Miele T 8823 C User manual

Operating instructions
for condenser tumble dryer
T 8823 C
To avoid the risk of accidents or
damage to the appliance, it is
essential to read these instructions
before it is installed and used for the
first time. M.-Nr. 07 847 190
en - AU, NZ

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Rather than just throwing these
materials away, please ensure they are
offered for recycling.
Disposal of your old appliance
or machine
Electrical and electronic appliances /
machines often contain materials
which, if handled or disposed of
incorrectly, could be potentially
hazardous to human health and to the
environment. They are, however,
essential for the correct functioning of
your appliance or machine. Therefore,
please do not dispose of your old
machine or appliance with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre and ensure that it presents no
danger to children while being stored
for disposal.
It should be unplugged or disconnected
from the mains electricity supply by a
competent person.
The plug must be rendered useless
and the cable cut off directly behind the
appliance or the machine to prevent
misuse.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
–Make sure that your laundry is
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
– Load according to the optimum
amount of laundry recommended for
the programme being used (see
Programme chart).
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
–Make sure the room in which the
dryer is located is well ventilated.
–Make sure the fluff filters are clean
before using the dryer.
–Check the condenser unit from time
to time and clean it when necessary.
Caring for the environment
2

Caring for the environment..........................................2
Warning and Safety instructions .....................................6
Operating the tumble dryer.........................................15
Control panel .....................................................15
Notes on laundry care .............................................17
Care symbols.....................................................17
Tips on drying ....................................................17
How to dry correctly ..............................................18
Brief instructions ..................................................18
Extra options/Delay start...........................................21
Extra options .....................................................21
Low temperature................................................21
Buzzer........................................................21
Delay start .......................................................21
Programme chart .................................................22
Changing the programme sequence .................................25
Once a programme has started ......................................25
- changing the programme........................................25
- cancelling the programme and then selecting a different programme .....25
- cancelling the programme and then removing the laundry ..............25
Changing Delay start ...............................................25
Adding or removing laundry after a programme has started ................25
Time remaining ...................................................25
Electronic system lock ............................................26
Contents
3

Cleaning and care ................................................27
Emptying the condensed water container...............................27
Cleaning the fluff filters .............................................28
Cleaning them whilst dry .........................................28
Cleaning them with water .........................................29
Cleaning the tumble dryer ...........................................29
Cleaning the condenser unit .........................................30
Removing the condenser unit......................................30
Checking the condenser unit ......................................31
Cleaning the condenser unit.......................................31
Replacing the condenser unit......................................32
Problem solving guide ............................................33
Problem solving guide ..............................................33
Check and fault messages in the display ...............................33
An unsatisfactory drying result .......................................36
Other problems ...................................................37
Changing the lamp ................................................39
After Sales service................................................40
Future updates (PC) ...............................................40
Optional accessories ...............................................40
Installation ......................................................41
Front view........................................................41
Rear view ........................................................42
Installation site ....................................................42
Transporting the machine to its installation site ........................42
Building under a continuous worktop / in a kitchen run ..................42
Levelling the machine............................................43
Room ventilation ................................................43
Washer-dryer stack..............................................43
Before moving the tumble dryer again (e.g. when moving houses).........43
External condensed water outlet ......................................44
Arranging the drain hose .........................................44
External drainage via a sink or gully ................................45
Installation conditions requiring a non-return valve .....................45
Electrical connection ...............................................47
Contents
4

Consumption data ................................................48
Technical data ...................................................49
Programmable functions...........................................50
Extending the range of the drying level for the "Cottons" programme..........50
Extending the drying level for the "Minimum iron" programme ...............51
Anti-crease setting.................................................52
Altering the volume of the buzzer .....................................53
Extending the drying level for the "Automatic plus" programme ..............54
Extending the cooling down time .....................................55
Standby .........................................................56
Memory function ..................................................58
Clean out airways indicator ..........................................59
Keypad tone .....................................................60
Adjusting the dryer's electronics for very soft water .......................61
Extending the drying level range......................................62
Contents
5

