Miditemp MP 22-W User manual

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
1
Important Informations
Important InformationsImportant Informations
Important Informations
!
!!
!IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONSIMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS !
!!
!
•GROUNDING INSTRUCTIONS
GROUNDING INSTRUCTIONSGROUNDING INSTRUCTIONS
GROUNDING INSTRUCTIONS
The product which is equipped with a three wire grounding type line plug must be grounded!
For the USA: This device must be grounded!
For the U.K.: This Apparatus must be earthed!
•Read all instructions below and the Owners’s Manual bevor using the device.
•Before the use in a foreign country consult your retailer or MIDITEMP.
•Protect the unit from strong impact. (Do not drop it!)
•Never place heavy objects on the device.
•Do not use this product near water (e.g. a swimming pool, a washbowl, or the like).
•The device should be located so that it does not interfere with its proper ventilation.
•The device should be located away from heat sources (p.e. radiators or other products
producing heat). Never use it in overheated or damp locations, or in strong direct sunlight.
•Always use only the original connection cables. The power-supply cord should be unplugges
from the outlet when left unused for a long period of time.
•The electronic components in the device are extremly sensitive to sudden voltage fluctuations.
You are therefore advised not to use it during electrical storms, or where the main supply is
suspect. Whenever the possibility of lightning in your area is suspected, pull the plug on the
power cord out of the outlet.
•Do not open or perform any internal modifications on the device. It contains no user-servicable
parts, and should be opened by authorized personnel only. Never open the casing yourself to
attempt a repair, because there is a risc of electric shock which could cause irreparable damage
to both you and the device.
!
!!
!Always observe the following:
Always observe the following:Always observe the following:
Always observe the following: !
!!
!
•Always grasp only the plug on the power cord when plugging into, or unplugging from, an
outlet or this device.
•Try to prevent cords and cables from becoming entangled. All cords and cables should be
outside of the reach of children.
•Never handle the power cord or ist plugs with wet hands.
•Before moving the unit make sure all connections and cords are disconnected.
•Before cleaning the device turn off the power and unplug the power cord from the outlet.
•When using the device with a rack or stand recommended by MIDITEMP, the rack or stand must
be carefully placed so it is level and sure to remain stable. If not using a rack or stand you have
to make sure the device is placed on a surface which properly supports the device, and keeps it
from wobbling.
•Avoid damaging the power- and the remote-controller-cord. Do not bend it excessively, step on
it, place heavy objects on it, etc. A damaged cord can easily become a shock or fire hazard.
Never use cords after they have been damaged!
•In households with small children, an adult should provide supervision until the child is capable
of following all the rules essential for the safe operation of the device.
•Do not force the power-supply cord of the device to share an outlet with an unreasonable
number of other devices. Be especially careful when using extension cords – do not exceed the
total power rating (watts/amperes) for the extension cord. Excessive loads can cause the
insulation on the cord to heat up and eventually melt through.

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
2
INTRODUCTION
Welcome aboard!
Thank you for purchasing this powerful MIDI controlling and processing
System belonging to the famous MIDITEMPs MIOC generation
MIOC generationMIOC generation
MIOC generation. The
following features are in common to all systems:
•Incredible MIDI data processing speed
•MIDITEMPs ASIC chip and Midi processor MIOC (M
MM
Midi I
IIInput O OO
Output
C
CC
Controller)
•Identical operation of allmost all units via unified remote controller
•Optional networking capability via FORNET (F
FF
Fiber O
OO
Optic R
RR
Realtime
NET
NETNET
NETwork)
•Huge storage capacity with built-in Smart-Media-slot, internal
IDE-harddisc-drive or external storage devices via SCSI-connector (only
MULTIPLAYER series)
The series can be used in the following five ways:
The series can be used in the following five ways:The series can be used in the following five ways:
The series can be used in the following five ways:
•Midi patchbay
Midi patchbayMidi patchbay
Midi patchbay
with smallest possible delay times over long distances
•Midi data processor
Midi data processorMidi data processor
Midi data processor
with highest flexibility and distinction of different event types
•Midi controller
Midi controllerMidi controller
Midi controller
with many simple-to-use and professional masterkeyboard functions
•Midi sequencer
Midi sequencerMidi sequencer
Midi sequencer
for playback and recording of Standard Midi Files (SMF) and sysex data
•Wave player
Wave playerWave player
Wave player
for stereo harddisc playback in CD-quality
The device can handle all these tasks – recording, storage and playback of
The device can handle all these tasks – recording, storage and playback ofThe device can handle all these tasks – recording, storage and playback of
The device can handle all these tasks – recording, storage and playback of
songs, playback of wave files together with reception, distribution and manipulation
songs, playback of wave files together with reception, distribution and manipulationsongs, playback of wave files together with reception, distribution and manipulation
songs, playback of wave files together with reception, distribution and manipulation
of incoming Midi data, simultaneously and independently!
of incoming Midi data, simultaneously and independently!of incoming Midi data, simultaneously and independently!
of incoming Midi data, simultaneously and independently!

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
3
The Sequencer
A 64 track sequence player with a resolution of 1/1536
th
notes. Although never intended to
rival the amazing editing capabilities of a software sequencer, the MULTIPLAYER can be
thought of as a vital additional tool for stage performance. It offers a compact and reliable
alternative in situations where the computer – far more at home in a cosy studio or office –
would be likely to let you down in the heat of the action. Since each song can be assigned its
own program number, songs can be selected as easily as the sounds on a synthesizer. With
the potential for memory expansion right up to 16 MBytes, it is possible with the unique
memory structure of the MIOC generation to get access to a maximum of 8192 songs nearly
without any loading time!
The MATRIX (Midi-Router)
The MIOC Midi processor has at its disposal a capable of recognizing, transforming and
rerouting Midi data in realtime. Each unit of the MIOC generation has the same Midi matrix
for its 2, 8 oder 16 MIDI in- and outputs and handles many of the masterkeyboard tasks as
split, transpose, velocity curves etc. Using FORNET the system may be extended to huge
arrays.
An exciting feature of the MIOC generation is their ability to use several matrix programs (up
to eight) simultaniously. This means that variations e.g. filter settings or velocity processing no
longer have to be programmed into every single matrix program.
The Wave Player
One digital stereo audio track offers playback capability for AIFF or WAVE files, sampling
rates from 5 kHz up to 50 kHz and the resolutions 8 and 16 bit. Each Wave is assigned to a
note number, therefore waves can – like the sounds of a drumset in a synthesizer – reside on
any desired key of a defined keyrange. Depending on the fittet harddisk and the RAM size
hundreds of waves can be assigned and played via the keyboard or the sequencer.
Daughterboards / Wavetables
The MULTIPLAYER offers plug-and-play capability via GM daughterboards (e.g. MIDITEMP,
ROLAND, YAMAHA, TURTLE BEACH, TERRATEC ...), which can directly be fittet inside the
MultiPlayer. They are internally accessed via a seperately software port (MP22 series) or OUT
7 (MP88-series), and can be monitored on one of the Audio output pairs of the MP.
SCSI Interface
All MULTIPLAYERs can optionally be delivered with built-in IDE-harddisk-drive. At the SCSI port
external removable or non-removable storage or SCSI-devices may be connected and used
with the audio functions of the MP.
Connecting a PC:
Connecting a PC:Connecting a PC:
Connecting a PC: By using a PC with built-in SCSI controllercard you can use this port to
organize the contens of the internal harddisk of the MP in a very comfortable way. These
devices will be recognized by the PC as additional drives.
Songtext display (Lyrics-/karaoke-function)
Together with the optional MIDITEMP karaoke card and a PAL TV set (even LCD/TFT monitors)
lyrics may be displayed in different font sizes and colours over different backgrounds. The
current syllables or words will be marked with a different colour, synchronized to the running
song, which makes it very easy for sing-along purposes.
FORNET network
Using FORNET, you can interconnect several MIOC units to make up for a higher number of
MIDI ports. For instance an interconnection of one MP88-W, one PMM-88E and one MT16-X
makes a system of 32 32 seperate MIDI in/outputs. On top of that you control the whole array
via one single remote control - even as if it would be a single unit! (not available for the
MP22-systems!)

