Miele DG 5061 Specification sheet

Operating and Installation instructions
Steam oven
DG 5051
DG 5061
To avoid the risk of accidents or
damage to the appliance it is
essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 07 500 500
en-GB

Warning and Safety instructions .....................................5
Caring for the environment.........................................10
Guide to the appliance ............................................11
Front view........................................................11
Accessories supplied ..............................................12
Control panel .....................................................13
Description of the functions ........................................14
Controls .........................................................14
Function selector ...............................................14
Temperature selector ............................................14
Sensors .......................................................14
Display ..........................................................15
Condensate tray ..................................................16
Water container ...................................................16
Temperature .....................................................16
Cooking duration (time) .............................................16
Noises ..........................................................16
Heating-up phase .................................................17
Cooking phase....................................................17
Before using for the first time.......................................18
Setting up the appliance for using for the first time........................18
Cleaning for the first time............................................20
Setting the correct boiling point for water ...............................21
Operation .......................................................22
Functions ........................................................22
Preparing the appliance for use ......................................23
Selecting a function ................................................23
To change the temperature ..........................................23
Setting a cooking duration...........................................24
At the end of the duration ...........................................25
After use.........................................................26
Contents
2

During operation ..................................................27
Interrupting operation ............................................27
Changing the temperature ........................................27
Changing the duration ...........................................28
Insufficient water................................................28
Automatic programmes .............................................29
Additional functions ..............................................30
Start time ........................................................30
Minute minder ....................................................31
Pre-heat .........................................................32
System lock ......................................................33
Settings.........................................................34
Language J......................................................34
Time of day ......................................................34
Start ............................................................34
Pre-heat .........................................................35
Recommended temperatures ........................................35
Water hardness ...................................................35
Display ..........................................................35
Volume ..........................................................35
Safety ...........................................................36
Temperature format ................................................36
Showroom programme .............................................36
Factory default ....................................................36
Cleaning and care ................................................37
Appliance front ...................................................38
Oven interior .....................................................39
Drip tray, rack and cooking containers .................................39
Water container ...................................................40
Coupling seal ..................................................41
FDescaling......................................................42
Removing and refitting the door ......................................44
Problem solving guide ............................................45
Contents
3

Optional accessories..............................................48
Cooking containers ................................................48
Cleaning and care products .........................................50
Other accessories .................................................51
Safety instructions for installation...................................52
Appliance and building-in dimensions ...............................53
Installation in a tall unit..............................................53
Installation in a base unit ............................................54
Installation in a tall unit in combination with an oven.......................55
Installing the appliance ............................................56
Electrical connection..............................................57
After sales service, data plate ......................................59
Contents
4

This steam oven conforms to current
safety requirements. Inappropriate
use can, however, lead to personal
injury and damage to property.
To avoid the risk of accidents and
damage to the steam oven, please
read these instructions carefully
before using it for the first time. They
contain important notes on
installation, safety, operation and
care of the appliance.
Keep these instructions in a safe
place and ensure that new users are
familiar with the content. Pass them
on to any future owner.
Correct application
~This appliance is not designed for
commercial use. It is intended for use in
domestic households and for use in
similar working and residential
environments such as:
–Shops
–Offices and showrooms
and by residents in establishments
such as:
–Hostels and guest houses.
~The steam oven is intended for
domestic use only as described in the
operating and installation instructions
and the user instructions.
Any other use is not supported by the
manufacturer and could be dangerous.
Miele cannot be held liable for damage
resulting from incorrect or improper use
or operation of the appliance.
~This steam oven is not intended for
use by people with reduced physical,
sensory or mental capabilities, or lack
of experience and knowledge, unless
they are supervised while using it or
have been shown how to use it
correctly by a person responsible for
their safety.
Warning and Safety instructions
5

