Mindray V60 User manual

V60 Anesthetic Vaporizer
Operator’s Manual

V60AnestheticVaporizerOperator’sManual ĉ
© 2015 Shenzhen Mindray Bio-Medical Electronics Co., Ltd. All rights Reserved.
Operator's Manual issue date November, 2015.

V60AnestheticVaporizerOperator’sManual II
Intellectual Property Statement
SHENZHEN MINDRAY BIO-MEDICAL ELECTRONICS CO., LTD. (hereinafter called Mindray)
owns the intellectual property rights to this Mindray product and this manual. This manual may refer
to information protected by copyright or patents and does not convey any license under the patent
rights or copyright of Mindray, or of others.
Mindray intends to maintain the contents of this manual as confidential information. Disclosure of the
information in this manual in any manner whatsoever without the written permission of Mindray is
strictly forbidden. Release, amendment, reproduction, distribution, rental, adaptation, translation or
any other derivative work of this manual in any manner whatsoever without the written permission of
Mindray is strictly forbidden.
,and are the trademarks, registered or otherwise, of Mindray in
China and other countries.
All other trademarks that appear in this manual are used only for editorial purposes without the
intention of improperly using them. They are the property of their respective owners.

V60AnestheticVaporizerOperator’sManual III
Manufacturer's Responsibility
Contents of this manual are subject to change without prior notice.
All information contained in this manual is believed to be correct. Mindray shall not be liable for
errors contained herein or for incidental or consequential damages in connection with the furnishing,
performance, or use of this manual.
Mindray is responsible for the effects on safety, reliability and performance of this product, only if:
all installation operations, expansions, changes, modifications and repairs of this product are
conducted by Mindray authorized personnel;
the electrical installation of the relevant room complies with the applicable national and local
requirements;and
the product is used in accordance with the instructions for use.
WARNING
zThis anesthetic vaporizer must be operated by skilled/trained clinical professionals.
zIt is important for the hospital or organization that uses this equipment to perform
a reasonable service/maintenance plan. Neglecting this may result in machine
breakdown or personal injury.
Warranty
Mindray DS USA, Inc. warrants that components within its products will be free from defects in
workmanship and materials for the number of years shown on the invoice. Under this extended
warranty, Mindray DS USA, Inc. will repair or replace any defective component at no charge for labor
and/or materials.
Recommended preventative maintenance, as prescribed in the Maintenance section of this manual, is
the responsibility of the user, and is not covered by this warranty.
Except as otherwise provided herein, the terms, conditions, and limitations of Mindray DS USA, Inc.ÿ
s standard warranty will remain in effect.
Mindray DS USA, Inc. warrants that its products will be free from defects in workmanship and
materials for a period of one (1) year from the date of purchase except that disposable or one-time use
products are warranted to be free from defects in workmanship and materials up to a date one year
from the date of purchase or the date of first use, whichever is sooner.
Mindray DS USA, Inc. will not be liable for any incidental, special, or consequential loss, damage, or
expense directly or indirectly arising from the use of its products, liability under this warranty and the
buyerÿs exclusive remedy under this warranty is limited to servicing or replacing at Mindray DS USA,
Inc.ÿs option at the factory or at an authorized distributor, any product which shall under normal use
and service appear to the Company to have been defective in material or workmanship.

V60AnestheticVaporizerOperator’sManual IV
No agent, employee, or representative of Mindray DS USA, Inc. has any authority to bind Mindray
DS USA, Inc. to any affirmation, representation, or warranty concerning its products, and any
affirmation, representation or warranty made by any agent, employee, or representative shall not be
enforceable by buyer.
This warranty is expressly in lieu of any other express or implied warranties, including any implied
warranty or merchantability or fitness, and of any other obligation on the part of the seller.
Damage to any product or parts through misuse, neglect, accident, or by affixing any non-standard
accessory attachments or by any customer modification voids this warranty. Mindray DS USA, Inc.
makes no warranty whatsoever in regard to trade accessories, such being subject to the warranty of
their respective manufacturers.
A condition of this warranty is that this equipment or any accessories which are claimed to be
defective be returned when authorized, freight prepaid to Mindray DS USA, Inc., Mahwah, New
Jersey 07430. Mindray DS USA, Inc. shall not have any responsibility in the event of loss or damage
in transit.
Exemptions
Mindray's obligation or liability under this warranty does not include any transportation or other
charges or liability for direct, indirect or consequential damages or delay resulting from the improper
use or application of the product or the use of parts or accessories not approved by Mindray or repairs
by people other than Mindray authorized personnel.
This warranty shall not extend to:
Malfunction or damage caused by improper use or man-made failure.
Malfunction or damage caused by unstable or out-of-range power input.
Malfunction or damage caused by major forces such as fire and earthquake.
Malfunction or damage caused by improper operation or repair by unqualified orunauthorized
service people.
Malfunction of the instrument or part whose serial number is not legible enough.
Others not caused by instrument or part itself.

