Systems Inc. Microhard Systems Inc.’s sole liability and responsibility under this warranty is to repair or
replace any product which is returned to it by the Buyer and which Microhard Systems Inc. determines does
not conform to the warranty. Product returned to Microhard Systems Inc. for warranty service will be shipped
to Microhard Systems Inc. at Buyer’s expense and will be returned to Buyer at Microhard Systems Inc.’s ex-
pense. In no event shall Microhard Systems Inc. be responsible under this warranty for any defect which is
caused by negligence, misuse or mistreatment of a product or for any unit which has been altered or modified
in any way. The warranty of replacement shall terminate with the warranty of the product.
Warranty Disclaims
Microhard Systems Inc. makes no warranties of any nature of kind, expressed or implied, with respect to the
hardware, software, and/or products and hereby disclaims any and all such warranties, including but not lim-
ited to warranty of non-infringement, implied warranties of merchantability for a particular purpose, any inter-
ruption or loss of the hardware, software, and/or product, any delay in providing the hardware, software, and/
or product or correcting any defect in the hardware, software, and/or product, or any other warranty. The Pur-
chaser represents and warrants that Microhard Systems Inc. has not made any such warranties to the Pur-
chaser or its agents MICROHARD SYSTEMS INC. EXPRESS WARRANTY TO BUYER CONSTITUTES MICROHARD
SYSTEMS INC. SOLE LIABILITY AND THE BUYER’S SOLE REMEDIES. EXCEPT AS THUS PROVIDED, MICROHARD
SYSTEMS INC. DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MER-
CHANTABILITY OR FITNESS FOR A PARTICULAR PROMISE.
MICROHARD SYSTEMS INC. PRODUCTS ARE NOT DESIGNED OR INTENDED TO BE USED IN
ANY LIFE SUPPORT RELATED DEVICE OR SYSTEM RELATED FUNCTIONS NOR AS PART OF
ANY OTHER CRITICAL SYSTEM AND ARE GRANTED NO FUNCTIONAL WARRANTY.
Indemnification
The Purchaser shall indemnify Microhard Systems Inc. and its respective directors, officers, employees, suc-
cessors and assigns including any subsidiaries, related corporations, or affiliates, shall be released and dis-
charged from any and all manner of action, causes of action, liability, losses, damages, suits, dues, sums of
money, expenses (including legal fees), general damages, special damages, including without limitation,
claims for personal injuries, death or property damage related to the products sold hereunder, costs and de-
mands of every and any kind and nature whatsoever at law.
IN NO EVENT WILL MICROHARD SYSTEMS INC. BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL,
INCIDENTAL, BUSINESS INTERRUPTION, CATASTROPHIC, PUNITIVE OR OTHER DAMAGES WHICH MAY BE
CLAIMED TO ARISE IN CONNECTION WITH THE HARDWARE, REGARDLESS OF THE LEGAL THEORY BEHIND
SUCH CLAIMS, WHETHER IN TORT, CONTRACT OR UNDER ANY APPLICABLE STATUTORY OR REGULATORY
LAWS, RULES, REGULATIONS, EXECUTIVE OR ADMINISTRATIVE ORDERS OR DECLARATIONS OR OTHERWISE,
EVEN IF MICROHARD SYSTEMS INC. HAS BEEN ADVISED OR OTHERWISE HAS KNOWLEDGE OF THE POSSIBIL-
ITY OF SUCH DAMAGES AND TAKES NO ACTION TO PREVENT OR MINIMIZE SUCH DAMAGES. IN THE EVENT
THAT REGARDLESS OF THE WARRANTY DISCLAIMERS AND HOLD HARMLESS PROVISIONS INCLUDED ABOVE
MICROHARD SYSTEMS INC. IS SOMEHOW HELD LIABLE OR RESPONSIBLE FOR ANY DAMAGE OR INJURY, MI-
CROHARD SYSTEMS INC.'S LIABILITY FOR ANYDAMAGES SHALL NOT EXCEED THE PROFIT REALIZED BY MI-
CROHARD SYSTEMS INC. ON THE SALE OR PROVISION OF THE HARDWARE TO THE CUSTOMER.
Proprietary Rights
The Buyer hereby acknowledges that Microhard Systems Inc. has a proprietary interest and intellectual prop-
erty rights in the Hardware, Software and/or Products. The Purchaser shall not (i) remove any copyright, trade
secret, trademark or other evidence of Microhard Systems Inc.’s ownership or proprietary interest or confiden-
tiality other proprietary notices contained on, or in, the Hardware, Software or Products, (ii) reproduce or modi-
fy any Hardware, Software or Products or make any copies thereof, (iii) reverse assemble, reverse engineer or
decompile any Software or copy thereof in whole or in part, (iv) sell, transfer or otherwise make available to
others the Hardware, Software, or Products or documentation thereof or any copy thereof, except in accord-
ance with this Agreement.

