Scala RK3399 R Pro User manual

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.0
RK3399 R PLAYER
User Manual
2019 September

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.0
1、Product Overview
R PLAYERIis a smart player box that supports Android and Linux operating systems.
Customers can develop their own under this system. (for detailed configuration, please refer
to the product configuration parameter table of R player Playbox). Customers can use the
playback box to provide multimedia content of the display through documents or network
Figure 1、Product interface diagram：
2、Boot up
1）、Connecting power supply
Connect the 12V / 2A power adapter of the accessory to the power socket, connect the
DC anti disconnection connector of the adapter to the DC12V socket of the equipment, and
tighten the nut;
2）、Key switch and status indication
Press the power button to turn on the device, and the power and status lights green.
In sleep mode, power is always on green and status is always on red. Press
and hold the power button for 8 ~ 10s, the power is always bright red, and the status is off。
3、Instructions

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.0
1）、External display：
The playback box HDMI out is connected with the external display HDMI in through the
HDMI cable to realize the display interface output;
The external device can input interface data through the playback box HDMI in, and the
playback box can synchronously output the display interface from the HDMI out to the
external display.
Figure 2: display desktop
2）. External USB device:
In the state of connected external display device, USB mouse and USB keyboard can be
connected through USB2.0 and USB3.0 ports to realize interface switching, data input and
output and other functions.
The function of copying or loading data files of external storage devices such as USB flash
disk can be realized.
Figure 3: USB insertion display in Explorer

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.0
3）. Wired, wireless networking and WiFi functions:
The playback box can be connected to the network through RJ45 port and wifi antenna for
network data transmission.
Figure 4: wired and wireless networking setting interface entrance
Figure 5: Bluetooth setting interface entry

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.0
4）. Audio transmission:
The playback box can transmit audio with external playback equipment through aux
port.
Figure 6: sound adjustmen
5）. Infrared remote control:
The playback box is equipped with IR infrared sensor. Through the infrared remote control,
you can switch on and off, return to the desktop, mute, move the cursor, switch the interface,
return, increase or decrease the output volume, and switch the mouse mode.
6）. Serial communication:
The external equipment can realize the RS232 serial communication function through the
COM port of the playback box.

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.0
7）. Extended infrared remote control: (it needs to be modified professionally, temporarily
omitted, you can contact the manufacturer)
8). Extended switch machine: (it needs to be refitted professionally, temporarily omitted, you
can contact the manufacturer)
9). Equipment reset: in case of equipment crash, the device can be forced to restart by
pressing reset hidden button.
10). Device upgrade: the recovery hidden button is used for device upgrade and firmware
burning. The customer cannot operate it by himself.
4. firmware upgrade:
The player box is equipped with the best firmware at the factory. Customers need to contact
skylard if they have firmware requirements.
5. packing configuration
1. Player box host, 1pcs;
2. Infrared remote control, 1pcs;
3. 12V / 2A adapter, 1pcs;
4. HDMI transfer line, 1pcs;
5. Install screw pack, 1pcs;
6. Type transfer line, 1pcs.
SCALA Digital Technology(Ningbo) Co., Ltd.
Address: No. 7 Hong Da Road , Jiang Bei District, Ning Bo,Zhe Jiang
Tel: [phone]
Fax: [phone]
Website:https://scala-china.com/

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.0
R PLAYER Product configuration parameters
Spec Date: 10th September, 2019
Product
Descriptions
Scala RK3399 R Player
Hardware &
OS
Soc
Rockchip RK3399 ( 28nm HKMG Process )
CPU
Six-Core ARM 64-bit processor, up to 2.0GHz
Based on Big.Little architecture, Dual-Core Cortex-A72 and Quad-Core
Cortex-A53 with separate NEON coprocessor
GPU
ARM Mali-T860 MP4 Quad-Core GPU
Support OpenGL ES1.1/2.0/3.0/3.1, OpenCL and DirectX 11
Support AFBC
VPU
Support 4K VP9 and 4K 10bits H265/H264 video decoding, up to 60fps
1080P multi-format video decoding (WMV, mpeg-1/2/4, VP8)
1080P video encoding, which supports h.264, VP8 format
Video post-processor: anti-cross, de-noising, edge/detail/color optimization
RAM
Dual-Channel DDR3 -1600 (800MHz)
( 2GB Standard/4GB Optional )
Flash
High-Speed eMMC 5.1 ( 32GB Standard/8GB/16GB/64GB/128GB Optional 256GB
in testing)
OS
SUPPORT ANDROID/LINUX
I/O Ports
1 x DC input[with anti-loose mechanism], 1 x RJ45, 1 x Power button,1 x LED
Status, 1 x Power Extension Cable Port, 1 x IR Receiver, 1 x IR Extension Cable Port,
1 x Reset,1 x Recovery, 1 x Wi-fi Antenna, 1 x HDMI Input (HDMI 2.0，up to
1080P@60fps , support HDCP 1.4a), 1 x HDMI Output (HDMI 2.0，up to 4K@60fps ,
support HDCP 1.4/2.2), 1 x AUX, 1 x USB 2.0, 1 x USB 3.0, 1 x USB 3.0/Service [Type
C],1 x DB9[Male]
Power
Power input by
adapter
DC12V, 2A
Power input by
PoE(Optional)
IEEE802 3at(25.5W) / Network cable requirement: CAT-5e or better
Remote
Control
Remote control
Support
Yes
Connectivity
RJ45(PoE)
Ethernet 10/100/1000, support 802.1Q tagging
IEEE802 3at(25.5W) / Network cable requirement: CAT-5e or better
WIFI
WiFi 2.4GHz/5GHz Dual-Band Support 802.11a/b/g/n/ac
Bluetooth
Built-in BLE 4.0 Beacon
General
Case Material
Top case - Aluminum / Bottom case - ABS

SCALA Digital Technology(Ningbo) Co., Ltd. Version：V1.0
information
Storage Temp
(-15 -- 65 degree)
Working Temp
(0 -- 50 degree)
Storage/Working
Humidity
(10 -- 90﹪)
Dimension
156*106*25.5 MM
Net Weight
0.478KGS
Bluetooth and WIFI can simultaneous transmit, 2.4G WIFI and 5G WIFI can’t simultaneous transmit.
The RF parameters are protected, so customers can’t change the RF parameters.
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement.
