Miele WXF 660 User manual

Operating Instructions
Washing machine
It is essential to read these operating instructions before installation
or use of this appliance. This prevents both personal injury and
damage to the appliance.
en-CA M.-Nr. 11 669 330

Contents
2
Caring for the environment .............................................................................. 6
Important safety instructions ........................................................................... 7
Operating the washing machine ...................................................................... 12
Control panel....................................................................................................... 12
Appliance operation examples ............................................................................ 14
Before using for the first time .......................................................................... 15
Miele@home ........................................................................................................ 16
1. Setting the language ....................................................................................... 17
2. Setting up Miele@home .................................................................................. 17
3. Removing the shipping struts ......................................................................... 18
4. Commissioning TwinDos ................................................................................. 18
Determining the water hardness .................................................................... 18
5. Starting the calibration program...................................................................... 21
Environmentally friendly washing .................................................................... 22
Energy and water consumption .......................................................................... 22
Detergent consumption....................................................................................... 22
Feedback ....................................................................................................... 23
1. Preparing the laundry.................................................................................... 24
2. Selecting a program...................................................................................... 25
3. Loading the washing machine ..................................................................... 27
4. Selecting program settings .......................................................................... 28
Selecting a temperature/spin speed ................................................................. 28
Selecting an extra option..................................................................................... 28
Degree of soiling ............................................................................................ 28
 Delay start/SmartStart ................................................................................... 29
5. Adding detergent........................................................................................... 31
TwinDos............................................................................................................... 31
How UltraPhase1 and UltraPhase2 work ..................................................... 31
Activating TwinDos dispensing ...................................................................... 31
Changing TwinDos dispensing ....................................................................... 31
Deactivating TwinDos dispensing .................................................................. 31
Selecting the degree of soiling.................................................................. 32
Replacing detergent cartridges ...................................................................... 32

Contents
3
Detergent dispenser drawer ................................................................................ 33
Using chlorine bleach..................................................................................... 33
Adding powder detergent............................................................................... 34
Using detergent tablets or pods..................................................................... 35
CapDosing........................................................................................................... 36
6. Starting a program ........................................................................................ 38
Adding laundry during a program sequence (AddLoad) ..................................... 38
7. Program end .................................................................................................. 39
Spinning.............................................................................................................. 40
Program chart.................................................................................................... 42
Extra options...................................................................................................... 49
SoftSteam ........................................................................................................... 49
Pre-wash ............................................................................................................ 49
Buzzer ................................................................................................................. 49
Extra options can be selected using the Optionssensor button ........................ 50
Extra Gentle.................................................................................................... 50
ExtraRinse ...................................................................................................... 50
Soak ............................................................................................................... 50
AllergoWash ................................................................................................... 50
Wash program chart – extra options ............................................................... 51
Program sequence ............................................................................................ 52
Changing the program sequence .................................................................... 54
Changing a program (child lock) ......................................................................... 54
Interrupting a program......................................................................................... 54
Cancelling a program .......................................................................................... 54
Detergent ........................................................................................................... 55
Recommended Miele Detergents........................................................................ 55
General detergent recommendations.................................................................. 56
Cleaning and care ............................................................................................. 57
Cleaning the housing and control panel.............................................................. 57
Cleaning the detergent dispensing drawer ......................................................... 57
TwinDos maintenance ......................................................................................... 60
Hygiene info(Cleaning the drum) ......................................................................... 61
Cleaning the water inlet filter............................................................................... 61

Contents
4
Frequently Asked Questions ............................................................................ 62
The wash program will not start .......................................................................... 62
Fault message after a program has been interrupted ......................................... 63
Fault message after the end of the program ....................................................... 64
Messages or faults affecting the TwinDos system .............................................. 65
General problems with the washing machine ..................................................... 67
An unsatisfactory wash result ............................................................................. 69
The door will not open......................................................................................... 70
Opening the door in the event of a blocked drain outlet and/or power failure ... 71
Technical Service............................................................................................... 73
Contact in the event of a fault ............................................................................. 73
Optional accessories........................................................................................... 73
Warranty .............................................................................................................. 73
Installation.......................................................................................................... 74
Front view ............................................................................................................ 74
Rear view............................................................................................................. 75
Installation surface .............................................................................................. 76
Transporting the washing machine to its installation site.................................... 76
Removing the shipping struts ............................................................................. 77
Installing the shipping struts ............................................................................... 79
Levelling the machine.......................................................................................... 80
Unscrewing and adjusting the feet................................................................. 80
Installing under a countertop.......................................................................... 81
Washer-dryer stack ........................................................................................ 81
Additional installation requirements .................................................................... 82
Installing under a countertop.......................................................................... 82
Setting up the cabinet .................................................................................... 82
For closets at room height.............................................................................. 83
Product dimensions ............................................................................................ 83
Dimensions..................................................................................................... 83
Installation on a plinth .................................................................................... 84
Washer-dryer stack ........................................................................................ 84
The Miele water protection system ..................................................................... 85
Water intake ........................................................................................................ 86
Drainage .............................................................................................................. 87
Fitting the elbow............................................................................................. 87
Electrical connection ........................................................................................... 88
Technical data.................................................................................................... 89

