Milly and Coup Pixi User manual

IMPORTANT! READ CAREFULLY
AND KEEP FOR FUTURE REFERENCE
Stroller Product Manual
Pixi

Contents
Pixi Product Manual
3.
5.
6.
7.
8.
9.
9.
9.
9.
10.
10.
10.
11.
12.
14.
15.
15.
Safety warnings
Parts checklist
Unfolding the stroller
Folding the stroller
Safety harness
Using your Pixi
Rear brake
Front swivel wheels
Adjusting the canopy
Reclining the seat
Adjusting the footrest
Using the belly bar
Accessories
Maintenance
Cleaning instructions
Spare parts
Warranty
2

Tips to avoid tears
Pixi Product Manual
The biggest safety risks relating to
lightweight, travel strollers include:
Tipping:
• Bags should never be hung
from the handlebar as they will
unbalance the stroller.
• The stroller is less stable when
travelling over uneven terrain or up/
down kerbs. Please take extra care.
Falls:
• Climbing into the stroller unassisted
could result in a fall and potentially
break the footrest.
• Securing your child in the safety
harness is the simplest way
to prevent falls.
Rolling:
• Due to their light weight, travel
strollers can easily roll away from
the user if the tether strap or
brake are not being used. Please
use these at all times.
Weight limits:
• Pixi is designed to be used from
birth (with or without newborn
parent facing pack).
• Maximum weight for a child in the
seat is 22kg.
• Maximum age and weight
limit for a child in the separate
newborn parent facing pack is
22kg, although we recommend
this separate seat be used from
newborn to 6 months.
• Maximum weight limit for the
basket is 5kg.
Pixi is designed and tested to comply with Consumer Protection Notice No. 8
of 2007, AS 2088:2022 and AS/NZS ISO 8124-3.
• FOLLOW THE MANUFACTURER’S INSTRUCTIONS.
• PUT ON ALL THE BRAKES WHENEVER YOU PARK THE STROLLER.
• DO NOT LEAVE CHILDREN UNATTENDED.
• DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS STROLLER.
• MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS IF YOU
ADJUST THE STROLLER, OTHERWISE THEY MAY BE INJURED.
• FOLLOW THE MANUFACTURER’S INSTRUCTIONS.
• PUT ON ALL THE BRAKES WHENEVER YOU PARK THE STROLLER.
• DO NOT LEAVE CHILDREN UNATTENDED.
• DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS STROLLER.
• MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS IF YOU
ADJUST THE STROLLER, OTHERWISE THEY MAY BE INJURED.
3

Tips to avoid tears
Pixi Product Manual
General Safety:
• Never use the stroller in a manner for which it is not designed.
• Do not allow your child to climb on, stand on or play with the stroller.
• The stroller should never be used as an unsupervised sleeping environment.
• Ensure you carefully explain usage and safety features to new carers before
they use the stroller.
• Do not use parts or accessories that are not approved for use with the Pixi
range. Doing so may be unsafe and void your warranty.
• Remove your child and take care when going up or down stairs or
escalators.
• Take your child out of the stroller when travelling by bus, tram or train.
• Gentle sloping surfaces may be unstable. On steeper sloping and uneven
surfaces, there is a possibility that the stroller may tip over and you may
need to remove your child.
• Do not use or leave the stroller near open fire or an exposed flame.
• Only to be used for walking. Not suitable for running, rollerblading or skating etc.
4

Pixi Product Manual
Meet Pixi!
5
Stroller
Belly bar
Harness covers
Carry bag
1
2
3
4
Parts Checklist
Please check that you have all the correct
parts before getting started.
1
24
3

Pixi Product Manual
Folding the stroller
Unfolding the stroller
With the handlebar facing up, undo the elastic loops connecting
the backrest to the stroller frame. Release the frame lock on the
left hand side of the frame and pull the handlebar up, swinging
the bottom half of the stroller out and into position
Pixi comes fully assembled in the box ready for your adventure!
Pull the footrest downwards and press firmly until you feel the
seat base click securely into place on the frame.
• ENSURE CHILDREN ARE OUT OF REACH OF THE STROLLER BEFORE
FOLDING.
• TAKE EXTRA CARE WHEN FOLDING, LIFTING AND CARRYING THE
STROLLER. ALWAYS LIFT AND CARRY YOUR STROLLER USING BOTH
HANDS.
• TO AVOID POSSIBLE INJURY, ALWAYS ENSURE THAT THE FRAME LOCK
IS SECURED BEFORE LIFTING AND CARRYING THE STROLLER.
• TO AVOID FINGER ENTRAPMENT, KEEP YOUR OWN AND YOUR
CHILDRENS’ FINGERS CLEAR OF ANY FOLDING PARTS.
6

