Midea MMC07S1AWW User manual

Microwave Oven
INSTRUCTION MANUAL
EN
Read these instructions
carefully before using your
microwave oven, and keep
it carefully.
If you follow the instructions,
your oven will provide you
with many years of good
service.
MMC07S1AWW
MMC07S1ABB
120V~60Hz, 1050W
Oven Capacity: 20Liter
Input

EN-2
01
(a) Do not attempt to operate this oven with the door
open since open door operation can result in harmful
exposure to microwave energy. It is important not to
defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front
face and the door or allows soil or cleaner residue to
accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is
particular important that the oven door close
properly and that there is no damage to the:
(1) DOOR (bent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACES
(d) The oven should not be adjusted or repaired by
anyone except properly qualified service personnel.
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY

EN-3
02
When using electrical appliances basic safety
precautions should be followed, including the following:
WARNING - To reduce the risk of burns, electric
shock, fire, injury to persons or exposure to excessive
microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific: "PRECAUTIONS
TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY " found on page 2.
3. This appliance must be grounded. Connect only
to properly grounded outlet. See "GROUNDING
INSTRUCTIONS" found on page 6 .
4. Install or locate this appliance only in accordance
with the provided installation instructions.
5. Some products such as whole eggs and sealed
containers - for example, closed glass jars - are able
to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as
described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specifically designed to heat, cook or dry
food. It is not designed for industrial or laboratory
use.
7. As with any appliance, close supervision is necessary
when used by children.
8. Do not operate this appliance if it has a damaged
IMPORTANT SAFETY
INSTRUCTIONS

EN-4
cord or plug, if it is not working properly, or if it has
been damaged or dropped.
9. This appliance should be serviced only by qualified
service personnel. Contact nearest authorized
service facility for examination, repair, or
adjustment.
10. Do not cover or block any openings on the
appliance.
11. Do not store this appliance outdoors. Do not use
this product near water - for example, near a kitchen
sink, in a wet basement, near a swimming pool, or
similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that
comes together on closing the door, use only mild,
nonabrasive soaps, or detergent applied with a
sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
(1) Do not overcook food. Carefully attend appliance
when paper, plastic, or other combustible
materials are placed inside the oven to facilitate
cooking.
(2) Remove wire twist-ties from paper or plastic bag
before placing bag in oven.
(3) If material inside of the oven ignite, keep oven
door closed, turn oven off, and disconnect the
power cord, or shut off power at the fuse or
circuit breaker panel.
(4) Do not use the cavity for storage purposes. Do
not leave paper products, cooking utensils, or
food in the cavity when not in use.

EN-5
17. Liquids, such as water, coffee, or tea are able to
be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or boiling
when the container is removed from the microwave
oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUID
SUDDENLY BOILING OVER WHEN THE CONTAINER
IS DISTURBED OR A UTENSIL IS INSERTED INTO
THE LIQUID.
To reduce the risk of injury to persons:
(1) Do not overheat the liquid.
(2) Stir the liquid both before and halfway through
heating it.
(3) Do not use straight-sided containers with narrow
necks.
(4) After heating, allow the container to stand in
the microwave oven for a short time before
removing the container.
(5) Use extreme care when inserting a spoon or
other utensil into the container.
SAVE THESE INSTRUCTIONS

EN-6
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk
of electric shock by providing an escape wire for
the electric current. This appliance is equipped with
a cord having a grounding wire with a grounding
plug. The plug must be plugged into an outlet that is
properly installed and grounded.
WARNING - Improper use of the grounding can result
in a risk of electric shock.
Consult a qualified electrician or serviceman if
the grounding instructions are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded. If it is necessary to
use an extension cord, use only a 3-wire extension
cord that has a 3-blade grounded plug, and 3-slot
receptacle that will accept the plug on the appliance.
The marked rating of the extension cord shall be
equal to or greater than the electrical rating of the
appliance.
DANGER - Electric Shock Hazard
Touching some of the internal components can cause
serious personal injury or death. Do not disassemble
this appliance.
WARNING - Electric Shock Hazard
Improper use of the grounding can result in electric
shock. Do not plug into an outlet until appliance is
properly installed and ground-ed.
GROUNDING INSTRUCTIONS
03

EN-7
the risks resulting from becoming entangled in or
tripping over a longer cord.
2. Longer cord sets or extension cords are available
and may be used if care is exercised in their use.
3. If a long cord or extension cord is used:
(1) The marked electrical rating of the cord set or
extension cord should be at least as great as
the electrical rating of the appliance.
(2) The extension cord must be a grounding-type
3-wire cord.
(3) The longer cord should be arranged so that it
will not drape over the counter top or tabletop
where it can be pulled on by children or
tripped over unintentionally.
1. A short power supply cord is provided to reduce