© Microhard 3
Important User Information (continued)
About This Manual
It is assumed that users of the products described herein have either system integration or
design experience, as well as an understanding of the fundamentals of radio communications.
Throughout this manual you will encounter not only illustrations (that further elaborate on the
accompanying text), but also several symbols which you should be attentive to:
Caution or Warning
Usually advises against some action which could result in undesired or
detrimental consequences.
Point to Remember
Highlights a key feature, point, or step which is noteworthy. Keeping
these in mind will simplify or enhance device usage.
Tip
An idea or suggestion to improve efficiency or enhance usefulness.
Information
Information regarding a particular technology or concept.

© Microhard 4
Important User Information (continued)
Please Note: These are only sample labels; different products contain different identifiers. The actual identifiers should be seen on
your devices if applicable.
Regulatory Requirements / Exigences Réglementaires
WARNING:
To satisfy FCC RF exposure requirements for mobile transmitting devices, a separation distance of 23 cm or more should be maintained between
the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended.
The antenna used for this transmitter must not be co-located in conjunction with any other antenna or transmitter.
WARNING:
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received including interference that may cause undesired operation.
WARNING:
Changes or modifications not expressly approved by Microhard Systems Inc. could void the user’s authority to operate the equipment. This device
has been tested with UFL to Reverse Polarity SMA connectors with the antennas listed in Appendix A When integrated in OEM products, fixed
antennas require installation preventing end-users from replacing them with non-approved antennas. Antennas not listed in the tables must be
tested to comply with FCC Section 15.203 (unique antenna connectors) and Section 15.247 (emissions).
WARNING:
MAXIMUM EIRP
FCC Regulations allow up to 36 dBm equivalent isotropically radiated power (EIRP). Therefore, the sum of the transmitted power (in dBm), the
cabling loss and the antenna gain cannot exceed 36 dBm.
WARNING:
EQUIPMENT LABELING
The FCC and IC numbers depend on the model of the radio module. Do NOT use the Marketing Name of the product but the Model to distinguish
the Certifications Numbers. This device has been modularly approved. The manufacturer, product name, and FCC and Industry Canada
identifiers of this product must appear on the outside label of the end-user equipment.
WARNING:
This device complies with Industry Canada’slicense-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired
operation of the device.
SAMPLE LABEL REQUIREMENT / EXIGENCE D'ÉTIQUETTE:
pMDDL5824:
FCCID: Pending
IC: Pending
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received including interference that may cause
undesired operation.