Safety with children
~Activate the system lock to ensure
that children cannot switch on the
appliance inadvertently.
~Keep children away from the steam
oven at all times. It is not a toy! To
avoid the risk of injury do not allow
them to play with it or to play with the
controls. Supervise children whilst you
are using it.
~Older children may use the
appliance only when its operation has
been clearly explained to them and
they are able to use it safely,
recognising the dangers of incorrect
use.
~Make sure that children do not
attempt to open the door when the
appliance is in operation. To safeguard
against burning, keep children well
away from the appliance at all times.
~Do not allow children to lean against
the open oven door, nor to sit on it or
swing on it.
~Packaging, e.g. cling film,
polystyrene and plastic wrappings,
must be kept out of the reach of babies
and young children. Danger of
suffocation. Dispose of or recycle all
packaging safely as soon as possible.
Technical safety
~Before installation, check the steam
oven for visible signs of damage. Do
not install and use a damaged
appliance. A damaged appliance is
dangerous.
~Before connecting the appliance to
the mains supply, ensure that the
connection data on the data plate
(voltage and connected load) match
the mains supply. Consult a qualified
electrician if in any doubt.
~The electrical safety of this
appliance can only be guaranteed
when continuity is complete between it
and an effective earthing system which
complies with current local and national
safety regulations. It is most important
that this basic safety requirement is
present and regularly tested, and
where there is any doubt, the
household wiring system should be
inspected by a qualified electrician.
The manufacturer cannot be held liable
for the consequences of an inadequate
earthing system (e.g. electric shock).
Warning and Safety instructions
6

~This appliance is supplied with a
moulded plug ready for connection to a
switched socket. If you wish to connect
it to a double-pole fused spur
connection unit, or to an isolator switch
or if the appliance is supplied without a
plug, it must be installed by a suitably
qualified and competent person in strict
accordance with current local and
national safety regulations. The
manufacturer cannot be held liable for
damage caused by incorrect
installation or connection.
~For safety reasons, this appliance
may only be used when it has been
built in. This is necessary to ensure that
all electrical components are shielded.
~Never open the casing of the
appliance.
Tampering with electrical connections
or components and mechanical parts is
highly dangerous to the user and can
cause operational faults.
~Installation, maintenance and
repairs may only be carried out by a
suitably qualified and competent
person in strict accordance with current
national and local safety regulations.
Repairs and other work by unqualified
persons could be dangerous. The
manufacturer cannot be held liable for
unauthorised work.
~If the connection cable is damaged,
it must be replaced with a special
connection cable of type H 05 V V-F
(pvc insulated), available from the Miele
Spare Parts Department.
~Faulty components must only be
replaced by genuine Miele original
spare parts. The manufacturer can only
guarantee the safety of the appliance
when Miele replacement parts are
used.
~During installation, maintenance and
repair work, the appliance must be
disconnected from the mains electricity
supply.
~While the appliance is under
guarantee, repairs should only be
undertaken by a service technician
authorised by the manufacturer.
Otherwise the guarantee is invalidated.
~Do not connect the steam oven to
the mains electricity supply by a
multi-socket unit or an extension lead.
These do not guarantee the required
safety of the appliance (e.g. danger of
overheating).
~In areas which may be subject to
infestation by cockroaches or other
vermin, pay particular attention to
keeping the appliance and its
surroundings in a clean condition at all
times. Any damage caused by
cockroaches or other vermin will not be
covered by the guarantee.
Warning and Safety instructions
7

Correct use
~Use heat-resistant pot holders or
gloves when using the appliance. Do
not let them get damp or wet, as this
causes heat to transfer through the
material more quickly with the risk of
scalding or burning yourself.
~When putting cooking containers or
the condensate tray into the oven or
taking them out, take care not to spill
the contents. Avoid contact with hot
steam, and do not touch the hot oven
interior walls. Danger of burning and
scalding.
~If using plastic cooking containers,
make sure that they are heat- and
steam-resistant to 100 °C. Otherwise
they may melt, distort or break.
~Do not use the appliance to heat up
food in sealed jars and tins. Pressure
will build up inside them and they can
explode causing damage to the
appliance, as well as the risk of injury
and scalding.
~Always ensure that food is
sufficiently cooked or reheated.
Some foods may contain
micro-organisms which are only
destroyed by thorough cooking at a
sufficiently high temperature for long
enough. Therefore, when cooking or
reheating food such as poultry, it is
particularly important that the food is
completely cooked through. If in doubt,
select a longer cooking or reheating
time.
~Do not leave cooked food in the
oven and do not use any cooking
containers which are susceptible to
corrosion as this could lead to
corrosion in the appliance.
~The appliance is designed in such a
way that there will always be a little
residual water left in the water container
after use. If there is no residual water,
there is something wrong. Call the Ser-
vice Department.
~Do not immerse the water container
in water, or clean it in a dishwasher.
Connecting the water container into the
appliance when wet could cause an
electric shock.
~For reasons of hygiene and to
prevent the build-up of moisture in the
appliance, the water container should
be emptied after each use.
~Take care not to tip the water
container when taking it out of the
appliance. Hot water can scald.
Warning and Safety instructions
8