~It is essential to read these instructions.
This tumble dryer conforms to current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
~This tumble dryer is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
~This tumble dryer must only be used to dry items which have
been washed in a water solution and which are marked on the
manufacturer's care label as being suitable for tumble drying. "Dry
cleaning kits" for freshening up garments in a tumble dryer are
increasingly available on the market. If using, do so at your own risk,
and follow the instructions provided on the packaging.
Any other usage is not supported by the manufacturer and could be
dangerous. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation of the tumble dryer.
Warning and Safety instructions
6

~The tumble dryer is not intended for outdoor use.
~This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge, unless they are supervised whilst
using it or have been shown how to use it correctly by a person
responsible for their safety.
~This tumble dryer must not be installed and operated in mobile
installations (e.g. on a ship).
Safety with children
~Keep children away from the tumble dryer at all times. It is not a
toy! To avoid the risk of injury do not allow them to play on or near it
or to play with its controls. Supervise children whilst you are using it.
~Older children may only use it if its operation has been clearly
explained to them, and they are able to use it safely, recognising the
dangers of incorrect use.
Warning and Safety instructions
7

Technical safety
~Before setting up the tumble dryer, check it for any externally
visible damage.
Do not install or use a damaged tumble dryer.
~Before connecting the tumble dryer, ensure that the connection
data on the data plate (voltage and connected load) match the
mains electricity supply. If in any doubt, consult a qualified
electrician.
~The electrical safety of this tumble dryer can only be guaranteed
when continuity is complete between it and an effective earthing
system which complies with current local and national safety
regulations. It is most important that this basic safety requirement is
present and regularly tested, and where there is any doubt, the
household wiring system should be inspected by a qualified
electrician. Miele cannot be held liable for the consequences of an
inadequate earthing system (e.g. electric shock).
~Do not connect the tumble dryer to the mains electricity supply by
an extension lead. Extension leads do not guarantee the required
safety of the tumble dryer (e.g. danger of overheating).
~Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele approved service technician. Ensure current
is not supplied to the tumble dryer until after maintenance or repair
work has been carried out.
~Faulty components must only be replaced by genuine Miele
original spare parts. Only when these parts are fitted can the safety
standards of the tumble dryer be guaranteed.
Warning and Safety instructions
8

~If the connection cable is faulty, it must only be replaced by a
Miele approved service technician to protect the user from danger.
~In the event of a fault or for cleaning purposes, the tumble dryer
is only completely isolated from the electricity supply when:
–it is switched off at the wall socket and the plug is withdrawn, or
–it is switched off at the mains, or
–the mains fuse is disconnected, or the screw-out fuse is removed
(in countries where this is applicable).
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the tumble dryer
and its surroundings in a clean condition at all times. Any damage
which may be caused by cockroaches or other vermin will not be
covered by the warranty.
~Do not make any alterations to the tumble dryer, unless
authorised to do so by Miele.
Warning and Safety instructions
9

Correct use
,Caution! Risk of fire.
To avoid the possible danger of fire, please
read these warnings carefully.
,A clogged filter is a fire hazard!
The fluff filter must be cleaned after every programme.
~Remove all objects from pockets such as lighters and matches.
~To prevent the risk of fire, the following textiles must not be dried
in this tumble dryer:
– Items which have not been washed.
– Items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other
desposits (such as cosmetics, lotions etc).
If items have not been thoroughly cleaned, there is a danger that
these might ignite when heated, even after they have been
removed from the dryer at the end of the programme.
–Items that have been soiled with substances such as cooking oil,
acetone, petrol, kerosene, spot removers, turpentine, waxes, wax
removers and other chemicals (e.g. mops and floor cloths) should
be washed in hot water with extra detergent before being dried in
the tumble dryer.
–Items which have been splashed with hair lacquer, hair spray, nail
polish remover or similar substances.
Warning and Safety instructions
10