© Microhard 5
Important User Information (continued)
Please Note: S'il vous plaît noter: Ce sont des exemples d'étiquettes seulement; différents produits contiennent des identifiants
différents. Les identifiants réels devrait être vu sur vos périphériques le cas échéant.
Regulatory Requirements / Exigences Réglementaires
WARNING:
Pour satisfaire aux exigences de la FCC d'exposition RF pour la base et mobiles sur une distance de séparation de 23 cm ou plus doit être
maintenue entre l'antenne de cet appareil et des personnes lors de fonctionnement du dispositif. Pour assurer la conformité des opérations au
plus près que cette distance n'est pas recommandée. L'antenne utilisée pour ce transmetteur ne doit pas être co-localisés en conjonction avec
toute autre antenne ou transmetteur.
WARNING:
Son fonctionnement est soumis aux deux conditions suivantes : ( 1 ) ce dispositif ne doit pas causer d'interférences nuisibles et ( 2) cet appareil
doit accepter toute interférence reçue, incluant les interférences qui peuvent provoquer un fonctionnement indésirable .
WARNING:
Les changements ou modifications non expressément approuvés par Microhard Systems Inc. pourraient annuler l'autorité de l'utilisateur à utiliser
l'équipement . Ce dispositif a été testé avec MCX et connecteurs SMA à polarité inverse sur les antennes répertoriées à l'annexe A Lorsqu'il est
intégré dans les produits OEM , antennes fixes nécessitent une installation empêchant les utilisateurs finaux de les remplacer par des antennes non
approuvées . Antennes ne figurant pas dans les tableaux doivent être testés pour se conformer à la Section 15.203 (connecteurs d'antenne
uniques ) et à la Section 15.247 ( émissions ) .
WARNING:
MAXIMUM EIRP
Règlement FCC permettent jusqu'à 36 dBm puissance isotrope rayonnée équivalente ( EIRP) . Par conséquent, la somme de la puissance émise ( en
dBm ), la perte de câblage et le gain d'antenne ne peut pas dépasser 36 dBm.
WARNING:
ÉQUIPEMENT DE MARQUAGE
Les numéros FCC et IC dépendent du modèle du module radio . Ne pas utiliser le nom marketing du produit, mais le modèle de distinguer les
numéros Certifications . Ce dispositif a été approuvé de façon modulaire . Le fabricant , nom du produit, et les identificateurs de la FCC et
d'Industrie Canada de ce produit doivent figurer sur l'étiquette à l'extérieur de l'équipement de l'utilisateur final .
WARNING:
Cet appareil est conforme aux CNR exempts de licence d'Industrie Canada . Son fonctionnement est soumis aux deux conditions suivantes : ( 1 ) Ce
dispositif ne peut causer des interférences ; et ( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences qui peuvent causer un
mauvais fonctionnement de l'appareil.
SAMPLE LABEL REQUIREMENT / EXIGENCE D'ÉTIQUETTE:
pMDDL5824:
FCCID: Pending
IC: Pending
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received including interference that may cause
undesired operation.

© Microhard 6
Revision History
Revision Description Initials Date
1.0.0 Preliminary Release. Based on Firmware v1.4.0 Build 1013-2PEH Nov 2018
1.1.0 Updated to firmware 1.4.0 Build 1013-13, Updated pictures,
drawings to reflect hardware changes and enclosure designs.
PEH Feb 2019

© Microhard 7
Table of Contents
1.0 Overview .........................................................................................................10
1.1 Performance Features .......................................................................................................10
1.2 Specifications .....................................................................................................................11
1.3 pMDDL5824 Performance .................................................................................................13
2.0 QUICK START.................................................................................................14
2.1 Getting Started ...................................................................................................................14
2.2 Simple Master and Slave (Auto - Using Defaults)..............................................................16
2.3 Simple Master and Slave (Manual) ....................................................................................17
2.3.1 Configuring the Master .............................................................................................17
2.3.2 Configuring the Slave /Remote ................................................................................19
2.3.3 Testing the Connection ............................................................................................21
3.0 Hardware Features.........................................................................................22
3.1 pMDDL5824 OEM ..............................................................................................................22
3.1.1 Mechanical Drawings ...............................................................................................23
3.1.2 PCB PAD Placement (Pad Landing) ........................................................................24
3.1.3 OEM Pin Descriptions ..............................................................................................25
3.1.4 USB Device Mode ....................................................................................................27
3.2 pMDDL5824 Development Board / Enclosed ....................................................................28
3.2.1 Development Board Mechanical Drawings ..............................................................29
3.2.2 Enclosed Mechanical Drawings ...............................................................................30
3.2.3 Connectors & Indicators ...........................................................................................31
4.0 Configuration..................................................................................................33
4.0 Web User Interface...........................................................................................................33
4.0.1 Logon Window..........................................................................................................34
4.1 System...............................................................................................................................35
4.1.1 Summary ..................................................................................................................35
4.1.2 Settings.....................................................................................................................36
Host Name................................................................................................................36
Date/Time.................................................................................................................37
4.1.3 Services ...................................................................................................................39
SSH ..........................................................................................................................39
Telnet........................................................................................................................39
HTTP/HTTPS ...........................................................................................................39
4.1.4 Maintenance .............................................................................................................40
Firmware Upgrade....................................................................................................40
Backup & Restore Configurations ............................................................................41
4.1.5 Reboot ......................................................................................................................42
4.2 Network .............................................................................................................................43
4.2.1 Status .......................................................................................................................43
4.2.2 LAN...........................................................................................................................44
LAN DHCP ...............................................................................................................46
4.2.3 WAN .........................................................................................................................48
4.2.4 USB ..........................................................................................................................50
4.2.5 DHCP (MAC Binding)...............................................................................................51
4.2.6 Routes ......................................................................................................................52
4.2.7 Ports .........................................................................................................................54
4.2.8 Device List ................................................................................................................55