EN-8
1. Operation of the microwave oven may cause
interference to your radio, TV or similar equipment.
2. When there is interference, it may be reduced or
eliminated by taking the following measures:
1) Clean door and sealing surface of the oven
2) Reorient the receiving antenna of radio or
television.
3) Relocate the microwave oven with respect to the
receiver.
4) Move the microwave oven away from the
receiver.
5) Plug the microwave oven into a different outlet
so that microwave oven are on different branch
circuits.
04 RADIO INTERFERENCE

EN-9
CAUTION - Personal Injury Hazard
Tightly-closed utensils could explode. Closed
containers should be opened and plastic pouches
should be pierced before cooking.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are
not safe to use for microwaving. If in doubt, you can
test the utensil in question following the procedure
below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
05
UTENSILS

EN-10
MATERIALS YOU CAN USE IN MICROWAVE OVEN
REMARKS
Follow manufacturer’s instructions. The bottom of browning
dish must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage may cause the turntable to break.
Dinnerware
Glass jars
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic wrap
Thermometers
Plastic
Glassware
UTENSILS
Browning dish
Microwave-safe only. Follow manufacturer's instructions.
Do not use cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no
metallic trim.
Do not use cracked or chipped dishes.
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic containers
soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as
directed by package.
Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Use as a cover to prevent splattering or a wrap for steaming.
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.

EN-11
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
REMARKS
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood will dry out when used in the microwave oven and
may split or crack.
May cause a fire in the oven.
May cause arcing and could cause a fire in the oven.
Metal shields the food from microwave energy. Metal trim
maycause arcing.
Aluminum tray
Metal or metal
trimmed utensils
Metal twist ties
Wood
Plastic foam
Paper bags
Food carton with
metal handle
UTENSILS

EN-12
▲Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
F
G
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
A
C B
ED
1
1
1
Glass tray
Turntable ring assembly
Instruction Manual
▲Turntable Installation
Hub (underside)
Glass tray
Turntable ring assembly
Turntable shaft
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both
glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If
glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
SETTING UP YOUR OVEN
06

EN-13
▲Countertop Installation
Remove all packing material and accessories. Examine the oven for
any damage such as dents or broken door. Do not install if oven is
damaged.
Cabinet: Remove any protective film found on the microwave oven
cabinet surface.
Do not remove the light brown Mica cover that is attached to the
oven cavity to protect the mag-netron.

EN-14
07 INSTALLATION
1. Select a level surface
that provide enough
open space for the
intake and/or outlet
vents.
A minimum clearance
of 3.0 inches (7.5cm) is
required between the
oven and any adjacent
walls. One side must
be open.
(1) Leave a minimum
clearance of 12
inches (30cm)
above the oven.
(2) Do not remove
the legs from the
bottom of the
oven.
(3) Blocking the intake
and/or outlet
openings can
damage the oven.
(4) Place the oven
as far away
from radios and
TV as possi-
ble. Operation
of microwave
oven may cause
interference to
your radio or TV
reception.
2. Plug your oven into a
standard household
outlet. Be sure the
voltage and the
frequency is the same
as the voltage and the
frequency on the rating
label.
WARNING: Do not install
oven over a range cooktop
or other heat-producing
appliance. If installed near
or over a heat source, the
oven could be damaged
and the warranty would be
void.
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
3.0 inch(7.5cm)

EN-15
08
OPERATION
Control Panel and Features

EN-16
▲1.Power Level
11 power levels are available.
Level 10 9 8 7 6 5 4 3 2 1 0
Power 100％90％80％70％60％50％40％30％20％10％0％
Display PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1 PL0
▲2.Clock Setting
1). Press " CLOCK "once, "00:00" will display
2). Press the number keys and enter the current time. For example,
time is 12:10 now, please press "1, 2, 1, 0" in turn.
3). Press " CLOCK " to finish clock setting. ":" will flash and the clock will be
lighted.
4). If the numbers input are not within the range of 1:00--12:59, the setting
will be invalid until valid numbers are input.
Note:
1). In the process of clock setting, if the " STOP/CANCEL " button is pressed
or if there is no operation within 1 minute, the oven will go back to the
former setting automatically.
2). If the clock need to be reset, please repeat step 1 to step 3.
▲3.Kitchen Timer
1). Press "TIMER " once, the screen will display 00:00, the first
hour figure flash.
2). Press the number keys and enter the timer time. (The maximum cooking
time is 99 minutes and 99 seconds.)
3). Press " START/+30SEC. " to confirm setting.
4). When the timer time arrives, the buzzer will ring 5 times.
If the clock has been set (12-hour system), the screen will display the
current time.
Note:
1). The kitchen time is different from 12-hour system. Kitchen Timer is a
timer.
2). During kitchen timer, any program cannot be set.
▲4.Microwave cook
1). Press "TIME COOK" once, the screen will display "00:00".
2). Press number keys to input the cooking time; the maximum cooking time
is 99 minutes and 99 seconds.
3). Press " POWER " once, the screen will display "PL10". The default power
is 100%power. Now you can press number keys to adjust the power level.
4). Press " START/+30SEC. " to start cooking.

