Microlight IR-294-S User manual

Operating manual
before you get started read the instruction carefully
and make sure that you understand everything
v2.1 april 2015
Infrared illuminators
IR-294-S
IR-294-M
IR-294-L
IR-294-XL
IR-294-XXL
MICROLIGHT
infrared illuminators
GENERAL INFORMATION
Thank you for purchasing of products Microlight!
Infrared LED illuminators IR-294 (hereinafter - illuminators) intended for use in
video surveillance systems for lighting objects in low light conditions, including total
darkness.
Deciphering the model name illuminator:
Icons used in this manual:
HELIOS IR-294-X/XX-XXX XXX FS ST3M XXX
Power supply of the illuminator (220 V AC, PoE,
without - 12...24 V AC/DC)
The presence and type of bracket
The presence of the light sensor
Case color of illuminator
Model of illuminator
Modification of the illuminator (S, M, L, XL, XXL)
The angle of illumination, °
Color temperature, Ê
Series of the illuminator
Produced by Microlight 23, Hausberg str,
Bad Nauheim, Germany, 61231
Tel./fax: +49 (0) 6032-8698410
www.microlightsecurity.com
Attention! Important Information!
damage to the eyes!
additional information
!
risk of electric shock
PACKAGE CONTENTS
1 Infrared illuminator 1
2 Bracket ST-3M
(optional - AST-3 or without bracket)
1
3 Set of fasteners consisting of:
Screw M6×25.56.096
Washer 6.01.049
Wrench 7812-0374 X9
1
1
1
4 Operation manual 1
5 Package 1
BEFORE YOU START
!Make sure your video camera is suitable for infrared illuminator.
To work with an infrared illuminator suitable black-and-white video cameras and
color video cameras with “day/night» feature, in which the corrective filter for cutting
off infrared radiation, automatically moves away from the matrix of the camera when
working in night mode.
To avoid loss of sharpness (focus) of the image in night mode when using infrared
light, the camera must be equipped with a lens with IR correction (IR marking on the
body or in the designation of the lens).
In operation the case of the illuminator may be heated. This is normal and does not
affect the lifetime of the illuminator and which is not by any malfunction or defect.
If the LED illuminator is out of order, it cannot be repaired and try to recover!
Unauthorized disassembly of the illuminator and technical intervention leads to a
denial of warranty service.
Do not disassemble to avoid accidents! LED illuminators are strictly prohibited
to disassemble!
Invisible radiation of infrared LEDs! To prevent eye injuries, do not look directly
at the switched-on illuminator.
Do not operate the LED illuminator with input voltage 185 ... 265 V without
protective earth.
Installation and connection of the illuminator should produce an expert in the
field of electrical engineering works.
Protect the illuminator from impacts and vibrations.
COMPLIANCE WITH STANDARDS OF SAFETY AND
ELECTROMAGNETIC COMPATIBILITY
Infrared LED illuminator IR-294 meets the requirements of the Eurasian Customs
Union TR CU 020/2011 «Electromagnetic compatibility of technical means» and TR
CU 004/2011 «On safety of low voltage equipment», as well as the requirements
EMC Directive 2004/108/ EC EN55015:2009, EN61547:2009, EN61000-3-
2:2006+A1:2009+A2:2009, EN61000-3-3:2009, EN61000-4-2:2009, EN61000-4-
3:2008, EN61000-4-4:2012, EN61000-4-5:2007, EN61000-4-6:2009, EN61000-
4-11:2005.
!
SAFETY ENGINEERING

4.3. Version of the illuminator with powered PoE (PoE+, UPoE) - connect the plug
RJ-45 to PoE injector or switch (IR-294-M - use equipment PoE+, IR-294-L/XL/XXL -
use equipment UPoE).
5. Make sure that the illuminator works.
Invisible radiation infrared LEDs. Do not look at the illuminator directly
6. Adjust the vertical position of the illuminator relative to the bracket and the
angle of the illuminator in accordance with the requirements of the lighting of the
object.
7. Tighten the bracket screws for final fixing the illuminator.
If necessary disable the light sensor is enough to cover the sensor with opaque
material.
