Minolta DiMAGE S404 User manual

INSTRUCTION MANUAL
E

2 3
Thank you for purchasing this Minolta digital camera. Please take the time to read
through this instruction manual so you can enjoy all the features of your new camera.
This manual contains information regarding products introduced before February, 2002.
To obtain compatibility information for products released after this date, contact a
Minolta Service Facility listed on the back cover of this manual.
Check the packing list before using this product. If any items are missing, immediately
contact your camera dealer.
Minolta DiMAGE S404 digital camera
AA alkaline batteries (set of four)
Neck strap NS-DG304
Lens cap LF-236
16MB CompactFlash card
AV cable AVC-100
USB cable USB-600
DiMAGE software CD-ROM
ArcSoft PhotoImpression CD-ROM
DiMAGE Image Viewer Utility instruction manual
Camera manual
Warranty card
BEFORE YOU BEGIN
Because the performance of alkaline batteries with digital cameras is low,
the use of Ni-MH batteries is recommended. Although alkaline batteries
are supplied with this product, its performance will be limited; only use
alkaline batteries for test photographs or when Ni-MH batteries, the
Minolta external battery pack, or the AC adapter are not available. Fully
recharge the Ni-MH batteries just before using the camera.
Read and understand all warnings and cautions before using this product.
Using batteries improperly can cause them to leak harmful solutions, overheat, or explode
which may damage property or cause personal injury. Do not ignore the following
warnings.
• Only use the batteries specified in this instruction manual.
• Do not install the batteries with the polarity (+/–) reversed.
• Do not use batteries which show wear or damage.
• Do not expose batteries to fire, high temperatures, water, or moisture.
• Do not attempt to short or disassemble batteries.
• Do not store batteries near or in metallic products.
• Do not mix batteries of different types, brands, ages, or charge levels.
• Do not charge alkaline batteries.
• When recharging rechargeable batteries, only use the recommended charger.
• Do not use leaking batteries. If fluid from the batteries enters your eye, immediately
rinse the eye with plenty of fresh water and contact a doctor. If fluid from the batteries
makes contact with your skin or clothing, wash the area thoroughly with water.
WARNING
FOR PROPER AND SAFE USE
• Use only the specified AC adapter within the voltage range indicated on the adapter
unit. An inappropriate adapter or current may cause damage or injury through fire or
electric shock.
• Do not disassemble this product. Electric shock may cause injury if a high voltage circuit
inside the product is touched.
• Immediately remove the batteries or unplug the AC adapter and discontinue use if the
camera is dropped or subjected to an impact in which the interior, especially the flash
unit, is exposed. The flash has a high voltage circuit which may cause an electric shock
resulting in injury. The continued use of a damaged product or part may cause injuries
or fire.

4 5
FOR PROPER AND SAFE USE
• Keep batteries or small parts that could be swallowed away from infants. Contact a
doctor immediately if an object is swallowed.
• Store this product out of reach of children. Be careful when around children, not to harm
them with the product or parts.
• Do not fire the flash directly into the eyes. It may damage eyesight.
• Do not fire the flash at vehicle operators. It may cause a distraction or temporary
blindness which may lead to an accident.
• Do not use the monitor while operating a vehicle or walking. It may result in injury or an
accident.
• Do not use this product in a humid environment, or operate this product with wet hands.
If liquid enters the product, immediately remove the batteries or unplug the AC adapter
and discontinue use. The continued use of a product exposed to liquids may cause
damage or injury through fire or electric shock.
• Do not use the product near inflammable gases or liquids such as gasoline, benzine, or
paint thinner. Do not use inflammable products such as alcohol, benzine, or paint
thinner to clean the product. The use of inflammable cleaners and solvents may cause
an explosion or fire.
• When unplugging the AC adapter, do not pull on the power cord. Hold the adapter unit
when removing it from an outlet.
• Do not damage, twist, modify, heat, or place heavy objects on the AC adapter cord. A
damaged cord may cause damage or injury through fire or electric shock.
• If the product emits a strange odor, heat, or smoke, discontinue use. Immediately
remove the batteries taking care not to burn yourself as the batteries become hot with
use. The continued use of a damaged product or part may cause injuries or fire.
• Take the product to a Minolta Service Facility when repairs are required
• Do not use or store the product in a hot or humid environment such as the glove
compartment or trunk of a car. It may damage the product and batteries which may
result in burns or injuries caused by heat, fire, explosion, or leaking battery fluid.
• If batteries are leaking, discontinue use of the product.
• The camera temperature rises with extended periods of use. Care should be taken to
avoid burns.
• Burns may result if the CompactFlash card or batteries are removed immediately after
extended periods of use. Turn the camera off and wait for it to cool.
• Do not fire the flash while it is in contact with people or objects. The flash unit
discharges a large amount of energy which may cause burns.
• Do not apply pressure to the LCD monitor. A damaged monitor may cause injury, and
the liquid from the monitor may cause inflammation. If liquid from the monitor makes
contact with skin wash the area with fresh water. If liquid from the monitor comes in
contact with the eyes, immediately rinse the eyes with plenty of water and contact a
doctor.
• When using the AC adapter, insert the plug securely into the electrical outlet.
• Do not use if the AC adapter cord is damaged.
• Do not cover the AC adapter. A fire may result.
• Do not obstruct access to the AC adapter; this can hinder the unplugging of the unit in
emergencies.
• Unplug the AC adapter when cleaning or when the product is not in use.
CAUTION