When washing such heavily soiled items, ensure that you use
sufficient detergent and select a high temperature. If in doubt,
wash the items several times.
~Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat.
If the heat cannot escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-affected items can prevent
heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics contaminated with vegetable or
cooking oil, or hair care products, be placed in a tumble dryer, they
should first be washed in hot water with extra detergent - this will
reduce, but not eliminate, the hazard.
~To prevent the risk of fire, the following textiles or products must
not be dried in this tumble dryer:
– Items which have been dry-cleaned (for example with a chemical
treatment).
–Fabrics which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
–Fabrics which contain padding or fillings (e.g. pillows, jackets). If
these were damaged, the filling could get out with the risk of
igniting in the dryer.
Warning and Safety instructions
11

~In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry
self-igniting). The programme is not finished until the cooling down
phase is complete.
Ensure that you always wait until the end of the programme before
removing the laundry.
~Warning: Do not switch the tumble dryer off before the end of the
drying programme. If this was done, remove and spread out all
items quickly so that the heat is dissipated.
~Fabric conditioner and similar products must be used according
to the instructions on the manufacturer's packaging.
~The tumble dryer is not to be used if industrial chemicals have
been used to clean it.
Warning and Safety instructions
12

~The dryer must not be used without the fluff filters in place or if
the fluff filters are damaged in any way.
~The fluff filters must be cleaned regularly.
~The dryer must not be used without the condenser unit in place.
~The fluff filters must be thoroughly dried after cleaning. Damp or
wet filters could cause operational faults.
~Do not install the tumble dryer in a room where there is a risk of
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly.
There is a risk of damage if the condensed water is allowed to
freeze in the pump, hoses and / or condensed water container.
The ambient room temperature should be between +2°C and
+35°C.
~If the water is drained externally through the drain hose instead of
being collected in the condensed water container, make sure the
drain hose is securely attached if you hang it in a sink or basin to
avoid the hose slipping and the water causing damage.
~Condensed water is not drinking water.
It can cause health problems in both people and animals.
~Always keep the area around the tumble dryer free of dust and
fluff. Dust drawn into the tumble dryer can cause blockages in the
condenser unit over time.
~Do not let anyone sit or lean on the door, as this can cause the
tumble dryer to tip up.
Warning and Safety instructions
13

~Always close the door after use. This way you will avoid the
danger of:
–Children climbing onto or into the dryer or hiding things in it.
–Pets or other small animals climbing into it.
~The tumble dryer must not be hosed down.
Accessories
~Only use genuine Miele spare parts and accessories with this
appliance.
If non-Miele parts are used, warranty, performance and product
liability claims may be invalidated.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
Warning and Safety instructions
14

Control panel
aLow temperature button
Delicate fabrics are dried at a lower
temperature.
bDrying level button
Indicator lights show the selected
drying level.
cDisplay
See the next page.
dDelay start button
This button is used for:
- Delaying the start of a programme.
- Selecting Warm air/Cool air.
eBuzzer button
An audible tone sounds at the end of
the programme.
fPerfect Dry indicator light
For all drying levels. See the next
page.
gCheck lights
See Problem solving guide and After
Sales service.
hStart/Stop button
For starting the programme selected
and cancelling a programme once it
has started.
The button flashes when a
programme is selected and then is
on constantly when the programme
has started.
iProgramme selector
Indicator lights show the selected
programme.
jDoor button
Pressing this button will open the
door even when the dryer is
switched off at the mains.
kjk button
For switching the tumble dryer on
and off.
Operating the tumble dryer
15

