Miele FN 35402 i User manual

Operating and installation instructions
Freezer
To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.
en – GB M.-Nr. 10 199 080

Contents
2
Warning and Safety instructions .......................................................................... 4
Caring for the environment................................................................................. 12
How to save energy ............................................................................................. 13
Guide to the appliance......................................................................................... 15
Control panel.......................................................................................................... 15
Switching on and off............................................................................................ 18
Before using for the first time................................................................................. 18
Operating the appliance......................................................................................... 18
Switching off for longer periods of time................................................................. 19
The correct temperature ..................................................................................... 20
Temperature display............................................................................................... 20
Setting the temperature ......................................................................................... 21
Using Super freeze............................................................................................... 22
Temperature and door alarm .............................................................................. 23
Temperature alarm ................................................................................................. 23
Switching the temperature alarm off early........................................................ 23
Door alarm ............................................................................................................. 24
Selecting further settings.................................................................................... 25
Safety lock ......................................................................................................... 25
Audible tones .................................................................................................... 26
Display brightness ............................................................................................. 27
Sabbath mode .................................................................................................... 28
Adjusting the interior fittings .............................................................................. 30
Removing freezer drawers on telescopic runners.................................................. 30
Removing the shelves............................................................................................ 30
Freezing and storing food ................................................................................... 31
Maximum freezing capacity................................................................................... 31
Freezing fresh food ................................................................................................ 31
Storing frozen food ................................................................................................ 31
Home freezing........................................................................................................ 32
Hints on home freezing..................................................................................... 32
Packaging ......................................................................................................... 32
Before placing food in the freezer..................................................................... 33
Placing food in the freezer ................................................................................ 33
Defrosting............................................................................................................... 34

Contents
3
Ice cubes................................................................................................................ 35
Cooling drinks........................................................................................................ 35
Cool pack............................................................................................................... 35
Automatic defrosting........................................................................................... 36
Cleaning and care................................................................................................ 37
Before cleaning ...................................................................................................... 38
To remove the telescopic rails .......................................................................... 38
Cleaning the interior and accessories.................................................................... 39
Door seal................................................................................................................ 40
Ventilation gaps...................................................................................................... 40
Problem solving guide......................................................................................... 42
Noises ................................................................................................................... 49
Miele@home ......................................................................................................... 50
After Sales / Guarantee ....................................................................................... 52
Information for test institutes ............................................................................. 53
Information for dealers........................................................................................ 54
Demo mode ........................................................................................................ 54
Electrical connection........................................................................................... 56
Installation ............................................................................................................ 57
Side-by-side........................................................................................................... 57
Location ................................................................................................................. 57
Ventilation .............................................................................................................. 58
Before installing the appliance............................................................................... 60
Does your old appliance have a different hinging mechanism?............................ 60
Building-in dimensions ....................................................................................... 61
Limiting the opening angle of the door.............................................................. 62
Changing the door hinging.................................................................................. 63
Installing the appliance ....................................................................................... 67

Warning and Safety instructions
4
This appliance complies with all statutory safety requirements.
Please note that inappropriate use can lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the appliance,
please read these instructions carefully before using it for the first
time. They contain important notes on installation, safety, use and
maintenance.
Miele cannot be held liable for non-compliance with these instruc‐
tions.
Keep these instructions in a safe place and ensure that new users
are familiar with the contents. Pass them on to any future owner.
Correct application
 This appliance is intended for use in domestic households and
similar working and residential environments.
It is not intended for outdoor use.
 It must only be used as a domestic appliance to store deep frozen
food, freeze fresh food and to make ice.
Any other usage is not supported by the manufacturer and could be
dangerous.

Warning and Safety instructions
5
 This appliance is not suitable for storing and keeping cool medi‐
cines, blood plasma, laboratory preparations or other such materials
or products. Incorrect use of the appliance for such purposes can
cause deterioration of the items stored. The appliance is not suitable
for use in areas where there is a risk of explosion.
Miele cannot be held liable for damage resulting from improper or in‐
correct use of the appliance.
 The appliance can only be used by people with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
if they are supervised whilst using it, or have been shown how to use
it in a safe way and recognise and understand the consequences of
incorrect operation.
Safety with children
 Children under 8 years of age must be kept away from the appli‐
ance unless they are constantly supervised.
 Children 8 years and older may only use the appliance unsuper‐
vised if they have been shown how to use it in a safe way and rec‐
ognise and understand the consequences of incorrect operation.
 Children must not be allowed to clean or maintain the appliance
unsupervised.
 Please supervise children in the vicinity of the appliance and do
not let them play with it.
 Danger of suffocation. Packaging, e.g. plastic wrappings, must be
kept out of the reach of babies and children. Whilst playing, children
could become entangled in packaging or pull it over their head and
suffocate.
Technical safety
 The coolant system is tested for leaks. This appliance complies
with statutory safety requirements and the appropriate EU guide‐
lines.