6 7
TABLE OF CONTENTS
The basic operation of this camera is covered between pages 10 and 27. This section
of the manual covers the camera parts, preparation of the camera for use, and the
basic camera operation for recording, viewing, and deleting images.
The auto-recording mode section covers all the basic functions of the camera in this
mode and the multi-function recording mode. Take time to read this section before
moving on to the multi-function recording mode section. The other sections, movie
recording mode, playback mode, setup mode, and data transfer mode, can be read as
needed.
Many of the features of this camera are controlled with menus. The menu navigation
sections concisely describe how to change menu settings. Descriptions of the settings
immediately follow the navigation sections.
Throughout the text are shooting tips and camera notes. Shooting tips give advice and
information on photography and how to use the camera to achieve the best results.
Camera notes cover details on camera operation.
ABOUT THIS MANUAL Basic recording operation........................................................................................................23
Focus lock ...............................................................................................................................24
Focus range.............................................................................................................................24
Focus signals...........................................................................................................................25
Special focusing situations......................................................................................................25
Quick view...............................................................................................................................26
Quick-view display......................................................................................................27
Deleting images in quick view ....................................................................................27
Digital-subject-program button ................................................................................................28
Flash modes............................................................................................................................30
Flash range - auto-recording mode.........................................................................................31
Flash signals............................................................................................................................31
Camera-shake warning ...........................................................................................................31
Drive modes ............................................................................................................................32
Self-timer.....................................................................................................................33
Remote control (sold separately)................................................................................34
Continuous advance...................................................................................................35
Bracketing...................................................................................................................36
Display button - recording mode .............................................................................................37
Navigating the auto-recording mode menu.............................................................................38
Image size ..................................................................................................................40
Image quality ..............................................................................................................41
Image-file size and CompactFlash card capacity.......................................................42
Voice memo................................................................................................................43
Date imprinting............................................................................................................44
Instant playback..........................................................................................................45
Exposure compensation..........................................................................................................46
What is an Ev? What is a stop?..............................................................................................47
Multi-function recording mode - advanced operation...........................................................................48
Autofocus areas and control....................................................................................................48
Navigating the multi-function recording mode menu...............................................................50
Exposure modes.........................................................................................................52
Program.................................................................................................................52
Aperture priority - A ...............................................................................................52
Manual exposure - M ............................................................................................53
White balance.............................................................................................................54
Automatic white balance .......................................................................................54
Preset white balance.............................................................................................54
Names of parts
Camera body...........................................................................................................................10
Viewfinder................................................................................................................................12
Mode dial.................................................................................................................................12
Data panel...............................................................................................................................13
LCD monitor display................................................................................................................14
Getting up and running.........................................................................................................................15
Attaching the neck strap and lens cap....................................................................................15
Changing batteries ..................................................................................................................16
Battery condition indicator.......................................................................................................17
Auto power save......................................................................................................................17
External power supplies (sold separately)...............................................................................18
Changing the CompactFlash card...........................................................................................18
Auto-recording mode - basic operation................................................................................................20
Handling the camera ...............................................................................................................20
Setting the camera to record images automatically................................................................21
Zoom lens and digital zoom ....................................................................................................22

8 9
TABLE OF CONTENTS
Custom white balance...........................................................................................55
Focus modes..............................................................................................................56
Camera sensitivity - ISO.............................................................................................57
Flash range and camera sensitivity............................................................................57
Full-time AF.................................................................................................................58
Metering modes..........................................................................................................58
Exposure bracketing...................................................................................................59
Digital zoom and image size.......................................................................................59
Image control - color, sharpness, contrast, & saturation............................................60
Bulb exposures........................................................................................................................61
A short guide to photography...............................................................................................................62
Movie recording....................................................................................................................................64
Recording movies with the RC-3 remote control (sold separately).........................................65
Playback mode - viewing and editing images......................................................................................66
Single-frame playback display.................................................................................................66
Histogram display....................................................................................................................67
Movie playback display............................................................................................................67
Viewing pictures ......................................................................................................................68
Viewing movies........................................................................................................................69
Deleting images.......................................................................................................................69
Display button - playback mode..............................................................................................70
Enlarged playback...................................................................................................................71
Navigating the playback-mode menu......................................................................................72
Playback-mode menu - basic..................................................................................................74
Deleting images..........................................................................................................74
Locking images...........................................................................................................75
Changing the index playback format..........................................................................75
Playback-mode menu - custom 1 (Slide Show)......................................................................76
Playback-mode menu - custom 2............................................................................................78
About DPOF ...............................................................................................................78
Creating a DPOF print order.......................................................................................78
Ordering an index print...............................................................................................79
Canceling a DPOF print order....................................................................................79
Copying images..........................................................................................................80
Frame-selection screen...........................................................................................................81
Viewing images on a television...............................................................................................82
Setup mode - controlling the camera’s operation ................................................................................83
Navigating the setup menu......................................................................................................84
Setup menu - basic .................................................................................................................86
LCD monitor brightness..............................................................................................86
Formatting CompactFlash cards.................................................................................86
Auto power save.........................................................................................................87
Audio signals ..............................................................................................................87
Volume........................................................................................................................87
Language....................................................................................................................87
Setup menu - custom 1...........................................................................................................88
File number memory...................................................................................................88
Select folder................................................................................................................88
Setup menu - Custom 2 ..........................................................................................................89
Resetting the camera..................................................................................................89
Setting the date and time............................................................................................90
Setting the date format...............................................................................................91
Video output................................................................................................................91
Data-transfer mode - connecting to a computer ..................................................................................92
Arcsoft PhotoImpression system requirements.......................................................................93
QuickTime system requirements.............................................................................................93
Connecting the camera to a computer....................................................................................94
Connecting to Windows 98 and 98SE.....................................................................................96
Automatic installation..................................................................................................96
Manual installation......................................................................................................97
Connecting to Mac OS 8.6......................................................................................................99
Auto power save (data-transfer mode)....................................................................................99
CompactFlash card folder organization .............................................................................................100
Disconnecting the camera from the computer ......................................................................102
Windows 98 and 98SE.............................................................................................102
Windows Me, 2000 Professional, and XP................................................................102
Macintosh..................................................................................................................103
Changing the CompactFlash card (data-transfer mode).......................................................104
Troubleshooting..................................................................................................................................105
About Ni-MH batteries...........................................................................................................107
Removing the driver software - Windows..............................................................................108
Care and storage ...............................................................................................................................109
Technical specifications......................................................................................................................114

