Miranda Kaleido-X User manual

Kaleido-X User’s Manual
Part Number: M770-2800-111 1 June 2011

ii
Copyright © 2007-2011 Miranda Technologies Inc.
All rights reserved.
ATTENTION: please read the following terms and conditions carefully. By using Kaleido-X documentation,
you agree to the following terms and conditions:
Miranda Technologies Inc. hereby grants permission and license to owners of Kaleido-X to use their
product manuals for their own internal business use.Manuals for Miranda Technologies Inc. products may
not be reproduced or transmitted in any form or by any means, electronic or mechanical, including
photocopying and recording, for any purpose unless specifically authorized in writing by Miranda
Technologies Inc.
A Miranda Technologies Inc. manual may have been revised to reflect changes made to the product during
its manufacturing life. Thus, different versions of a manual may exist for any given product. Care should be
taken to ensure that one obtains the proper manual version for a specific product serial number.
Information in this document is subject to change without notice and does not represent a commitment
on the part of Miranda Technologies Inc.
Title Kaleido-X User’s Manual
Part Number M770-2800-111
Revision 1 June 2011, 4:37 pm

iii
1 New Features 1
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
New Feature in Kaleido-X Version 5.30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features Introduced in Kaleido-X Version 5.20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features Introduced in Kaleido-X Version 5.10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Getting Started 5
About this Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Kaleido-Modular . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Kaleido-X16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Kaleido-X (4RU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Kaleido-X (7RU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Kaleido-X (7RU) x 2 Expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Kaleido-X Cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
KMV-3901/3911 Cascade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Verifying your System Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Loading a Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Cabling Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
RS-422 Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
XEdit Application Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3 Operation of the Monitor Wall 31
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Logging on to the Monitor Wall Using the Kaleido-RCP2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Displaying the Dashboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Hiding the Dashboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Loading Layouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Displaying a Source in Full Screen Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Table of Contents

iv
toc
Changing a Source’s Aspect Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Video Cropping/Zooming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Toggling Safe Area Markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Displaying Subtitles and Closed Caption Text. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Editing UMD Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Selecting an Input Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Assigning Sources to Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Changing Crosspoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Using Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Triggering Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Triggering GPI Output Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Acknowledging Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Triggering Audio Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Setting a Display Monitor’s Output Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Changing the IP Address of a Multi-Viewer from the Monitor Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4 Managing Kaleido-X Systems 63
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Opening the XEdit Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Using XEdit Online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Importing a Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Exporting a Database. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Creating a Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Retrieving a Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Creating a Single Multi-Viewer System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Creating a Cluster. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Configuring the System Representation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Restoring Factory Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Managing Multiple Databases Efficiently . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
5 Calibrating the Kaleido-X 93
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Multi-Viewer Output Calibrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Multi-Viewer Input Calibrations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Router Output Calibrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
GPI/Genlock Calibrations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
6 Configuring Alarms 119
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Alarm Debouncing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

v
Alarm Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Alarm Suppression. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Global Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Virtual Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Sub-Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Alarm Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Teletext, Subtitles, and Closed Captions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Dolby E/AC-3 Metadata. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Configuring Video/Audio Alarm Threshold. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Configuring Alarm Debouncing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Sharing Alarm Status Information Between Multi-Viewers and iControl. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Publishing Alarms to SNMP Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
7 Creating Logical Sources 135
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Creating and Configuring Logical Sources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Configuring Alarm Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Monitoring Internal-Router Outputs on the Monitor Wall (Sample Scenario). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
8 Setting Up Rooms 145
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Managing Rooms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Configuring Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Managing Display Libraries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
9 Creating Layouts 171
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Managing Layouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Configuring Video Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Configuring Audio Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
Configuring Audio Scales. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Configuring Timers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Configuring UMDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
Configuring Alarm Monitors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
Configuring Metadata Monitors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Configuring V-Chip Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Configuring Clocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Working with Composite Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225

vi
toc
Using the Region Editor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231
Format Painting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Managing Widget Libraries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
10 Creating Actions 237
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
Creating Monitor Wall Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
Creating Background Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241
11 Managing Kaleido-RCP2 Users 249
Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
XEdit Quick Start Task List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
RCP2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Managing RCP Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Managing Room Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251
Setting Room Preferences. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
Setting RCP User Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
12 Routers & Kaleido-X 265
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Internal Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Kaleido-X as a Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Router Control Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Router Protocols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Serial Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275
Q & A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Configuring an External Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Configuring a Router Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Configuring Internal Router Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
Router Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Router Card Expansion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 306
13 Tally Interface Devices 311
Configuring Kalypso, Andromeda, Serial to TCP/IP Dispatcher and TSL Serial Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 311
Ross Video Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313

