Micromaxx MM 2854 Installation guide

20
Precautions to avoid possible exposure
to excessive microwave energy
(a) Do not attempt to operate this oven with the door open since this can result in harmful exposure
to microwave energy.It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or
cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven do-
or closes properly and that there is no damage to the:
(1) DOOR(dent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACE
(d) The oven should not be adjusted or repaired by anyone except properly qualified
service personnel.
Model:..........................................................................MM 2854
Power Source:.............................................................230V~50Hz
Power Consumption (Microwave):...............................1450 W
Power Consumption (Convection + grill): ....................2400 W (1200 W + 1200 W)
Maximum Output: ........................................................850W
Oven Capacity:............................................................25L
Turntable Diameter:.....................................................Ø 315mm
External Dimensions (LxWxH):....................................512 mm x 441 mm x 307 mm
Net weight:...................................................................17.0 Kg
Specifications
READ these instructions carefully before using your microwave oven
and keep it carefully for future
reference. If you follow these instructions, your oven will provide you
with many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
Manual GB 2854 28.04.2004 23:56 Uhr Seite 20

1. The oven must be on a leveled surface.
2. The turntable and turntable roller rest must be in the oven during cooking. Place the cookware gently on
the turntable and handle it carefully to avoid possible breakage.
3. Incorrect use of browning dish may cause the turntable to break.
4. Use only the specified bag size when using Direct Access Popcorn.
5. The oven has several built-in safety switches to ensure that the power remains off when the door is
open. Do not tamper with these switches.
6. Do not operate the microwave oven empty. Operating the oven with no food or food that is extremely
low in moisture can cause fire, charring or sparking.
7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable may cause the
turntable to break.
8. Do not heat baby bottles or baby food in the microwave oven. Uneven heating may occur and could
cause physical injury.
9. Do not heat narrow-necked containers, such as syrup bottles.
10. Do not attempt to deep-fry in your microwave oven.
11. Do not attempt home canning in this microwave oven as it is impossible to be sure all contents of the jar
have reached boiling temperature.
12. Do not use this microwave oven for commercial purpose. This microwave oven is made for household
use only.
13. To prevent delayed eruptive boiling of hot liquids and beverages or scalding yourself, stir liquid before
placing the container in the oven and again halfway through cooking time. Let stand in the oven for a
short time and stir again before removing the container.
14 . Please do notice the food in the microwave oven to avoid burning due to excessive cooking when
cooking food in it.
15. When the appliance is operated in the combination mode, children should only use the oven under adult
supervision due to the temperatures generated.
16. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could ad-
versely affect the life of the appliance and possibly result in a hazardous situation.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
1) WARNING: When the appliance is operated in the combination mode, children should only use the oven
under adult supervision due to the temperatures generated.
2) WARNING: If the door or door seals are damaged, the oven must not be operated until it has
been repaired by a competent person.
3) WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair
operation that involves the removal of a cover which gives protection against exposure to microwave
energy.
4)
WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.
5) WARNING: Only allow children to use the oven without supervision when adequate instructions have
been given so that the child is able to use the oven in a safe way and understands the
hazards of improper use.
6) The minimum height of free space necessary above the top surface of the oven.
7) Only use utensils that are suitable for use in microwave ovens.
8) When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
9) If smoke is observed, switch of or unplug the appliance and keep the door closed in order to stifle any
flames.
10) Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be
taken when handling the container.
11) The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature
checked before consumption, in order to avoid burns.
12) Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they
may explode, even after microwave heating has ended.
13) Details for cleaning door seals, cavities and adjacent parts.
14) The oven should be cleaned regularly and any food deposits removed.
15) Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could ad-
versely affect the life of the appliance and possibly result in a hazardous situation.
16) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
Safety instructions
21
GB
Manual GB 2854 28.04.2004 23:56 Uhr Seite 21