V60AnestheticVaporizerOperator’sManual V
Service
Mindray maintains a network of service representatives and factory-trained distributors. Prior to
requesting service, perform a complete operational check of the instrument to verify proper control
settings. If operational problems continue to exist, In North America contact the Service Department
at [phone], ext: 8116 for Technical Support or [phone] for assistance in determining
the nearest field service location.
Please include the instrument model number, the serial number, and a description of the problem with
all requests for service.
Any questions regarding the warranty should be directed to your local sales or service representative.
Company Contact
Manufacturer: Shenzhen Mindray Bio-Medical Electronics Co., Ltd.
Address: Mindray Building,Keji 12th Road South,High-tech industrial
park,Nanshan,Shenzhen 518057,P.R.China
Website: www.mindray.com
E-mail Address: [email protected]
Tel: [phone]
Fax: [phone]
Distributor: Mindray DS USA, Inc.
Address: 800 MacArthur Blvd., Mahwah, NJ 07430
Dom. Customer Service: 1.800.288.2121
Intl. Customer Service: +1.201.995.8000

V60AnestheticVaporizerOperator’sManual VI
FOR YOUR NOTES

V60 Anesthetic Vaporizer Operator’s Manual 1
Table of Contents
1 Safety................................................................................................................................. 1-1
1.1 Safety Information .......................................................................................................... 1-1
1.1.1 Warnings............................................................................................................. 1-2
1.1.2 Cautions ............................................................................................................. 1-3
1.1.3 Notes .................................................................................................................. 1-3
1.2 Anesthetic Vaporizer Symbols ........................................................................................ 1-4
2 The Basics ......................................................................................................................... 2-1
2.1 Product Description......................................................................................................... 2-1
2.2 Intended Use ................................................................................................................... 2-2
2.3 Anesthetic Vaporizer Appearance.................................................................................... 2-2
2.3.1 Front View.......................................................................................................... 2-2
2.3.2 Rear View........................................................................................................... 2-3
2.4 Configuration Differences............................................................................................... 2-4
3 Method of Operation........................................................................................................ 3-1
3.1 Control Dial..................................................................................................................... 3-1
3.2 Connecting and Interlock System ................................................................................... 3-1
3.2.1 Plug-in Adapter/Plug-in Connector.................................................................... 3-2
3.2.2 Interlock Device ................................................................................................. 3-3
3.3 Filling System ................................................................................................................. 3-4
4 Filling and Draining......................................................................................................... 4-1
4.1 Checks before Filling ...................................................................................................... 4-1
4.2 Filling the Vaporizer........................................................................................................ 4-1
4.2.1 Key Filler System............................................................................................... 4-2
4.2.2 Quik-Fil System ................................................................................................. 4-7
4.3 Draining the Vaporizer .................................................................................................... 4-9
4.3.1 Key Filler System............................................................................................... 4-9
4.3.2 Quik-Fil System ............................................................................................... 4-12
4.4 Blowing off the Vaporizer ............................................................................................. 4-14
5 Checks before Use ............................................................................................................ 5-1
5.1 Checklist—checks before each use................................................................................. 5-1
5.2 Setting Checks................................................................................................................. 5-2
6 Basic Operations .............................................................................................................. 6-1
6.1 Connecting the Vaporizer ................................................................................................ 6-1
6.2 Adjusting the Concentration of Anesthetic Agent ........................................................... 6-4
6.3 Switching off the Vaporizer............................................................................................. 6-5
6.4 Disconnecting the Vaporizer ........................................................................................... 6-6
6.5 Moving when Filled ........................................................................................................ 6-6
7 Cleaning and Disinfecting................................................................................................ 7-1
7.1 Cleaning .......................................................................................................................... 7-1
7.2 Disinfecting..................................................................................................................... 7-2
8 User Maintenance............................................................................................................. 8-1
8.1 Repair Policy................................................................................................................... 8-1
8.2 Maintenance Schedule .................................................................................................... 8-1

