USER MANUAL OF SMART KIT
IMPORTANT NOTE:
Read the manual carefully before installing or
connecting your Smart kit(Wireless module). Make
sure to save this manual for future reference.

CONTENTS
1
SPECIFICATION...............................................
INSTALL THE SMART KIT
(wireless module) ...........................................
DOWNLOAD AND INSTALL APP.....................
PREPARATION ................................................
CREATE ACCOUNT..........................................
NETWORK CONFIGURATION.........................
HOW TO USE APP............................................
SPECIAL FUNCTIONS......................................
APP DECLARATION.........................................
1
2
3
4
5
6
7
8
9
2
3
4
4
5
6
17
20
26

2
1
SPECIFICATION
NOTE:
Company will not be liable for any issues
and problems caused by Internet, Wi-Fi
Router and Smart Devices. Please contact
the original provider to get further help.
Model: CE-SK103
Standard: IEEE 802. 11b/g/n
Antenna Type: Wxternal omnidirectional Antenna
Frequency Band: 2400-2483.5MHz
Operation Temperature:0 C~45 C/32 F~113 F
Operation Humidity: 10%~85%
Power Input: DC 5V/300mA
Maximum TX Power: 19.8dBm

3
KOODXXXXXXXXXXXX
2
INSTALL THE SMART KIT(wireless module)
1) Remove the protective cap of the smart kit.
2) Open the front panel and insert the smart kit
into the reserved interface.
3) Attach the QR code packed with SMART KIT
to the side panel of the machine or other
convenient location, ensure it is covenience to
be scanned by the mobile phone.
Kindly reminder: It is better to reserve the other
two QR Code in a safe place or take a picture
and save it in your own phone.
WARNING: This interface is only compatible with
SMART KIT(Wireless module) provided by the
manufacturer.

4
Scan QR code to download the “ Midea Air ” APP
or ge t it from G oogle p lay and app store by ma nu ally
searching.
CAUTION: The following QR Co de is only available
for downloading AP P. It is totally different with
the QR code packed with SMART KIT.
1) Please ensu re your mo bile device is conn ected
to Wifi router. Also, the Wifi rou ter has already
conne cted to Internet before doing us er
registration a nd ne twork configura tion.
2) Mak sure your mobile device has already been
connected to the wifi network which you want to
use. Also, you need to forget other irrelevant wifi
network in case it influences your configuration
process.
3DOWNLOAD AND INSTALL APP
4PREPARATION
Android iOS

5
12
Click "Login " Enter your email address
an d password, and then
cl ick " "Registration
VI 5
Creat Acc
Fo
rgot password?
5CREATE ACCOUNT
Reminder: When you register to use app, you
need read and agree the Data Privacy Notice.

6
6NETWORK CONFIGURATION
Cautions
Kindly reminder:
Using Android device to do network configuration
It is necessary to forget any other around network and
make sure the Android or i OS device just connect to
the Wi-Fi network you want to configure.
Make sure the Android or i OS device Wi-Fi function
works well and can be connected back to your original
Wi-Fi network automatically.
connect to the Wi-Fi network which you want to use.
Also, you need to forget other irrelevant Wi-Fi network
in case it influences your configuration process.
press the “ LED DISPLAY” or “DO NOT DISTURB”
button seven times in 10 seconds.
User must finish all the steps in 8 minutes after powering on
AC, otherwise you need to power on it again.
1
2
2
3
4
Make sure your mobile device has already been
Disconnect the power supply of AC.
Connect the power supply of AC, and continuously
When the AC displays AP , it means that the AC Wi-Fi
has already entered into AP Mode.
'
'
'
'
Some type of AC do not need the step to be in AP
mode

7
5Press “ + Add Device ” 6Select appliance type

8
7Follow the above steps to enter “AP” mode.

9
8Choose the network
configuration method.
9Choose the “Scan the
QR code” method.

10
9 Or choose the “Manual
Setup” method.
Please enter password
10

11
12
Network configuration is
successful
11
Configuration Success,
you can see the device
on the list.

12
Using iOS device to do network configuration
5Press “ + Add Device ” 6Select appliance type
1
2
3
4
Make sure your mobile device has already been
connected to the Wi-Fi network which you want to
use. Also, you need to forget other irrelevant Wi-Fi
network in case it influences your configuration process.
Disconnect the power supply of AC(some units).
Connect the power supply of AC, and continuously
press the “LED DISPLAY” button or “DO NOT
DISTURB” button seven times in 10 seconds.
When the AC displays “AP” , it means that the AC
Wi-Fi has already entered into “AP” Mode.

13
o
7Follow the above steps to enter “AP” mode.

14
o
8 Connect to the Wi-Fi
network.
Please enter password
9

15
11
Network configuration is
successful
10
Configuration Success,
you can see the device
on the list.

16
NOTE:
When finishing network configuration, APP will
display success cue words on the screen.
Due to different internet environment, it is possible
that the device status still display “offline” . If this
situation occurs, it is necessary to pull and refresh
the device list on the APP and make sure the device
status become “online” . Alternatively, user can
turn off the AC power and turn on it again, the device
status will become “online” after few minutes.

17
7HOW TO USE APP
1Click "Login "
SIM!
082
cc
2Choose the air conditioner.
Please ensure both your mobile device and air
conditioner are connected to the Internet before
using app to control the air conditioner via internet,
please follow the next steps:

18
3Thus, user can control air conditioners on/off status,
operation mode, temperature, fan speed and so on.

19
NOTE:
Not all the function of the APP is available on air
conditioner. For example: ECO, Turbo, Swing function,
please check the user manual to find more information.