10 11
* This camera is a sophisticated optical instrument. Care should be taken to keep
these surfaces clean. Please read the care and storage instructions in the back of
this manual (p. 109).
NAMES OF PARTS
CAMERA BODY
Data panel (p. 13)
Shutter-release button
Lens*
Card-slot door (p. 18)
The USB port and AV-out
terminal are located behind
the card-slot door.
Self-timer/
Remote-control
lamp (p. 32)
Flash (p. 30)
Digital-subject-program button (p. 28)
Strap eyelet (p. 15)
Viewfinder* (p. 12)
LCD monitor*
(p. 14)
Menu button
Battery-chamber lock (p. 16)
Flash mode/Magnification button (p. 30, 71)
DC terminal cover (p. 18)
Access lamp
QV/ Delete button (p. 26)
Tripod socket
Speaker
Microphone
Remote-control
receiver
Mode dial (main switch)
Viewfinder window*
Battery-chamber door (p. 16)
Card-slot door release
Drive-mode button (p. 32)
Exposure-compensation button (p. 46)
Controller
CCD plane
Display button (p. 37, 70)

12 13
DATA PANEL
Frame counter
(p. 42)
NAMES OF PARTS
MODE DIAL Auto-recording mode (p. 20)
Multi-function recording mode (p. 48)
Playback mode (p. 66)
Movie-recording mode (p. 64)
Setup mode (p. 83)
Data-transfer mode (p. 92)
VIEWFINDER
Focus lamp
(green)
Flash lamp
(orange)
Focus frame
This dial gives direct
and easy access to
the camera’s major
modes. It also acts
as the main switch
Digital-subject-program indicators (p. 28)
Exposure-compensation indicator (p. 46)
Camera-sensitivity indicator (p. 57)
Spot-metering indicator (p. 58)
Battery-condition indicator (p. 17)
White-balance indicator (p. 54)
Flash-mode indicators (p. 30)
Manual-focus indicator (p. 56)
Image-size display (p. 40)
Image-quality display (p. 41)
Drive-mode indicators (p. 32)
Microphone indicator (p. 43)
Exposure-mode indicators (p. 52)
Digital-subject-program icons (p. 28)
Because the optical viewfinder and the lens are slightly separated, the image seen
through one is not exactly the same as the other; this is called parallax. Parallax can
cause errors in framing at close distances and is more pronounced at longer focal
lengths. When the subject is closer than 1m (3ft) at the wide-angle lens positions or 3m
(9.8ft) at the telephoto lens position, use the LCD monitor to compose the image;
because the lens creates the monitor image, it does not suffer from parallax.

Using your thumb and
index finger, pinch the
outside tabs of the
lens cap to remove or attach.
• When the camera is not in use, always replace the
lens cap.
14 15
NAMES OF PARTS
Attach the camera strap to the strap eye-
lets as shown.
• Make sure the neck strap passes through
the loop of the lens-cap strap.
• Always keep the camera strap around your
neck in the event that you drop the camera.
Attach the small strap to the lens cap by passing one of the
small loops through the eyelet on the cap (1) and then pass-
ing the other loop through the first loop (2) and tightening. 1
2
ATTACHING THE NECK STRAP AND LENS CAP
GETTING UP AND RUNNING
4
3
LCD MONITOR DISPLAY
b. Flash-mode indicator (p. 30)
d. Contrast-compensation display (p. 60)
e. Color-saturation-compensation
display (p. 60)
f. Exposure-compensation display (p. 46)
g. White-balance indicator (p. 54)
m. Camera-sensitivity (ISO) display (p. 57)
j. Metering-mode indicator (p. 58)
l. Camera-shake warning (p. 31)
i. Shutter-speed display
k. Aperture display
n. Manual-focus indicator (p. 56)
r. Macro indicator (p. 28)
q. Drive-mode indicator (p. 32)
o. Focus signal (p. 25)
p. Frame counter (p. 42)
v. Digital-zoom display (p. 22)
u. Image-size display (p. 40)
t. Image-quality indicator (p. 41)
s. Battery-condition indicator (p. 17)
a. Mode indicator (p. 12)
1. Focus frame (p. 48)
2. Spot metering area (p. 58)
3. AF sensors (p. 23)
h. Exposure-mode (p. 52)/
Digital-subject-program indicators (p. 28)
c. Sharpness display (p. 60)

