Midstream Modus Series User manual

SEE DETAIL A
Modus Series
INSTALLATION GUIDANCE v1.0

midstreamlighting.com call [phone]
2 3
MODUS INSTALLATION GUIDANCE
Contents
24 mm standard wrench
#8, #10 and #14 allen keys
Powered drill-screwdriver with adjustable torque (clutch)r
Torx T30 insert bit for powered screwdriver (to be used
with M6 screws)
Torx T30 manual screwdriver
Monkey pliers
Electrician scissors for wires
Slotted manual screwdriver for connector’s screws
(blade dimensions: 3,5(w) x 0,6(t)mm)
DO NOT USE PERCUSSION DRILLS!
Equipment list

Wear safety shoes to protect yourself from material
dropping
Never energize the lamp if wiring operation are not
completed
H&S check
1. General notes
Section PAGE
1 General notes 2
2 Safety instructions 3
3 Contents 3
4 Bracket mounting and aiming 4
5 Visor mounting 6
6 Floodlight connection 7
7 Electrical connection 8
8 Electrical specifications 10
9 Dimensions 10
10 Weight and Windage 11
This user manual contains important information on safe
operation of the Luminaire.
Read and follow all safety notes and all instructions. Save this
manual for future reference.
Make sure that it is available to all persons using this device.
All wiring should be done by a licensed electrician in
accordance with state codes, local codes, and National
Electric Code (NEC) standards or International Electro
technical Commission (IEC) standards.
The Luminaire is suitable for wet locations.
NOTE: Prior to starting the installation, check the equipment
list to be sure of using the correct tools (mounting screw(s) and nut(s) are not
supplied).
DO
Store the Luminaire with care, avoiding placing the lenses
to the ground which may scratch or damage them
 To avoid damaging the Luminaire, keep it in the original
packaging when storing
 When handling the Luminaire, wear industrial safety
gloves and safety boots
 Operate on circuitry when the electrical power supply is
disconnected
DO NOT
Apply mains voltage through the control system cable.
This will damage the luminaire that will no longer be
covered by warranty
Unnecessarily remove the Luminaire from the box
Leave the LED Luminaire switched on when rested on the
ground with optics facing down
Place the Luminaire with the lens on the pavement, dirt
and metal surfaces
Clean the lenses with any industrial detergent, but with
water-soaked cloth if needed
1
A
2 3 456 7 8 9 10 11 12
B
C
D
E
F
G
H
1 2 3 4 5 67 8 9 10 11 12
H
G
F
E
D
C
B
A
MIDSTREAM
209.2
370
439
80°
95°
175.8
209
REV. DOCUMENT N° DESCRIPTION ZONE DATE DRAWN CHECKED
A0 ST00118A006A0 Dim. changed, inner reflecting side added 15/3/19 FG PC
B0 ST00118A006B0 Layout variation 29/5/19 FG PC
This drawing is property of MIDSTREAM LIGHTING LTD. All rights reserved the partial or total reproduction of it is forbidden without express consent.
MIDSTREAM LIGHTING LTD - 1 CHESHAM STREET - LONDON - SW1X 8ND - UNITED KINGDOM - Ph [phone]
Drawing Number ST00118A006B0 29-Mag-19
Date
1:2 1/1
Description Scale Sheet
FG PC MIDSTREAM 1.75 Kg B0
Drawing by Checked by Approved by Weight Rev.
1 12 RIVET_D3_2 POP RIVET 3.2 DIA x 6.0 LG ALUMINUM (LB4701002) RIVETTO BUSSOLA AL ø4, STELO INOX
2 1 ST00118P006B0 HYDRA SYMMETRIC VISOR
3 1 ST00118P01900 REFLECTING SIDE
POS QTY PART NUMBER DESCRIPTION NOTE
FINISHING:
POWDER COATING FOR OUTDOOR (POLYESTER)
AVG THICKNESS 80 micron
MATT FINISH - GLOSS 20 +10
COLOUR: BLACK RAL 9005
SHEET THICKNESS: 1 mm
A0
A0
B0
A0
2
3
1
Fitting bracket Set of connectorsVisor with screws and washers
x1 Modus 300
x2 Modus 600
x3 Modus 900
Caribiner hook and cable
Two persons
required to complete
the installation
Contains parts and
assemblies susceptible to
damage by electostatic
discharge (ESD)
The Luminaire should be
positioned so that prolonged
staring into the luminaire at
a distance closer than 4m
(13 ft) is not expected
Hard Hats, Safety shoes,
Hi-Vis vest and Safety
Gloves must be worn
at all times
Disconnect the electrical
supply power before
commencing the installation:
failure to do so could result
in serious injury
The luminaire is not to be
placed face down on any
surface other than the
provided foam pad
The light source of this
appliance must only be
replaced by the manufacturer,
its after-sales service or
qualified personnel
Do not use a
generator!
3. Contents
2. Safety instructions
Use the device only as described in this user manual. Any other
use or use under other operating conditions is considered to be
improper and may result in personal injury or property damage
as well as voiding the warranty.
No liability will be assumed for damages resulting from improper
installation.
Only persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience
may use this device.