Contents
5
Settings .............................................................................................................. 90
Calling up settings............................................................................................... 90
Selecting settings................................................................................................ 90
Changing a setting .............................................................................................. 90
Closing the settings menu................................................................................... 90
Language ......................................................................................................... 91
TwinDos............................................................................................................... 91
Select detergent ............................................................................................. 91
Degree of soiling.................................................................................................. 91
Buzzer volume..................................................................................................... 91
Keypad tone ........................................................................................................ 92
Welcome tone ..................................................................................................... 92
Code.................................................................................................................... 92
Units .................................................................................................................... 93
Brightness ........................................................................................................... 93
Display switch-off................................................................................................ 94
Program info........................................................................................................ 94
Memory ............................................................................................................... 94
Water intake .................................................................................................... 94
Soak duration ...................................................................................................... 95
Gentle action ....................................................................................................... 95
Temp. reduction................................................................................................... 95
Maximum rinse level............................................................................................ 95
Suds cooling........................................................................................................ 95
Low water pressure ............................................................................................. 96
Anti-Crease.......................................................................................................... 96
Miele@home ........................................................................................................ 96
Remote control.................................................................................................... 97
SmartGrid ............................................................................................................ 97
RemoteUpdate .................................................................................................... 98
Bleach ................................................................................................................. 99
Copyrights and licenses for the communication module.................................... 99
Detergents and care products ......................................................................... 100
Detergent............................................................................................................. 100
Special-purpose detergents......................................................................... 101
Fabric care.................................................................................................... 102
Additives....................................................................................................... 102
Machine care....................................................................................................... 102

Caring for the environment
6
Disposal of the packaging
material
The cardboard box and packaging
materials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also the
amount of waste.
Disposal of your old appliance
Electronic and electrical appliances
contain many valuable materials. They
also contain certain materials,
compounds and components which
were essential for the proper
functioning and safe use of the
equipment. These could be hazardous
to your health and to the environment if
disposed of with general waste or if
handled incorrectly. Therefore, please
do not dispose of your old appliance
with general waste.
Consult with local authorities, dealers or
Miele in order to dispose of and recycle
electrical and electronic appliances.
Miele assumes no responsibility for
deleting any personal data left on the
appliance being disposed. Please
ensure that your old appliance is kept
away from children until removal.
Observe safety requirements for
appliances that may tip over or pose an
entrapment hazard.

Important safety instructions
Warning
In order to reduce the risk of fire, electric shock, or injuries,
persons operating the appliance must adhere to the following
safety precautions:
 It is essential to read the operating instructions before using the
washing machine.
 GROUNDING INSTRUCTIONS
The washing machine must be grounded. Connecting the appliance
to ground reduces the danger of electric shock in the event of a
malfunction. The grounding is a protective conductor which provides
a path of least resistance for the current. The washing machine
comes complete with a power cord and plug with the corresponding
protective conductor. The power cord plug must be inserted into a
suitable outlet that has been installed and grounded in compliance
with all applicable local codes.
 WARNING: Incorrect grounding of the appliance will run the risk of
electric shock. In case of doubt, get in touch with a qualified
electrician and arrange to have your cabling inspected.
 Do not replace or make any changes to the plug supplied. If there
is no suitable socket available, a socket must be installed by a
qualified electrician.
 Do not use a damaged washing machine.
 Do not expose the washing machine to outdoor weather
conditions.
 Do not install the washing machine in an area where there is a risk
of freezing conditions. Frozen hoses may burst or split, and the
reliability of the electronic control unit may be impaired at
temperatures below freezing point.
7

