DMX4ALL DMX-Relais 2 INRUSH User manual

DMX-RELAIS 2 INRUSH
User manual

DMX-RELAIS 2 INRUSH 2
For your own safety, please read this user manual and warnings carefully
before installation.
Contents
Description.................................................................................................................. 3
Data sheet .................................................................................................................. 4
Max. DC load.............................................................................................................. 4
Connection ................................................................................................................. 5
LED-Display-Codes .................................................................................................... 5
DMX-FAIL Function .................................................................................................... 7
Select operating mode................................................................................................ 8
RDM ......................................................................................................................... 11
Factory Reset ........................................................................................................... 13
Dimensions............................................................................................................... 14
CE-Conformity .......................................................................................................... 16
Disposal.................................................................................................................... 16
Risk-Notes ................................................................................................................ 17

DMX-RELAIS 2 INRUSH 3
Description
The DMX-RELAIS 2 INRUSH is designed for several control tasks.
Two potential free switching outputs
2 potential free switching outputs (closer / NO) up to 8A switching capacity are
available.
Switching contact for direct and alternating voltage
The INRUSH version is suitable to direct voltage (DC) or alternating voltage (AC).
For voltages from 12V up to 24V
The DMX-Relais 2 INRUSH works with supply voltages from 12V up to 24V DC.
DMX FAIL-Function
An adjustable DMX FAIL function offers the option to hold the current state (HOLD)
or to adopt a predefined value if the DMX signal fails.
RDM support
The DMX-Relais 2 INRUSH allows the configuration via RDM or DMX.
Several operating modes
The DMX-Relais 2 INRUSH offers several operating modes which can be set via
jumper or RDM:
- Hysteresis 127/128
- Hysteresis 0/1
- Hysteresis 100/150
- Exclusive
- Monostable 1Second
- FogControl
Top hat rail mounting available
Suitable for the DMX-Relais 2 INRUSH the DIN rail housing 700 is available as
accessory.

DMX-RELAIS 2 INRUSH 4
Data sheet
Power supply: 12-24V DC
(150mA@12V / 100mA@24V)
Protocol: DMX512
RDM
DMX-Channels: 1 or 2 channels (depend on operation mode)
DMX-FAIL: HOLD / 0-100%
Operation modes: Hysteresis 127/128
Hysteresis 0/1
Hysteresis 100/150
Exclusive
Monostable 1Second
FogControl
Output: 2 potential free switching contacts NO
165A@20ms peak switch-on current
AC: each max. 8A / 250V~
DC: According to the max. DC load graph
Connection: Screw terminals
Dimensions: 64,2mm x 82mm
Max. DC load
The maximum current the switch contacts of the DMX RELAIS 2 INRUSH can switch
is shown in the following graph depending on the switching voltage:
(Source: Data sheet RTS3T012)

DMX-RELAIS 2 INRUSH 5
Connection
Switch contact
AC: each max. 8A / 250V~
DC: According to the max. DC load graph
(165A@20ms peak switch-on current)

DMX-RELAIS 2 INRUSH 6
LED-Display-Codes
The integrated LED is a multi-functional display.
During the normal operation the LED lights continuously. In this case the device is
working.
Furthermore, the LED shows the current status. In this case the LED lights up in
short pitches and then is missing for longer time.
The number of the flashing lights is equal to the status number:
Event-
number Error Description
1 No DMX There is no DMX-input signal
2 Addressingerror Please check the adjusted DMX-Address
3 DMX-Signal error An invalid DMX-input-signal is detected
Addressing
The starting address is adjustable via the DIP switches.
Thereby switch 1 has the valency 2
0
(=1), switch 2 valency 2
1
(=2) and so on, until
switch 9 has the valency 2
8
(=256).
The sum of the values of the switches set to ON corresponds to the start address.
Adresse Schalter Adresse Schalter
1 ... ...
2 508
3 509
4 510
5 511

DMX-RELAIS 2 INRUSH 7
DMX-FAIL Function
The DMX-RELAIS 2 INRUSH has a DMX-FAIL Function which stores the last value
in the case of a DMX signal loss (HOLD) or left the relays unchanged with a
predefined value in its conditions.
The DMX-HOLD function can be activated via RDM or by switch 10.
Switch 10 ON DMX-HOLD active
Switch10 OFF DMX-HOLD not active
If HOLD is switched on (switch 10 = ON), the last received DMX values are remained
in case of a DMX signal failure.
If HOLD is switched off (switch 10 = OFF), the DMX values are replaced with a value
set by RDM in case of a DMX signal failure. In the delivery state this value is 0, so
that the relays switch off.
In case of a power failure the DMX values held with HOLD are discarded!
A value set by RDM is deleted when HOLD is selected. After switching off the
HOLD function, the default value 0 is used.