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
4
Update Service
The update Service of a MULTIPLAYER is very easy. All units (2-Series
and older systems equiped with disk-drive and flash EEPROM) can update
their system via floppy disk. You don not have to open the unit, change an
EPROM, leave bloody spots on the board, etcetera – in about one minute
you can use all new functions!
And the update file contains the whole operating system – so you can
jump from an older version just to the latest without any problems!
To ensure that you have the most up-to-date version, please copy the
serial number of your device, which you will find on the back panel, onto a
postcard, together with your name and address, and register immediately at
the following address:
MIDITEMP GmbH
Am Pfanderling 62 fon: (0049) 08133 2488
D 85778 HAIMHAUSEN fax: [phone]
The fastest way to be registered, or to get your update, is working via
internet! TIP: by registering on our update-page you will automatically be
TIP: by registering on our update-page you will automatically beTIP: by registering on our update-page you will automatically be
TIP: by registering on our update-page you will automatically be
informed about new updates!
informed about new updates!informed about new updates!
informed about new updates!
Our internet address:
http://www.miditemp.com
For further information you can reach us via eMail:
[email protected]
OWNER OF a PMM 88 or MT 16-X:
After receiving and fitting the new EPROMs please return the old ones for the
conveniance of our free-of-charge update service!
Another helpful internet address is the MIDITEMP user group MPClub:
http://www.mpclub.net

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
5
Table of contents
INTRODUCTION
INTRODUCTIONINTRODUCTION
INTRODUCTION ................................
................................................................
................................................................
................................................................
.........................................................
..................................................
.........................2
22
2
Welcome aboard!..............................................................................................................2
The Sequencer...................................................................................................................3
The MATRIX (Midi-Router)...................................................................................................3
The Wave Player................................................................................................................3
Daughterboards / Wavetables ...........................................................................................3
SCSI Interface....................................................................................................................3
Songtext display (Lyrics-/karaoke-function).........................................................................3
FORNET network ...............................................................................................................3
Update Service ..................................................................................................................4
TABLE OF CONTENTS
TABLE OF CONTENTSTABLE OF CONTENTS
TABLE OF CONTENTS ................................
................................................................
................................................................
................................................................
.................................................
..................................
.................5
55
5
CHAPTER II - BASIC OPERATION
CHAPTER II - BASIC OPERATIONCHAPTER II - BASIC OPERATION
CHAPTER II - BASIC OPERATION................................
................................................................
.............................................................
..........................................................
............................. 10
1010
10
Setting up a system..........................................................................................................10
Remote controller.............................................................................................................10
1. Buttons and controls ....................................................................................................11
2. Display........................................................................................................................12
3. Selecting Programs......................................................................................................12
4. Numbering your Songs................................................................................................12
5. Selecting functions.......................................................................................................13
6. Activating MIDI inputs and outputs generally ................................................................14
6. Finding your way around Matrix Banks.........................................................................14
6.1 Example: Organizing Matrix programs...............................................................................16
7. General rules of naming..............................................................................................17
8. PANIC - Transparent MIDI Reset (TMR).........................................................................18
9. Disk functions (general) ...............................................................................................19
9.1 Change storage drive (CD)................................................................................................19
9.2 Load Songs, Matrix programs, Waves (LOA; LDB; LOA).......................................................20
9.3 Save Songs, Matrix programs, Waves (SAV; SVB; SAV)........................................................21
9.4 Copy file (COP).................................................................................................................22
9.5 Erase files (ERA)................................................................................................................23
9.6 Creating a folder (MKD)....................................................................................................23
9.7 Deleting a folder (RMD).....................................................................................................24
9.8 Alternative call for MKD/RMD............................................................................................24
9.9 Directory of a storage device (DIR).....................................................................................24
9.10 Backup of a storage device (BAK).....................................................................................25
9.11 Switch off hard disk drive motor (OFF) .............................................................................25
9.12 Audio-CD-Player using an internal/external CD-ROM-drive..............................................26
CHAPTER III - CONFIGURATION
CHAPTER III - CONFIGURATIONCHAPTER III - CONFIGURATION
CHAPTER III - CONFIGURATION................................
................................................................
.............................................................
..........................................................
............................. 27
2727
27
1. Double Click Time (DCT) .............................................................................................27
2. Display Layout (DSP)....................................................................................................28
3. Naming Midi Inputs and Outputs (NAM)......................................................................28
4. Device ID (ID)..............................................................................................................29
5. Send “all notes off“ after program change (ANO) ........................................................29
6. Setting footswitch functions (FS)....................................................................................29
7. Recognizing the footswitch polarity (+/-) ......................................................................30
8. Reset/ Initialisation of the entire memory (INI)...............................................................30
9. The Device Drive Manager (DRV) .................................................................................31
9.1 Connecting an IDE-/SCSI drive..........................................................................................32