vii
Sony Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 318
Kahuna Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323
Kayak Production Switcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330
Configuring the Kayak Switcher. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
Configuring the Multi-Viewer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 332
Serial Port Test Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 339
14 Using the Kaleido Remote Control Protocol 341
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 341
15 Using the Serial to TCP/IP Dispatcher 343
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 343
16 Administration and Servicing 345
Key Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 345
Default IP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 346
Hardware and Software Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 347
Dashboard Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 349
Network Considerations & Port Usage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 353
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 358
Assigning an IP Address to Each Device in Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 358
Enabling Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 371
Configuring Power Supply Redundancy on a Kaleido-X16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 373
Installing XEdit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 375
Obtaining EDID Data From Display Screens When Using the DXF-100 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 382
Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 383
Upgrading your Multi-Viewer System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 390
Index 391
Contact Us! 399

viii
toc

1
New Features
This chapter describes new features in Kaleido-X version 5.30.
Overview
Kaleido-X version 5.30 is a major release adding support for the new Kaleido-Modular KMV-3911 multi-
viewer model. Version 5.30 also introduces a few enhancements.
New Feature in Kaleido-X Version 5.30
•Support for the new Kaleido-Modular KMV-3911 multi-viewer: The KMV-3911 multi-viewer
replaces the KMV-3901. In addition to the earlier model’s existing features, the KMV-3911 supports up
to two HD-SDI monitoring outputs (with embedded audio): one associated with Head 1, and one with
Head 2. See “KMV-3901/3911” on page 348 for the list of optional features, and “Configuring the HD-
SDI Monitoring Output Format” on page 161 for more information.
Enhancements in Kaleido-X Version 5.30
•Teletext/subtitling color: Text color attributes are now supported for teletext (WST, OP-47). See
“Setting a Video Monitor’s Text Mode” on page 198.
Note: Other text formatting attributes specified in the OP-42 (WST) and OP-47 (HD teletext) standards
(e.g. background colors, italic and bold type, font case) are not supported. On the monitor wall, closed
captions (CC, DTVCC) appear in white against a black background.

2
New Features
1
•Support for embedded audio at the HD-SDI monitoring output: All multi-viewer models now
support monitoring of one audio pair, embedded on Group 1, at the HD-SDI output.
•KMV-3901/3911: Support for dynamic range calibration. See “Calibrating Detail Enhancement and
Dynamic Range” on page 111.
•Custom images: The maximum size for a custom safe area image, clock logo, or layout background
image has increased to 256 KB. See “Selecting a Background Image for a Layout” on page 182,
“Inserting a Clock Logo” on page 223, and “Adding a Custom Safe Area Image” on page 189.
Features Introduced in Kaleido-X Version 5.20
•Support for 3D-stereoscopic sources: Kaleido-X, Kaleido-X16, and KMV-3901-8×2 now support
merging two distinct signals (a left eye signal and a right eye signal) and interleaving them into a
composite video. The interleaved composite, displayed on a 3D-capable display, viewed with polarized
3D glasses, is seen as a stereoscopic, 3D image. In addition, combining 2D images and 3D images
(interleaved) on one display is supported.
•Support for audio monitoring output through HDMI: The Kaleido-X16 and KMV-3901-8x2 now
support audio monitoring output over HDMI, for PCM audio pairs from SDI sources.
•Support for Cascade solution: To address solutions with more inputs per head using smaller cost-
effective multi-viewers, KMV-3901-8x2 multi-viewers can now be configured in cascade. This allows
the support of the following configurations:
– KMV-3901-8x2 cascade with 16 inputs × 2 outputs
– KMV-3901-8x2 cascade with 16 inputs × 1 output
– KMV-3901-8x2 cascade with 24 inputs × 2 outputs
– KMV-3901-8x2 cascade with 24 inputs × 1 output
Features Introduced in Kaleido-X Version 5.10
Kaleido-X version 5.10 was a major release containing several new features, enhancements and bug fixes.
Note: In the case of the Kaleido-X16, support for audio monitoring at the HD-SDI output requires
version 5.30 (or later)of the Kaleido-X Software, and recent hardware. In the XAdmin Status and Options
page, under SYSTEM, the value indicated for the Card revision attribute must be 0x4 or more.
Note: To be able to monitor a 3D stereoscopic signal, you must first add a second video level to your
logical sources (so you have a level for each eye), and then for each video monitor or composite you wish
to use for 3D monitoring, you must assign the left-eye and right-eye levels.

