Miele G7106 User manual

Operating instructions
Dishwasher
Always read the operating instructions and the installation sheet
before setting up, installing, and commissioning the appliance. This
prevents both personal injury and damage to the machine.
en-CA M.-Nr. 11 859 130HG07

Contents
2
Warnings and safety instructions .................................................................... 5
Guide to the appliance...................................................................................... 14
Machine overview................................................................................................ 14
Control panel....................................................................................................... 16
Display functions................................................................................................. 18
Caring for the environment .............................................................................. 19
Initial commissioning ........................................................................................ 20
Opening the door ................................................................................................ 20
Closing the door.................................................................................................. 21
Activating the child lock ...................................................................................... 21
Basic settings...................................................................................................... 22
Setting the language ...................................................................................... 22
Setting the water hardness ............................................................................ 22
Reactivation salt.................................................................................................. 24
Filling the salt reservoir................................................................................... 25
Refilling the salt .............................................................................................. 26
Rinse aid.............................................................................................................. 27
Adding rinse aid ............................................................................................. 28
Filling the rinse aid reservoir........................................................................... 28
Settings .............................................................................................................. 29
Opening the Settings menu................................................................................. 29
Changing settings ............................................................................................... 29
Closing the Settings menu .................................................................................. 29
Language......................................................................................................... 30
Water hardness ................................................................................................... 30
Rinse Aid ............................................................................................................. 32
Display brightness............................................................................................... 32
Refill reminders.................................................................................................... 32
AutoOpen ............................................................................................................ 32
Extra clean........................................................................................................... 33
Extended drying .................................................................................................. 33
2nd interim rinse.................................................................................................. 33
Hygiene cycle ...................................................................................................... 33
Software version.................................................................................................. 34
Showroom program............................................................................................. 34
Factory default..................................................................................................... 34
Caring for the environment .............................................................................. 35
Energy-saving dishwashing................................................................................. 35

Contents
3
Loading the dishwasher.................................................................................... 36
General information............................................................................................. 36
Loading examples ............................................................................................... 38
Upper basket....................................................................................................... 42
Adjusting the upper basket ................................................................................. 45
Lower basket....................................................................................................... 46
Cutlery tray/cutlery basket (depending on model) ............................................ 48
Loading the 3D MultiFlex Tray........................................................................ 48
Loading the cutlery basket............................................................................. 49
Detergent ........................................................................................................... 50
Active ingredients ............................................................................................... 50
Detergent dispensing .......................................................................................... 51
Adding detergent................................................................................................. 52
Operation............................................................................................................ 53
Switching on the dishwasher .............................................................................. 53
Selecting a program ............................................................................................ 53
Display of program cycle time............................................................................. 54
Starting a program .............................................................................................. 54
End of program.................................................................................................... 55
Energy management ........................................................................................... 55
Turning off the dishwasher .................................................................................. 56
Unloading the dishwasher................................................................................... 56
Interrupting a program......................................................................................... 57
Cancelling or changing a program ...................................................................... 57
Options ............................................................................................................... 58
Timer .............................................................................................................. 58
Program overview ............................................................................................. 60
Program options................................................................................................ 62
Selecting program options .................................................................................. 62
Express..................................................................................................... 62
IntenseZone.............................................................................................. 62
Cleaning and care ............................................................................................. 63
Cleaning the wash cabinet .................................................................................. 63
Cleaning the door and the door seal................................................................... 64
Cleaning the control panel .................................................................................. 64
Cleaning the appliance front ............................................................................... 65
Cleaning the spray arms...................................................................................... 66
Checking the filters in the wash cabinet ............................................................. 69