~When using an electrical appliance,
e.g. a hand-held food blender, near the
steam oven, ensure that the cable of
the electrical appliance does not come
into contact with the hot appliance. The
insulation on the cable could become
damaged, giving rise to an electric
shock hazard.
~Do not place heavy objects on the
open door. The door can support a
maximum weight of 8 kg.
~If the appliance is installed behind a
kitchen furniture door, it may only be
used with the furniture door open.
Only close the door when the appliance
is not in use and is completely dry
inside.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
Warning and Safety instructions
9

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for
disposal, and should be recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre or contact your dealer for
advice. Ensure that it presents no
danger to children while being stored
for disposal.
Caring for the environment
10

Front view
aControl panel
bVentilation outlet
cDoor seal
dSteam channel
eCompartment for water container
fWater container (with insert)
gContact point for water container
hShelf levels
iSteam inlet
jDrip channel in the oven
kFloor heater
lTemperature sensor
mSteam outlet
Guide to the appliance
11

Accessories supplied
The accessories supplied with your appliance as well as a
range of optional ones are available to order from Miele (see
"Optional accessories").
Condensate tray DGG 17
To catch excess moisture
325x350x40mm(WxDxH)
DGGL 8
1 perforated cooking container
Gross capacity 2.0 litres / Usable capacity 1.7 litres
325x265x40mm(WxDxH)
DGGL 1
2 perforated cooking containers
Gross capacity 1.5 litres / Usable capacity 0.9 litres
325x175x40mm(WxDxH)
Rack
For placing your own cooking containers on
Silicone grease
For lubricating the coupling seal on the water container
Descaling tablets
For descaling the water container
Guide to the appliance
12

Control panel
aFunction selector
bTemperature selector
cDisplay
dSensors
Guide to the appliance
13

Controls
Function selector
You select the function you want by turning the function
selector (see "Operation / Functions").
Temperature selector
You can use the temperature selector to alter the
recommended temperature for the function selected in 1°
steps within the permitted range (see "Operation / Setting the
temperature")
The function selector and the temperature selector can be
turned both clockwise and anti-clockwise. Push them in to
retract them.
Sensors
Lightly touch the sensors to operate the appliance. An
audible tone will sound each time a sensor is pressed. You
can alter the volume of the tone or switch the tone off in the
Settings menu (see "Settings / Volume").
Sensor Function
?For setting the cooking duration.
For scrolling through the menus.
For scrolling through the automatic programmes.
;For setting the cooking duration.
For scrolling through the menus.
For scrolling through the automatic programmes.
OK For confirming a selection.
lFor activating and deactivating the minute minder.
For selecting the minute minder time.
Description of the functions
14

Display
The following symbols will appear in the display in addition to
the text:
Symbol Meaning
-
e
A maximum of 2 options can be shown in the
display.
These arrows indicate if more than two options
are available.
- - - A dotted line will appear under the last option
available. The beginning of the list will appear
under the dotted line.
LA tick will appear beside the option which is
currently selected.
KInformation about operating the oven and tips
are shown in the display. You can delete the
information window by confirming "OK" or by
following the instructions.
<
=
?
Water level in the water container:
full
half full
nearly empty.
TEntered cooking duration (time)
RStart time
$System lock activated
Description of the functions
15