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
6
9.1.1 Install a drive (INS)...........................................................................................................................32
9.1.2 Release a drive (REL) ........................................................................................................................33
9.2 Using multiple partitions on a drive....................................................................................33
9.3 Using a Smart Media Card ................................................................................................33
9.4 Format the IDE- or SCSI medium (FMT)..............................................................................34
9.5 Initialize partition table (INI)..............................................................................................34
9.6 Setting the SCSI-ID of the MULTIPLAYER (HID)....................................................................35
9.7 Switching SCSI parity on/off (PAR)......................................................................................35
10. Formatting floppy disks..............................................................................................36
11. Load (update) a new operating system (UPD).............................................................36
12. Reserving memory for the Waveplayer (WVM)............................................................37
13. Setting the size of the pre-loaded Wave parts (WVP)...................................................38
14. Delay of the booting process (DLY) ............................................................................38
15. Night Mode (NIT) ......................................................................................................39
16. Song numbering mode (SNM) ...................................................................................39
17. Miscellaneous ... (MSC) .............................................................................................40
18. Configuring a password (PW) ....................................................................................41
19. Locking the device (LOK) ...........................................................................................42
20. Exclude MIDI chanels during TMR (XMR).....................................................................43
21. Processing order of send data commands..................................................................43
22. Equalizer settings for the DS-48 (Soundcard)..............................................................43
23. AUDIO functions (Soundcard, Wave & CD)................................................................44
CHAPTER IV - SEQUENCER
CHAPTER IV - SEQUENCERCHAPTER IV - SEQUENCER
CHAPTER IV - SEQUENCER ................................
................................................................
................................................................
................................................................
.....................................
..........
..... 45
4545
45
1. General.......................................................................................................................45
1.0 Playback the first Midisong with the MULTIPLAYER:.............................................................46
1.1 Select a Song....................................................................................................................47
1.1.1 Selecting a new Song memory place ...............................................................................................47
1.1.2 Switching Songs via MIDI ................................................................................................................47
1.2 Select a Song Bank ...........................................................................................................47
1.3 Load a Song .....................................................................................................................48
1.3.1 Loading a Song during playback .....................................................................................................48
1.4 Like a CD player ... ...........................................................................................................48
2. File Assignment (ASG) .................................................................................................49
2.1 The Assign file ..................................................................................................................49
2.2 File work with the Assign file .............................................................................................50
2.2.1 Load new Assignment (LOA)............................................................................................................50
2.2.2 Merge Assignment (MER).................................................................................................................51
2.2.3 Save Assignment (SAV)....................................................................................................................51
2.2.4 Showing the storage path of the current entry (PTH) ........................................................................52
2.3 Functions of the Assign menu............................................................................................52
2.3.1 Assign to file (ASG) .........................................................................................................................52
2.3.2 Move a Song in the assignment (MOV)............................................................................................53
2.3.3 Clear Assignment (CLR)...................................................................................................................53
2.3.4 Delete Program (DEL)......................................................................................................................53
2.3.5 Insert Program (INS)........................................................................................................................54
2.3.6 Sort Programs alphabetically (SRT)...................................................................................................54
2.3.7 Default Output Assign (DOA)..........................................................................................................54
2.4 Working on the Assign file in your computer ......................................................................55
2.5 Automatic loading of Songs with Assignment .....................................................................56
2.5.1 Loading a single Song within the Assignment ..................................................................................56
2.5.2 Loading all Songs of an Assignment (LDA).......................................................................................56
2.6 Automatic erasure of Songs from internal memory.............................................................57
2.6 Erasing an Assign file from disk (ERA).................................................................................57
3. Sequencer functions.....................................................................................................58
3.1 Recording a Song..............................................................................................................58
3.1.1 Resolution (Division) (DIV) ...............................................................................................................58
3.1.2 Record Song (REC) ..........................................................................................................................59
3.1.3 Permanent Record...........................................................................................................................60
3.1.4 Recording MIDI Events (SysEx, PC, CC ...) ........................................................................................60
3.1.5 Track numbers................................................................................................................................61

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
7
3.1.6 Keep tracks (REC)........................................................................................................................... 61
3.1.7 Naming tracks (NAM)...................................................................................................................... 61
3.1.8 Couple Matrix Program with Song (MXP).......................................................................................... 62
3.1.9 Outset of the Loop function (LOP).................................................................................................... 62
3.1.10 Configuration menu (CNF)............................................................................................................ 62
3.2 Dump functions ................................................................................................................63
3.2.1 Universal Dump.............................................................................................................................. 63
3.2.2 Dump Request ................................................................................................................................ 63
3.2.3 Saving, Loading and Sending Dump Requests .................................................................................63
3.3 Synchronisation (SYN).......................................................................................................64
3.3.1 Inputs ............................................................................................................................................ 64
3.3.2 Outputs ......................................................................................................................................... 64
3.4 Output Assignment (OUT).................................................................................................65
3.4.1 Procedure ...................................................................................................................................... 66
3.5 Remove Songs from memory (RMV) ...................................................................................67
3.6 Display remaining memory (MEM) .....................................................................................67
4. The Performance mode................................................................................................68
4.1 Bar counter (symbol !"#)...............................................................................................68
4.2 Repeat loops and markers (LOP; SP1-SP4) .........................................................................68
4.3 GM Transpose of a Song (TRP)...........................................................................................69
4.4 Tempo change (temporarily)..............................................................................................70
4.5 Edit functions (EDI)............................................................................................................70
4.5.1 How to reach the different edit functions ........................................................................................ 70
4.5.2 Editing the sound-parameters of a Song......................................................................................... 71
4.5.3 Tempo change ............................................................................................................................... 72
4.5.4 Time signature............................................................................................................................... 72
4.5.5 Delete tempo and time signature changes...................................................................................... 72
5. Jobs ............................................................................................................................73
5.1 Commands.......................................................................................................................73
5.2 Operation ........................................................................................................................74
5.3 Starting a Job ...................................................................................................................75
5.4 Jumping to specific Job commands ....................................................................................75
5.5 Job runtime display...........................................................................................................75
5.6 Saving and loading a Job..................................................................................................75
5.7 Quit Job...........................................................................................................................76
5.8 Examples..........................................................................................................................76
6. Karaoke settings (LYR)..................................................................................................79
6.1 Selecting Lyrics track (TRK).................................................................................................79
6.2 Selecting color (COL) ........................................................................................................79
6.3 Selecting font (FNT)...........................................................................................................79
6.4 Aktivate marker (MRK).......................................................................................................80
6.5 Marker mode (TMM) .........................................................................................................80
6.6 Aktivate space mode (SPC)................................................................................................80
6.7 Select new line mode (NWL)..............................................................................................80
CHAPTER V - THE MATRIX / MIDI ROUTER
CHAPTER V - THE MATRIX / MIDI ROUTERCHAPTER V - THE MATRIX / MIDI ROUTER
CHAPTER V - THE MATRIX / MIDI ROUTER ................................
................................................................
..............................................
............................
.............. 81
8181
81
1. General.......................................................................................................................81
1.1 Selecting a Matrix program ...............................................................................................81
1.2 Installing a new Matrix bank..............................................................................................82
1.3 Selecting an existing Matrix bank.......................................................................................82
1.4 Copying a Matrix program (COP).......................................................................................82
1.5 Deleting Matrix programs (DEL).........................................................................................83
1.6 Name a Matrix program (NAM).........................................................................................83
1.7 Dump functions (DMP) ......................................................................................................83
1.8 Configuration menu (CNF)................................................................................................84
2. MIDI connections.........................................................................................................85
3. MIDI inputs and outputs...............................................................................................85
3.1 “MIDI-eye“ display............................................................................................................85
3.2 Switching MIDI inputs and outputs on/off...........................................................................85
4. PANIC - Transparent MIDI Reset (TMR).........................................................................85
5. Routing (RTG)..............................................................................................................86