Contents
4
Cleaning the filters............................................................................................... 69
Cleaning the drain pump..................................................................................... 71
Frequently Asked Questions ............................................................................ 73
Technical problems ............................................................................................. 73
Fault messages ................................................................................................... 74
Door release ........................................................................................................ 75
Water intake fault................................................................................................. 76
Water drainage fault ............................................................................................ 77
General dishwasher problems............................................................................. 78
Noises.................................................................................................................. 79
Poor cleaning results........................................................................................... 80
Technical Service............................................................................................... 84
Contact in the event of a fault ............................................................................. 84
Warranty .............................................................................................................. 84
Optional accessories ........................................................................................ 85
Installation.......................................................................................................... 87
Water intake ........................................................................................................ 87
Water drainage .................................................................................................... 89
Electrical connection ........................................................................................... 91
Sound emission testing .................................................................................... 93

Warnings and safety instructions
5
This dishwasher complies with all current local and national safety
requirements. Inappropriate use can, however, lead to personal
injury and material damage.
Please observe the installation sheet and read the operating
instructions carefully before setting up the dishwasher and using it
for the first time. They both contain important information on the
installation, safety, use, and maintenance of the machine. This
prevents both personal injury and damage to the dishwasher.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
section on installing the dishwasher as well as the safety
instructions and warnings.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep the installation sheet and the operating instructions in a safe
place and pass them on to any future owner.

Warnings and safety instructions
6
Correct application
 This dishwasher is intended for use in domestic households and
similar residential environments.
 This dishwasher is not suitable for outdoor use.
 This dishwasher is intended for use at altitudes of up to 4,000m
above sea level.
 This dishwasher must only be used for cleaning domestic
dishware and cutlery. All other types of use are not permitted.
 This dishwasher is not intended for use by people with reduced
physical, sensory, or mental capabilities or lack of experience and
knowledge, unless they have been given supervision and instruction
concerning its use by a person responsible for their safety. They may
only use the dishwasher without supervision if they have been
shown how to use it in a safe manner. They must be able to
recognize and understand the possible consequences of incorrect
operation.

Warnings and safety instructions
7
Safety with children
 Children under 8 years of age must be kept away from the
dishwasher unless they are constantly supervised.
 Children must not be allowed to clean or maintain the appliance.
 Children should be supervised in the vicinity of the dishwasher.
Never allow children to play with the dishwasher. There is a danger
that children might shut themselves in the dishwasher.
 If the automatic door opening mechanism is active (depending on
the model), keep young children away from the area in which the
dishwasher door opens. There is a danger of injury in the unlikely
event of a fault with the opening mechanism.
 Danger of suffocation. While playing, children may become
entangled in packaging material (such as plastic wrapping) or pull it
over their head, presenting the risk of suffocation. Keep packaging
material away from children.
 Keep children away from detergents. Detergents cause severe
skin burns and severe eye damage. They can cause burning in the
mouth and throat, or inhibit breathing. It is therefore important to
keep children away from the dishwasher when the door is open.
Detergent residues could still be present in the machine. Seek
medical advice immediately if a child has swallowed or inhaled any
detergents.

Warnings and safety instructions
8
Technical safety
 Unauthorized installation, maintenance, and repairs can cause
considerable danger for the user. Installation, maintenance, and
repairs must only be carried out by a qualified technician.
 Damage to the dishwasher can compromise your safety. Before
using the dishwasher and in particular following transport, check it
for any visible damage. Never use a damaged dishwasher.
 The electrical safety of the dishwasher can only be guaranteed
when correctly grounded. It is most important that this basic safety
requirement is fulfilled. If in doubt, the electrical installation should
be checked by a qualified electrician.
Miele cannot be held liable for the consequences of an inadequate
or lack of grounding system (e.g., electric shock).
 Reliable and safe operation of this dishwasher can only be
assured if it has been connected to the domestic electricity supply.
 If the dishwasher is plugged into the domestic electricity supply
using a 3-pin plug with a grounding contact (it must not be hard-
wired), the electrical socket must be easily accessible after the
dishwasher is installed so that it can be disconnected from the
domestic electricity supply at any time.
 There must be no electrical sockets behind the dishwasher
because the building-in niche may be too small. Danger of
overheating and fire risk if the dishwasher were to be pushed up
against a plug.
 The dishwasher must not be installed underneath a cooktop. The
high temperatures radiated by cooktops could damage the
dishwasher below. For the same reason, the dishwasher must not be
installed next to open fires or other appliances that give off heat,
such as heaters etc., not normally found in a kitchen.