1. Read all instructions before using the appliance.
2. Read and follow the specific: " PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY".
3. As with most cooking appliances,close supervision is necessary to reduce the risk
of a fire in the oven cavity.
If a fire should start:
1. Keep the oven door closed
2. Turn the oven off, and unplug the appliance.
3. Disconnect the power at the fuse or circuit breaker panel.
Keep in mind the following rules at all times:
1. Do not overcook food. Carefully attend the appliance if paper,plastic,or other
combustible materials are placed inside the oven to facilitate cooking.
2. Do not use the oven cavity for storage purposes. Do not store combustible items
such as bread, cookies, paper products, etc. inside the oven. If lightning strikes the
power line, the oven may turn on by itself.
3. Remove wire twist-ties and metal handles from paper or plastic containers/bags
before placing them in the oven.
4. This oven must be grounded. Connect only to properly grounded outlet.
See "GROUNDING INSTRUCTIONS".
5.
Install or locate this oven only in accordance with the installation instructions provided.
6. Some products such as whole eggs, water with oil or fat, sealed containers and
closed glass jars may explode and therefore should not be heated in this oven.
7. Use this appliance only for its intended uses as described in the manual.
Do not use corrosive chemicals or vapors in this appliance. This oven is specifically
designed to heat or cook food. It is not designed for industrial or laboratory use.
8. As with any appliance, close supervision is necessary when used by children.
9. Do not operate this oven if it has a damaged cord or plug, if it is not working
properly or if it has been damaged or dropped.
10. This appliance should be serviced only by qualified service technicians. Contact
the nearest authorised service facility for examination,repair or adjustment.
11. Do not cover or block any vents on the oven.
12. Do not store or use this appliance outdoors.
13. Do not use this oven near water, near a kitchen sink, in a wet basement or near a
swimming pool.
14. Do not immerse cord or plug in water.
15. Keep cord away from heated surfaces.
16. Do not let cord hang over edge of
table or counter.
17. When cleaning door and oven surfaces use only mild, nonabrasive soaps or deter-
gents applied with a sponge or soft cloth.
SAVE THESE INSTRUCTIONS
Important safety instructions
22
WARNING: To reduce the risk of fire, electric shock, injury to persons, or exposure to
excessive microwave oven energy when using your appliance, follow these basic
precautions:
Manual GB 2854 28.04.2004 23:56 Uhr Seite 22

Grounding installation
Utensils
23
GB
DANGER: Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death.
Do not disassemble this appliance.
WARNING: Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an outlet
until appliance is properly installed and grounded.
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood or if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord
that has a 3-pronged grounding plug, and a 3-slot receptacle that will accept the plug
on the appliance.
1. A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
3. If a long cord set or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least
as great as the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord, and
3) The longer cord should be arranged so that it will not drape over the counter top
or tabletop where it can be pulled on by children or tripped over unintentionally.
CAUTION: Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be opened and plastic
pouches pierced before cooking.
See next page for further instructions “Materials you can use in microwave oven or to
be avoided in micro-wave oven“.
Manual GB 2854 28.04.2004 23:56 Uhr Seite 23

Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin
parts of meat or poultry to prevent overcooking. Arcing can occur
if foil is too close to oven walls. The foil should be at least 1 inch
(2.5cm) away from oven walls.
Browning dish Follow manufacturer’s instructions. The bottom of browning dish
must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions.
Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
Paper plates Use for short –term cooking/warming only. Do not leave oven
unatte and cups ned while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer’s instructions.
Should be labelled “Microwave Safe”. Some plastic containers
soften as the food inside gets hot. “Boiling bags” and tightly
closed plastic bags should be slit, pierced or vented as directed
by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Utensils Remarks
Aluminium tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with May cause arcing. Transfer food into microwave-safe metal
metal handle handle dish.
Metal or metal- Metal shields the food from microwave energy. Metal trim may
trimmed utensils cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood Wood will dry out when used in the microwave oven and may split
or crack.
Materials you can use in microwave oven
Materials to be avoided in microwave oven
24
Manual GB 2854 28.04.2004 23:56 Uhr Seite 24