Overview
3
•Support for 3Gbps input signals: The new KXI-16HSV3 is a universal input card that accepts 3Gbps
(1080p 60 Hz, 1080p 59.94 Hz, and 1080p 50 Hz), HD-SDI, SD-SDI, and composite inputs; the KXI-
16HS3 supports 3Gbps, HD-SDI, and SD-SDI inputs.
•Support for version 5.0 of the TSL UMD protocol:Version 5.0 of the protocol allows TCP/IP or UDP/IP
communicationbetweenthe TSLUMD controllerand a multi-viewer,overa network.Since the protocol
and connection mode are totally different, devices using version 5.0 of the TSL UMD protocol and those
using version 3.1 of the protocol are considered different devices in XEdit. To use the latest protocol
(v. 5.0), select the TSL (network) device from XEdit’s Equipment library. As of XEdit version 5.10, the
earlier version-3.1 TSL device is called TSL (serial).
Enhancements in Kaleido-X Version 5.10
•[Ref. #25844] Router Control: Support for the HCO-1821 HD/SD/ASI Change Over with Clean Switch.
•[Ref. #25706] Viewing assignment information for a video source on the monitor wall: Right-click a
video monitor, and then point to Info on the shortcut menu, to view the monitor-wall destination
label, current logical source, physical source ID.
•[Ref. #25780/26851] Viewing assignment information between router sources and multi-viewer
inputs: The Signal Path Viewer application can be launched from the Kaleido-X home page. It opens as
a standalone panel, updated in real time as multi-viewer inputs are assigned different router sources,
and crosspoints are changed on the upstream router. For each multi-viewer input, the panel displays
the current router source assignment, the corresponding router destination, as well as router status
information. In the case of a Kaleido-X multi-viewer model, it also indicates if an input card has been
removed.
•Kaleido-X (7RU), Kaleido-X (7RU) × 2, and Kaleido-X16: With earlier versions of the Kaleido-X
Software, it was possible to send sources to a multi-viewer’s internal router outputs, as long as these
sources were associated with multi-viewer inputs. As of Kaleido-X version 5.10, sending sources from
an upstream router to the multi-viewer’s router outputs is also supported.
Note: The current implementation of the TSL UMD v. 5.0 protocol in the Kaleido-X Software does not
support multicast mode.
Note: In the case of a Kaleido-X multi-viewer model, if you remove or reseat output cards, Signal Path
Viewer may stop displaying real-time updates, in which case close the application and then open it
again.
Note: This feature is based on the KX Router logical router, instead of using the internal router. This
means that you must add the multi-viewer’s router outputs to the KX Router configuration, otherwise
the Send to [router] output menu will not be enabled. Once this is done, do not use the Internal Router
logical router. In addition, KX Router must have only one level.

4
New Features
1
•HD-SDI monitoring output: Information about the optional SDI outputs is available in XAdmin’s
Status and Options; SDI output calibrations and other settings can be configured in XEdit. In the case of
the Kaleido-X multi-viewer models, the presence and status (normal mode, safe mode) of the KXO-
HDM mezzanine are available via SNMP. Traps are also available for both alarms.
Note: Like other card presence alarms, the KXO-HDM traps are not configurable, and are always sent.

5
Getting Started
Welcome to the Kaleido-X! This chapter provides an overview of the different multi-viewer
models and their initial configuration process.
Summary
System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Detailed Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cabling Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
RS-422 Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
XEdit Application Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
About this Document
The Kaleido-X User’s Manual is intended to help you leverage the full working potential of the Kaleido-X
Software and XEdit application for controlling and monitoring audio, and video broadcast signal paths for
interfacing, routing distribution and other peripheral devices.
The Kaleido-X series hardware—including the Kaleido-Modular, Kaleido-X16, and Kaleido-X multi-
viewer models—and the associated software products are designed and produced by Miranda
Technologies Inc.
For installation instructions, refer to the Quick Start Guide that shipped with your multi-viewer. Once you
have completed your multi-viewer’s initial installation perform a system verification (see “Verifying your