Pixi Product Manual
Folding the stroller
Unfolding the stroller
7
Ensure the brake is on and the front
wheel locks are not engaged.
Lift the footrest and seat upwards to meet
the backrest.
Secure the elastic loops on the back of the
backrest to the clips on either side of the
frame.
Simultaneously push the lock button (A) and
the release button (B) on the handlebar while
pushing the handlebar forward and down so
that the stroller folds onto itself.
Ensure the frame lock has engaged before
lifting and carrying.
When carrying the stroller, grasp the
handle and avoid lifting with a bent back.
A
B

8
Pixi Product Manual
Using your Pixi
Safety harness
To secure the harness
Insert each of the four harness straps into
the central buckle.
To release, press the button in the middle
of the buckle.
To adjust the length of the shoulder straps
Slide the buckle along the strap to the desired
position.
To adjust the length of the waist straps
Pull the adjustor buckle along the strap
to the desired length.
To adjust the height of the shoulder
straps
Slide the buckle that is secured to the
seat back up or down the strap to the
desired position for your child.
• ALWAYS USE THE HARNESS WHEN YOUR CHILD IS IN THE STROLLER.
• ALWAYS ADJUST THE HARNESS APPROPRIATELY FOR YOUR CHILD’S SIZE.
• NEVER LEAVE THE HARNESS BUCKLED WHEN NOT FITTED TO YOUR
CHILD IN THE STROLLER. THE HARNESS CAN FORM LOOPS WHICH MAY
CAUSE A STRANGULATION HAZARD.

9
Pixi Product Manual
Using your Pixi
Safety harness
Rear brake
When stopped, use the brake at all times
by pressing down on the bottom of the red
brake paddle with your foot until you feel it
click into place.
To start travelling again press down on the
top of the red brake paddle with your foot to
disengage the brake and o you go!
To lock the front wheels into place. turn the
wheels to their locked position and press the
black button down on the back of the front
wheel hub.
To go back to 360 swivel mode, pull the button
up again.
Front swivel wheels
When travelling quickly along straight surfaces or across uneven terrain, the
front wheels may spin or cause what’s commonly known as ‘wheel shudder’.
Simply pull or push the canopy forward or back.
For maximum protection, undo the zip to extend
the canopy to its maximum length to protect
your child from the sun or wind.
For additional air flow, open the peek-a-boo
flap on the canopy.
Adjusting the canopy

Pixi Product Manual
Accessories
Using your Pixi
condense the ‘using your Pixi’ parts like Pixi
:)
Reclining the seat
Squeeze the recline adjustor on the
strap on the back of the seat, pulling
it downwards to your desired position.
To raise the seat, hold the end of the
recline strap with one hand and squeeze
the recline adjustor while sliding it
upwards, bringing the seat up to the
desired position.
Lift the footrest to raise it into place.
To lower, simultaneously squeeze the two
levers located underneath the footrest and
lower into position.
Adjusting the footrest
Simultaneously insert each end of the bar
into the belly bar sockets.
To remove, press the release buttons on both
sides of the bar and pull out.
The belly bar is flexible but does not pivot
or swivel. Overly flexing the belly bar could
distort its shape so take care when removing.
Using the belly bar
10

Pixi Product Manual
Accessories
Using your Pixi
Parent Facing Newborn Pack (sold separately)
We oer a separate newborn seat that
is interchangeable with the stroller seat.
This seat is parent facing and remains
in the flattest, reclined position only.
This seat is designed to be used from
newborn to 6 months.
11
Carry bag
Some airlines require that travel strollers
be placed into a carry bag for storage in
overhead compartments.
We oer a carry bag that is designed to hold
the stroller while in overhead compartments.
This bag is not designed to protect the stroller,
it is for storage purposes only.
Damage incurred to your stroller as a result of airline travel is not
covered by our warranty. We recommend checking if your airline
covers any potential damage incurred.