V60AnestheticVaporizerOperator’sManual 2
8.3 Checking the Concentration ............................................................................................ 8-2
8.4 Checking the Filling System ........................................................................................... 8-3
8.5 Checking the Plug-in Adapter ......................................................................................... 8-3
9 Troubleshooting................................................................................................................ 9-1
9.1 Operation Related Faults and Remedies ......................................................................... 9-1
9.2 Filling and Draining Related Faults and Remedies......................................................... 9-3
9.3 Plug-in Adapter Related Faults and Remedies ................................................................ 9-3
10 Storage and Transport ................................................................................................. 10-1
10.1 Storage ........................................................................................................................ 10-1
10.2 Transport ..................................................................................................................... 10-1
11 Theory of Operation......................................................................................................11-1
11.1 Operating Principle ......................................................................................................11-1
11.2 Calibration....................................................................................................................11-3
11.3 Influence of Temperature .............................................................................................11-3
11.4 Influence of Flow .........................................................................................................11-5
11.5 Influence of Gas Composition......................................................................................11-6
11.6 Influence of Atmospheric Pressure...............................................................................11-7
11.7 Influence of Fluctuations in Pressure ...........................................................................11-8
11.8 Influence of Running Time...........................................................................................11-8
11.9 Anesthetic Agent Consumption ....................................................................................11-9
A Product Specifications.................................................................................................... A-1
A.1 Standards Compliance................................................................................................... A-1
A.2 Physical Specifications.................................................................................................. A-1
A.3 Operating Range............................................................................................................ A-2
A.4 Performance Specifications........................................................................................... A-2
A.5 Product Configurations ................................................................................................. A-3
A.6 Flow Range ................................................................................................................... A-3
B Accessories List ................................................................................................................B-1
C Symbols and Terminology ............................................................................................. C-1
C.1 Symbols ..........................................................................................................................C-1
C.2 Terminology ...................................................................................................................C-1

V60 Anesthetic Vaporizer Operator’s Manual 1-1
1Safety
1.1 Safety Information
WARNING
zIndicates a potential hazard or unsafe practice that, if not avoided, could result in death or
serious injury.
CAUTION
zIndicates a potential hazard or unsafe practice that, if not avoided, could result in minor
personal injury or product/property damage.
NOTE
zProvides application tips or other useful information to ensure that you get the most from
your product.

V60AnestheticVaporizerOperator’sManual 1-2
1.1.1 Warnings
WARNING
zDo not operate the anesthetic vaporizer before reading this manual.
zThe user of the anesthetic vaporizer must fully understand and strictly follow the
instructions for use.
zBefore putting the system into operation, the user must verify that the anesthetic vaporizer
is in correct working order and operating condition.
zDo not use the anesthetic vaporizer in the environment outside the specified temperature
and pressure ranges.
zTo avoid explosion hazard, do not use the anesthetic vaporizer in the presence of
flammable anesthetic agent, vapors or liquids.
zDispose of the package material, observing the applicable waste control regulations and
keep them out of children’s reach.
zTo avoid explosion hazard, use only specified non-combustible anesthetic agent in
compliance with the requirement of ISO8835-4.
zAny unauthorized organization or untrained person must not change or disassemble the
anesthetic vaporizer.
zThis anesthetic vaporizer may not be modified without the manufacturer’s permission.
zThe medical device must be inspected and serviced regularly by authorized service
personnel.
zBefore use, check that the shipping package is intact.
zThe anesthetic vaporizer shall not be serviced or maintained while in use with a patient.
zDo not use the anesthetic vaporizer when there is an anesthetic agent leak.
zThe vaporizer is designed for use only with the specific anesthetic agent named on the filler
block (and further indicated by labels of different colors). Do not use the vaporizer if the
vaporizer is filled with any agent other than the agent specified on the front label.
zThis anesthetic vaporizer is not suitable for use in an MRI environment.

V60AnestheticVaporizerOperator’sManual 1-3
1.1.2 Cautions
CAUTION
zUse only accessories specified in this manual.
zAt the end of its service life, the anesthetic vaporizer, as well as its accessories, must be
disposed of in compliance with the guidelines regulating the disposal of such products.
zThe anesthetic vaporizer may become unstable if the unit is tilted beyond 10 degrees.
zAlways install or carry the anesthetic vaporizer properly to avoid damage caused by drop,
impact, strong vibration or other mechanical force. Do not carry by the control dial or the
handle for locking lever.
1.1.3 Notes
NOTE
zKeep this manual close to the anesthetic vaporizer so that it can be obtained conveniently
when needed.
zThis manual describes all features and options. Your anesthetic vaporizer may not have all
of them.

V60AnestheticVaporizerOperator’sManual 1-4
1.2 Anesthetic Vaporizer Symbols
Refer to instruction manual/booklet
Gas flow direction
Adjust concentration as the arrow shows
Press and lock as the arrow shows
Caution
MR Unsafe – do not subject to magnetic resonance imaging (MRI)
The device has been type tested to the regulatory requirements and
bears the SGS Mark for safety. SGS is Nationally Recognized Test
Laboratory (NRTL) per OSHA.
Rx only
U.S. Federal Law restricts this device to sale by or on the order of a
physician or other practitioner licensed by state law to use or order the
use of this device.