Warnings and safety instructions
9
 Ensure that the connection data on the dishwasher’s data plate
(fuse rating, frequency, and voltage) match the domestic electricity
supply. This data must correspond in order to avoid the risk of
damage to the dishwasher. Compare these before connecting the
appliance to the electricity supply. If in any doubt, consult a qualified
electrician.
 Do not connect the dishwasher to the domestic electricity supply
until it has been fully installed and any adjustments have been made
to the door springs.
 The dishwasher may only be operated if the door opening
mechanism is working correctly. Otherwise there could be a risk of
danger while the automatic door opening mechanism (depending on
the model) is active.
To check that the door opening mechanism is working correctly:
- The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half
open (approx. 45° opening angle). It is also important that the
door cannot fall open.
- The door locking pins automatically retract when the door opens
at the end of the drying phase.
 Multi-socket adapters and extension leads do not guarantee the
required safety of the appliance (risk of fire). Do not connect the
dishwasher to the domestic electricity supply using a power bar or
an extension cord.
 The dishwasher must not be used in a non-stationary location
(e.g., on a ship).
 Do not install the dishwasher in a room where there is a risk of
frost. Frozen hoses are at risk of tearing or bursting. The reliability of
the electronic control unit may be impaired at temperatures below
freezing point.
 To avoid any damage to the dishwasher, it must only be operated
when it is connected to a fully vented plumbing system.

Warnings and safety instructions
10
 The water-connection pressure needs to be between 50 and
1,000kPa.
 A damaged dishwasher could be dangerous. If the dishwasher
gets damaged, turn it off at the electricity supply immediately and
contact your Miele dealer or Miele Service.
 The manufacturer’s warranty will be invalidated if the appliance is
not repaired by a Miele authorized service technician.
 We recommend replacing defective components with original
spare parts. If original Miele spare parts are installed correctly, Miele
ensures full compliance with safety requirements and the warranty
remains valid.
 During installation, maintenance, and repair work, the dishwasher
must be disconnected from the domestic electricity supply (turn it off
and withdraw the plug from the socket).
 If the power cable is damaged, it must only be replaced with a
specific cable of the same type (available from Miele Service). For
safety reasons, this must only be done by Miele Service or a service
technician authorized by Miele.
 Do not sit the dishwasher on the hose. The hose needs to be free
of kinks and able to move freely after installation. Do not place the
hose or power cord next to a heat source e.g., hot water pipes. Do
not expose the hose or power cord to corrosive substances (e.g.,
chloride). Damage to the hose or power cord could cause electrical
shock or water damage.
Correct installation
 The dishwasher must be installed and connected in compliance
with the supplied installation sheet.
 Be careful before and while installing the dishwasher.
Some metal parts pose a risk of injury/being cut. Wear
protective gloves.

Warnings and safety instructions
11
 The dishwasher must be correctly aligned horizontally to ensure
problem-free operation.
 In order to ensure stability, built-under and integrated dishwashers
must only be installed under a continuous countertop which is
secured to adjacent cabinetry.
 The dishwasher must only be built into a tall unit if additional
safety precautions are taken. In order to safely install the appliance
in a tall unit, please use the tall unit installation kit and observe the
installation sheet provided. Otherwise there is the danger of the unit
tipping over.
 The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half
open (approx. 45° opening angle). It is also important that the door
cannot fall open.
The appliance must only be operated with properly adjusted door
springs.
If the door cannot be adjusted properly, contact Miele Service.
The maximum weight of the front panel that can be aligned with the
factory fitted door springs is 10–12kg (depending on model).
Correct use
 Do not use solvents in the wash cabinet. There is a danger of
explosion.
 Dishwasher detergents can cause burning on the skin and in the
eyes, nose, mouth, and throat. Avoid contact with detergents. Do not
inhale powder detergents. Do not swallow dishwasher detergents.
Seek medical attention immediately if detergent has been swallowed
or inhaled.
 Avoid leaving the dishwasher door open unnecessarily. You could
injure yourself on the opened door or trip over it.
 Do not sit, stand, or lean on the opened door. The dishwasher
could tip over. This could injure you or damage the dishwasher.