The following information appears in
the display:
–Programme duration.
–Programme sequence
Drying
Cooling down
Finish
–Check and fault messages
The following functions are selected
via the display
–Programme duration
Warm air, Cool air
– Delay start
You can delay the start of a
programme.
Once the Delay start time has
finished, the programme begins
automatically.
– Programmable functions
The programmable functions are
used to alter the machine's
electronics to suit changing
requirements. See "Programmable
functions" for more details.
Perfect Dry indicator light
The Perfect Dry system measures the
laundry's residual moisture in
programmes with drying levels and
provides a more precise drying result.
After starting the programme, the
electronics will measure the duration of
the programme (Estimated time
remaining). The Perfect Dry indicator
light will flash during this time.
The programme duration will be shown
after a short time and the indicator light
will go out.
Once the selected drying level has
been reached, the Perfect Dry indicator
light will remain on until the end of the
programme.
The Perfect Dry indicator light always
remains dark during the following time
controlled programmes: Woollens
handcare, Cool air, Warm air, Gentle
smoothing.
Programme duration /
Estimated time remaining
The expected time will automatically be
displayed (Estimated time remaining).
The following factors all affect the
estimated time remaining: Residual
moisture content after spinning; type of
fabric; size of load; room temperature;
fluctuations in power supply.
The electronics continually assess
conditions in the tumble dryer and
adjust the estimated time remaining for
a more accurate reading. Because of
this, the time displayed can alter during
the course of a programme.
In the same way, programmes may
finish early. This can happen with
particularly fine fabrics, very small
loads or if items were partly dry
beforehand.
Operating the tumble dryer
16

Care symbols
Drying
qNormal/higher temperature.
rReduced temperature:
Select Low temperature for
sensitive fabrics.
sDo not tumble dry
Ironing
IVery hot.
HHot.
GWarm.
JDo not iron.
Tips on drying
– See the "Programme chart" for
maximum recommended loads for
each programme.
Overloading can cause unnecessary
wear and tear to the laundry, give a
disappointing drying result and
cause more creasing.
–Do not tumble dry loopknit garments!
Spin garments for at least 30
seconds after washing.
–Open jackets so that they can dry
evenly.
–Use the Automatic plus programme
for drying mixed loads of cottons,
colours and minimum iron fabrics.
–Woollen fabrics and wool blends
tend to shrink and become matted if
dried in a tumble dryer. These
fabrics should only be dried using
the Woollens handcare programme.
–Down-filled fabrics have linings
which have a tendendency to shrink,
depending on the quality of the item.
These fabrics should only be dried in
the Smoothing programme.
–Pure linen should only be machine
dried if specified as suitable by the
manufacturer on the care label.
Otherwise the surface of the fabric
may become rough.
–Loopknit garments (e.g. T-shirts,
underwear) have a tendency to
shrink after the first wash. Therefore:
To avoid further shrinking, do not
overdry these fabrics. When buying
loopknit garments, it is advisable to
take their shrinkage properties into
account.
– Creasing in minimum iron fabrics
increases with the size of the load.
This applies in particular to very
sensitive fabrics (e.g. shirts,
blouses).
If in doubt, reduce the size of the
load.
–Starched laundry can be dried in the
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
–New dark coloured garments should
be washed separately from light
coloured garments. Do not dry these
together with light garments as they
may lose their colour (also onto
plastic components in the tumble
dryer). Dark coloured fibres can also
settle on light coloured garments and
vice versa.
Notes on laundry care
17