© Microhard 8
Table of Contents
4.3 Wireless.............................................................................................................................56
4.3.1 Status .......................................................................................................................56
4.3.2 Radio1 ......................................................................................................................57
Radio On/Off.............................................................................................................57
Channel Bandwidth ..................................................................................................58
Radio Channel (Frequency) .....................................................................................58
TX Power..................................................................................................................58
MIMO On/Off ............................................................................................................58
Operating Mode........................................................................................................59
TX Rate ....................................................................................................................59
Network ID................................................................................................................60
Encryption.................................................................................................................60
4.4 Firewall .............................................................................................................................62
4.4.1 Summary ..................................................................................................................62
4.4.2 General.....................................................................................................................63
4.4.3 Port Forwarding ........................................................................................................64
4.4.4 MAC-IP List ..............................................................................................................66
4.4.5 Rules ........................................................................................................................68
4.4.4 Default ......................................................................................................................70
4.5 Serial..................................................................................................................................71
4.5.1 Summary ..................................................................................................................71
4.5.2 Data/Console Port Settings ......................................................................................72
Data Baud Rate ........................................................................................................73
IP Protocol Config.....................................................................................................75
TCP Client ............................................................................................................75
TCP Server...........................................................................................................75
TCP Client/Server................................................................................................76
UDP Point-to-Point ..............................................................................................76
UDP Point-to-Multipoint (P) .................................................................................76
UDP Point-to-Multipoint (MP) ..............................................................................76
PPP......................................................................................................................78
4.5.3 Gadget (USB - Device Mode)...................................................................................79
4.6 Diag....................................................................................................................................80
4.6.1 Ping.........................................................................................................................80
4.6.2 Traceroute...............................................................................................................80
4.6.3 Iperf.........................................................................................................................81
4.6.4 USB Tethering ........................................................................................................82
4.7 Admin ................................................................................................................................83
4.7.1 Users.......................................................................................................................83
4.7.2 SNMP......................................................................................................................85
4.7.3 Discovery ................................................................................................................90
4.7.4 Logout .....................................................................................................................91

© Microhard 9
Table of Contents
5.0 AT Command Line Interface ..........................................................................92
5.1 AT Command Overview...................................................................................................92
5.1.1 Telnet (TCP/IP).......................................................................................................92
5.2 AT Command Syntax .......................................................................................................93
5.3 Supported AT Commands...............................................................................................94
6.0 Installation .......................................................................................................107
6.1 Path Calculation ...............................................................................................................109
6.2 Installation of Antenna System Components ...............................................................110
6.2.1 Antennas.................................................................................................................110
6.2.2 Antenna Selection, Placement & Orientation .........................................................111
6.2.3 Coaxial Cable..........................................................................................................112
6.2.4 Surge Arrestors.......................................................................................................112
6.2.5 External Filter..........................................................................................................112
Appendices ..........................................................................................................113
Appendix A: Firmware Recovery................................................................................................113
Appendix B: Sample Interface Schematic (Future) ....................................................................114
Appendix C: Serial Port Extension .............................................................................................115
Appendix D: Troubleshooting/FAQ ............................................................................................116