Setting up your oven
Turntable installation
25
GB
Turntable ring assembly
Turntable shaft
Glass tray
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring assembly
must always be used during cooking.
c.
All food and containers of food should be
always placed on the glass tray for cooking.
d. The glass tray rotates clockwise; this is normal.
e. If glass tray or turntable ring assembly cracks
or breaks, contact your nearest authorised
service centre.
Shuts off oven power if door is opened during operation.
Caution: The grill grate may only be in the microwave oven
during grilling operation, but not during microwave operation!
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
H) Grill rack
F
G
ED CB
A
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
H
Manual GB 2854 28.04.2004 23:56 Uhr Seite 25

A minimum clearance of 3.0 inch (7.5cm) is required between the oven and any
adjacent wall. One side must be open.
(1) Leave a minimum clearance of 12 inch(30cm) above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV as possible.
Operation of icrowave oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the
frequency is the same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing appliance.
If installed could be damaged and the warranty would be void.
Remove all packing material and accessories. Examine the oven for any damage such
as dents or broken door. Do not install if oven is damaged.
Countertop
Cabinet: Remove any protective film found on the cabinet surface.
WARNING: Do not remove the light brown Mica cover that is screwed to the oven
cavity to protect the magnetron.
Installation
1. Select a level surface that provide enough open space for the intake and/or outlet
vents.
Installation
26
3.0 inch (7.5 cm)
12 inch (30 cm)
3.0 inch (7.5 cm)
Manual GB 2854 28.04.2004 23:56 Uhr Seite 26

Operation
27
GB
0:00
Operation and Function
1. Clock Setting:
Plug in the oven, "0:00" will be shown and a "beep" will be heard.
(1) Press "Clock/Pre-Set" , "0"'s in the hour position will flash;
(2) Turn the digital knob to set the hour within the range from 0 to 23;
(3) Press "Clock/Pre-Set" and the "0"'s in the minute position will flash;
(4) Turn the digital knob to set the minutes within the range from 0 to 59;
(5)
Press "Clock/Pre-Set" to complete clock setting, " : " will flash denoting that the setting is ok.
Note: The clock is 24 hours a cycle. The clock will only show 0:00 and will not march
forward if no clock setting is made.To cancel the clock setting during the setting process,
press "Stop/Cancel".
2. Program Setting in Advance (When clock is well set):
Input the cooking program. The program can be set as three stages the most.
(1) Press "Clock/Pre-Set" , the numbers in the hour position will flash.
(2) Turn the digital knob to preset the hour between 0 and 23.
(3) Press "Clock/Pre-Set" , the numbers in the minute position will flash.
(4) Turn the digital knob to preset the minute between 0 and 59.
(5) Input the cooking program;the program can be set multiple stages with three stages the most.
(Defrost can not be set as one of the stages)
(6) Press "Start/Express/Ok" to stop the program setting in advance. When the preset time
reaches,if the door is well closed, there will be one "beep" and the cooking will begin. If the
dooris not well closed, there will be no cooking even when the time arrives and there will be
one "beep" and the preset program will be cancelled.
3. Cooking by Microwave
(1) Press "Microwave" ,"P100" will be flashing,and " " will be lighted;
(2) Turn the digital knob to choose the microwave power level wanted;
(3) Press "Start/Express/Ok" to confirm;
(4) Turn the digital knob to choose the cooking time; (maximun time is 95 minutes)
(5) Press "Start/Express/Ok" to start cooking. (" " for microwave will be flashing)
Manual GB 2854 28.04.2004 23:56 Uhr Seite 27