DMX-RELAIS 2 INRUSH 8
Select operating mode
Hysteresis 127/128
In this operating mode, both relays switch independently of each other each via one
DMX channel. The switching threshold (Hysteresis) is 127/128 which means that the
relay is switched off when the DMX value is 127 or less and that the relay is switched
on when the DMX value is 128 or greater.
DMX
Channel
DMX
Value Function
1
0-127 Output 1 OFF
128-255 Output 1 ON
2
0-127 Output 2 OFF
128-255 Output 2 ON
For this operation mode choose via RDM the Personality 1 or open all MODE jumper
1-5:
Hysteresis 0/1
In this operating mode, both relays switch independently of each other each via one
DMX channel. The switching threshold (Hysteresis) is 0/1 which means that the relay
is switched off when the DMX value is 0 and that the relay is switched on when the
DMX value is 1 or greater.
DMX
Channel
DMX
Value Function
1
0 Output 1 OFF
1-255 Output 1 ON
2
0 Output 2 OFF
1-255 Output 2 ON
For this operation mode choose via RDM the Personality 2 or close only MODE
jumper 5:

DMX-RELAIS 2 INRUSH 9
Hysteresis 100/150
In this operating mode, both relays switch independently of each other each via one
DMX channel. The Hysteresis is 100/150 which means that the relay is switched off
when the DMX value is 100 or less and that the relay is switched on when the DMX
value is 150 or greater.
DMX
Channel
DMX
Value Function
1
0-100 Output 1 OFF
101-149 Output 1 doesn’tchange
150-255 Output 1 ON
2
0-100 Output 2 OFF
101-149 Output 2 doesn’tchange
150-255 Output 2 ON
For this operation mode choose via RDM Personality 3.
Exclusive (Jalousie-Control)
In this operation mode both relays are turned on with one DMX channel as soon as
the DMX value is 128 or higher.
However, not both relays can be switched on at the same time.
DMX
Channel
DMX
Value Function
1
0-127 Output 1 OFF
128-255 Output 1 ON, ifoutput 2 OFF
2
0-127 Output 2 OFF
128-255 Output 2 ON, ifoutput 1 OFF
For this operation mode choose via RDM the Personality 4 or close only MODE
jumper 2:

DMX-RELAIS 2 INRUSH 10
Monostable 1Second (Impulse)
In this operating mode, both relays switch independently of each other each via one
DMX channel.As soon as the DMX value is 128 or higher the relay switches for 1
second. Then the DMX value must fall below 128 to trigger again a switching
impulse.
DMX
Channel
DMX
Value Funktion
1
0-127 Output 1 OFF
128-255 Output 1 1x 1-Second ON
2
0-127 Output 2 OFF
128-255 Output 2 1x 1- Second ON
For this operation mode choose via RDM the Personality 5 or close only MODE
jumper 4:
FogControl
In this operation mode both relays are controlled via one DMX channel.
Therefore, output 1 is for the heating element and output 2 for the pump. An internal
timer allows an automatically fog output.
For this operation mode choose via RDM the Personality 6 or close only MODE
jumper 1:
DMX
Channel
DMX
Value Function
1
0-7 Device off aus
8-20 Device on, no fog emission
21-40 Timer 10s on / 300s off *
41-60 Timer 20s on / 350s off *
61-80 Timer 30s on / 200s off *
81-100 Timer 40s on / 150s off *
101-120 Timer 50s on / 100s off *
121-140 Timer 60s on / 75s off *
141-160 Timer 70s on / 50s off *
161-180 Timer 80s on / 40s off *
181-200 Timer 90s on / 30s off *
201-220 Timer 100s on / 20s off *
221-240 Timer 110s on / 10s off *
141-255 Permanent fogemission

DMX-RELAIS 2 INRUSH 11
RDM
(from hardware V1.1)
RDM is the short form for Remote Device Management.
As soon as the device is within the system, device-dependent settings can occur
remotely via RDM command due to the uniquely assigned UID. A direct access to the
device is not necessary.
If the DMX start address is set via RDM, all address switches at the DMX-
Relais 2 INRUSH must be set to OFF ! A DMX start address set by the
address switches is always prior !
This device supports the following RDM commands:
Parameter ID
Discovery
Command
SET
Command
GET
Command
ANSI/
PID
DISC_UNIQUE_BRANCH

