Miele CS 1028 User manual

Operating and installation instructions
Gas hob
CS 1028 (Town Gas or LP Gas)
To avoid the risk of accidents or
damage to the appliance it is
essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 07 206 050
en-HK

GThis appliance can be used in countries other than those specified on the
appliance. It is, however, set up for connection to the gas and electricity
supplies in the countries specified. For use in other countries please contact
the Miele spare parts or customer service department in your country.
DDas Gerät ist auch für den Gebrauch in anderen als auf dem Gerät
angegebenen Bestimmungsländer zugelassen. Die landesspezifische
Ausführung und die Anschlussart des Gerätes haben wesentlichen Einfluss auf
den einwandfreien und sicheren Betrieb. Für den Betrieb in einem anderen als
auf dem Gerät angegebenen Bestimmungsland wenden Sie sich bitte an den
für das Land zuständigen Kundendienst.
EEl aparato está autorizado para el uso en países diferentes a los países de
destino indicados. La ejecución específica para cada país y el tipo de
conexión del aparato influyen de forma decisiva en el funcionamiento correcto
y seguro. Para el funcionamiento en un país diferente al país de destino
indicado en el aparato, consulte al Servicio Post-venta autorizado para el país.
FCet appareil est également homologué dans des pays différents de ceux
mentionnés sur l'appareil. Pour que l'appareil fonctionne parfaitement et en
toute sécurité, il est important de disposer de l'exécution spécifique au pays et
du type de raccordement approprié. Pour le fonctionnement dans un pays
autre que celui spécifié sur l'appareil, veuillez vous adresser au service
après-vente du pays où sera installé l'appareil.
IL'apparecchio può essere usato anche in paesi diversi da quello indicato
sull'apparecchio stesso. Tuttavia, le varianti specifiche di un determinato paese
e il tipo di allacciamento alla rete hanno un'importanza fondamentale per il suo
sicuro e corretto funzionamento. Per questo se si vuole usare l'apparecchio in
un paese diverso rivolgersi al servizio di assistenza tecnica Miele del paese in
cui si intende usarlo.
MHet apparaat is ook toegelaten voor gebruik in andere landen dan de landen
die op het apparaat vermeld staan. De specifieke uitvoering en de aansluitwijze
zijn van groot belang voor het goed en veilig functioneren. Neem daarom
contact op met de Technische Dienst van de fabrikant in uw land als u het
apparaat in een land wilt gebruiken dat niet op het apparaat vermeld staat.
2

Gas-heated appliances
Safety precautions to take if you smell gas
ßTurn off the gas emergency control valve immediately.
This is usually located near the gas meter.
ßEliminate all sources of ignition in a safe manner.
Do not smoke, light cigarette lighters or matches.
ßDo not operate electrical lights or switches, i.e. do not switch them "On" or "Off".
ßOpen all doors and windows to ventilate the area.
ßIf the smell of gas persists, evacuate the building.
3

Guide to the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Front view.........................................................6
Burner ...........................................................7
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Switching on, adjusting the flame and switching off .......................21
Pans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
General notes ....................................................25
Stainless steel surfaces .............................................26
Pan supports, control knobs .........................................26
Burner ..........................................................27
Problem solving guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Optional accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Safety instructions for installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Appliance and building-in dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Preparing the worktop. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Installation of several appliances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Fixing the spring clamps and spacer bars . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Contents
4

Installing / removing the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
General installation tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Gas connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Conversion to another type of gas. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Jet table .........................................................48
Changing the jets..................................................49
To change the main jet .............................................50
To check the first intake of air......................................51
To change the small jets..........................................52
After changing the jets..............................................53
After sales service, data plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Contents
5

Front view
aPan support
bBurner
cControl knob
Guide to the appliance
6

Burner
dBurner cap
eBurner head
fCover plate
gIgnitor
hIgnition safety device
iBurner base
Guide to the appliance
7

This appliance complies with all current local and
national safety requirements. Improper use can,
however, present a risk of both personal injury and
material damage.
To avoid the risk of accidents and damage to the
appliance, please read these instructions carefully
before installation and before using it for the first time.
They contain important notes on installation, safety,
use and maintenance.
Keep these instructions in a safe place and ensure
that new users are familiar with the content. Pass
them on to any future owner.
Warning and Safety instructions
8