Power display (There are 10 levels for microwave power):
Power level 100% 90% 80% 70% 60%
Display
P100 P90 P80 P70 P60
Button Press Function Display Micro power Grill power
Once Grill G-1 33/33
Twice Combi. 1 G-2 12/33 21/33
Three times Combi. 2 G-3 18/33 15/33
Power level 50% 40% 30% 20% 10%
Display
P50 P40 P30 P20 P10
4. Grill & Mic.+Grill Combination
(1) Press "Grill/Mic.+Grill" ,"G-1" will be flashing and " " will be lighted;
(2) Turn the digital knob to choose Grill or the combination choose wanted;
(3) Press "Start/Express/Ok" to confirm;
(4) Turn the digital knob to choose the cooking time wanted; (95 minutes the most);
(5) Press "Start/Express/Ok" to start cooking; and " " will be flashing. (The icon of " "
will be flashing in combined cooking)
Grill is working with 100% power.The combination of grill with microwave refers to the
alternative function of microwave and grill. One cycle is 33 Second.
Note: During grill cooking without other function combined,only the element and the fan will be
working. The "beep" will sound twice when half time is passed to remind of turning over the food.
And the cooking will be continued if there is no such operation after 1 minute.
Note: There is no need to set time for pre-heating, just directly press "Start/Express/Ok";
If the set temperature cannot be reached winthin 30 minutes,the element will stop working and
"E-3" will be displayed reminding the error.
5. Conv.&Mic.+Conv. combination
(1) Press "Conv.&Mic.+Conv.","140" will be flashing; " " " " " " will be lighted;
(2) Turn the digital knob to choose the temperature for convection and power for combination
wanted;
(3) Press "Start/Express/Ok" to confirm;
(4) Turn the digital knob to choose the cooking time needed; (95 mintue the most)
(5) Press "Start/Express/Ok" to start cooking; " " " " will be flashing;
(" " will also be flashing in combined cooking)
Operation
28
Manual GB 2854 28.04.2004 23:56 Uhr Seite 28

Operation
29
GB
There are ten temperature grades for convention; 140° C *150° C *160° C *170° C*180° C *
190° C *200° C*210° C *220° C *230° C.
Note: Controlling system for cooking with convection only:
When the temperature is between 140° C - 190° C: The motor for convection is working
during the whole process. At the early stage, the convection element will be working in a cycle
of being on for 15 seconds, then being off for 15 seconds; the element for grill will be on all
the time. When the temperature inside the cavity at the center point is -20° C, the element for
grill will stop working (and no working since then); the element for convection will be working
all the time. When the temperature inside the cavity at the center point reaches the set tempe-
rature, the element for convection will be off and be on again until the temperature inside the
cavity reaches -1° C .
When the temperature is between 200° C - 230° C: The motor for convection is working
during the whole process. At the early stage, the element for convection will be working in a
cycle of being on for 22 seconds, then being off for 8 seconds; the element for grill will be on
all the time. When the temperature inside the cavity at the center point is -5 0 C, the element
for grill will stop working (and no working since then) ; the element for convection will be
working all the time. When the temperature inside the cavity at the center point reaches the
set temperature, the element for convection will be off and be on again until the temperature
inside the cavity reaches -1° C.
The combined cooking of convection and microwave:
There are four levels for combined cooking: C-1(170° C) , C-2(180° C), C-3 (190° C),
C-4(200° C), a cycle is 33 seconds.
Combined cooking C-1 (170°C) C-2 (180°C) C-3 (190°C) C-4 (200°C)
Time for
microwave 20” 17” 13” 9”
Time for
convection 13” 16” 20” 24”
A cycle of cooking 33” 33” 33” 33”
6. Auto Defrost
(1) Press "Defrost" , "100" will be displayed," " " " " AUTO " " " will be lighted.
(2) Turn the digital knob to choose the weight to be defrosted.
(3) Press "Start/Express/Ok" to start defrosting. " " " AUTO " " "will be flashing;
and the defrosting will the started.
Manual GB 2854 28.04.2004 23:56 Uhr Seite 29