Warnings and safety instructions
12
 Dishware may be very hot at the end of the program. Allow
dishware to cool until it is comfortable enough to handle before
unloading them.
 Only use detergent and rinse aid formulated for domestic
dishwashers. Do not use liquid dish soap.
 Do not use any commercial or industrial detergents. These may
cause material damage, and there is a risk of a severe explosive
chemical reaction (such as an explosive oxyhydrogen gas reaction).
 Do not fill the rinse aid reservoir with powder or liquid detergent.
This will cause damage to the rinse aid reservoir.
 Do not fill the AutoDos (depending on model) with powder or
liquid detergent. Loose detergent will damage the AutoDos.
 Do not fill the salt reservoir with powder or liquid detergent.
Dishwasher detergent will damage the water softener.
 Use only special, coarse-grained reactivation salt or other pure
evaporated salt. Other types of salt may contain insoluble
components which can cause the water softener to malfunction.
 In dishwashers with a cutlery basket (depending on model), knives
and forks should be placed with the handles upwards in the basket
for safety reasons. Knives and forks placed with the handles
downwards pose a danger of injury. However, cutlery placed handle
down in the basket will come out cleaner and drier.
 Plastic items which cannot withstand being washed in hot water,
such as disposable plastic containers or plastic cutlery, should not
be cleaned in the dishwasher. The high temperatures in the
dishwasher may cause them to melt or lose shape.
 If you use the timer option (depending on model), the detergent
compartment must be dry. Wipe dry with a cloth first if necessary.
The detergent will clump together if the detergent compartment is
not dry, and this may mean that it is not fully rinsed out.

Warnings and safety instructions
13
Accessories and spare parts
 Only use original Miele accessories. If other parts are used,
warranty, performance, and, if applicable, product liability claims will
be invalidated.
 Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the
discontinuation of your dishwasher.
Transport
 Damage to the dishwasher can compromise your safety. Before
using the dishwasher, check it for any visible transport damage.
Never use a damaged dishwasher.
 Only transport the dishwasher in an upright position so that no
water flows into the electrical controls, as this would cause faults.
 If you wish to transport the dishwasher, empty it and securely
fasten all loose parts such as baskets, hoses, and power cables.
Disposal of your old dishwasher
 Remove the door of the dishwasher so that children cannot
become trapped inside.

Guide to the appliance
14
Machine overview
aDoor locking pins
bTop spray arm
c3D MultiFlex Cutlery Tray (depending
on model)
dUpper basket (depending on model)
eMiddle spray arm
fAeration valve
gLower spray arm
hFilter combination
iSalt reservoir
jData plate
kRinse aid reservoir
lDetergent compartment
mDoor locking pins
nTop spray arm
o3D MultiFlex Cutlery Tray (depending
on model)
pUpper basket (depending on model)
qMiddle spray arm
rAeration valve

Guide to the appliance
15
sLower spray arm
tFilter combination
uSalt reservoir
vData plate
wRinse aid reservoir
xDetergent compartment