Pixi Product Manual
Pixi maintenance
Accessories
Pixi maintenance
Excessive wear can reduce the eectiveness and safety of your stroller.
Please be gentle, don’t overload it, avoid excessive o-road use and be
sure to follow the maintenance instructions below to keep your stroller
looking and feeling newer for longer!
Regular maintenance:
• Inspect the locking devices, levers, joints, buttons, brakes, wheels, safety
harness and fixtures to ensure they are secure, moving freely and in full
working order.
• If your front wheels or any parts of the stroller have become sti, dicult to
operate or begin to squeak, first ensure that dirt is not the cause and give
12
• NEVER LEAVE THE STROLLER COVERED INDOORS, IN VERY HOT
WEATHER OR NEAR A HEAT SOURCE.
• ALWAYS SUPERVISE WHILE THE STROLLER IS COVERED.
Rain cover (sold separately)
Place the rain cover over the stroller
as shown.

Pixi Product Manual
Pixi maintenance
Accessories
Pixi maintenance
them a good clean with a damp (not wet) cloth. Then try a light application
of a sprayable silicone lubricant, ensuring that it penetrates between the
components.
POISONOUS, TOXIC SUBSTANCE. USE WITH CARE.
• ENSURE CHILDREN ARE NOT PRESENT WHEN APPLYING SILICONE
LUBRICANT OR ALLOWING IT TO DRY.
• ALWAYS SPRAY OUTSIDE OR IN A WELL-VENTILATED AREA.
• ENSURE YOU USE MINIMAL PRODUCT AND WIPE AWAY EXCESS
SOLUTION BEFORE USE.
Correct storage:
• Do not leave the stroller in direct sunlight for prolonged periods of time to avoid
colour fade.
• Do not leave the stroller in your car on hot days or near any heat source or fire.
• Do not store the stroller with heavy items on top of it.
• Store the stroller in a dry, well-ventilated, and safe place.
Preventing rust and mould:
After exposure to wet or damp conditions (especially trips to the beach, snow
or in the rain), leave the stroller fully open in a warm, well ventilated environment
to prevent rust and mould.
You may need to dry the stroller with a soft, lint free cloth. Left damp it will
encourage mildew, mould or rust to form causing damage.
Try to store your stroller in a dry, well-ventilated room inside your house.
Ventilation is key.
Note: mould is an environmental issue caused by excess moisture in the air.
If you live in a humid climate, please keep this in mind and take extra care to
prevent mould.
13

Pixi Product Manual
Spare parts
Cleaning instructions
DO NOT
• Do not immerse the seat or canopy in water, sponge clean only.
• Do not clean with abrasive materials or use ammonia, bleach, solvents,
caustic or spirit-based cleaners.
• Do not press or iron.
• Do not rub or wring fabric.
• Do not tumble dry.
• Do not dry clean.
To keep your stroller looking and functioning like new, we recommend a deep,
comprehensive clean every 6 months.
Refer to the care labels on your stroller. For a full guide on how to clean your
stroller, please refer to our website.
Failing to adhere to these maintenance and cleaning instructions could
damage or aect the safety of your stroller and may void your warranty.
• Do not clean your stroller with children around.
• Do not remove, dismantle, or alter any part of the folding mechanisms,
frame, brake axle or wheels for cleaning or any other reason.
• Do not use if any part is broken, torn, or missing. Replacement parts
are available from our website or by contacting us.
Tips to avoid tears
Warranty
14

Pixi Product Manual
Spare parts
Cleaning instructions
The wheels are subject to normal wear and tear and should be replaced
if necessary.
Spare parts are available for purchase on the Accessories and Spare Parts
page of our website (millyandcoup.com). If the part you require is not listed,
please email us for a quote at:
[e-mail] or [e-mail]
Warranty
Pixi comes with a 3 year defects warranty to cover against faults in materials
and workmanship when your stroller is used under normal conditions,
according to our user manual and technical specifications.
Our goods come with guarantees that cannot be excluded under the
Consumer Law in the country of purchase. You are entitled to a replacement
or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
For full warranty terms and conditions or to make a claim, please visit the
Warranty page of our website for details.
15

Contact Us:
[e-mail] | [e-mail]
Model: Pixi Version: 1 - January 2023
Information subject to change. Please see website for current version.
millyandcoup.com