Brief instructions
The headings numbered (A,B,C...)
show the operating sequence and can
be used as a brief guide to using your
machine.
ASort the laundry
Separate the washed laundry and sort it
according to...
. . . the drying level required,
. . . the type of fibre or weave,
. . . size,
. . . the moisture content after spinning.
In this way an even drying result will be
achieved.
,Make sure that objects, e.g.
detergent dispensing balls, have
been removed from the laundry.
They could melt and cause damage
to the dryer or the laundry.
– Check seams and stitching to ensure
that padding and linings are intact.
–Remove all objects from pockets
such as lighters and matches.
–Fasten duvet covers and pillow
cases to prevent small items from
being rolled up inside them.
–Fasten zips, hooks and eyes etc.
–Tie fabric belts and apron strings.
–Sew in or remove underwiring from
bras.
BSwitch on the tumble dryer
The tumble dryer may be switched on
after loading, saving energy as the light
will not come on.
^Switch on the dryer by pressing the
jk button.
CLoad the tumble dryer
^Press the Door button to open the
door.
^Load the laundry loosely into the
drum.
Do not overload the drum. See the
"Programme chart" for
recommended loads for each
programme.
Overloading can cause unnecessary
wear and tear to the laundry and
give a disappointing drying result.
^Before closing the door, make sure
the fluff filter is correctly positioned in
the door.
Check the laundry is right inside the
drum so that it cannot get trapped or
damaged when the door is shut.
^Shut the door either with a gentle
swing, or lean against it and push it
shut.
How to dry correctly
18

DSelect a programme
^Select the programme you want.
The relevant indicator light will come
on. Indicator lights for drying levels or
Extra options and times may also be
displayed.
Programmes with drying levels
–Cottons, Minimum iron, Delicates,
Proofing, Express, Automatic plus,
Denim, Shirts
^Press the button repeatedly until the
relevant indicator light comes on
(with almost all programmes).
Four drying levels can be selected from
Cottons and Express. The selection of
the other programmes is either limited
or not changeable.
Note
You can extend the range of drying
levels for some of the programmes (see
"Programmable functions").
Woollens handcare, Gentle
smoothing
–this programme cannot be changed.
Select Cool air/Warm air duration
The indicator light for the Delay start
button will flash when this function is
selected.
^Press the Delay start button until the
required time appears in the display.
Selectable functions:
–Cool air:20 minutes up to 1hour.
–Warm air:15 minutes up to 2hours.
ESelect any Extra options / Delay
start
^By pressing the relevant button, you
can select:
Low temperature, Buzzer, Delay start
(see "Extra options/Delay start").
Anti-crease (see next page) is always
switched on.
However: Delay start is not possible in
combination with Warm air/Cool air.
How to dry correctly
19

FStarting the programme
The indicator light for the Start/Stop
button will flash when a programme is
being selected. The flashing indicates
that a programme can be started.
^Press the Start/Stop button.
The Start/Stop button will now light up.
Perfect Dry only flashes/illuminates
during programmes with drying levels.
It remains dark during time controlled
programmes (see "Operating the
tumble dryer").
Note: The duration shown in the display
is only an estimate and can change.
Before the end of a programme
The heating phase is followed by a
cooling down phase (Cooling down
lights up). The programme is not
finished until the cooling down phase
has been completed.
There is no cooling down phase with
Woollens handcare.
GRemove the laundry when the
programme has finished.
0and Finished will appear in the
display to indicate that the programme
has finished. The buzzer (if selected)
will sound at intervals.
After the programme has finished, the
drum will continue to rotate for 2 hours
at intervals if the garments are not im-
mediately removed. This reduces
creasing.
There is no anti-crease with: Woollens
handcare.
^Press the Door button.
^Open the door.
^Remove the laundry.
Check that all items have been
removed from the drum. If items are
left in the dryer, they could be
damaged by overdrying when the
dryer is next used.
If the dryer is switched on and the door
is opened, the drum lighting will come
on. It will go out a few minutes later to
save energy.
^Switch off the dryer by pressing the
jk button.
^Clean the fluff filters.
^Close the door.
^Empty the condensed water
container (unless the dryer has been
connected for external drainage).
^Check the condenser unit
intermittently and clean if necessary
(see "Cleaning and care").
Using the Cottons Normal Plus
programme is recommended for a
mixed cotton load and is the programme
used in energy consumption tests to
AS/NZS 2442 (Refer to
www.energyrating.gov.au website for
consumption data).
How to dry correctly
20