Important safety instructions
 Before connecting the washing machine, make sure that the
connection data on the data plate (voltage and connected load)
match the domestic electricity supply. If in doubt, request the
connection data from a qualified electrician.
 Do not connect the washing machine to the domestic electricity
supply by a multi-socket adapter, extension lead or similar. These do
not guarantee the required safety of the machine (fire hazard due to
the risk of overheating).
 The washing machine is not intended for maritime applications or
for use in mobile units such as motor homes or aircraft. However,
installation in such scenarios may be possible under certain
conditions. Get in touch with Miele's Technical Service department
regarding these specific requirements.
 Do not make any changes or repairs on the washing machine if
this is not expressly permitted in these operating instructions.
 Only Miele is permitted to replace a damaged power cord. Miele
service technicians use original power cords from Miele.
 If hot-water systems are not used for longer than two weeks, there
may be a buildup of hydrogen under certain conditions. HYDROGEN
IS EXPLOSIVE. If the hot-water systems have not been in use for
longer than two weeks, allow hot water to run from all valves for
several minutes before operating the washing machine. This reduces
the formation of hydrogen. Refrain from smoking and keep away
from naked flames while the water valves are open. The gas will be
flammable during this time.
 Remove the door or destroy the door lock before disposing of the
washing machine.
8

Important safety instructions
Use
 Children are not allowed to play with, on, or inside the washing
machine. If you are operating the washing machine in the presence
of children, the children must be supervised at all times.
 The temperature of the porthole glass becomes very high during
washing. Danger of burning! Refrain from touching the porthole
glass. You must therefore keep children away from the porthole glass
during the wash cycle.
 Only use the washing machine for washing fabrics with a care
label stating that they are suitable for machine washing. Other
applications may be dangerous.
 Do not wash any fabrics which have been cleaned, washed, or
soaked with cleaning agents containing solvents (e.g. benzine) or
other flammable substances. These fabrics release vapours which
can ignite or explode. Do not add these kinds of fabric to a load of
washing.
 Do not use any solvents or other flammable substances or
explosive materials in the washing machine. These materials can
release vapours which can ignite or explode.
 Never use solvent based cleaning agents on or in the washing
machine. Surfaces are damaged on contact with cleaning agents.
 Always make sure that the drum is stationary before reaching in to
remove laundry. Do not touch the drum whilst it is still rotating.
 Do not make any alterations to the machine.
KEEP THESE OPERATING INSTRUCTIONS IN A SAFE
PLACE
9

Important safety instructions
 Miele tumble dryers and Miele washing machines can be installed
as a washer-dryer stack. A Miele washer-dryer connection kit is
required as an optional accessory for this. Please ensure that the
washer-dryer connection kit is suitable for the Miele tumble dryer
and the Miele washing machine.
 If installing the machine on a Miele plinth (available as an optional
accessory), please make sure you order the correct one for this
washing machine.
 Should detergent enter the eyes, rinse out immediately with plenty
of lukewarm water. If accidentally ingested, seek medical advice
immediately. People who have sustained damage to the skin or who
have sensitive skin should avoid contact with the detergent.
 Be careful when opening the door following use of the steam
function. There is a danger of burning due to escaping steam and
the high temperature of the surface of the drum as well as the
porthole glass. Step back and wait until the steam has dissipated.
 The maximum dry laundry weight is 17.6 lb (8 kg). See the
“Program chart” for the maximum recommended loads for individual
programs.
 Temporary or permanent operation on an autonomous power
supply system or a power supply system that is not synchronized
with the grid power supply (e.g. island networks, back-up systems)
is possible. A prerequisite for operation is that the power supply
system complies with the specifications of EN50160 or an
equivalent local standard.
The function and operation of the protective measures provided in
the domestic electrical installation and in this Miele product must
also be maintained in isolated operation or in operation that is not
synchronized with the grid power supply, or these measures must be
replaced by equivalent measures in the installation. As described, for
example, in the current version of VDE-AR-E 2510-2 or an equivalent
local standard.
10

Important safety instructions
FCC Declaration of Conformity
 These devices comply with FCC Rules Part15. This equipment
has been tested and found to be in compliance with the limits for a
ClassB digital device, pursuant to Part15 of the FCC Rules of
Operation and is subject to the following conditions:
These devices may not cause harmful interference.
These devices must accept any interference received, including
interference that may cause undesired operation.
FCC Radiation Exposure Statement
 This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 8“ (20cm) between
the radiator and your body.
Industry Canada Statement
 This digital apparatus does not exceed the ClassB limits for
Radio Noise Emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of
Communications.
Complies with Canadian ICES-003 ClassB specifications.
11