Correct application
~This hob is not designed for commercial use. It is
intended for use in domestic households and in similar
working and residential environments such as:
–Shops
–Offices and showrooms
and by residents in establishments such as:
– Hostels and guest houses.
~The hob is intended for domestic use only to cook
food and keep it warm.
Any other use is not supported by the manufacturer
and could be dangerous. Miele cannot be held liable
for damage resulting from incorrect or improper use or
operation.
~The hob is not intended for outdoor use.
~The hob can only be used by people with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they are supervised
whilst using it, or have been shown how to use it in a
safe way and understand the hazards involved.
Warning and Safety instructions
9

Safety with children
~The hob is not a toy! To prevent the risk of injury, do
not let children play with the appliance or its controls.
~Children under 8 years of age must be kept away
from the hob unless they are constantly supervised.
~Children 8 years and older may use the hob only if
they have been shown how to use it in a safe way and
understand the hazards involved.
~The hob gets hot when in use and remains hot for
quite a while after being switched off. Keep children
well away from the appliance until it has cooled down
and there is no danger of burning.
~Do not store anything which might arouse a child's
interest in storage areas above or next to the hob.
Otherwise they could be tempted into climbing onto the
appliance with the risk of burning themselves.
~Keep all pans out of reach of children. Turn pan
handles inwards away from the edge of the hob.
Danger of burning or scalding.
~Packaging, e.g. cling film, polystyrene and plastic
wrappings, must be kept out of the reach of babies
and young children. Danger of suffocation. Dispose of
or recycle all packaging safely as soon as possible.
Warning and Safety instructions
10

Technical safety
~Before installation, check the hob for visible signs of
damage. Do not install and use a damaged appliance.
It could be dangerous.
~The electrical safety of the hob can only be
guaranteed if correctly earthed. It is most important that
this basic safety requirement is observed and regularly
tested, and where there is any doubt, the household
wiring system should be inspected by a qualified
electrician.
Miele cannot be held liable for the consequences of an
inadequate earthing system (e.g. electric shock).
~Before connecting the hob to the mains electricity
supply, make sure that the data quoted on the data
plate match the household mains supply, otherwise the
appliance could be damaged. Consult a qualified
electrician if in any doubt.
~For safety reasons, the hob may only be used after it
has been built in.
~Do not open the casing of the hob.
Tampering with electrical connections or components
and mechanical parts is highly dangerous to the user
and can cause operational faults.
Warning and Safety instructions
11

~The connection to the gas supply should only be
undertaken by an registered gas installer under the gas
safety regulations (Registration of Gas Installers and
Gas Contractors). If the appliance is supplied without a
plug, or if the plug is removed, it must be connected to
the mains electricity supply by a suitably qualified and
competent electrician in strict accordance with current
local and national safety regulations. The manufacturer
cannot be held liable for damage caused by incorrect
installation or connection.
~Installation, maintenance and repairs may only be
carried out by a suitably qualified and competent
person in strict accordance with current national and
local safety regulations.
Repairs and other work by unqualified persons could
be dangerous. The manufacturer cannot be held liable
for unauthorised work.
~During installation, maintenance and repair work, the
hob must be disconnected from the gas supply and
mains electricity supply.
~While the hob is under guarantee, repairs should
only be undertaken by a service technician authorised
by Miele. Otherwise the guarantee is invalidated.
Warning and Safety instructions
12

~Faulty components must only be replaced by
genuine Miele original spare parts. The manufacturer
can only guarantee the safety of the appliance when
Miele replacement parts are used.
~If the connection cable is damaged, it must be
replaced by a suitably qualified electrician with a
special connection cable of type H 05 V V-F (pvc
insulated), available from Miele.
~The hob is not intended for use with an external timer
switch or a remote control system.
~Do not connect the hob to the mains electricity
supply by a multi-socket adapter or an extension lead.
These do not guarantee the required safety of the
appliance (e.g. danger of overheating).
~Do not use the hob if it is faulty. Switch it off immedi-
ately and disconnect it from the mains electricity supply
and the gas supply. Call the Service Department.
Warning and Safety instructions
13

Correct use
~The hob gets hot when in use and remains hot for
quite a while after being switched off. Do not touch it
whilst it could still be hot.
~If a cooker hood is installed above the hob, ensure
that the burners are always covered with a pan when in
use. Otherwise flames could reach the cooker hood,
parts of which could then be damaged or set on fire.
~Do not leave the hob unattended whilst it is being
used. Oil and fat are potential fire hazards as they can
ignite if overheated.
~If oil or fat does catch fire, do not attempt to put out
the flames with water. Use a suitable fire blanket,
saucepan lid, damp towel or similar to smother the
flames.
~Do not use the hob to heat up the room. Due to the
high temperatures radiated, objects near the appliance
could catch fire. The life of the appliance could also be
reduced.
Warning and Safety instructions
14