7. Multi-Stage Cooking
Two stage cooking can be set at most. Defrost should always be set as the first stage if it is
included in a multi-stage cooking. "Auto Menu" cannot be set as a stage in a multi-stage
cooking.
8. Speedy Cooking
When the oven is standing by, press "Start/Express/Ok" to start cooking for one minute at the
100% power, " " will be flashing. During the cooking, each press on "Start/Express/Ok"
will increase the cooking time by one minute.
9. Auto Menu
(1) Press "Auto Menu" , " Auto" " " will be lighted and "A-1" will be flashing.
(2) Turn the digital knob to choose the menu. The menu will come out at the following sequence:
Potato --> Rice cook --> Vegetables --> Chicken --> Meat --> Reheat Bread -->
Instant Noodles --> Congee Porridge and the corresponding code from "A-1" to "A-8" will be
displayed.
(3) Press "Start/Express/Ok" to confirm the menu selected; ("A-1" to "A-8" will be lighted)
(4) Turn the digital knob to choose the weight.
(5) Press "Start/Express/Ok" to start cooking. " " will be flashing.
10. Children Lock-out Function
(1) Lock: In the standing by status, press "Stop/Cancel" for 3 seconds, a long "beep" will be
heard denoting entering into the children lock-out status. " " will be lighted.
(2) Unlock: In the children lock-out status, press "Stop/Cancel" for 3 seconds, there will be a
long "beep" denoting that the lock is released," " will disappear.
11. Inquiring Function
(1) Check the microwave power level: When during the microwave cooking process, press
“Microwave” to see the power level which will be displayed for 3 seconds.
(2) Check the convection temperature and the way of combination: When during the convection
or the combined cooking between convection and microwave, press “Conv/Mic.+Conv”
to see the convection temperature or the way for combination which will be displayed for
3 seconds.
(3) Check the way of combination between grill and microwave: When during the process of the
combined cooking, press “Grill/Mic.+Grill” to see the way of combination between grill
and microwave which will be displayed for 3 seconds.
(4) Check the Auto-menu: When during the cooking of the program from Auto Menu, press
“AUTO MENU” to see the current menu which will be displayed for 3 seconds.
Operation
30
Manual GB 2854 28.04.2004 23:56 Uhr Seite 30

Operation
31
GB
12. Special Notes:
(1). When cooking under “microwave”.”grill”.”convection” “microwave and grill combination”,
“microwave and convection combination”, the longest cooking time can be 95 minutes.
(2). When cooking under “grill”, there will be two beeper when the cooking time is half passed to
remind of turning over the food. And the cooking will be continued if there is no such action
within 1 minute.
13. Protecting Function:
(1). Protection when the thermo sensor is open circuit or short circuit: When the thermo sensor is
of open circuit, the appliance will stop working and “E-1” will be displayed while all indicators
for temperature will be flashing. When the thermo sensor is of short circuit, “E-2” will be
displayed and all indicators for temperature will be flashing.
(2). Protection when the temperature inside the cavity is too high: During the cooking process,
when the temperature at the center point of the cavity is over 250° C, the cooking will be
stopped and the fan will be started working; when the temperature at the center point is lower
than 220° C, the cooking will be continued until the cooking time set is completed.
During the convection process, when the preheating time has been over 30 minutes, but the
temperature still has not reached the temperature set, the appliance will stop working and “E-3”
will be displayed.
14. Extended Fan Function for Protection
When the microwave cooking time is equal to or over 5 minutes, at the last 15 seconds,
microwave will be stopped and only fan will be working.
SPECIAL NOTE:
1. The power will be switched to mid-low if a cooking with high power level has been continued
for over 30 minutes to protect the magnetron.
2. There will be one "beep" when thedigital knob is turned.
3. There will be 4 "beep" when a cooking program ends;
4. If the door is opened during a cooking, "Start/Ok" should be pressed to continue the paused
cooking.
5. An effective operation will be confirmed by a "beep". There will be no "beep" if the order is
invalid.
Manual GB 2854 28.04.2004 23:56 Uhr Seite 31

