NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010305
Product and Cut-out Dimensions
60 cm Single Oven
H4680B
22 1/16" min.
22 7/8"
21 5/8"
23 7/16"
7/8"
23 7/16"
O
23 3/8" - 23 7/16"
A
22 1/16" - 22 3/8"
5 foot electrical main with plug
connects top center.
208-240 Volt - 20 Amp - 4-wire
connection box with NEMA 14-30R.
Location must be accessible.
Height to base of oven
Locate 34 5/8" - 36" from floor.
Based on user height of 5'6" to 5'10"
E -
O -
A -
Location Codes
21 9/16"
E
• All installations must be done in
accordance with local codes.
Notes