2. Mounting
Align the bracket’s central screw hole with desired mounting surface.
Insert and tighten the central bolt to secure the position of the bracket. Tightening torque: 250 Nm for M20 bolt, 130 Nm for M16
bolt.
4. Securing
When the LED luminaire installation has been completed, insert the safety cable in the left or right eye bolt.
Connect the safety cable to the holding frame with the supplied carabiner hook.
1. Insert screws
Insert each screw with its plain and spring washer through the central hole of the fitting bracket flange and loosely tighten.
3. Adjusting angle
Loosen the central screw on both sides of the bracket to tilt the luminaire with ease.
The LED luminaire can be tilted at 5° intervals. Once the tilting operation is complete, tighten and lock the screws.
Tightening torque: Modus 150: 25 Nm, Modus 300: 25 Nm, Modus 600: 50 Nm, Modus 900: 90 Nm, Modus 1200: 120 Nm
5°
SEE DETAIL A
midstreamlighting.com call [phone]
4 5
MODUS INSTALLATION GUIDANCE
4. Bracket mounting and aiming
Use A2-80 stainless steel bolts or 8.8 class
steel bolts with hot dip galavnised coating
Do not use percussion drills
1
A
2 3 456 7 8 9 10 11 12
B
C
D
E
F
G
H
1 2 3 4 5 67 8 9 10 11 12
H
G
F
E
D
C
B
A
MIDSTREAM
17 13
81.5
79.5
21 17
30
30
1.6 0.83.2
( )
REV. DOCUMENT N° DESCRIPTION ZONE DATE DRAWN CHECKED
This drawing is property of MIDSTREAM LIGHTING LTD. All rights reserved the partial or total reproduction of it is forbidden without express consent.
MIDSTREAM LIGHTING LTD - 1 CHESHAM STREET - LONDON - SW1X 8ND - UNITED KINGDOM - Ph [phone]
ST00117P08200 3/3 1:2
Drawing Number Sheet Scale
FITTING BRACKET A1 0
DESCRIPTION Format Rev.
PA CP MIDSTREAM 18-Nov-20
Drawing by Checked by Date
-
Approved by
TREATMENT
Weight Kg
1.4003 STEEL ( 3CR12 )
Roughness
MATERIAL
precise 0.05 0.1 0.15 0.2 0.3 0.5 - -
Angles 30°
All materials employed
have to be selected
among RoHS compliant
materials:
the EC directives
to be referred to are
2002/95/EC and
correlated subsequent
ones.
medium x0.1 0.2 0.3 0.5 0.8 1.2 2 3
Shaft h11
coarse 0.2 0.5 0.8 1.2 2 3 4 5
Holes H11
Tolerance class up to
6
over 6
up to 30
over 30
up to120
over 120
up to315
over 315
up to1000
over 1000
up to2000
over 2000
up to4000
over
4000
Lead screws 6H / Screws 6g
ISO Metric Screw
DIMENSIONS WITHOUT TOLERANCE DEGREE:
MODUS 300
MODUS 600/900
1
A
2 3 456 7 8 9 10 11 12
B
C
D
E
F
G
H
1 2 3 4 5 67 8 9 10 11 12
H
G
F
E
D
C
B
A
MIDSTREAM
17 13
81.5
79.5
21 17
30
30
1.6 0.83.2
( )
REV. DOCUMENT N° DESCRIPTION ZONE DATE DRAWN CHECKED
This drawing is property of MIDSTREAM LIGHTING LTD. All rights reserved the partial or total reproduction of it is forbidden without express consent.
MIDSTREAM LIGHTING LTD - 1 CHESHAM STREET - LONDON - SW1X 8ND - UNITED KINGDOM - Ph [phone]
ST00117P08200 3/3 1:2
Drawing Number Sheet Scale
FITTING BRACKET A1 0
DESCRIPTION Format Rev.
PA CP MIDSTREAM 18-Nov-20
Drawing by Checked by Date
-
Approved by
TREATMENT
Weight Kg
1.4003 STEEL ( 3CR12 )
Roughness
MATERIAL
precise 0.05 0.1 0.15 0.2 0.3 0.5 - -
Angles 30°
All materials employed
have to be selected
among RoHS compliant
materials:
the EC directives
to be referred to are
2002/95/EC and
correlated subsequent
ones.
medium x0.1 0.2 0.3 0.5 0.8 1.2 2 3
Shaft h11
coarse 0.2 0.5 0.8 1.2 2 3 4 5
Holes H11
Tolerance class up to
6
over 6
up to 30
over 30
up to120
over 120
up to315
over 315
up to1000
over 1000
up to2000
over 2000
up to4000
over
4000
Lead screws 6H / Screws 6g
ISO Metric Screw
DIMENSIONS WITHOUT TOLERANCE DEGREE:
MODUS 300
MODUS 600/900