Warning and Safety instructions
6
 This appliance contains the coolant Isobutane (R600a), a natural
gas which is environmentally friendly. Although it is flammable, it
does not damage the ozone layer and does not increase the green‐
house effect.
The use of this coolant has, however, led to a slight increase in the
noise level of the appliance. In addition to the noise of the compres‐
sor, you might be able to hear the coolant flowing around the sys‐
tem. This is unavoidable, and does not have any adverse effect on
the performance of the appliance.
Care must be taken during the transportation and setting up of the
appliance that no parts of the cooling system are damaged. Leaking
coolant can damage the eyes.
In the event of any damage:
– avoid naked flames or anything which creates a spark,
– disconnect the appliance from the mains electricity supply,
– ventilate the room where the appliance is located for several mi‐
nutes, and
– contact the Miele Service Department.
 The more coolant there is in an appliance, the larger the room it
should be installed in. In the event of a leakage, if the appliance is in
a small room, there is the danger of combustible gases building up.
For every 8 g of coolant at least 1 m3of room space is required. The
amount of coolant in the appliance is stated on the data plate inside
the appliance.
 To avoid the risk of damage to the appliance, make sure that the
connection data (fuse rating, frequency and voltage) on the data
plate corresponds to the household supply.
Check that this is the case before connecting the appliance. Consult
a qualified electrician if in any doubt.
 The electrical safety of this appliance can only be guaranteed
when correctly earthed. It is essential that this standard safety re‐
quirement is met. If in any doubt please have the electrical installa‐
tion tested by a qualified electrician.

Warning and Safety instructions
7
 Reliable and safe operation of this appliance can only be assured
if it has been connected to the mains electricity supply.
 If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
 Do not connect the appliance to the mains electrical supply by a
multi-socket adapter or extension lead. These are a fire hazard and
do not guarantee the required safety of the appliance.
 Do not use in a damp or wet environment (e.g. garage or utility
room). Moisture could reach live components or the electrical con‐
nection and cause a short circuit.
 This appliance must not be used in a non-stationary location (e.g.
on a ship).
 Do not use a damaged appliance. It could be dangerous. Check
the appliance for visible signs of damage.
 For safety reasons, this appliance may only be used when it has
been fully installed.
 The appliance must be isolated from the electricity supply during
installation, maintenance and repair work.
 Unauthorised installation, maintenance and repairs can cause
considerable danger for the user.
Installation, maintenance and repairs must only be carried out by a
Miele authorised technician.
 While the appliance is under guarantee, repairs should only be un‐
dertaken by a Miele authorised service technician. Otherwise the
guarantee is invalidated.
 Miele can only guarantee the safety of the appliance when genu‐
ine original Miele replacement parts are used. Faulty components
must only be replaced by Miele spare parts.

Warning and Safety instructions
8
Correct use
 The appliance is designed for use within a certain climate range
(ambient temperatures), and should not be used outside this range.
The climate range for your appliance is stated on the data plate in‐
side the appliance. Installing it in a room with too low an ambient
temperature, e.g. a garage, will lead to the appliance switching off
for longer periods so that it cannot maintain the required tempera‐
ture.
 Do not cover or block the air vents as this could impair the effi‐
ciency of the appliance, increase the electricity consumption and
could cause damage to the components.
 If storing food which contains a lot of fat or oil in the appliance,
make sure that it does not come into contact with plastic compo‐
nents as this could cause stress cracks or break the plastic.
 Do not store explosive materials in the appliance or any products
containing propellants (e.g. spray cans). Electrical components
could cause flammable vapours to ignite. Danger of fire and explo‐
sion.
 Do not operate any electrical equipment (e.g. an electric ice
cream maker) inside the appliance. Danger of sparking and explo‐
sion.
 Do not store cans or bottles containing carbonated drinks or liq‐
uids which could freeze in the freezer. The cans or bottles could ex‐
plode. Danger of injury and damage to the appliance.
 When cooling drinks quickly in the freezer, make sure bottles are
not left in for more than one hour; otherwise they could burst, caus‐
ing injury or damage.
 Never handle frozen food or the metal parts of the appliance with
wet hands. Your hands may freeze to the frozen food or to the metal.
Danger of frost burn.

Warning and Safety instructions
9
 Do not take ice cubes out with your bare hands and never place
ice cubes or ice lollies in your mouth straight from the freezer.
The very low temperature of the frozen ice or lollies can cause frost
burn to the lips and tongue.
 Do not refreeze partially or fully defrosted food. Consume defros‐
ted food as soon as possible, as it will lose its nutritional value and
spoil if left for too long. Defrosted food may only be re-frozen after it
has been cooked.
 Observe the manufacturer's "use-by" dates and storage instruc‐
tions given on food to avoid the risk of food poisoning. Storage
times will depend on several factors, including the freshness and
quality of the food, as well as the temperature at which it is stored.
 Only use genuine original Miele accessories and spare parts with
this appliance. Using accessories or spare parts from other manu‐
facturers will invalidate the guarantee, and Miele cannot accept lia‐
bility.