© Microhard 10
1.0 Overview
The pMDDL5824 is a feature rich, high power, 2x2 MIMO Wireless OEM Digital Data Link.
The pMDDL5824 is designed to provide high performance wireless capabilities in a compact
and rugged OEM module for system integration. The pMDDL5824 features simultaneous dual
10/100 Ethernet & Serial (RS232/485) Gateway capabilities for high speed wireless applica-
tions
The pMDDL5824 can be configured using a built-in WebUI interface which does not require
any additional software or tools to setup or download. The unit can operate as a Master,
Slave or Relay (future) to establish robust long range wireless links between locations.
Providing reliable wireless Ethernet bridge functionality as well gateway service for most
equipment types which employ a serial RS232/485 interface, the pMDDL5824 can be used in
various types of applications such as:
1.1 Performance Features
Key performance features of the pMDDL5824 include:
• High-speed backbone
• IP video surveillance
• Voice over IP (VoIP)
• Ethernet wireless
extension
• UAV/UAS
• Legacy network/device
migration
• SCADA
• Remote Telemetry
• Multicast Video
• Adjustable, High Power Tx (up to 1W Total) w/ Excellent Rx Sensitivity
• Up to 25 Mbps data rate*
• Master, Slave/Remote, Repeater, Mesh operating modes
• Point to Point, Point to Multipoint topology support
• Firewall with ACL Security, Port Forwarding
• Serial Gateway (RS232/485)
• Dual 10/100 Ethernet Ports
• RSSI LED pins for Antenna Alignments
• Industrial grade operating temperature (-40oC to +85oC)
• Administration via local console, telnet, web browser, SNMP
• Local and remote wireless firmware upgradable
* See Section 1.3 Performance Specifications

© Microhard 11
1.0 Overview
1.2 Specifications
For detailed specifications, please see the specification sheets available on the Microhard website @
http:///www.microhardcorp.com for your specific model.
Electrical/General
Frequency: 2.402 - 2.478 GHz or
5.000 - 5.900 GHz
Link Rate: See Section 1.3 Performance Specifications
TX Power: 20 dBm - 30 dBm Total (Adjustable)
Channel Bandwidth: 1, 2, 4, 8 MHz (Selectable)
Error Detection/Control: CRC, ARQ
Data Encryption*: 128-bit AES (Optional 256-bit)
(*Requires Export Permit)
Serial Port: 300bps to 921kbps
Ethernet: Dual 10/100 BaseT, Auto - MDI/X, IEEE 802.3
USB: 2.0
Network Protocols: TCP, UDP, TCP/IP, ARP, ICMP, DHCP, HTTP, HTTPS*, SSH*,
SNMP, FTP, DNS, Serial over IP (*May require an export permit)
Operating Modes: Master, Slave/Remote, Repeater, Mesh Node
Management: Local Serial Console, Telnet, WebUI, SNMP, FTP &
Wireless Upgrade
Diagnostics: Status LED’s, RSSI, remote diagnostics, SNR
Input Voltage: OEM: Digital Voltage: 3.3 VDC (500mA)
RF Voltage: 5.0 VDC (1.5A)
Current:
2.4 GHz 5.8 GHz
MIMO ON MIMO OFF MIMO ON MIMO OFF
Tx Power
(dBm) Vcc @ 3.3V VRF @ 5V Vcc @ 3.3V VRF @ 5V Vcc @ 3.3V VRF @ 5V Vcc @ 3.3V VRF @ 5V
Peak Avg. Transmit Current (mA)
20 250 - 720 630 250 - 560 350 250 - 620 340 250 - 510 400
22 250 - 720 720 250 - 560 400 250 - 620 390 250 - 510 440
24 250 - 720 800 250 - 560 440 250 - 620 450 250 - 510 490
26 250 - 720 880 250 - 560 510 250 - 620 520 250 - 510 570
28 250 - 720 1020 250 - 560 600 250 - 620 620 250 - 510 650
30 250 - 720 1250 250 - 560 780 250 - 620 790 250 - 510 740
Instantaneous Current Draw - 500 1500 500 1500 500 1000 500 1000
Typical Receive Current Draw
(mA) - 250-720 - 250 - 560 400 - 460 - 250 - 510
Table 1-1: pMDDL5824 Current Consumption

