MicroVision PSE-0400li3 User manual
QUICK START GUIDE
PSE-0400li3
Consumer LiDAR
Explorer Edition
SAFETY INFORMATION, CLASS 1 LASER PRODUCT
This Explorer Edition is a Class 1 Laser Product as defined in
IEC60825-1:2014 (Edition 3). This device also complies with
the US FDA 21 CFR 1040.10 and 1040.11 except
for deviations pursuant to Laser Notice
No. 50 dated June 24, 2007.
CAUTIONS & WARNINGS
All users of the Explorer Edition must read this safety information before
operating the unit.
Warnings regarding use and care
of the Explorer Edition:
Use of external optics or controls, adjustments of performance other than
those specified in this Quick Start Guide or User Guide may result in hazardous
laser radiation exposure
SERVICE & MAINTENANCE
THERE ARE NO OPERATOR SERVICEABLE
PARTS INSIDE THE EXPLORER EDITION
For preventative maintenance or repair of performance-related issues, the
system must be returned to MicroVision. See the Warranty accompanying in
this Quick Start Guide for contact information to initiate a return.
• Do not remove label from the assembled Explorer Edition module
• Do not separate the electronics module from the photonics module
The electronics module and the photonics module have been calibrated
together. Swapping the electronics module and photonics module between
Explorer Editions may damage the MEMS mirror and will invalidate the laser
product classification certification for the module and will invalidate any
warranties that may apply.
PSE-0400li3
CONSUMER LIDAR EXPLORER EDITION
The Consumer LiDAR Explorer Edition is a prototype produced by
MicroVision to facilitate the development of potential applications using
MicroVision’s Consumer LiDAR technology.
The Explorer Edition, sometimes referred to as the Engine, is not designed
for standalone operation. The Engine must be mated to a host board* that
delivers the required power and control signals and also receives the
streaming depth map of the field-of-view (FOV) as measured by the Engine.
The form factor of the Engine can allow exploration of target industrial
designs of the final application.
* The MicroVision Consumer LiDAR Starter Kit (sold separately) can
serve this function and facilitate ease of visualizing the streaming
depth data and enable off-device application development.
Please contact MicroVision Customer Service by e-mail
IN THE BOX
• Consumer LiDAR - Explorer Edition
• Quick Start Guide (this booklet)
DATASHEET AND SOFTWARE
Please contact MicroVision Customer Service by e-mail at
Visit https://github.com/MicroVision-Inc/Consumer-LiDAR/ for product brief,
interface specifications and Software Development Kit.
Consult the bar code label on the box for your specific model.
SERVICE AND SUPPORT
For questions and support please contact MicroVision Customer Service by
e-mail at customerservice@microvision.com.
Engineering and development support are not included with the purchase of
the PSE-0400li3. For expanded support services beyond basic
troubleshooting, please contact your MicroVision sales representative.
NOTICE AND LIMITED WARRANTY
EXPLORER EDITION IMPORTANT NOTICE
The enclosed Explorer Edition is a“Prototype”intended for use for ENGINEERING
DEVELOPMENT OR EVALUATION PURPOSES ONLY and is not considered by
MicroVision, Inc., to be fit for commercial use. As a Prototype, this device may
not meet the technical requirements of the European Union directive on
electromagnetic compatibility.
The user assumes all responsibility and liability for proper and safe handling
of the unit. Also be aware that the enclosed unit may not be regulatory
compliant or agency certified (such as FCC, UL, CE, etc.) with the exception
of IEC 60825-1 Laser Safety. MicroVision assumes no liability for application
assistance, customer’s product design, or software performance.
Subject to the terms of the MicroVision End User License Agreement found
in the downloadable User Guide at http://github.com/microvision-inc. MicroVision
grants Customer a limited, non-transferable, non-exclusive license to use
MicroVision software and firmware in connection with the use of the Prototypes.
MicroVision is not selling any MicroVision software or firmware to Customer.
Customer is not licensed to use MicroVision software or firmware in connection
withanyotherapplicationorforany purposeotherthanevaluationofthePrototype.
Contact Information. If you have any questions, please contact MicroVision
LimitedWarranty. MicroVision warrantsthat thePrototype willbe freeof defects
in material and workmanship for ninety (90) days from the delivery date.
MicroVision will at its option, repair or replace the Prototype or refund the
purchase price paid by Customer for the defective Prototype. The repaired or
replaced parts or Prototype may include new, reconditioned or re-manufactured
parts and equipment at MicroVision’s option. Such repair, replacement or
refund shall be the sole remedy of Customer in the event of MicroVision’s
breach of this limited warranty. All costs associated with shipment to
MicroVision for warranty service, including but not limited to freight,
duties, insurance and customs fees are Customer’s responsibility. MicroVision
will pay the freight costs associated with the return shipment to Customer.
Duties, insurance, customs and any other fee are Customer’s responsibility.
The method of shipment will be at MicroVision’s discretion. Repair or
replacement of any parts or equipment does not extend the period of warranty.
If a component MicroVision bought from a third party fails and the component
is still covered by a warranty from a third party, MicroVision will take
reasonable action to pass that warranty on to customer. THIS LIMITED
WARRANTY IS MICROVISION’S ONLY WARRANTY. MICROVISION
EXPLICITLY DISCLAIMS ANY AND ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE WARRANTIES
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE,
AND INFRINGEMENT.
The warranty considerations by MicroVision set-forth above do not cover,
and MicroVision will have no obligations hereunder if any non-conformance
is caused in whole or in part by (a) accident, transportation, neglect, misuse,
exposure to extreme temperatures or excessive dust or moisture, alteration,
modification or enhancement of the Prototype(s), (b) incorporation, interfacing,
attachment of any feature, program, or device to the Prototype(s) by a person
or entity other than MicroVision, (c) use of the Prototype(s) for other than the
specific purpose for which the Prototype(s) are designed or (d) any use of the
Prototype(s) not in accordance with a guide or user manual. MicroVision does
not warrant that the Prototype or associated software will run error free or
without interruptions or will operate with third party applications. MicroVision is
not liable for loss of data or down time. MicroVision is not responsible for resolving
software issues caused by Customer Components or third party software.
LIMITATION OF LIABILLITY. IN NO EVENT WILL MICROVISION BE LIABLE
TO CUSTOMER FOR ANY LOST PROFITS, LOST OPPORTUNITIES,
OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES,
REGARDLESS OF THE FORM OF ACTION, BASIS OF THAT CLAIM, OR
THE THEORY UNDER WHICH THE CLAIM IS PRESENTED, EVEN IF THAT
PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
IN NO EVENT WILL MICROVISION BE LIABLE TO CUSTOMER
FOR ANY DAMAGE OR LOSS IN EXCESS OF THE TOTAL PURCHASE
PRICE PAID FOR THE PROTOTYPE(S). IN NO EVENT WILL MICROVISION
BE LIABLE FOR ANY CLAIM AGAINST IT BY ANY THIRD PARTY.
