Microlight IR-1 ZOOM User manual

Operation manual
before you get started read the instruction carefully
and make sure that you understand everything
v2.1 april 2015
Infrared illuminator
IR-1 ZOOM
MICROLIGHT
infrared illuminators
GENERAL INFORMATION
Thank you for purchasing of products Microlight!
Infrared LED illuminators IR-1 ZOOM intended for use in video surveillance systems
for lighting objects in low light conditions, including total darkness.
Deciphering the model name illuminator:
attention! important information!
damage to the eyes!
additional information
Icons used in this manual:
IR-1-XXX XXX ST3M FS XXX
The presence and type of bracket
Presence of the light sensor
Case color of illuminator
Model of illuminator
The radiation wavelenght, nm
Electrical power (PoE+,
without - 12...24 V AC/DC)
!
risk of electric shock
BEFORE YOU START
COMPLIANCE WITH STANDARDS OF SAFETY AND
ELECTROMAGNETIC COMPATIBILITY
PACKAGE CONTENTS
1 Infrared illuminator 1
2 Bracket ST-3M 1
3 Set of fasteners consisting of:
Screw М4х10
Screw М6х25
Washer 4
Washer 6
2
1
2
1
4 Operation manual 1
5 Package 1
!Make sure your video camera is suitable for infrared illuminator.
To work with an infrared illuminator suitable black-and-white video cameras and
color video cameras with “day/night» feature, in which the corrective filter for cutting
off infrared radiation, automatically moves away from the matrix of the camera when
working in night mode.
To avoid loss of sharpness (focus) of the image in night mode when using infrared
light, the camera must be equipped with a lens with IR correction (IR marking on the
body or in the designation of the lens).
In operation the case of the illuminator may be heated. This is normal and does not
affect the lifetime of the illuminator and which is not by any malfunction or defect.
Infrared LED illuminator IR-1 ZOOM meets the requirements of the Eurasian
Customs Union TR CU 020/2011 «Electromagnetic compatibility of technical
means» and TR CU 004/2011 «On safety of low voltage equipment», as well as the
requirements EMC Directive 2004/108/ EC EN55015:2009, EN61547:2009,
EN61000-3-2:2006+A1:2009+A2:2009, EN61000-3-3:2009, EN61000-4-2:2009,
EN61000-4-3:2008, EN61000-4-4:2012, EN61000-4-5:2007, EN61000-4-6:2009,
EN61000-4-11:2005.
SAFETY ENGINEERING
If the LED illuminator is out of order, it cannot be repaired and try to recover!
Unauthorized disassembly of the illuminator and technical intervention leads
to a denial of warranty service.
Do not disassemble to avoid accidents! LED illuminators are strictly prohibited
to disassemble
Invisible radiation of infrared LEDs! To prevent eye injuries, do not look directly
at the switched-on illuminator.
Installation and connection of the illuminator should produce an expert in the
field of electrical engineering works.
Protect the illuminator from impacts and vibrations.
!
Produced by Microlight 23, Hausberg str,
Bad Nauheim, Germany, 61231
Tel./fax: [phone]
www.microlightsecurity.com

TECHNICAL SPECIFICATION
The radiation wavelength, nm 850
The angle of radiation, ° adjustable in the range 2...100
Distance of illumination, m 18...400
Power consumption, W 4.0 max
Supply voltage, V 12...24 AC/DC (optional PoE)
Weight, kg 0.74
Dimensions (WхHхD), мм 72х73.5х185
Operating temperature, °С -40...+50
Ingress Protection IP66
the angle of radiation, ° 2 5 9 17 25 40 50 65 90 100
distance of illumination,
m400 120 80 50 40 30 25 22 20 18
the spot size at a
distance, m 12 9 11 13 16 20 20 35 35 40
llumination distance is shown for B/W camera without IR correction, 1/3-inch
CCD, sensitivity not less than1,5x10-5 W/m2for 0.8…1 µm of IR range (equivalent
for 0.01 lux), F number 1.4.
!
Built-in light sensor automatically turns on the illuminator when the light intensity drops
to less than 3 Lux. To avoid tripping illuminator with occasional short-term increase in
ambient light, such as headlights of a passing car, provided the time interval delay turn off
the illuminator, equal to 25...35 sec .
LIGHT SENSOR
INSTALLATION AND CONNECTION
Illuminator can be installed outdoors and indoors. When installing, ensure free air
flow past casing to cool the illuminator.
The installation of illuminator should be made in the following order:
1. Assemble the bracket as shown in figure.
2. Install the illuminator on the bracket, pre-slightly tighten the bracket screws.
3. Mount the bracket on the wall.
4. Plug the illuminator to a low voltage power supply 12 ... 24 V AC or DC.
The polarity need not be obeyed.
When using the illuminator with PoE to connect the plug RJ-45 with PoE
injector or switch.
5. Make sure that the illuminator works.
Invisible radiation infrared LEDs. Do not look at the illuminator directly.
6. Adjust the angle of radiation illuminator, for this:
remove the screw plug on the back of the case illuminator;
rotating the adjusting screw to achieve the desired angle of radiation: set screw
plug in place.
7. Adjust the vertical position of the illuminator relative to the bracket and the
angle of the illuminator in accordance with the requirements of the lighting of the
object.
8. Tighten the bracket screws for final fixing the illuminator.
If necessary disable the light sensor is enough to cover the sensor with opaque
material.
INSTALLATION AND CONNECTION
!
The Illuminator should be stored indoors in the absence of aggressive environment
in the form of vapor and acids and alkalis. Ambient temperature from -50 °C to
+ 50 °C; relative humidity less than 95% at 25 °C.
RETENTION RULES
WARRANTY
!
The Manufacturer guarantees the absence of manufacturing defects and malfunctions of
Equipment.
The warranty period shall be counted from the date of purchase of Equipment and shall be 36
months.
During the warranty period, the Manufacturer will correct the defects in the Equipment
through its repair or replacement for a similar, provided that the defect has arisen through the
fault of the Manufacturer. Equipment offered to replace, can be both new and restored, but in
any case, the Manufacturer guarantees that its characteristics are not worse than replaced
Equipment.
Under no circumstances will the Manufacturer be liable for any damages, including loss of
data, loss of profits or other incidental, consequential or indirect damages caused by incorrect
installation, maintenance, operation or performance-related, failure or temporary Equipment
malfunction.
Manufacturer assumes no liability under the guarantee in the case that produced the testing
and/or analysis revealed that the alleged defect in the Equipment is missing or it has arisen as
a result of incorrect installation or operation conditions, as well as any actions associated with
attempts to make the Equipment perform functions that are not declared by the Manufacturer,
as well as attempts to change the technical characteristics of Equipment.
Warranty does not include cleaning and preventive maintenance of the Equipment by and at
the expense of the Manufacturer.
WARRANTY DOES NOT COVER:
The counterfeit devices, the offensive of force majeure (fire, natural disasters and others),
failures due to violations of the rules of transportation, storage, operation, or improper
installation, defects caused by repair or modification of the equipment by persons not authorized
by the Manufacturer, on the illuminators with external defects (obvious mechanical damage,
cracks, chips).