Condensate tray
When you are using perforated containers, place the
condensate tray on the floor of the appliance to collect any
drops of liquid and allow them to be removed easily.
Water container
The maximum water level is 1.2 litres, the minimum 0.75 litres.
The water level markers are located inside and outside the
container. On no account exceed the upper or maximum
level marker.
The maximum quantity of 1.2 litres of water is sufficient to run
a cooking programme at 100 °C for approx. 2 hours, and the
minimum quantity of 0.75 litres of water is sufficient to run a
cooking programme at 100 °C for approx. 30 minutes,
providing the door is not opened.
The water level in the water container is represented by a
symbol in the display.
Temperature
Some of the functions are allocated with a recommended
temperature. You can alter the recommended temperature for
an individual cooking process or permanently (see "Settings /
Recommended temperature").
Cooking duration (time)
A duration of between 1 minute (0:01) and 9 hours 59 minutes
(9:59) can be set.
Noises
You can hear the noise of the fan when the appliance is
operating.
Noises similar to those of a kettle can be heard when steam is
being generated.
Description of the functions
16

Heating-up phase
During the heating-up phase the oven compartment is heated
to the set temperature. The display will show the temperature
of the cooking compartment as it rises.
The duration of the heating-up phase will depend on the
quantity and the temperature of the food. In general the
heating-up phase will last for approx. 7 minutes. The duration
will be longer if you are preparing frozen or refrigerated food.
Filling the water container with hot water will shorten the
heating-up time.
Cooking phase
The cooking phase begins when the set temperature is
reached. During the cooking phase the duration remaining
(time left) will be shown in the display.
Please refer to the "User instructions" booklet supplied with
your appliance for more information and tips on how to use
your steam oven.
Description of the functions
17

Setting up the appliance for using for the first time
The appliance will switch on automatically when it is
connected to the electricity supply.
Welcome screen
A welcome screen will appear in the display and you will then
be requested to select some basic settings which are needed
to set up the appliance up for using for the first time.
Follow the instructions in the display.
Setting the language
The welcome screen will be replaced by the request to set a
language:
^Touch the ;or ?sensor until the language you want
appears highlighted in the display.
^Confirm with "OK".
A tick Lwill appear beside the language you have selected.
If you select the wrong language by mistake,
- disconnect the appliance from the electricity supply and
switch it back on again. The process will start again with
the welcome screen.
or
- continue setting up the appliance in the language
selected.
Then turn the function selector to Settings %and confirm
with "OK". You will reach the Language sub-menu by
following the Jsymbol. Select and confirm the language
you require as described above.
Before using for the first time
18

Clock format
The request to select a Clock format will appear. The default
setting for the clock is 24 h.
^Touch the ;or ?sensor until the clock format you want
appears highlighted in the display.
Confirm with "OK".
Setting the time of day
You will then be requested to enter the Time of day. The hour
is highlighted.
^Use the ;or ?sensor to set the hour you want and
confirm with "OK".
The minutes are highlighted.
^Use the ;or ?sensors to set the minutes you want and
confirm with "OK".
Time of day display
You will then be asked if you want the display to always show
the time:
On = the display will always show the time of day
On for 60 seconds = the display will show the time for 60
seconds after the appliance is switched off
Do not display = the display will not show the time
^Use the ;or ?sensor to select the setting you want and
confirm with "OK".
After you have confirmed your selection with "OK", the display
will show a message to tell you that setting up for the first time
has been successfully completed.
^Confirm with "OK".
Your steam oven is now ready for use.
Before using for the first time
19

Please stick the extra data plate for the appliance supplied
with this documentation in the space provided in the "After
sales service" section of this booklet.
Cleaning for the first time
Remove any protective foil and adhesive labels.
Water container
Take the water container out of the appliance and remove the
insert (see "Cleaning and care / Water container"). Rinse the
water container and the insert thoroughly by hand using hot
water. Do not use any washing-up liquid or detergent.
Do not clean the water container or the insert in a
dishwasher. Do not immerse the water container in water.
Accessories / Oven interior
Take all accessories out of the oven. Wash them in a mild
solution of washing-up liquid and hot water or in the
dishwasher.
The interior of the steam oven has been treated at the factory
with a conditioning agent. To remove this, clean the oven
interior with a mild solution of washing-up liquid and hot water
and then dry thoroughly with a soft cloth.
Before using for the first time
20