Operating the washing machine
12
Control panel
     
aControl field
The control field consists of a
display and various sensor buttons.
The individual sensor buttons are
explained in the following sections.
bSensor buttons 
The values in the display can be
changed with the  sensor
buttons. The  sensor button
increases the value or moves the
selection list up; the  sensor
button decreases the value or moves
the selection list down.
cSensor buttons for extra options
You can supplement the wash
programs with extra options.
If a wash program has been
selected, the sensor controls for the
possible extra options light up dimly.
dDisplay
The following values are displayed
and/or selected on the display:
1. The temperature, spin speed, and
time left for the selected wash
program.
2. The individual values of the
selection lists for extras and
settings.
eOK sensor button
The OK sensor button is used for
confirming selected values.
fSensor button 
The sensor button  starts the
delay start function. With the delay
start function, you can delay the
start of the program. The start of the
program can be delayed from
15minutes up to a maximum of 24
hours. This allows you to make use
of night-time economy electricity
rates, for example.
Please see “Delay start” for more
information.

Operating the washing machine
13
gsensor button
You can view information about the
energy and water consumption of
your washing machine with the 
sensor button.
See “Washing environmentally and
economically” under the “Feedback”
section for additional information.
The following information will appear
in the display:
– An estimate of the energy and
water consumption before the
program begins.
– The actual energy and water
consumption during the program
or at the end of the program.
hsensor button
You can specify the degree of soiling
of the load in three settings. This
sensor button is only active with the
TwinDos option activated.
iStart/Add laundrysensor button
The program can be started as
soon as the sensor button is
flashing on and off. Touching
theStart/Add laundry sensor
button starts the selected
program. The sensor button
lights up constantly.
Once the program has been
started, theStart/Add laundry
sensor button allows you to
add laundry.
jSensor button 
Activate detergent dispensing with a
capsule by using the sensor buttons.
kTwinDos sensor button with the
additional White and Color sensor
buttons
The TwinDos sensor button is used
for deactivating and activating
automatic detergent dispensing.
Depending on the colour
composition of the laundry load,
control the composition of the
detergent dispensing via the White
or Color sensor button.
Please see “TwinDos” for additional
information.
lOptical interface
This is used by the Service
department as a transmission point.
mProgram selector
for selecting programs and for
switching the machine off. The
washing machine is switched on by
selecting a program, and switched
off by turning the program selector
to the position.

Operating the washing machine
14
Appliance operation examples
Scrolling through a list
The  scroll bar in the display indicates
that a selection is available.
Language  OK




The list scrolls down when the 
sensor button is touched. The list
scrolls up when the  sensor button is
touched. The OK sensor button is used
to activate the option in the display.
Identifying the selected option
Cap  OK





An activated option in a list will have a
check mark  next to it.
Setting numerical values
Start in OK




h:0000
The numerical value is highlighted in
white. Touching the  sensor button
decreases the value. Touching the 
sensor button increases the value. The
OK sensor button is used to activate
the value in the display.
Exiting a sub-menu
Select Back  to exit a sub-menu.

Before using for the first time
15
Damage from incorrect
installation and connection.
Installing and connecting the
washing machine incorrectly will
cause serious damage to property.
See “Installation”.
Removing the protective foil
and stickers
Remove:
- any protective film from the door
- any stickers from the front and the lid
Please do not remove any labels
(e.g. the data plate) which are visible
when you open the door.
This washing machine has undergone
a complete functional test at the
factory and some residual water will
therefore remain in the drum from this
process.
Remove the detergent
cartridges and the drain hose
elbow from the drum
Two detergent cartridges for automatic
detergent dispensing and an elbow
piece for the drain hose are stored in
the drum.
Pull open the door.
Take the two cartridges and the
elbow piece out of the drum.
Shut the door with a gentle swing.

Before using for the first time
16
Miele@home
Your washing machine is equipped
with an integrated WiFi module.
To use this feature, you will need:
- A WiFi network
- The Miele@mobile app
- A Miele user account. The user
account can be created via the
Miele@mobile app.
The Miele@mobile app will guide you as
you connect your washing machine to
your home WiFi network.
Once your washing machine is
connected to your WiFi network, you
can use the app, for example, to carry
out the following activities:
- Operate your washing machine
remotely
- Access information about the
operating status of your washing
machine
- Access information about a program
sequence on your washing machine
Connecting your washing machine to
your WiFi network will increase energy
consumption, even when the washing
machine is switched off.
Before installing the washing
machine in its final location, ensure
the signal strength is sufficient for
your WiFi network.
Availability of the WiFi connection
The WiFi connection shares a frequency
range with other appliances (including
microwave ovens and remote control
toys). This may result in sporadic or
even complete connection failures.
Therefore, the availability of featured
functions cannot always be guaranteed.
Miele@home availability
The ability to use the Miele app
depends on the availability of the
Miele@home service in your country.
The Miele@home service is not
available in every country.
For information about availability,
please visit www.miele.com.
Miele app
The Miele App is available to download
free of charge from the Apple App
Store® or from the Google Play™ store.