TECHNICAL SPECIFICATION
Model IR-294-S IR-294-M IR-294-L IR-294-XL IR-294-XXL
Wavelenght, nm Angle, ° Distance, m / Horizontal spot size, m
850±20
30±5 47 / 24 66 / 34 81 / 42 94 / 49 105 / 54
45±5 32 / 24 45/ 34 55 / 42 64 / 49 72 / 55
60±6 23 / 23 32 / 32 40 / 40 46 / 46 51 / 51
90±9 16 / 24 23 / 33 28 / 40 32 / 45 36 / 51
120±12 12 / 21 17 / 29 21 / 36 24 / 42 27 / 47
940±20
30±5 22 / 11 31 / 16 38 / 20 44 / 23 49 / 25
45±5 14 / 11 20 / 15 24 / 19 28 / 21 31 / 24
60±6 11 / 11 16 / 16 19 / 19 22 / 22 25 / 25
90±9 8 / 11 11 / 16 14 / 20 16 / 23 18 / 25
120±12 6 / 10 8 / 14 10 / 17 11 / 19 12 / 21
Power consumption, W 12,0 max 25,0 max 37,0 max 50,0 max 62,0 max
Supply voltage, V 12...24 AC/DC or185...265 AC or PoE (PoE+, UPoE)
12...24 AC/DC
185...265 AC
Operation temperature, °C -40...+50
Dimensions (W×H×D), mm
134x95x68 134x145x68 134x180x68 134x230x68 134x265x68
Weight, kg 1,0 max 1,2 max 1,7 max 1,9 max 2,2 max
Ingress Protection IP66
Distance of illumination is indicated for the camera with a matrix of 1.3 ‘’ 2Mpix, with Sence-Up mode off.
To determine the approximate distance of the backlight for analog video cameras use a correction factor
of 2.5 - 3.0. a correction factor of 2.5 - 3.0.
!
!
!
Built-in light sensor automatically turns on the illuminator when the light intensity drops
to less than 3 Lux. To avoid tripping illuminator with occasional short-term increase in
ambient light, such as headlights of a passing car, provided the time interval delay turn off
the illuminator, equal to 25...35 sec.
LIGHT SENSOR
INSTALLATION AND CONNECTION
Illuminator can be installed outdoors and indoors. When installing, ensure free air
flow past casing to cool the illuminator.
The installation of illuminator should be made in the following order:
1. Assemble the bracket as shown in figure.
2. Mount the bracket on the wall.
3. Install the illuminator on the bracket, pre-slightly tighten the bracket screws.
4. Connect the illuminator to the power supply as follows:
4.1. Version of the illuminator with powered 12 ... 24 V AC / DC - plug the illuminator
to low voltage supply 12 ... 24 V AC or DC.
The polarity need not be obeyed.
4.2. Version of the illuminator with powered 185 ... 265 V AC - plug the illuminator
to the power supply 185 ... 265 V AC.
The polarity: brown wire - phase, blue wire - zero, yellow-green wire – ground.
INSTALLATION AND CONNECTION
The Illuminator should be stored indoors in the absence of aggressive environment
in the form of vapor and acids and alkalis. Ambient temperature from -50 °C to
+ 50 °C; relative humidity less than 95% at 25 °C.
RETENTION RULES
WARRANTY
The Manufacturer guarantees the absence of manufacturing defects and malfunctions of
Equipment.
The warranty period shall be counted from the date of purchase of Equipment and shall be 36
months.
During the warranty period, the Manufacturer will correct the defects in the Equipment
through its repair or replacement for a similar, provided that the defect has arisen through the
fault of the Manufacturer. Equipment offered to replace, can be both new and restored, but in
any case, the Manufacturer guarantees that its characteristics are not worse than replaced
Equipment.
Under no circumstances will the Manufacturer be liable for any damages, including loss of
data, loss of profits or other incidental, consequential or indirect damages caused by incorrect
installation, maintenance, operation or performance-related, failure or temporary Equipment
malfunction.
Manufacturer assumes no liability under the guarantee in the case that produced the testing
and/or analysis revealed that the alleged defect in the Equipment is missing or it has arisen as
a result of incorrect installation or operation conditions, as well as any actions associated with
attempts to make the Equipment perform functions that are not declared by the Manufacturer,
as well as attempts to change the technical characteristics of Equipment.
Warranty does not include cleaning and preventive maintenance of the Equipment by and at
the expense of the Manufacturer.
WARRANTY DOES NOT COVER:
The counterfeit devices, the offensive of force majeure (fire, natural disasters and others),
failures due to violations of the rules of transportation, storage, operation, or improper
installation, defects caused by repair or modification of the equipment by persons not authorized
by the Manufacturer, on the illuminators with external defects (obvious mechanical damage,
cracks, chips).