© Microhard 12
1.0 Overview
Environmental
Operation Temperature: -40oF(-40oC) to 185oF(85oC)
Humidity: 5% to 95% non-condensing
Mechanical
Dimensions: OEM: 1.25” (32 mm) X 2.25” (57mm) X 0.2” (5 mm)
Development Board: 2.75” (70 mm) X 3.25” (83 mm) X 0.0.75 (19 mm)
Weight: OEM: Approx. 20 grams
Development Board: Approx. 65 grams (85 grams with radio installed)
Connectors: OEM: Antenna: UFL x2 (ANT1, ANT2)
Data: 100 pin OEM Header
Development Board: 2x RJ45 Ethernet Ports
DB9 Serial Port
USB Type A
4pin Power
USB Micro-AB
2x SMA Female (Antenna 1, Antenna 2)

© Microhard 13
1.0 Overview
1.3 Performance Specifications
MIMO (2X2) ON
Modulation IPerf Throughput
(Mbps) Throughput @ Sensitivity (dBm) Maximum Total Tx Power (dBm) +/- 1dB
8 MHz Channel Bandwidth
BPSK_1/2 3.0 -99.5 30dBm
QPSK_1/2 5.9 -98 30dBm
QPSK_3/4 8.8 -96 30dBm
16QAM_1/2 11.6 -92 30dBm
16QAM_3/4 17.1 -90 30dBm
64QAM_2/3 22.8 -85 30dBm
64QAM_3/4 25.5 -83.5 30dBm
64QAM_5/6 27.8 -81 30dBm
4 MHz Channel Bandwidth
BPSK_1/2 1.51 -102.5 30dBm
QPSK_1/2 2.98 -101 30dBm
QPSK_3/4 4.4 -99 30dBm
16QAM_1/2 5.8 -95.5 30dBm
16QAM_3/4 8.6 -93 30dBm
64QAM_2/3 11.4 -88 30dBm
64QAM_3/4 12.8 -86 30dBm
64QAM_5/6 14 -83.5 30dBm
Table 1-2: pMDDL5824 Performance Specifications
MIMO OFF
Modulation IPerf Throughput
(Mbps) Throughput @ Sensitivity (dBm) Maximum Tx Power (dBm) +/- 1dB
8 MHz Channel Bandwidth
BPSK_1/2 3.0 -96.5 30dBm
QPSK_1/2 5.8 -95 30dBm
QPSK_3/4 8.6 -93 30dBm
16QAM_1/2 11.5 -89 30dBm
16QAM_3/4 16.9 -87 30dBm
64QAM_2/3 22.2 -82 28dBm
64QAM_3/4 24.7 -80.5 28dBm
64QAM_5/6 27.4 -78 27dBm
4 MHz Channel Bandwidth
BPSK_1/2 1.5 -99.5 30dBm
QPSK_1/2 2.9 -98 30dBm
QPSK_3/4 4.3 -96 30dBm
16QAM_1/2 5.7 -92.5 30dBm
16QAM_3/4 8.4 -90 30dBm
64QAM_2/3 11.3 -85 28dBm
64QAM_3/4 12.5 -83 28dBm
64QAM_5/6 14 -80.5 27dBm