16 17
CHANGING BATTERIES
Insert the batteries.
• Make sure the positive and negative
battery terminals are orientated as
illustrated on the diagram in the
battery chamber.
This digital camera uses four AA-size alkaline or Ni-MH batteries. Ni-MH batteries are
recommended because of longer life. When using Ni-MH batteries, fully recharge them
with a battery charger suitable for complex electronic equipment. Please consult your
vendor about an appropriate charger.
When replacing batteries, the mode dial should be in
the off position.
• If the camera is not turned off when replacing exhausted
batteries, the low-battery warning may not reset.
Close the battery-chamber door and slide it back toward the
body (4) to engage the safety catch. Move the lock lever (5)
to the close position .
• After installing the batteries, the set-time/date message may
appear on the monitor. The clock and calendar are set in the
custom 2 section of the setup menu (p. 84).
BATTERY CONDITION INDICATOR
Full-battery Icon - the batteries are fully charged. This icon is
displayed for five seconds on the monitor when the camera is
turned on. The icon remains on the data panel.
Blinking low-battery icon - when displayed on the data panel
with no other icons, power is insufficient for camera operation.
The shutter will not release. When replacing exhausted
batteries, wait thirty seconds between removing the old
batteries and inserting the new ones.
Low-battery warning - battery power is very low. The batteries
should be replaced as soon as possible. This warning
automatically appears and remains on the monitor until the
batteries are changed.
AUTO POWER SAVE
To conserve battery power, the camera will turn off displays and unnecessary functions
if an operation is not made within a certain period. The LCD monitor will turn off after
thirty seconds. The data panel turns off after one minute. To restore the displays, press
any button or key, or turn the mode dial to another position. The length of the auto-
power-save period for the data panel can be changed in the basic section of the setup
menu (p. 84).
This camera is equipped with an automatic battery-condition indicator. When the
camera is on, the battery-condition indicator appears on the data panel and monitor.
The monitor icon will change from white to red when battery power is low. If the data
panel and monitor are blank, the batteries may be dead or installed incorrectly.
Open the battery-chamber door by moving the battery-
chamber lock (1) to the open position . Slide the door
forward (2) to release the safety catch; the door should spring
open (3).
1
2
4
3
5
GETTING UP AND RUNNING
When installing batteries, make sure the battery terminals are clean. Residue or dirt on
the terminals can sometimes cause a false low-battery warning. Always use a clean,
dry cloth to clean batteries.

18 19
GETTING UP AND RUNNING
EXTERNAL POWER SUPPLIES (SOLD SEPARATELY)
CHANGING THE COMPACTFLASH CARD
The AC Adapter allows the camera to be powered from an electrical household outlet.
The AC Adapter is recommended when the camera is interfaced with a computer or
during periods of heavy use. AC Adapter model AC-1L is for use in North America,
Japan, and Taiwan and AC-2L is for use in all other areas.
The External High-power Battery Pack Kit EBP-100 is a portable source of power for
the camera. The kit contains a high-power lithium-ion battery, holder, and charger. The
battery and charger are also available separately. This battery pack will significantly
extend the operating time of the camera.
Insert the mini plug of the AC adapter or battery
pack into the DC terminal.
• Always remove exhausted batteries before
connecting an external power supply. Always wait
thirty seconds between removing the old batteries
and plugging in the external power source.
Insert the AC adapter plug into an electrical outlet.
Do not change the power supply while the camera is on.
Always turn off the camera before changing between power supplies.
Remove the DC terminal cover from the left.
• The cover is attached to the body to prevent loss.
A type I CompactFlash card must be inserted for the camera to operate. If a card has
not been inserted, a no-card warning will automatically be displayed on the monitor and
three dashes (– – –) will be displayed on the data-panel frame counter. For
CompactFlash card care and storage, see page 109.
Slide the card-slot door release down to open the card-slot door (1).
Insert the CompactFlash card into the card slot until the card-eject lever pops out (3).
• Insert the card so the face is toward the front of the camera. Always push the card in straight,
never at an angle. Never force the card. If the card does not fit, check that it is orientated
correctly.
Close the card-slot door (4).
To eject a CompactFlash card, press the card-eject lever (2). The card can now be
pulled out.
• Take care when removing the card as it becomes hot with use.
If the card-not-recognized message appears, the inserted card in the camera may need
to be formatted. A card used in another camera may have to be formatted before
being used. If the unable-to-use-card message appears, the card is not compatible with
the camera and cannot be formatted. A card can be formatted in the basic section of
the setup menu (p. 84). When a card is formatted, all the data on the card is perma-
nently erased.
1
Always turn off the camera and confirm the access lamp is not lit before inserting or
removing a CompactFlash card, otherwise the card may be damaged, and data lost.
2 3 4