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
8
5.1 Making and breaking connections .....................................................................................86
5.1.1 Connection settings; re-transmitting the original channel (omni; orig)..............................................87
5.1.2 Multi Converting .............................................................................................................................87
5.1.3 Checking connections (READ)..........................................................................................................87
6. Realtime MIDI processor..............................................................................................88
6.1 Calling up functions..........................................................................................................88
6.2 Filter functions (FLT) ..........................................................................................................88
6.2.1 Channel events...............................................................................................................................89
6.3 Split functions (SPL)...........................................................................................................91
6.3.1 Special handling of controllers ........................................................................................................92
6.4 Transpose (TRP).................................................................................................................93
6.5 Velocity functions (VEL)......................................................................................................93
6.5.1 >Threshold<, >Below<, >Above<, >Offset< and >Position< ......................................................94
6.5.2 Velocity switch.................................................................................................................................97
6.5.3 Reverse velocity..............................................................................................................................97
6.6 Controller mapping (CTR)..................................................................................................98
6.7 Program change (PRG)......................................................................................................99
6.8 MIDI volume...................................................................................................................100
6.9 Sending SysEx and other MIDI messages (SND)................................................................100
6.9.1 Example: Local off, Local on..........................................................................................................101
6.10 Remote selection of programs via MIDI (RMT).................................................................102
6.10.1 Direct control of particular Banks.................................................................................................102
6.10.2 Controlling the active Bank in each Group ..................................................................................103
6.10.3 Bank Select command before Program Change...........................................................................103
6.10.4 Simultaneous control of several Banks.........................................................................................103
6.10.5 Combining control methods........................................................................................................104
6.11 Call another Matrix program with the Program (CAP)......................................................104
6.12 Trigger Waves by MIDI (WAV)........................................................................................105
7. Disc functions in Matrix mode ....................................................................................105
CHAPTER VI - WAVE PLAYER
CHAPTER VI - WAVE PLAYERCHAPTER VI - WAVE PLAYER
CHAPTER VI - WAVE PLAYER................................
................................................................
................................................................
................................................................
.................................
..
. 106
106106
106
1. General.....................................................................................................................106
2. Wave Formats ...........................................................................................................106
2.1 WAV format....................................................................................................................106
2.2 AIF format ......................................................................................................................106
3. Wave banks ..............................................................................................................106
4. Triggering Waves ......................................................................................................107
4.1. Global Wave processor ..................................................................................................107
4.2 Wave processor of Matrix programs.................................................................................107
5. Procedure..................................................................................................................107
5.1 Reserve Memory for Waveplayer (WVM)...........................................................................107
5.2 Set MIDI channel and keyboard range.............................................................................108
5.3 Load, select and play Waves............................................................................................108
5.4 Songspecific Assign of Wave files.....................................................................................109
6. Wave utilities....................................................................................................................110
APPENDIX
APPENDIXAPPENDIX
APPENDIX................................
................................................................
................................................................
................................................................
...............................................................
..............................................................
............................... 111
111111
111
A Troubleshooting ........................................................................................................111
B Signal flow charts ......................................................................................................115
B.1 One MIDI channel – from input to output.........................................................................115
B.2 Split................................................................................................................................115
C Glossary ...................................................................................................................116
D Specifications............................................................................................................117
E Event list....................................................................................................................118
F Error Messages..........................................................................................................119
G Format of the Assign files..........................................................................................120
H Mode structures.........................................................................................................122
I Default parameters.....................................................................................................128
K INDEX.......................................................................................................................129

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
9
List of conventional icons
①... ⑨These icons in front of a row show common settings on the unit where
you don ’t have directly to press a button (e.g. „connect the Midi line
using a 5-pole cable“)
$This icon indicates you have to press a button to prepare the execution
of a function
➊.. ➓These icons indicate the following steps are necessary for the execution
of the previously described functions
%This icon indicates by acting with this function you can either cancel the
execution of the previous described or leave the function
"This icon shows the importance of the following
☞This icon shows the following describes a variety of settings or
alternatives
&This icon signals a tip or hint which is not next to understand the manual
– in a quiet moment drink a cup of coffee and work off the presented
background informations
!This icon symbols the use of the blue data wheel on the remote
controller

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
10
Chapter II - Basic operation
Setting up a system
You centainly may connect more than the above shown number of Midi-inputs, e.g. a second
keyboard, a midified accordeon, a breath controller (via your keyboard). Please notice the Midi-
output-chain should not serve more than three devices – otherwise you could catch a Midi dealy!
Remote controller
Every MIDITEMP system is controlled via the unique cable remote controller. Please connect
it with the delivered cable between the REMOTE SLOTS of the system and the remote controller.
The start/stop/continue sequencer functions, or the up/down matrix functions, can be
controlled via an optional foot switch. More examples you will find in the section »JOBS«(page 73).
Owner of an MP88 with 1st generation remote controller: in case of problems please contact
the MIDITEMP technical support.
You can use the W-series remote controller as well for the “old“ systems, of course.
MIDITEMP supplies the needed adapter.
New functions, like »AUDIO«can only reached with the W-series system and are without a
function with “older“ systems.
Vocalist
VocalistVocalist
Vocalist
lightcontroller
lightcontrollerlightcontroller
lightcontroller
Expander 3
Expander 3Expander 3
Expander 3
Expander 2
Expander 2Expander 2
Expander 2
Expander 1
Expander 1Expander 1
Expander 1
Guitar Effect
Guitar EffectGuitar Effect
Guitar Effect
Guitar Preamp
Guitar PreampGuitar Preamp
Guitar Preamp Effect 2
Effect 2Effect 2
Effect 2
Effect 1
Effect 1Effect 1
Effect 1