© Microhard 14
2.0 Quick Start
To reset to factory
defaults, press and
hold the CONFIG for 8
seconds with the
pMDDL5824 powered
up. The pMDDL5824
will reboot with factory
default settings.
This QUICK START guide will walk you through the setup and configuration of a few
basic applications. The QUICK START will rely on the WebUI for configuration. This
walkthrough also assumes the units used are installed in microhard interface/
development boards or custom boards that allow access to the LAN port. See the
appropriate section for pin-outs.
Note that the units arrive from the factory with a Radio Configuration of ‘Master’
and the Local Network setting configured as ‘Static’ (IP Address 192.168.168.1,
Subnet Mask 255.255.255.0). DHCP is enabled by default, and will assign an IP to a
connected device or computer with DHCP enabled.
2.1 Getting Started
✓ Connect the appropriate Antenna(s) to the pMDDL5824.
✓ Connect and/or apply a suitable power source to the unit. Allow the unit to boot
up fully, the CPU LED (Blue) should be on in a solid state
✓ Connect A PC to the LAN port of the pMDDL5824 Dev Board, using an Ethernet
Cable.
✓ The PC must have its Network Setting (TCP/IP Properties) set to DHCP (The mo-
dem will assign a IP address to you), or STATIC with an IP Address of (e.g.)
192.168.168.10 and a Subnet Mask of 255.255.255.0.
✓ Open a Browser Window and enter the IP address 192.168.168.1 into the ad-
dress bar.
The factory default
network settings:
IP: 192.168.168.1
Subnet: 255.255.255.0
LAN
192.168.168.1

© Microhard 15
2.0 Quick Start
✓ The pMDDL5824 will then ask for a Username and Password. Enter the factory
defaults listed below.
✓ Once successfully logged in, the System Summary window will be displayed.
The factory default login:
User name: admin
Subnet: admin
You will be forced to
change the default
password upon logging in
for the first time.
The Factory default login:
User name: admin
Password: admin
Once successfully logged in for the first
time, the pMDDL5824 will force a pass-
word change

© Microhard 16
2.0 Quick Start
2.2 Simple Master and Slave - Auto (Using Defaults)
This Quick Start example requires (2) pMDDL5824 units, one will be configured as
a Master (M), the second unit will be configured as a Slave/Remote (S). This exam-
ple will use factory defaults to set up each unit so that a simple network will be es-
tablished.
✓ Use Section 2.1 Getting Started to power up a pair of pMDDL5824 modules
mounted in a Pico Ethernet Motherboard.
✓ Master: Once the pMDDL5824 is fully booted (solid blue CPU LED), press and
hold the CFG button. Once the CPU LED begins to flash, continue to hold for at
least 10 seconds, then release.
✓ The pMDDL5824 will then reset all settings to default values, and set the follow-
ing settings that are required to automatically create a link with a slave:
- IP Address: 192.168.168.1, Operating Mode: Master
- Network ID: pMDDL, Channel Bandwidth: 8 MHz
- Channel-Frequency: 76 - 2477 MHz
✓ Slave: Ensure the pMDDL5824 is fully booted (solid blue CPU LED), then press
and hold the CFG button. Once the CPU LED begins to flash, continue to hold for
5 seconds, then release.
✓ The pMDDL5824 will then reset all settings to default values, and set the follow-
ing settings that are required to automatically create a link with a slave:
- IP Address: 192.168.168.2, Operating Mode: Slave
- Network ID: pMDDL, Channel Bandwidth: 8 MHz
- Channel-Frequency: 76 - 2477 MHz
✓ Once both units have finished changing settings (~60 seconds) a wireless link
should automatically be established between them, this can be seen by observ-
ing the RSSI LEDS, they should be on solid, indicating a link (the more LEDs il-
luminated = stronger the link).
MS
Wireless
Press and hold CFG button for at least
10 seconds to reset to a default Master pMDDL5824
Press and hold CFG button for 5 seconds
to reset to a default Slave pMDDL5824
CPU LED (Blue) / RSSI LEDS (Green) (On bottom of PCB)