AUTO MENU
A-1 Potato
A-2 Rice cook
A-3 Vegetables
A-4 Chicken
A-5 Meat
A-6 Reheat Bread
A-7 Instant Noodles
A-8 Congee Porridge
WEIGHT(g)
200
400
600
50
100
150
200
250
100
200
300
400
500
600
400
600
800
1000
1200
1500
100
200
300
400
500
750
50
100
150
200
1
2
1
2
TIME
5’30
7’00
9’00
14’12”
17’42”
18’30”
19’42”
22’00”
2’00”
2’45”
3’30”
4’45”
5’00”
6’00”
23’30”
26’30”
30’48”
34’28”
36’40”
43’05”
3’00”
5’00”
7’00”
9’00”
12’00”
14’00”
0’16”
0’28”
0’38”
0’55”
4’24”
7’42”
8’00”
10’00”
Auto Menu
32
Manual GB 2854 28.04.2004 23:56 Uhr Seite 32

Trouble shooting
33
GB
This appliance conforms with CE directives for radio interference suppression and low-voltage
safety and has been built to meet current safety requirements. Subject to technical changes
without prior notice.
Trouble possible cause remedy
(1) Power cord not plugged in tightly. Unplug. Then plug again after
10 seconds.
Oven can not (2) Fuse blowing or circuit breaker Replace fuse or reset circuit breaker
be started works.
(repaired by professional personnel
of our company)
(3) Trouble with outlet. Test outlet with other electrical
appliances.
Oven does (4) Door not closed well. Close door well.
not heat
Glass turntable (5) Dirty roller rest at oven bottom
Refer to "Maintenance of Microwave"
makes noise to clean dirty parts.
when microwave
oven operates
Normal
Radio and TV reception may be interfered when microwave
Microwave oven interfering oven is operation. It is similar to the interference of small
TV reception electrical appliances, like mixer, vacuum cleaner,and
electric fan. It is normal.
Dim oven light In low power microwave cooking, oven light may
become dim. It is normal.
Steam accumulating on In cooking , steam may come out of food . Most will
door, hot air out of vents come out from vents . But some may accumulate
on cool place like oven door. It is normal.
Oven started accidentally It does no damage to oven if it operates empty for
with no food in. quite short time. But it should be avoided.
Manual GB 2854 28.04.2004 23:56 Uhr Seite 33

Notes
34
1. Before commissioning this oven please read this instruction manual and keep it
carefully.
2. There must be more than 30 cm high space necessary above the top surface of
oven.
3. Do not repair the oven yourself, please consult an authorized expert.
4. The contents of feeding bottles and baby food jars are to be stirred or shaken and
the temperature is to be checked before consumption, in order to avoid burns.
5. Check the oven and the cable regularly for damage. If there is any kind of damage,
the oven should not be used.
WARNING:
1. It is hazardous for anyone other than a trained person to carry out any service or
repair operation, which involves the removal of any cover which gives protection
against exposure to microwave energy.
2. Only allow children to use the oven without supervision when adequate instructions
have been given so that the children is able to use the oven in a safe way and
understands the hazards of improper use.
3. If the suply cord is damaged, it must be replaced by the manufacture or its service
agent or a similarly qualified person in order to avoid a hazard.
• Do not attempt to operate this oven with the door open since open-door operation
can result in harmful exposure to microwave energy. It is important not to defeat or
tamper with the safety interlocks.
• Carefully clean door seala and sealing surfaces
• Do not operate the oven if it is damaged. It is particularly important that the oven door
is closed properly and that there is no damage at the:
1) door(bent),
2) hinges and latches (broken or loosened),
3) door seals and sealing surfaces.
• Utensils should be checked to ensure that they are suitable for use in microwave
ovens.
• When heating food in plastic or paper containers, check the oven frequently due to
the possibility of ignition.
• Microwave heating of beverages can result in delayed eruptive boiling, therefore care
has to be taken when handling the container.
• If smoke is observed, switch off or unplug the appliance and deep the door closed in
order to stifle any flames.
• Eggs in their shell and whole hard-boiled eggs shall not be heated in microwave
ovens since they may explode.
• If the door or door seals are damaged, the oven must not be operated until it has be-
en repaired by a trained person.
• Liquids or other foods must not be heated in sealed containers since they are liable
to explode.
Manual GB 2854 28.04.2004 23:56 Uhr Seite 34