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
11
1. Buttons and controls
•While entering numbers: figure 0
•After changing disks: refreshing the display
•Display of all files of the current directory (*.*)
•All other cases: panic-function »Transparent Midi reset« (TMR)
The LEDs light up for functions
regarding the inputs
inputsinputs
inputs and outputs
outputsoutputs
outputs
Backlighted display
with 2 x 40 characters
•Numeric keys
•Soft-key function
(
number entr
y)
•aborting functions
•In dialogs: “NO”
In dialogs: “NO”In dialogs: “NO”
In dialogs: “NO”
•Disk directories:: »close«,
(bringing you one structure level
hi
g
her
)
•Pressing shortly: Cursor jumps one
position further
•Pressing and holding in some displays:
quick value-change
Data wheel
Data wheelData wheel
Data wheel
•Chossing functions
•Change parameters in
steps of +/- 1
ENTER
ENTERENTER
ENTER
•Opposite of “EXIT”
•Selecting function in the
different modes MATRIX,
SEQUENCER und WAVE.
•Entering values
•in dialogs: “YES”
in dialogs: “YES”in dialogs: “YES”
in dialogs: “YES”
•Disk directories:: »open«
Bank
BankBank
Bank select level
Pause-/Continue
Pause-/ContinuePause-/Continue
Pause-/Continue
•Stops the running song
•Continues the stopped song
at the current position
DRIVE
DRIVEDRIVE
DRIVE
•Access to the storage devices
•double click: reload of the displayed
song or Wave
•clicking while a file list is shown:
changing the drive
PLAY
PLAYPLAY
PLAY
•Start at the current
song position
During song playback the
LED flashes in the current
tempo
•once: MATR
MATRMATR
MATRix mode
•double click: entering the
»device configuration menue«
STOP
STOPSTOP
STOP
•once: song stops
•double click: Song
returns to the start
p
osition
Audio
A
udioAudio
A
udio-settings
•once: WAVE
WAVEWAVE
WAVE mode
•Double-click: switching into
the global wave settings
SKIP
SKIPSKIP
SKIP
•left key
left keyleft key
left key switches to the
previous song
•right key
right keyright key
right key switches to the
next song
both keys are locked if
a song is running
Entering the
PERF
PERFPERF
PERFormance
mode
A
ccess to
the Midi in
and out of
the system
•once: SEQ
SEQSEQ
SEQuencer mode
•double click: entering the
»device configuration menue«

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
12
2. Display
The LCD display always shows where you are in the device, or, with the cursor position,
which parameter can be changed at that moment. Immediately after powering-up the unit is on the
highest operational level (= top level), and the display (default) is divided into an upper “Matrix” line
with one shown Matrix Bank and a lower “Sequencer” line showing the song Bank.
However, the “Display Layout” configuration function allows a different division to be used (page
28). You may also notice the „Night mode“ (page 39). The position of the mode arrow indicates
which mode the unit is in at any time.
3. Selecting Programs
$Press or , depending on whether you want to switch to a Matrix or Song Program.
The arrow jumps to the corresponding display line.
➊Enter a Program number using the number keys.
Number and name (if any) of the Program are now displayed, but as long as the arrow to the
left of the display is hollow and the cursor blinks right to the number the Program is not yet
recalled! You can also use !to search for the new Program, while the settings of the last
recalled Program are still active.
$Press . Through this action the new entry will be confirmed, and the new program is
activated.
The blinking cursor disappears and the arrow turns to black. This means that the unit has switched to
the displayed program and all settings of that program are now active.
4. Numbering your Songs
There are three different types of numbering your playlist of Standard Midi Files:
•Standard Bank/Programm mode
•3-digit-mode
•4-digit-mode
'
''
'M1A 1
S1A 1
(
((
(M1A123)
))
)Dancefloor
S1A 1
'
''
'M1A123 Dancefloor
S1A 1

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
13
In the Standard Bank/Program
Standard Bank/ProgramStandard Bank/Program
Standard Bank/Program mode the numbering is organized in a maximum of 56
Banks, each with up to 128 entries (= Midifiles). Via Midi you can reach them with Bank select
starting at no. 65, value is the desired song. All other numbering modes are based on this system,
but display your playlist in a linear counting system.
In the 3-digit
3-digit3-digit
3-digit mode you can choose your songs without using the bank button directly from
001 up to 999 songs in one display. You can select the song places via Midi still the same way as in
the Standard Bank/program mode (but only with eight different bank selects, of course).
In the 4-digit
4-digit4-digit
4-digit mode you can choose your songs without using the bank button directly from
001 up to 8.192 songs (7.168 if the wave player is activated) in one display. The possibility of
selecting song places via Midi are still the same as written above.
The system for the two linear counting modes is:
Bank S1A 1 to S1A 128 = S 001 to S 128
Bank S1B 1 to S1B 128 = S 129 to S 256
Bank S1C 1 to S1C 128 = S 257 to S 384
etc.
&An assign-file written with an operating system higher than version 4.09 can only be
read with an older version if the Standard Bank/program mode had been used!
5. Selecting functions
Almost all functions of the unit are recalled with a special kind of menu
menumenu
menu. For instance, if
you are in Sequencer mode and press , the upper line of the display will show “Select
Function”. In the lower line three letters will appear above each number key. These are
abbreviations for the names of each function. The number keys act as soft keys
soft keyssoft keys
soft keys (keys with variable
functions). Pressing a number key ( to ) will immediately call up the relevant function. If
arrows appear above the keys and , there are more functions in the specified direction. In
case you forget what one of the abbreviations means, simply turn the data wheel !. The LED of
the number key for each function will flash, and the function’s full title will appear in the upper line
of the display. The required function can then be called up either by pressing or by pressing
the relevant number key.
After entering a function, the number keys may still serve as soft keys, whereas the data
wheel in this stage is more likely to be used to set parameter values instead of selecting functions.