Before using for the first time
17
Switching on the washing
machine
Turn the program selector to the
Normal program.
The welcome tone will sound and the
welcome screen will light up.
The display will guide you through the
5steps of the initial commissioning.
1. Setting the language
You will be asked to set the display
language. It is possible to change the
language at any time by setting the
program selector to Additional
programs in the Settings  sub-
menu.
  
english (CA) OK




Touch the  sensor buttons until
the language you want appears in the
display.
Confirm your choice of language by
touching the OK sensor button.
2. Setting up Miele@home
The following message appears in the
display:
 Miele@home
Confirm with OK.
The following message appears in the
display:
Set up now
To set up Miele@home now, touch
the OKsensor button.
To postpone setup until later, touch
the sensor button until Set up later
appears in the display and press the
OKbutton to confirm.
The following selection options appear
in the display:
1. Connect via WPS
2. Connect via App
Select the required connection type.
You will then be guided by the display
and the Miele app.

Before using for the first time
18
3. Removing the shipping
struts
Damage resulting from failure to
remove the transit bars.
Failure to remove the shipping struts
can result in damage to the washing
machine and to adjacent cabinetry or
appliances.
Remove the shipping struts as
described in “Installation and
connection”.
The following message appears in the
display:
 Remove shipping struts
Confirm with the OK sensor button.
4. Commissioning TwinDos
The UltraPhase1 and UltraPhase2
values are pre-set in the standard
settings and only need to be confirmed.
The following message appears in the
display:
 TwinDos
Confirm with the OKsensor button.
The following message appears in the
display:
Set up now
To set up TwinDos now, touch the
OKsensor button.
To postpone setup until later, touch
the sensor button until Set up later
appears in the display and press the
OKbutton to confirm.
Determining the water hardness
Water hardness is an indication of the
amount of minerals dissolved in water.
The more minerals in the water, the
higher the water hardness and more
detergent must be dispensed.
Useful tip: You can measure the water
hardness yourself using the enclosed
test strip. Alternatively, your local water
authority will be able to tell you the
hardness of water in your area.
Dip the test strip in the water for
approx. 1second. Shake excess
water off the test strip.
After approx. 1minute, and based on
the coloration, you will be able to read
the water hardness from the table
below.
Test strip Hardness range
4green areas Hardness level I
1 red area
2 red areas Hardness level II
3 red areas Hardness level III
4 red areas

Before using for the first time
19
Settings for compartment
The UltraPhase1 values are pre-set in
the standard default settings.
Agent for  OK





Confirm with the OKsensor button.
Miele UltraPhase 1 OK





Confirm with the OKsensor button.
The following will appear in the display:
Set the dosage. Observe water hardness
levels
Confirm with the OKsensor button.
The dispensing quantity for
UltraPhase1 for (hardness level I)
is pre-set.
Per load OK




ml46
Confirm the pre-set value with the
OKsensor button. If you want to
change this value, use the
sensor buttons and confirm with
the OKsensor button.
UltraPhase1
Hardness level I 46ml
Hardness level II 58ml
Hardness level III 70ml
The following will appear in the display:
Insert 
Remove the film from the detergent
cartridge.
Open the TwinDos flap.

Before using for the first time
20
Push the UltraPhase1 detergent
cartridge into compartment1 until it
locks into position.
Settings for compartment
The UltraPhase2 values are pre-set in
the standard default settings.
After the cartridge has been pushed in,
the display message switches to:
Agent for  OK





Confirm with the OKsensor button.
Miele UltraPhase 2 OK




Confirm with the OKsensor button.
The dispensing quantity for
UltraPhase2 for (hardness level I)
is pre-set.
Per load OK




ml36
Confirm the pre-set value with the
OKsensor button. If you want to
change this value, use the
sensor buttons and confirm with
the OKsensor button.
UltraPhase2
Hardness level I 36ml
Hardness level II 45ml
Hardness level III 54ml
The following will appear in the display:
 Insert 
Remove the film from the detergent
cartridge.