SEE DETAIL A
5. Visor mounting
Secure visors
Mount the LED luminaire with the highlighted threaded holes of LED modules facing upwards and pointing away from the mast.
Mount on each LED module a visor. The visor must be fixed with the supplied screws along with the plain and serrated washers as
shown (7-8 Nm).
Securing the cable
Power supply cable must have 3 conductors:
L BROWN
N BLUE
GND YELLOW & GREEN
Control cable must have 2 conductors:
L  BROWN
N  BLUE
Secure the control plug with the supplied closure cap when the control system is not used.
Mains cable – power connection (not supplied). Control cable – 0-10 V, DALI (not supplied)
Control system
1-10 V or DALI
2 poles - yellow
6. Floodlight connection
Use a main circuit breaker
with a rated current of
at least 10A
Do not apply mains voltage
through the control sytem
cable. This will damage
the luminaire.
Power supply
3 poles - white
M6 SCREWS
VISOR
midstreamlighting.com call [phone]
6 7
MODUS INSTALLATION GUIDANCE

SEE DETAIL
A
SEE DETAIL
B
SCALE 2:5
B
DETAIL
DA1
DA2
+
+
=
DA1
DA2
+
+
=
Connector socket
The connector socket can fit a H05RN-F or H07RN-F rubber cable with a maximum outer diameter of 12 mm and the conductor
section a maximum of 1.5 mm2. The cable must have three wires: L (live) – N (neutral) – GND (ground).
Wiring the terminal
Insert each wire into the socket terminal, matching wire color with the “L”, “N” and “GND” symbol on the socket and tighten
the screws.
Housing and gasket
Insert the socket into the housing until the inner part “clicks” in and then insert the gasket.
Securing the socket
Tighten the nut using a 21 mm spanner and connect the socket to the plug on the LED luminaire and tighten the housing to ensure
IP68 protection. Test the luminaire before attaching it to the final connection point.
Remove cable sheath
Remove the cable sheath for a maximum of 25 mm. The wires do not need to be stripped because the connector is equipped with
piercing clip terminals.
Inserting the cable
Insert the cable through the socket housing of the connector. If the cable diameter is greater than 9 mm, remove the inner part of
the gasket.
midstreamlighting.com call [phone]
8 9
MODUS INSTALLATION GUIDANCE
7. Electrical connection 7. Electrical connection
25mm Self-piercing
CONTROL - 2 pole POWER - 3 pole

8. Electrical specications
9. Dimensions
10. Weight and windage
Modus 150 Modus 300 Modus 600 Modus 900 Modus 1200
Input Voltage 90-305 V ac
Input Frequency 50 – 60 Hz
Absorbed Power 145 W 330 W 660 W 990 W 1320 W
Power Factor 0.95
Inrush Current (I2t) 2.6 A2s 3.4 A2s 6.4 A2s 10.2 A2s 13.6 A2s
Modus 300 Modus 600 Modus 900
Weight 11kg 23kg 36kg
Windage 0.094m20.187m20.280m2
* at 220 V ac input, 25°C cold start, 10% Ipk – 10% Ipk
Modus 300 – Floodlight (not to scale)
Modus 600 – Floodlight (not to scale)
Modus 900 – Floodlight (not to scale)
This device is subject to the European directive 2002/96/EC.
Do not dispose of the device with your normal household waste.
Dispose of this device through an approved waste disposal firm or through your local waste facility.
When discarding the device, comply with the rules and regulations that apply in your country.
If in doubt, consult your local waste disposal facility.
midstreamlighting.com call [phone]
10 11
MODUS INSTALLATION GUIDANCE

2020
For translations, digital versions or more information please
head to https://www.midstreamlighting.com/installation-guides
European HQ
Midstream Ltd. Wessex House, 1 Chesham Street, London SW1X 8ND, United Kingdom
Telephone: [phone] Email: [email protected]
US HQ
Midstream Lighting Ltd. 66 West Flagler Street, Miami, FL 33130, USA
Telephone: [phone] Email: [email protected]
midstreamlighting.com