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
14
6. Activating MIDI inputs and outputs generally
Pressing one of the keys or in the highest function level will display as MIDI EYE
MIDI EYEMIDI EYE
MIDI EYE
the status of the MIDI ports
status of the MIDI portsstatus of the MIDI ports
status of the MIDI ports (no entry for on, “off” of course means off!). Where there are more than eight
inputs and outputs (e.g. on the MT-16 X), the extra ones are displayed by turning !or and ).
With the numeric keys these ports can be switched on or off (see also page 85).
The keys and also provide instant access to the input and output stages from
within the Routing, Split and similar functions. The LED of one of the keys will flash to show whether an
input or an output has been selected. After a selection has been made the display will show the current
settings for this port.
If a function affecting the MIDI inputs or outputs is selected, the LEDs will light on the number
keys to show which inputs or outputs have active assignments, data filters etc. This makes it easier to find
and alter event filters etc.
6. Finding your way around Matrix Banks
The organisation of the total of 128 Memory Banks (each one of them containing 128 Pro-
gram spaces), definitely is not easy to understand as a whole, however, while you are working with it, you
will always find it logical and it never distracts.
You just shouldn’t care thinking about using all of the theoretically possible 16384 Programs
at the same time. More likely the task is to use the complexity of this structure in a way that for each
Song, each masterkeyboard, each working situation you have the right set of Programs.
Following are the seven magic spells for MultiPlayers (to learn by heart):
Following are the seven magic spells for MultiPlayers (to learn by heart):Following are the seven magic spells for MultiPlayers (to learn by heart):
Following are the seven magic spells for MultiPlayers (to learn by heart):
I.
I.I.
I. One Program
One ProgramOne Program
One Program is either a Matrix Program, a Song or a Wave.
is either a Matrix Program, a Song or a Wave.is either a Matrix Program, a Song or a Wave.
is either a Matrix Program, a Song or a Wave.
II.
II.II.
II. The Programs are subdivided into Banks
The Programs are subdivided into BanksThe Programs are subdivided into Banks
The Programs are subdivided into Banks with 128 Programs each.
with 128 Programs each.with 128 Programs each.
with 128 Programs each.
III.
III.III.
III. The Banks are subdivided into 10 Groups:
The Banks are subdivided into 10 Groups:The Banks are subdivided into 10 Groups:
The Banks are subdivided into 10 Groups:
IV.
IV.IV.
IV. There are eight Matrix Groups, one Song Group
There are eight Matrix Groups, one Song GroupThere are eight Matrix Groups, one Song Group
There are eight Matrix Groups, one Song Group and one Wave Group.
and one Wave Group.and one Wave Group.
and one Wave Group.
V.
V.V.
V. The 8 Matrix Groups each contain 8 Banks, the Song Group contains 56 Banks
The 8 Matrix Groups each contain 8 Banks, the Song Group contains 56 BanksThe 8 Matrix Groups each contain 8 Banks, the Song Group contains 56 Banks
The 8 Matrix Groups each contain 8 Banks, the Song Group contains 56 Banks
(7
(7(7
(7*
**
*8) and the last 8 Banks are Wave Banks.
8) and the last 8 Banks are Wave Banks.8) and the last 8 Banks are Wave Banks.
8) and the last 8 Banks are Wave Banks.
VI.
VI.VI.
VI. One Program can be set per Group, which allows for a maximum of eight
One Program can be set per Group, which allows for a maximum of eightOne Program can be set per Group, which allows for a maximum of eight
One Program can be set per Group, which allows for a maximum of eight
Matrix Programs, one Song and one Wave to be active simultaneously.
Matrix Programs, one Song and one Wave to be active simultaneously.Matrix Programs, one Song and one Wave to be active simultaneously.
Matrix Programs, one Song and one Wave to be active simultaneously.
VII.
VII.VII.
VII. If one Program is selected, the previously active Program of the same Group will
If one Program is selected, the previously active Program of the same Group willIf one Program is selected, the previously active Program of the same Group will
If one Program is selected, the previously active Program of the same Group will
be switched off and the new Program will be active. All Programs in the other
be switched off and the new Program will be active. All Programs in the otherbe switched off and the new Program will be active. All Programs in the other
be switched off and the new Program will be active. All Programs in the other
Groups remain active.
Groups remain active.Groups remain active.
Groups remain active.

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
15
You may imagine the ten Groups as ten different “devices”. Eight devices serve for process-
ing Midi data, device no. 9 can record and playback Midi Songs, no. 10 can playback Waves. If you
initialize (or activate) one Bank in a Group, you have literally switched on this device (this Group).
A maximum of eight Matrix Banks can be activated per unit. If coupled via FORNET
A maximum of eight Matrix Banks can be activated per unit. If coupled via FORNETA maximum of eight Matrix Banks can be activated per unit. If coupled via FORNET
A maximum of eight Matrix Banks can be activated per unit. If coupled via FORNET
with more systems the number of possible groups and banks will raise adequate.
with more systems the number of possible groups and banks will raise adequate.with more systems the number of possible groups and banks will raise adequate.
with more systems the number of possible groups and banks will raise adequate.
WVA WVB WVC WVD WVE WVF WVG WVH
S7A S7B S7C S7D S7E S7F S7G S7H
S6A S6B S6C S6D S6E S6F S6G S6H
S5A S5B S5C S5D S5E S5F S5G S5H
S4A S4B S4C S4D S4E S4F S4G S4H
S3A S3B S3C S3D S3E S3F S3G S3H
S2A S2B S2C S2D S2E S2F S2G S2H
S1A S1B S1C S1D S1E S1F S1G S1H
M8A M8B M8C M8D M8E M8F M8G M8H
M7A M7B M7C M7D M7E M7F M7G M7H
M6A M6B M6C M6D M6E M6F M6G M6H
M5A M5B M5C M5D M5E M5F M5G M5H
M4A M4B M4C M4D M4E M4F M4G M4H
M3A M3B M3C M3D M3E M3F M3G M3H
M2A M2B M2C M2D M2E M2F M2G M2H
M1A M1B M1C M1D M1E M1F M1G M1H
Again all figures:
Again all figures:Again all figures:
Again all figures:
•eight Matrix Groups, each with eight Banks, numbered A to H.
•One Song Group with 64 Banks. The 56 Song Banks are numbered S1A to S7H.
•eight Wave Banks are numbered WVA to WVH.
•Each Bank with 128 Program places.
To make it possible to select banks via Midi (using Program Change or Song Select messages), each
bank has its own Midi number. Matrix Banks range from 1 to 64, Song Banks from 65 to 120 and Wave
Banks from 121 to 128.
Wave Group
W
ave GroupWave Group
W
ave Group
8 banks with 128 programs
8 banks with 128 programs8 banks with 128 programs
8 banks with 128 programs
= 1024 Wave entries
= 1024 Wave entries= 1024 Wave entries
= 1024 Wave entries
Song Group
Song GroupSong Group
Song Group
56 banks with 128 programs
56 banks with 128 programs56 banks with 128 programs
56 banks with 128 programs
= 7168 Song entries
= 7168 Song entries= 7168 Song entries
= 7168 Song entries
8 Matrix Sroups with each
8 Matrix Sroups with each8 Matrix Sroups with each
8 Matrix Sroups with each
8 banks with 128 programs
8 banks with 128 programs8 banks with 128 programs
8 banks with 128 programs
= 8192 Matrix entries
= 8192 Matrix entries= 8192 Matrix entries
= 8192 Matrix entries