20 21
AUTO-RECORDING MODE
BASIC OPERATION
AUTO-RECORDING MODE
SETTING THE CAMERA TO RECORD IMAGES AUTOMATICALLY
Turn the mode dial to automatic recording (1); all
camera operations are now fully automatic. The
autofocus, exposure, and imaging systems will work
together to bring beautiful results effortlessly.
While many of the camera’s systems in this mode are
automatic, the camera’s operation can be optimized to
different subjects very simply with the digital subject
program button (p. 28). The flash mode (p. 30) and
drive mode (p. 32) can also be changed. Image size
and quality can be set on the auto-recording mode
menu (p. 38).
1
Exposure mode
Camera sensitivity (ISO)
Flash mode
Focus area
Focus control
Drive mode
Exposure compensation
Sharpness
Color mode
White balance
Program
Multi-segment
Auto
Metering mode
Auto flash
Wide focus area
Autofocus
0.0
Normal
Color
Auto
Fixed
Fixed
Fixed
Can be changed*
Fixed
Fixed
Can be changed*
Can be adjusted*
Fixed
Fixed
Fixed
Single-frame advance
* Changes to the flash or drive mode will reset when the mode dial is turned to another
position. Adjustments made with exposure compensation will be reset to 0.0 when the
camera is turned off or changed to another mode.
While using the viewfinder or LCD monitor, grip the camera
firmly with your right hand while supporting the body with
your left hand. Keep your elbows at your side and your feet
shoulder-width apart to hold the camera steadily.
When taking vertical pictures, hold the camera so that the
flash is above the lens with the grip to the bottom. Take
care not to cover the lens with your fingers or the strap.
HANDLING THE CAMERA
This section covers the basic operation of this camera. Thoroughly familiarize yourself
with the operations in this section before moving on to the other sections in the manual.
The sophisticated technology employed in the auto-recording mode frees the photogra-
pher from complicated camera settings to be able to simply concentrate on the subject
and composition. Although automated, the camera’s operation can be changed to meet
various conditions as well as to suit personal shooting preferences.
To set the camera’s clock and calendar, see the navigating the setup menu section on
page 84. The menu language can also be changed on the setup menu.

22 23
AUTO-RECORDING MODE
BASIC RECORDING OPERATION
Press the shutter-release button partway down (1) to lock
the focus and exposure.
• The focus signals (p. 25) on the monitor will confirm the focus. If
the focus signal is red, the camera was unable to focus on the
subject. Repeat the previous steps until the signal is white.
• When the focus is set, an AF sensor will briefly appear on the
live image to indicate the point of focus.
• The shutter speed and aperture value will change from white to
black indicating the exposure is locked.
Press the shutter-release button all the way down (2) to take
the picture.
• The access lamp will glow indicating image data is being
written to the CompactFlash card. Never remove a
CompactFlash card while data is being transferred.
With the mode dial set to auto recording, the camera will be on and
the LCD monitor will activate.
1
2
ZOOM LENS AND DIGITAL ZOOM
This camera is equipped with a 7.15 to 28.6mm optical zoom. This is equivalent to a 35
to 140mm zoom lens on a 35mm camera. In 35mm photography, focal lengths below
50mm are referred to as wide-angle; the angle of view is larger than that of the human
eye. Above 50mm is referred to as telephoto and makes distant objects appear closer.
The effect of the optical zoom is visible in both the viewfinder and LCD monitor.
Assisting the optical zoom is a 2.2X digital zoom. The effect of the digital zoom doubles
the power of the telephoto position of the optical zoom giving the equivalent of a
308mm lens on a 35mm camera. The effect of the digital zoom is visible on the LCD
monitor only. This digital-zoom function is canceled if the LCD monitor is turned off (p.
37). The digital zoom can be disabled in the auto-recording menu (p. 38). In the multi-
function recording mode, the zoom can be disabled in the custom 1 section of the
multi-function recording mode menu (p. 50).
At the maximum telephoto position,
pressing the up key (T) will activate
the digital zoom.
• X2.2 will be displayed in the top right
corner of the monitor.
• To cancel the digital zoom, press the
down key.
The zoom lens is operated by the
controller. Pressing the up key (T)
will zoom in to the telephoto position
of the lens. Pressing the down key
(W) will zoom out to the wide-angle
position.
Controller
Place the subject within the focus frame.
• The focus-lock function (p. 24) can be used with off-center
subjects.
• Make sure the subject is within the focus range of the
lens: 0.5m - ∞(wide-angle position), 0.9m - ∞(telephoto
position. For subjects closer than 0.6m, use the macro
function (p. 28).
• If the subject is closer than 1m at the wide-angle lens
position or 3m at the telephoto lens position, use the LCD
monitor to frame the subject (p. 12).

24 25
FOCUS LOCK FOCUS SIGNALS
SPECIAL FOCUSING SITUATIONS
This digital camera has a quick, accurate autofocusing system. The focus icon in the
lower right corner of the LCD monitor and the green focus lamp next to the viewfinder
indicate the focus status.
Focus confirmed.
Focus icon: white
Focus lamp: steady
Focus icon: red
Focus lamp: blinking
The camera may not be able to focus in certain situations. If the autofocus system
cannot focus on a subject, the focus icon will turn red. In this situation the focus-lock
function can be used to focus on another object at the same distance as your main
subject, and then the image can be recomposed to take the picture.
The subject in the
focus frame is low in
contrast.
The subject is too dark. Two subjects at differ-
ent distances overlap
in the focus frame.
The subject is near a
very bright object or
area.
The focus-lock function is used when the subject is off-center and outside the focus
frame. Focus lock may also be used when a special focusing situation prevents the
camera from focusing on the subject. This function is controlled with the shutter-release
button.
Place the subject within the focus frame. Press and
hold the shutter-release button partway down.
• The focus signals will indicate that the focus is locked.
The shutter speed and aperture value will change from
white to black indicating the exposure is locked.
• When the focus is set, an AF sensor will briefly appear
on the live image to indicate the point of focus.
Without lifting your finger from the shutter-release
button, recompose the subject within the image area.
Press the shutter-release button all the way down to
take the picture.
Cannot focus. The subject is too close or a special
situation is preventing the AF system from focusing.
• The shutter can be released even if the camera cannot focus on the subject.
• When the AF system cannot focus, the focus is set to infinity. When the flash is in use, the
focus is set between 3.0 and 3.8m. In this case, focus lock can be used with an object at the
same distance as the main subject or the camera can be focused manually in the multi-
function recording mode (p. 56).
AUTO-RECORDING MODE
FOCUS RANGE
Wide-angle lens position
Telephoto lens position
Macro mode (p. 28)
0.5m - ∞(1.6ft - ∞)
0.9m - ∞(3ft - ∞)
0.16m - 0.6m (0.5ft - 2ft)
All distances are measured from the CCD
CCD plane

