Microlight IR-Plate-2-850 User manual

Operation manual
before you get started read the instruction carefully
and make sure that you understand everything
v2.1 april 2015
If the LED illuminator is out of order, it cannot be repaired and try to recover!
Unauthorized disassembly of the illuminator and technical intervention leads to a
denial of warranty service.
Do not disassemble to avoid accidents! LED illuminators are strictly prohibited
to disassemble!
Invisible radiation of infrared LEDs! To prevent eye injuries, do not look directly
at the switched-on illuminator.
Do not operate the LED illuminator with input voltage 185 ... 265 V without
protective earth.
Installation and connection of the illuminator should produce an expert in the
field of electrical engineering works.
Protect the illuminator from impacts and vibrations.
Infrared illuminator
IR-Plate
MICROLIGHT
infrared illuminators
Thank you for purchasing of products Microlight!
Infrared LED illuminators IR-Plate (hereinafter - illuminators) intended for use in
video surveillance systems for lighting objects in low light conditions, including total
darkness.
Deciphering the model name illuminator:
Icons used in this manual:
IR-Plate-X-XXX
model
modification
wavelenght
!
!
Produced by Microlight 23, Hausberg str,
Bad Nauheim, Germany, 61231
Tel./fax: [phone]
www.microlightsecurity.com
GENERAL INFORMATION
Attention! Important Information!
damage to the eyes!
additional information
!
risk of electric shock
PACKAGE CONTENTS
1 Infrared illuminator 1
2 Operation manual 1
3 Package 1
BEFORE YOU START
Make sure your video camera is suitable for infrared illuminator.
To work with an infrared illuminator suitable black-and-white video cameras and
color video cameras with “day/night» feature, in which the corrective filter for cutting
off infrared radiation, automatically moves away from the matrix of the camera when
working in night mode.
To avoid loss of sharpness (focus) of the image in night mode when using infrared
light, the camera must be equipped with a lens with IR correction (IR marking on the
body or in the designation of the lens).
In operation the case of the illuminator may be heated. This is normal and does not
affect the lifetime of the illuminator and which is not by any malfunction or defect.
COMPLIANCE WITH STANDARDS OF SAFETY AND
ELECTROMAGNETIC COMPATIBILITY
Infrared LED illuminator IR-28 SPH meets the requirements of the Eurasian
Customs Union TR CU 020/2011 «Electromagnetic compatibility of technical
means» and TR CU 004/2011 «On safety of low voltage equipment», as well as the
requirements EMC Directive 2004/108/ EC EN55015:2009, EN61547:2009,
EN61000-3-2:2006+A1:2009+A2:2009, EN61000-3-3:2009, EN61000-4-2:2009,
EN61000-4-3:2008, EN61000-4-4:2012, EN61000-4-5:2007, EN61000-4-6:2009,
EN61000-4-11:2005.
SAFETY ENGINEERING

TECHNICAL SPECIFICATION
Model IR-Plate-2-850 IR-Plate-3-850 IR-Plate-2-940 IR-Plate-3-940
Wavelenght, nm 850±20 940±20
Angle, ° 120 150 120 150
Distance of illumination, m 2.5 3.0 1.5 2.5
Ðàçìåð ïÿòíà íà äèñòàí-
öèè, ì 9.0 12.0 6.0 12.0
Power consumption, W 4,5 max 5,1 max 4,5 max 5,1 max
Supply voltage, V 12±0.3 DC
Operation temperature, °C -40...+50
Dimensions (WxHxD), mm 106×72×6
Weight, kg 0,1 max
Ingress protection IP65
Distance of illumination is indicated for the camera with a matrix of 1.3 ‘’ 2Mpix, with Sence-
Up mode off.
To determine the approximate distance of the backlight for analog video cameras use a
correction factor of 2.5 - 3.0. a correction factor of 2.5 - 3.0.
!
Illuminator can be installed outdoors and indoors. When installing, ensure free air
flow past casing to cool the illuminator.
The installation of illuminator should be made in the following order:
1. Set the Illuminator on a flat surface with two screws, wood screws or self-
tapping screws.
2. Connect the Illuminator for low voltage supply 12 VDC, polarity marks. Red wire
\ Illuminator connect to the positive power supply, connect the black wire Illuminator
with less power.
Excess voltage of more than 0.3 may result in damage to the illuminator.
3. Make sure that IR illuminator is running.
The device has invisible rays of infrared light emitting diodes. Do not look at the
illuminator directly!
The design provides for the illuminator to apply labels (such as the words «EXIT», the
designation of apartment number, etc.) on the front of the illuminator.
Attention! The applied label must not overlap zone, where the radiating elements.
The construction involves the installation of illuminator miniature video camera behind
illuminator for a covert video surveillance.
!
!
45
15
area of the emitter
The Illuminator should be stored indoors in the absence of aggressive environment
in the form of vapor and acids and alkalis. Ambient temperature from -50 °C to
+ 50 °C; relative humidity less than 95% at 25 °C.
RETENTION RULES
WARRANTY
The Manufacturer guarantees the absence of manufacturing defects and malfunctions of
Equipment.
The warranty period shall be counted from the date of purchase of Equipment and shall be 36
months.
During the warranty period, the Manufacturer will correct the defects in the Equipment
through its repair or replacement for a similar, provided that the defect has arisen through the
fault of the Manufacturer. Equipment offered to replace, can be both new and restored, but in
any case, the Manufacturer guarantees that its characteristics are not worse than replaced
Equipment.
Under no circumstances will the Manufacturer be liable for any damages, including loss of
data, loss of profits or other incidental, consequential or indirect damages caused by incorrect
installation, maintenance, operation or performance-related, failure or temporary Equipment
malfunction.
Manufacturer assumes no liability under the guarantee in the case that produced the testing
and/or analysis revealed that the alleged defect in the Equipment is missing or it has arisen as
a result of incorrect installation or operation conditions, as well as any actions associated with
attempts to make the Equipment perform functions that are not declared by the Manufacturer,
as well as attempts to change the technical characteristics of Equipment.
Warranty does not include cleaning and preventive maintenance of the Equipment by and at
the expense of the Manufacturer.
WARRANTY DOES NOT COVER:
The counterfeit devices, the offensive of force majeure (fire, natural disasters and others),
failures due to violations of the rules of transportation, storage, operation, or improper
installation, defects caused by repair or modification of the equipment by persons not authorized
by the Manufacturer, on the illuminators with external defects (obvious mechanical damage,
cracks, chips).
INSTALLATION AND CONNECTION
INSTALLATION AND CONNECTION