~Use heat-resistant pot holders or gloves when using
the hob. Ensure that they do not come into contact with
the flames. Do not use large cloths, tea towels or
similar as the ends could touch the flames and catch
fire. Do not let the gloves get damp or wet, as this
causes heat to transfer through the material more
quickly with the risk of scalding or burning yourself.
~Do not flambé under a cooker hood. The flames
could set the cooker hood on fire.
~Do not use the hob as a resting place for anything.
When the appliance is switched on either deliberately
or by mistake, or when there is residual heat present,
the article could melt or catch fire.
~Where several appliances are installed side by side
Do not place hot pots or pans on the cover strip as this
can damage the seal.
~Do not cover the hob, e. g. with a hob cover, a cloth
or protective foil. The material could catch fire, shatter
or melt if the appliance is switched on by mistake or if it
is still warm.
~Do not use plastic or aluminium foil containers.
These melt at high temperatures and could catch fire.
~Do not heat up unopened tins of food on the hob, as
pressure will build up in the tin, causing it to explode.
This could result in injury and scalding or damage.
Warning and Safety instructions
15

~Make sure all the components of the gas burners
have been correctly assembled before switching on.
~Pans must be the correct size for the burner they are
used on (see "Suitable pans"). A pan which is too small
will be unstable on the pan support. If the pan diameter
is too large, flames can spread out to the sides and
damage or burn the worktop, wall claddings or
surrounding units and also parts of the hob. Miele
cannot be held liable for this type of damage.
~Ensure that the flames from the burner do not spread
out beyond the base and up the sides of the pan.
~Unless the pan manufacturer states that you can do
so, do not use pans with very thin bases on the hob,
and never heat up empty pans as they could get
damaged. This could also damage the appliance.
~The pan support supplied must always be used.
Pans must not be placed directly on the burner.
~Do not store any inflammable objects near the hob.
~Remove splashes of fat and other food debris from
the surface as soon as possible. These are a fire
hazard.
~Replace the pan supports carefully to avoid
scratching the surface of the hob.
Warning and Safety instructions
16

~Using the hob will cause a build-up of heat and
moisture in the room in which it is installed. Ensure that
the room has sufficient natural or mechanical means of
ventilation, e.g. an extractor.
~If the hob is used for very long periods of time
additional ventilation of the room may be necessary,
e.g. by opening windows or doors, or running the
extractor on the highest setting.
~When using an electrical appliance, e.g. a hand-held
food blender, near the hob, ensure that the cable of the
electrical appliance does not come into contact with
the hot hob. The insulation on the cable could become
damaged, giving rise to an electric shock hazard.
~Spray canisters, aerosols and other inflammable
substances must not be stored in a drawer under the
hob. Cutlery inserts must be heat-resistant.
~Always ensure that food is sufficiently cooked or
reheated. Some foods may contain micro-organisms
which are only destroyed by thorough cooking at a
sufficiently high temperature for long enough.
Therefore, when cooking or reheating food such as
poultry, it is particularly important that the food is
completely cooked through. If in doubt, select a longer
cooking or reheating time.
Warning and Safety instructions
17

~Avoid allowing liquids or foods containing salt to spill
onto the hob. If salty foods or liquids do get on the hob,
they should be removed as soon as possible to avoid
the risk of corrosion.
~If the hob is installed behind a kitchen furniture door,
it may only be used with the furniture door open.
Only close the door when the appliance is switched.
~If the hob has not been used for a long period of
time it should be thoroughly cleaned before it is used
again. It is also advisable to have the appliance tested
for safety.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety
instructions.
Warning and Safety instructions
18

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for
disposal, and should be recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection/recycling
centre or contact your dealer for
advice. Ensure that it presents no
danger to children while being stored
for disposal.
Caring for the environment
19

Please stick the extra data plate for the
appliance supplied with this
documentation in the space provided in
the "After sales service" section of this
booklet.
Cleaning for the first time
^Remove any protective foil and
stickers.
^Clean all removable parts of the
burners with a solution of warm water
and a little washing-up liquid applied
with a soft sponge. Dry all parts
thoroughly after cleaning and then
reassemble the burners (see
"Cleaning and care").
^Clean the stainless steel trough with
a damp cloth, and then wipe dry.
Metal components have a protective
coating which may give off a slight
smell when heated up for the first time.
The smell and any vapours will
dissipate after a short time, and do not
indicate a faulty connection or
appliance.
Before using for the first time
20