Press the QV/delete button to play back the recorded images.
AUTO-RECORDING MODE
Captured images can be viewed in auto-recording and multi-function
recording mode. Simply press the QV/delete button to access the
images. The date and time of capture, frame number, printing status,
lock status, image size and image quality are displayed with the
images. The histogram and shooting data of the image can also be
displayed in Quick View.
In quick view, the displayed image can be deleted. When
selecting an image for deletion, a confirmation screen will
appear before the operation is executed.
QUICK VIEW QUICK-VIEW DISPLAY
Once deleted, an
image cannot be
recovered.
DELETING IMAGES IN QUICK VIEW
Date of capture
Frame number/ total number of images
Lock icon (p. 75)
Print icon (p. 78)
Image size (p. 40)
Image quality (p. 41)
Time of
capture
Mode indicator
Delete this frame?
NoYes
Press the up key to see the histogram of the displayed image.
• When the histogram is displayed, the left/right keys cannot scroll to the next
image. Press the down key to cancel the histogram display.
Voice-memo icon (p. 43)
To view the histogram,
press the up key.
Shutter speed
Aperture value
White-balance
setting (p. 54)
Sensitivity
setting (p. 57)
Degree of exposure
compensation (p. 46)
Folder name (p. 100)
Folder number - image file number
To return to the recording
mode, press the menu button
or shutter-release button.
Histogram (p. 67)
26 27
To delete a displayed image, press the QV/delete
button.
• A confirmation screen will appear.
Press the controller to delete the image.
Use the left/right keys to highlight “YES.”
• “NO” will cancel the operation.
Controller
Menu button
QV/Delete button
Display button
Use the left/right keys of the controller to scroll through the images.
• Pressing the display button switched between displaying the image with and
without information.

28 29
TEXT - for the crisp reproduction of black text on
white backgrounds. The flash mode is set to
flash cancel (p. 30). Fill-flash can be used.
• Use a tripod to eliminate camera shake and ensure
the sharpest images.
NIGHT PORTRAIT - for deep, subtle night scenes.
When used with fill-flash, the subject and background
exposures are balanced.
• When taking pictures of a landscape at night, use a tripod to
eliminate blurring from camera shake. To take portraits with
night scenes, set the flash
mode to fill-flash (p. 30). Ask
your subject not to move
after the flash burst; the
shutter will still be open for
the background exposure.
The digital-subject-program button (1) optimizes
the camera’s performance for various conditions
and subjects. Exposure, white-balance, and
image-processing systems work in unison for
beautiful results.
Pressing the subject-program button cycles
through the modes: macro, portrait, landscape,
night portrait, text, macro & text, and the original
exposure mode. A pointer will indicate the active
subject program. The subject program will
remain in effect until it is changed or the mode
dial is turned to another position. Except for
macro, digital subject programs cannot be used
in the multi-function recording mode.
While camera performance is optimized for each shooting condition, some changes
can be made to camera settings with subject programs. The flash mode (p. 30) can be
changed and the exposure can be altered using the exposure-compensation function
(p. 46). In extreme lighting conditions, changes in exposure compensation may not
produce the intended results in the portrait, night portrait, or text modes. The camera-
shake warning (p. 31) may appear in macro, landscape, night portrait, or text modes.
AUTO-RECORDING MODE
DIGITAL-SUBJECT-PROGRAM BUTTON
1
CCD plane
MACRO - used for close-up photography between 16 and
60 cm from the CCD. When the macro mode is selected,
the lens will automatically zoom to the correct position.
The zoom position cannot be changed. The LCD monitor
should be used to compose the picture and will
automatically activate if off. The viewfinder cannot be
used because of parallax. The flash is set to flash cancel
(p. 30). Fill-flash can be used, but can cause extreme
overexposure and uneven illumination.
PORTRAIT - optimized to reproduce soft skin tones and
a slight defocusing of the background. The flash mode
can be changed (p. 30).
• Most portraits look best at a telephoto setting; longer focal
lengths do not exaggerate facial features and the shallower
depth of field softens the background.
LANDSCAPE - optimized to
produce sharp, colorful
landscapes. The flash mode
is set to flash cancel. Fill-
flash can be used (p. 30).
MACRO & TEXT - for close-up images of text between
16cm to 60cm from the CCD. Two pointers will indicate
the combined modes on the data panel and both the
macro and text icons will be displayed on the LCD
monitor.
• Use a tripod to ensure the sharpest images.