EN-17
Example: to cook the food with 50% microwave power for 15 minutes.
a. Press "TIME COOK" once. "00:00" displays.
b. Press "1", "5", "0", "0" in order.
c. Press "POWER" once, then press "5" to select 50% microwave power.
d. Press "START/+30SEC. " to start cooking.
Note:
1). In the process of setting, if the " STOP/CANCEL" button is pressed or if
there is no operation within 1 minute, the oven will go back to the former
setting automatically.
2). If "PL 0" selected, the oven will work with fan for no power. You can use
this level to remove the odour of the oven.
3). During microwave cooking, " POWER" can be pressed to change the
power you need. After pressing " POWER",the current power flash for 3
seconds, now you can press number button to change the power. The
oven will work with the selected power for the rest time.
▲5.Speedy Cooking
1). In waiting state, instant cooking at 100% power level can be started by
select a cooking time from 1 to 6 minutes by pressing number pads1 to
6. Press " START/+30SEC. " to increase the cooking time; the maximum
cooking time is 99 minutes and 99 seconds.
2). In waiting state, instant cooking at 100% power level with 30 seconds'
cooking time can be started by pressing " START/+30SEC ". Each press
on the same button will increase cooking time by 30 seconds. the
maximum cooking time is 99 minutes and 99 seconds.
Note: during microwave cooking and time defrost, time can be added by pressing
"START/+30SEC. " button.
▲6.Weight Defrost Function
1). Press " WEIGHT DEFROST "once, the screen will display "dEF1".
2). Press numerical buttons to input weight to be defrosted.Input the weight
ranged between 4~100 Oz.
3). Press " START/+30SEC. " to start defrosting and the cooking time
remained will be displayed.
▲7.Time Defrost Function
1). Press " TIME DEFROST " once, the screen will display "dEF2".
2). Press number pads to input defrosting time. The effective time range
is 0:01~99:99
3). The default microwave power is power level 3. If you want to change the
power level, press " POWER " once, and the screen will display "PL3",
then press the number pad of the power level you wanted.
4). Press " START/+30SEC. " to start defrosting. The remained cooking time
will be displayed.

EN-18
▲8.POPCORN
1). Press " POPCORN " repeatedly until the number you wish appears in the
display, "1.75", "3.0 " ,"3.5 " Oz will display in order. For example, press
"
POPCORN" once, "1.75" appears.
2). Press " START/+30 SEC. " to cook, buzzer sounds once. When cooking
finishes, buzzer will sound five times and then turn back to waiting state.
▲9.POTATO
1). Press "POTATO " repeatedly until the number you wish appears in the
display,
"1", "2", "3" will display in order.
"1"SET : 1 potato (approximate 8 Oz)
"2"SETS: 2 potatoes (approximate 16 Oz)
"3"SETS: 3 potatoes (approximate 24 Oz)
For example, press " POTATO" once, "1" appears.
2). Press " START/+30 SEC. " to cook, buzzer sounds once. When cooking
finishes, buzzer sounds five times and then turn back to waiting state.
▲10.FROZEN VEGETABLE
1). Press " FRZ. VEG. " repeatedly until the number you wish
appears in the display, "4.0 ", "8.0 ", "16.0 " Oz will display in order.
For example, press " FRZ. VEG " once, "4.0. " appears.
2). Press " " to cook, buzzer sounds once. When cooking
finishes, buzzer sounds five times and then turn back to waiting state.
▲11.BEVERAGE
1). Press "BEVERAGE " repeatedly until the number you wish appears in the
display , " 1 ", "2 ", "3 " cup will display in order. One cup is about 120ml.
For example, press " BEVERAGE " once "1 " appears.
2). Press " START/+30 SEC. " to cook, buzzer sounds once. When cooking
finishes, buzzer sounds five times and then turn back to waiting state.
▲12.DINNER PLATE
1). Press " DINNER " repeatedly until the number you wish appears in
the display, "9.0 ", "12.0 ", "18.0 " Oz will display in order.
For example, press " DINNER " once, " 9.0 " appears.
2). Press " START/+30SEC " to cook, buzzer sounds once. When cooking
finishes, buzzer sounds five times and then turn back to waiting state.
▲13.PIZZA
1). Press " PIZZA " repeatedly until the number you wish appears in the
display, " 4.0 ", " 8.0 ", " 14.0 " Oz will display in order.
For example, press " PIZZA" once, " 4.0 " appears.
2). Press " START/+30 SEC. " to cook, buzzer sounds once. When cooking
finishes, buzzer sounds five times and then turn back to waiting state.
START/+30 SEC.