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
16
6.1 Example: Organizing Matrix programs
Let's say you work in two different situations: you play in a live band, and you
occasionally do songwriting at home. Let’s also assume you have a professional master keyboard
with polyphonic aftertouch and several synth modules permanently installed in your transportable
rack for stage work. At home you have a few more MIDI devices plus a sequencer for composition
purposes. To satisfy all your (MIDI-) needs in both situations, it is a good idea to create a single
global program for each of the above scenarios to cover all the various basic conditions:
*For the live band, this program could filter out the superfluous aftertouch data and increase the
velocity sensitivity of the keyboard so that you don't have to hammer your fingers to the bone
when the engineer turned you down …. You can also determine a MIDI input and channel for
the first (M1A) bank’s MIDI program changes: this allows the master keyboard to be used to
select sub-programs which are only needed for specific songs or passages.
*For home use, you’ll want to record all the data from the master keyboard without changing it,
so filter functions etc. won't apply here. Though you can program your composing environment;
programming conditions like “I always want the drum pads to appear with channel 10 on MIDI
port A of my sequencer”, and so on.
It’s best if the “global program” is created in Group 8 (please read also section
“Combining control methods”, page 104), because you won’t need to edit this program while
playing. The “sub-programs” within the global program are stored in the first bank and contain only
those routing, filter and processing functions which are required for specific sounds or songs. The
advantage is that the global settings defined for both scenarios above don’t have to be programmed
again for each sub-program.
The global program
The global programThe global program
The global program remains in the background and is not changed for another one: it serves as a
remains in the background and is not changed for another one: it serves as aremains in the background and is not changed for another one: it serves as a
remains in the background and is not changed for another one: it serves as a
“working environment” for specific performance situations.
“working environment” for specific performance situations.“working environment” for specific performance situations.
“working environment” for specific performance situations.
The sub-programs operate in the foreground. They are switched manually or via MIDI and contain
The sub-programs operate in the foreground. They are switched manually or via MIDI and containThe sub-programs operate in the foreground. They are switched manually or via MIDI and contain
The sub-programs operate in the foreground. They are switched manually or via MIDI and contain
the settings for individual songs or passages.
the settings for individual songs or passages.the settings for individual songs or passages.
the settings for individual songs or passages.
&The possibilities offered by even just two active Matrix Programs are pretty staggering. For instance
you could use the Programs of Group 2 to filter out unwanted events from any of the Midi inputs.
Provided you don’t switch off the Program containing these filters, it will perform its functions
independently from the Program in Group 1. This means that you no longer need to call up lots of
different Matrix Programs just to get them to filter out an extra type of event - you only need to alter a
single Program in Group 2, and the new settings will act on the whole device. Then you could make
the Banks in Group 1 (as well as the Song Banks, of course) respond to Midi Program Changes so
that you can control your Matrix via Midi in the usual way.
If you want to connect several Midi musicians into a Matrix, each one of them (up to a maximum of
eight) can be given his or her own Group containing the programs that determine the routings
required by the musicians. Midi Remote can be used independently for each Bank (i.e. that thankfully
each musician will only be changing Programs within his or her own Group). Each of the eight Banks
within a group contains 128 Program spaces so no-one is going to run out of memories.
When networking more than one device the number of Midi ports increases, as does the total number
of available Banks. The number of simultaneously active Banks, however, remains the same as for
one device - no more than ten (8 x Matrix, 1 x Song, 1 x Wave).

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
17
7. General rules of naming
During the work it turned out to store the results in intervals because some of them could get
lost if the power shuts down (... maybe in a break down of the current supply). Therefore you find
some different types of storing. But all of them have the method of naming in common:
At the end of a storage operation you find in the lower line of the display the name suggestion of the
MIDITEMP (e.g. assign.asg, noname.mid, matrix.m88 ...).
$press to get the cursor
➊select by using the soft keys the character class (spc, 1, A, a, ins and del) and insert the
sign at the current cursor position – or erase the sign at the cursor position:
☞=> space
☞=> numbers
☞=> capital letter
☞=> small letter
☞=> insert
☞=> delete
➋After slecting the character class with the soft keys you choose the needed
sign by the !data wheel.
➌press to jump one position further.
➍press to close the storage.
%press to leave.
This procedure of naming not only works in the storage functions but everywhere you have to give
This procedure of naming not only works in the storage functions but everywhere you have to giveThis procedure of naming not only works in the storage functions but everywhere you have to give
This procedure of naming not only works in the storage functions but everywhere you have to give
names (e.g. “naming midi ins and outs“, page 28).
names (e.g. “naming midi ins and outs“, page 28).names (e.g. “naming midi ins and outs“, page 28).
names (e.g. “naming midi ins and outs“, page 28).
Working with storage functions normally the MIDITEMP shows the right extension for that menu you
are in. Press to refresh the display or to show all file extensions (very useful after changing a
removable storage device like a disk without leaving the menu.)
&In the storage functions pressing doesn’t produce an “a“ but a “_“ or
a “ “ because filenames with small letters are not allowed!
To navigate in the file system you can use two keys:
Using
UsingUsing
Using
you open folders or move one structure level deeper.
you open folders or move one structure level deeper.you open folders or move one structure level deeper.
you open folders or move one structure level deeper.
Using
UsingUsing
Using
you close folders or move one structure level higher.
you close folders or move one structure level higher.you close folders or move one structure level higher.
you close folders or move one structure level higher.
nonam_
spc 1 A a ins del

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
18
8. PANIC - Transparent MIDI Reset (TMR)
Any connection between two MIDI instruments which is accidentally or prematurely broken
could result in “hanging” notes, where notes which are already sounding are never told to stop, or in
controllers which were in use at the time not being zeroed or switched off. Worse than that, if any of
your expanders do not recognize the “All Notes Off” command, you could be in serious trouble in a
live situation.
All MIDITEMP devices have a “Transparent MIDI Reset” function, which can correct these
problems without interrupting the flow of incoming MIDI data, with the result that these catastophes
usually pass unnoticed.
Simply press the on the highest level (also works on many other levels). The display
shows ** Transparent MIDI Reset ** and the “Panic” function commences immediately. While the
function is at work (approx. 6 seconds) you may continue to play your master keyboard, or run the
Sequencer. Pressing any other key will abort the “Panic” function, otherwise the device will return to
the Mode you were in at the time you pressed the “Panic” button.
In the Configuration Menu „Miscellaneous“ you can exclude this function on the top level to
prevent an inadverntently release during a live situation on stage.
The following data is sent via all MIDI ports and channels when the Panic function is activated:
The following data is sent via all MIDI ports and channels when the Panic function is activated:The following data is sent via all MIDI ports and channels when the Panic function is activated:
The following data is sent via all MIDI ports and channels when the Panic function is activated:
☞Pitch Wheel Value 64 (neutral point)
☞Controller No. 1 (Modul.) Value 0
☞Controller No. 2 (Breath Ctrl.) Value 0
☞Controller No. 33 (Mod. [fine]) Value 0
☞Controller No. 64 (Hold/Sust.) Value 0
☞Controller No. 65 (Portamento) Value 0
☞Controller No. 66 (Sostenuto) Value 0
☞Controller No. 67 (Soft Pedal) Value 0
☞Note Off 1-128 on all 16 MIDI channels
&The huge amount of data necessary for this function can sometimes mean that you will experience
slight timing delays during complex passages. This is because the expanders, and indeed the MIDI
ports themselves, are being stretched to the limit. It is usually only the expanders which are in “Omni
Mode” which have the most trouble. This is because they have to laboriously process every
command on every channel.