30 31
AUTO-RECORDING MODE
If the shutter speed falls below the point where the camera can be safely hand held,
the camera-shake warning will appear on the LCD monitor and the orange focus lamp
will blink slowly. Camera shake is slight blurring caused by subtle hand motion and is
more pronounced at the telephoto setting of the lens than at the wide-angle setting.
Although the warning appears, the shutter can still be released. If the warning appears,
the following steps can be taken:
• Place the camera on a tripod.
• Use the built-in flash.
• Zoom the lens towards the wide-angle position until the warning
disappears.
CAMERA-SHAKE WARNING
FLASH RANGE - AUTO-RECORDING MODE
The camera will automatically control the flash output. For well-exposed images, the
subject must be within the flash range. Because of the optical system, the flash range
is not the same at the lens’ wide-angle position as it is at the telephoto position.
Wide-angle position
Telephoto position 0.5m ~ 3.5m (1.6 ft. ~ 11.5 ft.) 0.9m ~ 3.0m (3.0 ft. ~ 9.8 ft.)
Autoflash
Fill-flash
Flash cancel
Autoflash with
red-eye reduction
Fill-flash with
red-eye reduction
LCD
monitor Data panel
Autoflash - the flash fires automatically
in low-light and backlit conditions.
Red-eye reduction - the flash fires twice before the
main flash burst to reduce red-eye; an effect caused
by light reflected from the retina. Use in low-light con-
ditions when taking photographs of people or ani-
mals. The pre-flashes contract the pupils of the sub-
ject’s eyes.
Flash cancel - the flash will not fire.
Use flash cancel when flash photogra-
phy is prohibited, natural light is desired
to illuminate the subject, or the subject
is beyond the flash range. The camera-
shake warning may appear when flash
cancel is selected (p. 31).
Fill-flash - the flash fires with each
exposure regardless of the amount of
ambient light. Fill-flash can be used to
reduce harsh shadows caused by strong
direct light or sunshine.
FLASH MODES
To set the flash mode, sim-
ply press the flash mode
button (1) on the back of
the camera until the
desired mode is displayed.
1
FLASH SIGNALS The orange flash lamp next to the viewfinder indi-
cates the status of the flash. When the lamp
glows steadily, the flash is charged and ready to
fire. When the lamps blinks quickly, the flash is
charging and the shutter will not release. The
flash lamp is also used as a camera-shake warn-
ing, see below.
At the wide-angle lens position, when using the flash with subjects closer than 1m
(3ft.), vignetting can occur. A slight shadow or shading may be apparent at the bottom
of a horizontal image.

32 33
Used for self-portraits, the self-timer will delay the release of the shutter for
approximately ten seconds after the shutter-release button is pressed. The self-timer is
set with the drive-mode button (p. 32).
With the camera on a tripod, compose the picture as described in the
basic recording operation section (p. 23). Focus lock (p.24) can be
used with off-center subjects. Press the shutter-release button partway
down to lock the exposure and focus (1). Press the shutter-release
button all the way down to begin the countdown (2). Because focus and
exposure are determined when the shutter-release button is pressed,
do not stand in front of the camera when taking a self-timer image.
Always confirm the focus with the focus signals before beginning the
countdown (p. 25).
During the countdown, the self-timer lamp on the front
of the camera (3) will start to blink and is accompanied
by an audio signal. A few seconds before the exposure,
the self-timer lamp will blink rapidly. The lamp will glow
steadily just before the shutter fires. To stop the
countdown, press the drive-mode button. The audio
signal can be turned off in the basic section of the
setup menu (p. 84).
AUTO-RECORDING MODE
The drive modes control the rate and method images are
captured. Icons indicating the selected drive mode appear on
the data panel and LCD monitor.
To change the drive mode, simply press the drive-mode
button (1) on the back of the camera until the desired mode is
displayed.
DRIVE MODES
Single-frame
advance
Continuous
advance
Self-timer/
Remote control
Bracketing
To take a single image each time the shut-
ter-release button is pressed (p. 23).
To take multiple images when the shutter-
release button is pressed and held.
To delay the release of the shutter. Used for
self-portraits.
To take a series of three images with
differing exposures.
LCD monitor
Data panel
All icons have been
shown for clarity. The
single-frame advance
and continuous drive
indicators occupy the
same area of the data
panel. All the drive-mode
icons appear in the lower
right corner of the
monitor.
LCD
Monitor Data Panel
1
The self-timer can be used to minimize camera shake with long exposures. When using the
camera on a tripod, photographs of static subjects (landscapes, still-lifes, or close-up pho-
tographs) can be made with the self-timer. Because no contact is made with the camera during
exposure, there is no risk of camera shake caused by the operator.
Shooting tips
1
2
3
SELF-TIMER