EN-19
▲14.MEMORY FUNCTION
1). Press " 0/MEMORY " to choose memory 1-3 procedure. The screen will
display 1, 2, 3.
2). If the procedure has been set, press " START/ +30 SEC. " to use it. If not,
continue to set the procedure. Only one or two stages can be set.
3). After finishing the setting, press " START/ +30 SEC. " once to save the
procedure.
If press " START/ +30 SEC. " again, it will start cooking.
Example: To set the following procedure as the second memory, that is
memory 2.
To cook the food with 80% microwave power for 3 minutes and 20 seconds.
The steps are as follow:
a. In waiting states, press " 0/MEMORY " twice, stop pressing until the screen
displays "2".
b. Press " TIME COOK " once, then press "3", "2", "0" in order.
c. Press " POWER " once, "PL10" displays, then press "8" and "PL8" displays.
d. Press " START/ +30 SEC. " to save the setting. Buzzer sounds once and
the screen will display "2". If you press " START/+30SEC. " again, the
procedure will be saved as the memory 2 and operated.
e. If you want to run the saved procedure, in waiting state, press " 0/
MEMORY " twice, screen displays "2", then press " START/+30SEC. " to
run.
▲
At most 2 stages can be set for cooking. In multi-stage cooking, if one stage
is defrosting, then defrosting shall be placed at the first stage automatically.
Note: Auto cooking cannot work in the multi-stage cooking.
Example: if you want to cook with 80% microwave power for 5 minutes +
60% microwave power for 10 minutes. The cooking steps are as following:
1). Press " TIME COOK " once, then press "5", "0", "0" to set the cooking
time;
2). Press " POWER " once, then press "8" to select 80% microwave power.
3). Press " TIME COOK " once, then press "1", "0", "0", "0" to set the cooking
time;
4). Press " POWER " once, then press "6" to select 60% microwave power.
5). Press " START/ +30 SEC. " to start cooking.
▲16.LOCK FUNCTION FOR CHILDREN
Lock: In waiting state, press " STOP/CANCEL " for 3 seconds, there will be a
long "beep" denoting the entering into the children-lock state; meanwhile,
screen will display " ".
Lock quitting: In locked state, press " STOP/CANCEL " for 3 seconds, there
will be a long "beep" denoting that lock is released.
15.Multi-stage cooking

EN-20
▲17.INQUIRING FUNCTION
1). In cooking state, if the clock has been set, press " CLOCK ", the oven will
display clock for three seconds.
2). In the microwave cooking state, press " POWER " to inquire microwave
power level, and the current microwave power will be displayed. After
three seconds, the oven will turn back to the previous state. In multi-
stage state, the inquiring way can be done by the same way as above.
▲18.COOKING END REMINDING FUNCTION
When the cooking is over, the buzzer will sound 5 "beep"s to alert user the
cooking is finished.
▲19.OTHER SPECIFICATIONS
1). In standby state , if the set clock digital tube displays current time, the
icon " : " would flash; otherwise, it shows " 0:00 ".
2). In setting function state, the screen displays corresponding setting.
3). In working or pause state, the screen displays surplus cooking
time.
▲20. Silent mode
1). To activate the silent mode:
In waiting state, press and hold “8” for 3 seconds. A long beep will sound.
When you press the keys, it does not make a sound.
2). To deactivate the silent mode:
In silent mode, press and hold “8” for 3 seconds. A long beep will sound.
▲21. ECO Function
1). To enter ECO mode:
In waiting state, press “ STOP/CANCEL ”, Then the screen will turn off.
2). To cancel ECO mode:
In ECO mode, press any keys or open and close the oven door.