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
19
9. Disk functions (general)
All storage functions in the MIDITEMP MULTIPLAYERs are similar. In the modes ,
and you reach the drive functions pressing . You get the following display:
TMR
TMRTMR
TMR =>
=>=>
=> Transparent Midi Reset
Transparent Midi ResetTransparent Midi Reset
Transparent Midi Reset
LOA
LOALOA
LOA =>
=>=>
=> Load ...
Load ...Load ...
Load ...
SAV
SAVSAV
SAV =>
=>=>
=> Save ...
Save ...Save ...
Save ...
LDA
LDALDA
LDA =>
=>=>
=> Load all Songs of the
Load all Songs of theLoad all Songs of the
Load all Songs of the current Assign into internal memory (only SEQ mode)
current Assign into internal memory (only SEQ mode)current Assign into internal memory (only SEQ mode)
current Assign into internal memory (only SEQ mode)
COP
COPCOP
COP =>
=>=>
=> Copy files ...
Copy files ...Copy files ...
Copy files ...
ERA
ERAERA
ERA =>
=>=>
=> Erase file ...
Erase file ...Erase file ...
Erase file ...
DIR
DIRDIR
DIR =>
=>=>
=> Show directory of the current drive
Show directory of the current driveShow directory of the current drive
Show directory of the current drive
CD
CDCD
CD =>
=>=>
=> Change drive
Change driveChange drive
Change drive
Pressing soft key » !« and » "« you switch between the two possible displays:
MKD
MKDMKD
MKD =>
=>=>
=> Make directory on the current drive
Make directory on the current driveMake directory on the current drive
Make directory on the current drive
RMD
RMDRMD
RMD =>
=>=>
=> Remov
RemovRemov
Remove directory on the current drive
e directory on the current drivee directory on the current drive
e directory on the current drive
BAK
BAKBAK
BAK =>
=>=>
=> Backup a complete drive or medium
Backup a complete drive or mediumBackup a complete drive or medium
Backup a complete drive or medium
FMT
FMTFMT
FMT =>
=>=>
=> Format Floppy Disk
Format Floppy DiskFormat Floppy Disk
Format Floppy Disk
OFF
OFFOFF
OFF =>
=>=>
=> Turn drive motor of the current drive off
Turn drive motor of the current drive offTurn drive motor of the current drive off
Turn drive motor of the current drive off
9.1 Change storage drive (CD)
First of all, starting your storage work in this session, you have to select which storage device
is first needed. After pressing choose your drive using the soft key »CD « :
This is the default setting after an update or an initialisation, too. The letters mean:
A:
A:A:
A: always the disk drive
always the disk drivealways the disk drive
always the disk drive
B:
B:B:
B: the internal hard disk (modifyable)
the internal hard disk (modifyable)the internal hard disk (modifyable)
the internal hard disk (modifyable)
C:
C:C:
C: the interna
the internathe interna
the internal/external CD-ROM drive (modifyable)
l/external CD-ROM drive (modifyable)l/external CD-ROM drive (modifyable)
l/external CD-ROM drive (modifyable)
D:
D:D:
D: an external hard disk (via SCSI)
an external hard disk (via SCSI)an external hard disk (via SCSI)
an external hard disk (via SCSI)
F:
F:F:
F: the Smart Media Card slot (modifyable)
the Smart Media Card slot (modifyable)the Smart Media Card slot (modifyable)
the Smart Media Card slot (modifyable)
This is valid for all situations you want to change the drive.
&If you are in any disk operation and want to change the drive immediately
just press and you reach the »DRIVE Select function« menu.
<DRIVE> Select function:
TMR LOA SAV LDA COP ERA DIR CD #
##
#
<DRIVE> Select function:
!
!!
!MKD RMD BAK FMT OFF
select drive:
A: B: C: D: -- F: -- --

MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-XMIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
MIDITEMP MP 22-W, MP 22-CD, MP 88-W, MP 88-CD, PMM 88-E, MT 16-X
20
9.2 Load Songs, Matrix programs, Waves (LOA; LDB; LOA)
$To load a song select the place (program number) you want to load the song in and
confirm with . Then press and to get the drive functions menu:
➊With »LOA« and the data wheel !you can select your Song file.
The upper line in this example shows you are on drive B, root position, and are ready to
load a Midifile ( \*.MID ). The lower line indicates the name of the Midifile, the size and the
free space on the internal RAM memory.
➋If you want to change the drive now just press and select the drive.
➌If you see the name of the song in the lower line confirm with .
%With you leave the function.
In the Matrix mode the work is similar:
In the Matrix mode the work is similar:In the Matrix mode the work is similar:
In the Matrix mode the work is similar:
$To load a Matrix bank select with and the bank you want to load the datas in.
➊With , »LDB« and the data wheel !you can select your Matrix file.
➋If you want to change the drive now just press and select the drive.
➌If you see the wanted Matrix file in the lower line confirm with .
%With you leave the function.
In the Wave mode the work is similar:
In the Wave mode the work is similar:In the Wave mode the work is similar:
In the Wave mode the work is similar:
$To load a Wave select with ,and !the place you want to load the datas in.
Press to get the wave disk functions. To get a Wave with another extension (e.g. AIF)
just change the file-extension by pressing .
➊With »LOA« and the data wheel !you can select your file.
➋If you want to change the drive now just press and select the drive.
➌If you see the wanted Audio file in the lower line confirm with .
%With you leave the function.
<DRIVE> Select function:
TMR LOA SAV LDA COP ERA DIR CD #
##
#
B:
\
*.MID
JINGLE1.MID 2k [load] 14737k
B:
\
*.M88
MATRIX.M88 2k [load] 14737k
B:
\
*.WAV
BEATE.WAV 2112k [load] 14737k