34 35
AUTO-RECORDING MODE
REMOTE CONTROL (SOLD SEPARATELY) The continuous-advance drive mode allows a series of images to be captured while
holding down the shutter-release button. Continuous advance acts like a motor drive on
a film camera. The number of images that can be captured at one time and the rate of
capture depend on the image-quality and image-size setting. The maximum rate of
capture is 1.3 fps. The continuous-advance mode is set with the drive-mode button (p.
32).
When the shutter-release button is pressed and held, the camera will
begin recording images until the maximum number has been taken or
the shutter button is released. This mode cannot be used with super-
fine images (p. 41). The built-in flash can be used, but the rate of
capture is reduced because the flash must recharge between frames.
Compose the picture as described in the basic
recording operation section (p. 23). Press the shutter-
release button partway down to lock the exposure and
focus for the series. Press and hold the shutter-release
button all the way down (1) to begin taking pictures.
The following chart lists the maximum number of
images that can be captured with different image-
quality and image-size combinations.
Economy
Standard
Fine
2272 X 1704
Quality
Size 1600 X 1200 1280 X 960 640 X 480
7
10
16
12
18
28
17
26
36
38
53
66
1
The IR Remote Control RC-3 allows remote camera operation
up to 5m (16 ft.) away. The remote control unit can be used in
movie recording (p. 65).
Place the camera on a tripod, and set the
drive mode to self-timer / remote control
(p. 32).
Arrange the camera and subject to compose
the picture. Frame the subject within the
focus frame when setting up the camera.
• Focus lock cannot be used with the IR remote
control.
• In multi-function recording mode, focus area
selection can be used for off-center subjects
(p. 48).
While pointing the emitter window of the
remote control unit toward the camera, press
the release button or the delay button to
take the picture.
• When the release button is pressed, the self-
timer lamp on the front of the camera will blink
once before the picture is taken.
• When the delay button is pressed, the self-
timer lamp on the front of the camera will blink
for two seconds before the picture is taken.
• The remote control may not operate with
backlit subjects or under fluorescent light.
Emitter window
Delay button
Release button
CONTINUOUS ADVANCE

36 37
This mode makes a three-image bracket of a scene. Bracketing is a
method of taking a series of images of a static subject in which each
image has a slight variation in exposure. The bracketing mode is set
with the drive-mode button (p. 32). Brackets cannot be made with
super-fine images (p. 41).
The order of the bracket series is normal exposure (as indicated by the
shutter speed and aperture displays), underexposure, and
overexposure. The exposure bracket in auto-recording mode is set to
0.5 Ev increments. In multi-function recording mode the increment can
be set to 0.3, 0.5, or 1.0 Ev increments (p. 50).
Compose the picture as described in the basic recording operation
section (p. 23). Press the shutter-release button partway down (1) to
lock the exposure and focus for the series. Press and hold the shutter-
release button all the way down (2) to make the bracket series; three
consecutive images will be captured. If the CompactFlash is filled or
the shutter button is released before the series has completed, the
camera will reset and the entire bracket must be made again. When
using flash, there will be a delay between frames as the flash charges.
The remaining number of frames in the bracket series is displayed on
the monitor next to the bracketing icon.
When using exposure compensation (p. 46), the bracketing series will
be made in relation to the compensated exposure.
Under extreme conditions, one of the bracketed
exposures may be inaccurate because it is outside the
exposure control range of the camera.
Number of frames
in bracketing series
Frame counter
Under
AUTO-RECORDING MODE
1
2
LCD
monitor
off
The display-information button controls the LCD monitor display. The display cycles to
the next position each time the button is pressed: full display, live image only, and
monitor off.
Battery power can be conserved by turning the monitor off and using the viewfinder to
take pictures. When the menu or exposure-compensation button is pressed, or the
macro mode is activated, the monitor will automatically turn on. Full-time AF (p. 58) and
the digital zoom are disabled when the monitor is off.
Full display Live image only
Display button
DISPLAY BUTTON - RECORDING MODE
Over
Normal
BRACKETING

39
Settings made with the auto-recording menu
will remain in effect until changed or the cam-
era is reset to its default settings (p. 89).
Image size - To set the pixel resolution of the
images. Image size affects the size of the
image file.
Image quality - To set the rate of compression
of the images. Image quality affects the size of
the image file.
Voice memo - To record audio after a still
image has been captured. The function can be
turned off and the length of the recording can
be set.
Date imprint - The date of recording can be
imprinted on each image. The date is set in the
custom 2 section of the setup menu (p. 84).
Digital zoom - The digital zoom can be turned
off or on (p. 22).
Instant playback - After taking a picture, the image will be displayed on the monitor for
two or ten seconds. The displayed image can be deleted before being saved to the
CompactFlash card.
Read the following sections for more details on these options and settings. All of these
functions appear on the multi-function recording mode menu.
NAVIGATING THE AUTO-RECORDING MODE MENU
In auto-recording mode, press the menu button to activate the menu. The menu button
also turns off the menu after settings are made. The four-way keys of the controller are
used to move the cursor in the menu. Pressing the center of the controller will enter a
setting.
Use the up/down keys of the controller (2) to scroll through the menu options.
Highlight the option whose setting needs to be changed.
• When scrolling in one direction, the cursor will jump between the top and bottom
of the menu.
With the menu option to be changed highlighted, press the right controller key; the
settings will be displayed with the current setting highlighted.
• To return to the menu options, press the left key.
Once a setting has been
selected, the cursor will return to
the menu options and the new
setting will be displayed. Changes
can continue to be made. To
return to the auto-recording
mode, press the menu button.
Changes made on the auto-
recording mode menu will also
affect the multi-function recording
mode.
Auto
Auto
Image size
Quality
Voice memo
Date imprint
Digital zoom
2272 X1704
Standard
Off
Off
On
Inst.Playback Off
38
Use the up/down keys to highlight the new setting.
Press the center of the
controller to select the
highlighted setting.
AUTO-RECORDING MODE
Menu button
Controller
Auto
Image size
Quality
Voice memo
Date imprint
Digital zoom
2272 X 1704
1600 X 1200
1280 X 960
640 X 480
Super fine
Fine
Standard
Economy
5 sec.
15 sec.
Off
Inst.Playback
On / Off
On / Off
2 sec.
10 sec.
Off