Guide to the appliance
16
Control panel
yProgram selection
Normal = Normal
Pots = Pots & pans
Crystal = China & crystal
Quick = QuickIntenseWash
Sani = SaniWash
More = Additional
programs/settings
zDisplay
For further information, see “Display
functions” under “Guide to the
appliance”.
{Start button with indicator light
For starting the selected program.
|IntenseZone button
For increasing the cleaning
performance in the lower basket.
}Express button
For reducing the program cycle time.
~Timer button
For selecting a later program start.
OKbutton
For selecting menu options and
values displayed.
For confirming messages.
buttons
For program selection.
For changing the values displayed.
For scrolling to other menu pages.
Backbutton
For navigating back to the previous
menu or deleting values which have
been set previously.
Program program selection button
For program selection.
Optical interface
For Miele Service.
On/Off button
For turning the dishwasher on and
off.
mProgram selection
Normal = Normal
Pots = Pots & pans
Crystal = China & crystal
Quick = QuickIntenseWash
Sani = SaniWash
More = Additional
programs/settings

Guide to the appliance
17
nDisplay
For further information, see “Display
functions” under “Guide to the
appliance”.
pIntenseZone button
For increasing the cleaning
performance in the lower basket.
sOKbutton
For selecting menu options and
values displayed.
For confirming messages.
tbuttons
For program selection.
For changing the values displayed.
For scrolling to other menu pages.
uBackbutton
For navigating back to the previous
menu or deleting values which have
been set previously.
vProgram program selection button
For program selection.

Guide to the appliance
18
Display functions
The display is used to select or set the
following:
- the program
- the timer
- theSettings 
The display can show the following:
- the program stage
- the estimated time left for the
program to run
- any relevant fault messages and
information
To save energy, the dishwasher
switches off after a few minutes if you
do not press any buttons during this
time.
Press the button to switch the
dishwasher back on.
The OKbutton is used to confirm a
message or setting and also to move to
the next menu or another menu level.
Under More, a scroll bar will
appear in the right of the display. This
offers further options. These options
can be shown using the buttons.
You can alter the dishwasher’s controls
to suit changing requirements in the
Settings menu (see “Settings”).
The option which is selected will have a
check next to it.
To exit a sub-menu again, press the
Backbutton.
If you do not press any buttons for
several seconds, the display will revert
to the previous menu level. You will then
have to enter your settings again.
These operating instructions apply to
several different dishwasher models of
different heights.
The different dishwasher models will
be named as follows:
normal = dishwasher measuring
80.5cm high (built-in appliance)
or 84.5cm high (freestanding
appliance)
XXL = dishwasher measuring 84.5cm
high (built-in appliance).

Caring for the environment
19
Disposal of the packaging
material
The cardboard box and packaging
materials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also the
amount of waste.
Disposal of your old appliance
Electronic and electrical appliances
contain many valuable materials. They
also contain certain materials,
compounds and components which
were essential for the proper
functioning and safe use of the
equipment. These could be hazardous
to your health and to the environment if
disposed of with general waste or if
handled incorrectly. Therefore, please
do not dispose of your old appliance
with general waste.
Consult with local authorities, dealers or
Miele in order to dispose of and recycle
electrical and electronic appliances.
Miele assumes no responsibility for
deleting any personal data left on the
appliance being disposed. Please
ensure that your old appliance is kept
away from children until removal.
Observe safety requirements for
appliances that may tip over or pose an
entrapment hazard.

Initial commissioning
20
Every dishwasher is tested at the
factory. There will be residual water in
the machine from this test. It is not an
indication that the dishwasher has
been used previously.
Opening the door
In some programs the door
automatically opens slightly to assist
the drying process.
This function can be deactivated, if
preferred (see “AutoOpen” under
“Settings”).
To open the door, reach under the
recessed grip and pull the handle.
Open the door fully to disengage the
locking mechanism.
At the end of the program, if the
AutoOpen function is on, the door
locking pins automatically retract.
To prevent a technical fault, do not
hold the door locking pins firmly
when they are retracting.
If the door is opened during operation,
all functions are automatically
interrupted.
Risk of scalding due to hot
water.
During operation, water in the
dishwasher may be very hot.
During operation, only open the door
with extreme caution.
Risk of injury due to door
opening automatically.
The door may open automatically at
the end of a program.
Keep the area around the door free
of obstructions.