Warning and Safety instructions
10
Cleaning and care
 Do not use any oils or grease on the door seal, as these will cause
the seal to deteriorate and become porous with time.
 Do not use a steam cleaning appliance to clean or defrost this ap‐
pliance.
Steam could reach electrical components and cause a short circuit.
 Sharp edged or pointed objects will damage the evaporator,
causing irreversible damage to the appliance. Do not use to sharp
edged or pointed objects to
– remove frost and ice,
– separate frozen foods or remove ice trays.
 Do not place electric heaters or candles in the appliance to de‐
frost it. These can damage the plastic parts.
 Do not use defrosting sprays or de-icers, as they could contain
substances which could damage the plastic parts or which might
cause the build-up of gases and pose a danger to health.

Warning and Safety instructions
11
Transporting the appliance
 Always transport the appliance in an upright position and in its
original transport packaging to avoid damage in transit.
 Danger of injury and damage. The appliance is very heavy and
must be transported by two people.
Disposal of your old appliance
 Before disposing of an old appliance, first make the door latch or
lock unusable.
This way you will prevent children from accidentally locking them‐
selves in and endangering their lives.
 Splashes of coolant can damage the eyes. Be careful not to dam‐
age any part of the pipework whilst awaiting disposal, e.g. by
– puncturing the coolant channels in the condenser,
– bending any pipework, or
– scratching the surface coating.

Caring for the environment
12
Disposal of the packing mate‐
rial
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur‐
ing process and also reduces the
amount of waste in landfill sites.
Disposal of your old appliance
Electrical and electronic equipment of‐
ten contain valuable materials. They al‐
so contain materials which, if handled
or disposed of incorrectly, could be po‐
tentially hazardous to human health and
to the environment. They are, however,
essential for the correct functioning of
your appliance. Please do not therefore
dispose of it with your household
waste.
Please dispose of it at your local com‐
munity waste collection / recycling cen‐
tre.
Take care not to damage the pipework
at the back of it before or during trans‐
portation to an authorised collection
depot.
In this way, coolant in the pipework and
oil in the compressor will be contained,
and will not leak into the environment.
Please ensure that your old appliance
presents no danger to children while
being stored awaiting disposal. See
"Warning and Safety instructions" for
more information.

How to save energy
13
Normal energy consump‐
tion Increased energy con‐ sumption
Installation site /
Maintenance In a ventilated room. In an enclosed, unventilated room.
Protected from direct sun‐
light. In direct sunlight.
Not near to a heat source
(radiator, oven). Near to a heat source (radia‐ tor, oven).
Where the ideal ambient
room temperature is approx.
20 °C.
Where there is a high ambi‐
ent room temperature.
Ventilation gaps uncovered
and dusted regularly. Ventilation gaps covered or dusty.
Temperature
setting Freezer section -18 °C The lower the temperature in the appliance, the higher the
energy consumption.

How to save energy
14
Normal energy consump‐
tion Increased energy con‐ sumption
Use Drawers and shelves ar‐
ranged as they were when
the appliance was delivered.
Only open the door when
necessary and for as short a
time as possible. Store food
in an organised way.
Frequent opening of the
door for long periods will
cause a loss of coldness.
The appliance works harder
to cool down and the com‐
pressor runs for longer peri‐
ods.
Take an insulated cool bag
when shopping and load
food in the appliance as
soon as possible. Replace
any food removed as quickly
as possible, before it begins
to thaw.
Allow hot food and drinks to
cool down before placing
them in the appliance.
Hot food or food at room
temperature raises the tem‐
perature inside the appli‐
ance. The appliance works
harder to cool down and the
compressor runs for longer
periods.
Store food well packaged. The evaporation or conden‐
sation of liquids will cause a
loss of coldness.
Do not over-fill the appliance
to allow air to circulate.