© Microhard 17
2.0 Quick Start
To connect to an
existing network,
contact your Network
Administrator for valid
network settings.
2.3 Simple Master and Slave — Manual Setup
This Quick Start example requires (2) pMDDL5824 units, one will be configured as
a Master (M), the second unit will be configured as a Slave/Remote (S). This exam-
ple will show the basic steps required to set up each unit so that a simple network
will be established.
For the best performance it is required to connect the Master to the video source (camera) and
the remote to the video receiver. The pMDDL5824 can support Point-to-Multipoint applications
and multiple remotes could be used to view the video from multiple locations.
2.3.1 Configuring the Master
✓ Use Section 2.1 Getting Started to connect, power up and log in to a
pMDDL5824 unit.
✓ Give the pMDDL5824 unit a unique IP address.
MS
Wireless
Select Network from the top/main
navigation.
Select LAN from the submenu list.
Select Edit on the LAN interface 1.
Choose Static IP for the Connection
Type.
Enter the following Network
Information:
IP Address: 192.168.168.11
IP Subnet Mask: 255.255.255.0
Click on the Submit button to write the
changes to the pMDDL5824. The Can-
cel button will revert back to last values
saved to the unit.
Once the IP Address is changed,
you will need to type the new ad-
dress into your browser to continue
the configuration.
Refer to Section 5.2.2 LAN for additional
information.
EthernetEthernet

© Microhard 18
2.3.1 Configuring the Master (Con’t)
✓ Configure the pMDDL5824 as a Master
2.0 Quick Start
If any additional
settings need to be
changed, ensure they
are also changed on
the Slave.
Select Master from the Operation
Mode dropdown box.
Set a Network ID, which will need
to be the same on each unit in the
network. This example uses
TEST_ID.
Select Wireless from the top/main navi-
gation, and then RF from the submenu
list.
For bench or close proximity testing
it is best to use a lower power setting
to prevent RF saturation. Select
20dBm from the TX Power setting.
The remaining settings in the Wireless menu
should be left as defaults for this exercise.
Refer to Section 5.3 Wireless for additional
information.
Click on the Submit button to write the
changes to the pMDDL5824. The Cancel but-
ton will revert back to previously saved val-
ues
In the RF Configuration ensure the
Compatibility Mode, Channel
Bandwidth and Channel-
Frequency are set the same on each
module.

© Microhard 19
2.0 Quick Start
To connect to an
existing network,
contact your Network
Administrator for valid
network settings.
2.3.2 Configuring the Slave/Remote
The following procedure describes the steps required to set up a pMDDL5824 unit
as a Slave (S). A Slave provides a single wireless connection (i.e to an Master) and
provides a wired connection to a PC or other devices.
✓ Use Section 2.1 Getting Started to connect, power up and log in to a second
pMDDL5824 unit.
✓ Give the pMDDL5824 unit an unique IP address.
Choose Static IP for the Connection
Type.
Enter the following Network
Information:
IP Address: 192.168.168.12
IP Subnet Mask: 255.255.255.0
Default Gateway: 192.168.168.11
Click on the Submit button to write the
changes to the pMDDL5824. The Cancel
button will revert back to last values
saved to the unit.
Once the IP Address is changed, you
will need to type the new address into
your browser to continue the configu-
ration.
Refer to Section 5.2.2 LAN for additional
information.
Select Network from the top/main
navigation.
Select LAN from the submenu list.
Select Edit on the LAN interface 1.

© Microhard 20
2.0 Quick Start
If any additional
settings need to be
changed, ensure they
are also changed on
the Slave.
2.3.3 Configuring the Slave/Remote (Con’t)
✓ Configure the pMDDL5824 as a Slave
Select Slave from the Operating
Mode dropdown box.
Set a Network ID, which will need
to be the same on each unit in the
network. This example uses
TEST_ID.
Select Wireless from the top/main
navigation, and then RF from the
submenu list.
For bench or close proximity testing
it is best to use a lower power setting
to prevent RF saturation. Select
20dBm from the TX Power setting.
The remaining settings in the Wireless menu
should be left as defaults for this exercise.
Refer to Section 5.3 Wireless for additional
information.
Click on the Submit button to write the
changes to the pMDDL5824. The Cancel but-
ton will revert back to previously saved values
In the RF Configuration ensure the
Compatibility Mode, Channel
Bandwidth and Channel-
Frequency are set the same on each
module.