E1.20
DISC_MUTE

E1.20
DISC_UN_MUTE

E1.20
DEVICE_INFO

E1.20
SUPPORTED_PARAMETERS

E1.20
PARAMETER_DESCRIPTION

E1.20
SOFTWARE_VERSION_LABEL

E1.20
DMX_START_ADDRESS

E1.20
DEVICE_LABEL

E1.20
MANUFACTURER_LABEL

E1.20
DEVICE_MODEL_DESCRIPTION

E1.20
IDENTIFY_DEVICE

E1.20
FACTORY_DEFAULTS

E1.20
DMX_PERSONALITY

E1.20
DMX_PERSONALITY_DESCRIPTION

E1.20
DISPLAY_LEVEL

E1.20
DMX_FAIL_MODE

E1.37

DMX-RELAIS 2 INRUSH 12
Parameter ID
Discovery
Command
SET
Command
GET
Command
ANSI/
PID
SERIAL_NUMBER
1)

PID:
0xD400
IDENTIFY_MODE1)

PID:
0xD402
1) Manufacturer depending RDM control commands (MSC - Manufacturer Specific Type)
Manufacturer depending RDM control commands :
SERIAL_NUMBER
PID: 0xD400
Outputs a text description (ASCII-Text) of the device serial number.
GET Send: PDL=0
Receive: PDL=21 (21 Byte ASCII-Text)
IDENTIFY_MODE
PID: 0xD402
Stellt den Mode ein der mit IDENTIFY_DEVICE ausgeführt wird.
GET Send: PDL=0
Receive: PDL=1 (1 Byte IDENTIFY_MODE_ID)
SET Send: PDL=1 (1 Byte IDENTIFY_MODE_ID)
Receive: PDL=0
IDENTIFY_MODE_ID
Funktion
0 FULL Identify
All relays switch ON / OFF simultaneously
and the status LED flashes
1 LOUD Identify
The relays switch ON / OFF one after the
other and the status LED flashes
2 QUIET Identify
The relays do not switch, only the status
LED flashes

DMX-RELAIS 2 INRUSH 13
Factory Reset
Before running the Factory Reset, read all steps carefully.
To reset the DMX-RELAIS 2 INRUSH to delivery state, proceed as follows:
-Turn off device (turn off power supply !)
-Set DIP switch 1 up to 10 to ON
-Turn on the device (turn on power supply)
-The LED lights up 20x during ca. 3 seconds
While the LED lights up set DIP switch 10 to OFF
-Now, the Factory Reset is executed
The LED lights up with 4 short light pulses
-Turn off the device (turn off power supply !)
-Now, the device can be used
If a Factory Reset is needed again, this procedure can be repeated at any
time.

DMX-RELAIS 2 INRUSH 14
Dimensions
All details in mm

DMX-RELAIS 2 INRUSH 15
Accessory
Top-hat railhousing700
Power supply 12V

DMX-RELAIS 2 INRUSH 16
CE-Conformity
This assembly (board) is controlled by a microprocessor and
uses high frequency. In order to maintain the properties of
the module with regard to CE conformity, installation into a
closed metal housing in accordance with the EMC directive
2014/30/EU is necessary.
Disposal
Electronical and electronic products must not be disposed in
domestic waste. Dispose the product at the end of its service
life in accordance with applicable legal regulations.
Information on this can be obtained from your local waste
disposal company.
Warning
This device is no toy. Keep out of the reach of children.
Parents are liable for consequential damages caused by
nonobservance for their children.

DMX-RELAIS 2 INRUSH 17
Risk-Notes
You purchased a technical product. Conformable to the best
available technology the following risks should not excluded:
Failure risk:
The device can drop out partially or completely at any time without warning. To
reduce the probability of a failure a redundant system structure is necessary.
Initiation risk:
For the installation of the board, the board must be connected and adjusted to
foreign components according to the device paperwork. This work can only be
done by qualified personnel, which read the full device paperwork and understand
it.
Operating risk:
The Change or the operation under special conditions of the installed
systems/components could as well as hidden defects cause to breakdown within
the running time.
Misusage risk:
Any nonstandard use could cause incalculable risks and is not allowed.
Warning: It is not allowed to use the device in an operation, where the safety of
persons depend on this device.

DMX4ALL GmbH
Reiterweg 2A
D-44869 Bochum
Germany
Last changes: 30.06.2022
© Copyright DMX4ALL GmbH
All rights reserve. No part of this manual may be reproduced in any form (photocopy, pressure, microfilm or in another
procedure) without written permission or processed, multiplied or spread using electronic systems.
All information contained in this manual was arranged with largest care and after best knowledge. Nevertheless, errors are to
be excluded not completely. It is pointed out that neither a guarantee nor the legal responsibility or any liability for
consequences which are due to incorrect information is assumed. This document does not contain assured characteristics. The
guidance and the features may be changed at any time and without previous announcement