V60AnestheticVaporizerOperator’sManual 2-1
2The Basics
2.1 Product Description
This vaporizer is an unheated, calibrated anesthetic vaporizer used for evaporating liquid anesthetic
agents and delivering mixed gas of controlled concentration to an anesthetic delivery system.
Each vaporizer is calibrated for a specified anesthetic agent and is only suitable for that anesthetic
agent. The specific agent that the vaporizer must be used with is marked in text and by specific color
on the vaporizer.
The vaporizer compensates for variations of temperature, pressure and flow. Therefore, under the
circumstances specified in this manual, the output concentration of the vaporizer is not influenced by
ambient conditions, such as temperature, gas flow and ventilation pressure.
The anesthetic vaporizer is not suitable for use with an anesthetic delivery system with vaporizer
placed inside the circuit system due to relatively high internal pneumatic resistance.
The vaporizer delivery system is in compliance with ISO8835-4.
The Key Filler system is in compliance with ISO5360.
Quik-Fil system complies with the performance data of ISO5360.
Mindray recommends that the output concentration is monitored through an anesthetic gas monitoring
device in compliance with ISO80601-2-55 to detect any hazardous output values.
Use an anesthetic gas scavenging system in compliance with ISO8835-3 to minimize atmospheric
pollution in the operating room.
WARNING
zDo not use the anesthetic vaporizer in mobile vehicles, aeroplanes, helicopters and / or
ships.

V60AnestheticVaporizerOperator’sManual 2-2
2.2 Intended Use
V60 Anesthetic Vaporizer is an unheated, calibrated anesthetic vaporizer used for evaporating liquid
anesthetic agents and delivering mixed gas of controlled concentration to an anesthetic delivery
system.
The V60 Anesthetic Vaporizer is available in models specific for use with Isoflurane and models
available specific for use with Sevoflurane.
WARNING
zThe anesthetic vaporizer is intended to be operated only by licensed clinicians and qualified
anesthesia personnel who have received adequate training in its use. Anyone unauthorized
or untrained must not perform any operation on the anesthetic vaporizer.
zThis anesthetic vaporizer is not suitable for use in an MRI environment.
2.3 Anesthetic Vaporizer Appearance
2.3.1 Front View
1. “0” button
2. Control dial
3. Filling system
4. Color mark for anesthetic agent
5. Sight glass for filling level
6. Drainage screw

V60AnestheticVaporizerOperator’sManual 2-3
2.3.2 Rear View
1. Handle for locking lever
2. Interlock system
3. Locking pin

V60AnestheticVaporizerOperator’sManual 2-4
2.4 Configuration Differences
Model Sevoflurane Key Filler
Vaporizer
Isoflurane Key Filler
Vaporizer
Sevoflurane Quik-Fil
Vaporizer
Anesthetic agent Sevoflurane Isoflurane Sevoflurane
Filling system Key Filler system Key Filler system Quik-Fil system
Filler Accessory
Drainage
Accessory

V60AnestheticVaporizerOperator’sManual 3-1
3Method of Operation
3.1 Control Dial
The control dial is used to set the output concentration of the anesthetic agent. The control dial is
marked with output concentration of the anesthetic agent from the vaporizer. The graduation to which
the dial is turned indicates the output concentration.
The “0” button on the vaporizer has a locking function. Press this button first before turning the
control dial.
If the vapor is stored in high temperature and then used, the concentration of the delivered anesthetic
agent may be high. To enable pressure equalization, always turn the control dial to 1% after
connecting to the anesthetic workstation, and wait for at least 15 seconds.
3.2 Connecting and Interlock System
When the anesthetic delivery system is connected to multiple vaporizers, the interlock systems of the
vaporizers ensure that only one vaporizer can be switched on at any one time while the others remain
off and in a locked state.
“0” button
control dial
Interlock device

V60AnestheticVaporizerOperator’sManual 3-2
3.2.1 Plug-in Adapter/Plug-in Connector
The vaporizer is for use with anesthetic delivery systems utilizing the Ohmeda Selectatec®
compatible manifold system.
The openings in the plug-in adapter on the vaporizer fit onto the pins on the plug-in connector on the
anesthetic delivery system.
To connect/disconnect the vaporizer, the control dial must be at the “0” setting indicating locked
status.
Plug-in adapter and pin
Plug-in connector
Control dial at the “0” setting