Guide to the appliance
15
Control panel
aOn/Off sensor
for the whole appliance
bOptical interface
(for Service technicians only)
cOn/Off sensor the Super freeze func‐
tion
dFor setting the temperature
(= colder),
Selector sensor in settings mode
eOK sensor for confirming a selection
fFor setting the temperature
(= warmer),
Selector sensor in settings mode
gSensor for accessing or leaving set‐
tings mode
hFor switching off the door alarm
iDisplay with temperature and sym‐
bols (symbols only visible in settings
mode, in the event of an alarm/
message; see table for explanation of
symbols)

Guide to the appliance
16
Symbols
Symbol Meaning Function
Safety lock Prevents the appliance being switched off,
the temperature being altered, Super freeze
being switched on and settings being al‐
tered by mistake.
Audible tones Choice of sensor tone and door and tem‐
perature alarm tone
Miele@home Only visible when a communication module
is fitted and signed on (see "Miele@home")
SmartGrid Only visible when a communication module
is fitted and signed on (see "Miele@home")
Display brightness set‐
tings For adjusting the brightness of the display
Sabbath mode For switching Sabbath mode on and off
Mains connection Confirms that the appliance is connected
to the electricity supply when it is not
switched on; flashes in the event of a pow‐
er cut
Alarm Lights up when there is a door alarm; flash‐
es when there is a temperature alarm, pow‐
er cut or a fault
Demo mode
(only visible when
Demo mode is switch‐
ed on)
For switching off Demo mode

Guide to the appliance
17
This drawing is for illustration purposes only.
aControl panel
bInterior lighting
cFrost free unit
dTop freezer drawer, can also be used
as a freezing tray
eFreezer drawers (number depends
on model)

Switching on and off
18
Before using for the first time
Packaging material
Remove all packaging material from
the inside of the appliance.
Cleaning
Please refer to the relevant instruc‐
tions in "Cleaning and care".
Clean the inside of the appliance and
the accessories.
Operating the appliance
A light touch of the finger on the sen‐
sors is all that is required to operate this
appliance.
A tone will sound each time a sensor is
touched. You can deactivate this, if you
wish (see "Selecting further settings -
Audible tones").
Switching on
When the appliance is connected to the
electrical supply, the mains connection
symbol will appear in the display af‐
ter a short while.
Touch the On/Off sensor.
The mains connection symbol goes
out and the temperature appears in the
display.
Two bars will flash in the display while
the current temperature is above 0 °C.
The appliance begins to cool.
The temperature display and the alarm
symbol will flash at the same time
until the required temperature is
reached.
When the door is opened, the interior
lighting comes on and the LED lighting
becomes brighter until it reaches its
maximum brightness.
To enable the temperature to get suf‐
ficiently cold inside the appliance, al‐
low the appliance to run for a few
hours before placing food in it.

Switching on and off
19
Switching off
Touch the On/Off sensor.
If this does not work, the safety lock
is still activated.
The temperature display will go out and
the mains connection symbol  will
appear.
The cooling process will be switched
off.
Switching off Sabbath mode
The appliance can be switched off di‐
rectly at any time.
Touch the On/Off sensor.
The temperature display will go out and
the mains connection symbol  will
appear.
The cooling process will be switched
off.
When the appliance is switched
back on again, Sabbath mode is de‐
activated.
Switching off for longer peri‐
ods of time
If the appliance is not going to be used
for a longer period of time, e.g. whilst
on holiday:
switch the appliance off,
disconnect it from the mains,
clean the appliance and
leave the door slightly ajar to air the
appliance.
If, during a long absence, the appli‐
ance is switched off but not cleaned
and the door(s) left shut, there is a
danger of mould and odours building
up inside the appliance.

The correct temperature
20
It is very important to set the correct
temperature for storing food in the ap‐
pliance. Micro-organisms will cause
food which is not stored at the correct
temperature to deteriorate rapidly. Tem‐
perature influences the growth rate of
these micro-organisms. Reducing the
temperature reduces their growth rate.
To freeze fresh food and to store frozen
food for a long time, a temperature of
-18 °C is required. At this temperature
the growth of micro-organisms is gen‐
erally halted. As soon as the tempera‐
ture rises above -10 °C, the micro-or‐
ganisms become active in the food
again so that it cannot be kept as long.
For this reason, partially defrosted or
fully defrosted food must not be re-fro‐
zen. Food may be re-frozen once it has
been cooked, as the high temperatures
achieved when cooking destroy most
micro-organisms.
The temperature in the appliance will
rise:
– the more often the door is opened
and the longer it is kept open,
– the more food that is stored in it,
– the warmer the food is which is being
put into it,
– the higher the ambient temperature
surrounding the appliance. The appli‐
ance is designed for use within spe‐
cific ambient temperatures (climate
range). Do not use in ambient tem‐
peratures for which it is not de‐
signed.
Temperature display
In normal operation the temperature
display shows the average, current
temperature in the freezer.
If the temperature is not within the nor‐
mal temperature display range, dashes
will flash in the display.
Depending on the ambient temperature
and the temperature setting, it can take
the appliance a few hours to reach the
temperature required.
If the temperature in the freezer re‐
mains above -18 °C for a long time,
check that the frozen food has not
started to defrost. If it has, check
that the food is safe to use and if it
is, then use it as soon as possible.