6
Getting Started
2
System Configuration” on page 15), load a layout on the monitor wall if you haven’t done so already (see
“Loading a Layout” on page 22), and then review the more advanced topics in “Administration and
Servicing” on page 345, to fine-tune your initial system configuration.
After you have established that your basic configuration works as expected, move on to the other chapters
in this manual, to complete your system configuration until it meets your actual monitoring requirements.
System Overview
This section reviews the different multi-viewer models that support the Kaleido-X Software:
Kaleido-Modular . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Kaleido-X16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Kaleido-X (4RU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Kaleido-X (7RU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Kaleido-X (7RU) x 2 Expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Kaleido-X Cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
KMV-3901/3911 Cascade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Kaleido-Modular
The Kaleido-Modular KMV-3911, which has replaced the earlier KMV-3901 model, is an expandable, 8-
input, dual-output multi-viewer (3Gbps/HD/SD) on one Densité Series card. Hosted in a Densité 3 frame,
the KMV-3911 is the most space- and energy-efficient multi-viewer system, with up to 20 multi-viewer
outputs per 3 RU frame, or up to 288 multi-viewer outputs when connected to an upstream router.
Note: In line with our commitment to environmental preservation, only the Release Notes, the Quick
Start Guide for your multi-viewer model, and some ancillary documents (e.g. welcome letters, warranty
cards) are distributed in printed form. All manuals are available on the Kaleido-X DVD. You can also obtain
them from the Software Downloads section of Miranda’s Technical Support portal.

Kaleido-Modular
7
Kaleido-Modular KMV-3901/3911 Features
With its unmatched space and energy efficiency, Kaleido-Modular is ideal for production monitoring in
trucks. The multi-viewer system integrates tightly with the highly space-efficient NVISION 8288 Truck
router (288 × 576 in 10 RU), as well as Densité signal processing cards, and third-party production
switchers. Control of a highly integrated system is simplified with the RCP-200 panel, which can operate
the router and multi-viewer, as well as signal processing and distribution cards.
The KMV-3901/3911 provides a subset of the features of the Kaleido-X (4RU) and (7RU) models:
• Eight auto-sensing 3Gbps/HD/SD video inputs, two independent HDMI outputs
• Video signals can be repeated in up to eight windows, and scaled up to 1920 × 1200 pixels
• Audio signal, video time code and AFD/WSS data can be extracted for on-screen display
• A reference signal from a REF-1801 Densité card can be used to minimize processing delay, and
reference clocks on the monitor wall
• Expansion through combination with upstream router
• DXF-200 extension module simplifies long runs to monitors from Densité frame, and is a single fiber
solution for supporting high-resolution (1920 × 1200) displays over distances of up to 1000 m
(3300 ft)
• Choice of multi-viewer remote control panels: simple Kaleido-RCP2 and advanced RCP-200 with router
control
• Control by NVISION control panel and NV9000 controller
• Super silent for installation within studios and control rooms

8
Getting Started
2
Kaleido-X16
The Kaleido-X16 is a compact, ultra-quiet multi-viewer with 16 inputs and two multi-viewer outputs. It
offers the highest level of image quality, and can be used with 3Gbps/HD/SD and Analog video. It is ideal
for small control rooms, although it can also be paired with routers to create the very largest combined
multi-viewer and routing systems.
There are two types of Kaleido-X16: Kaleido-X16-S (single head) and Kaleido-X16-D (dual head).

Kaleido-X16
9
Kaleido-X16 system overview
The 1RU Kaleido-X16 is ideal for smaller monitoring facilities, such as call letter television station master
control rooms, mobile trucks and production fly cases, as well as community television. The Kaleido-X16’s
super silent design is highly appreciated for use within studios and control rooms.
Kaleido-X16 provides a subset of the features of the Kaleido-X (4RU) and (7RU) models:
• 1RU non-modular frame
• 16 auto-sensing 3Gbps/HD/SD/Analog video inputs, two independent HDMI outputs
• Two 3Gbps/HD/SD router outputs
• 3Gbps with 3D support (SMPTE-425M Level A & B)

10
Getting Started
2
• Expansion through combination with upstream router
• 4 analog channel, 2 digital channel audio monitoring
• 2 HD-SDI monitoring outputs
• DXF-100 optical DVI extension module simplifies long runs to monitors from frame, and is a single fiber
solution for supporting high-resolution (1920 × 1200) displays over distances of up to 1000 m
(3300 ft)
• Choice of multi-viewer remote control panels: simple Kaleido-RCP2 and advanced RCP-200 with router
control
• Internal router control by NVISION control panel and NV9000 Controller
• Super silent for installation within studios and control rooms
Kaleido-X (4RU)
The Kaleido-X (4RU) is a multi-room, multi-image display processor and router in a single, expandable
chassis. Its unique mix of capabilities represents the most integrated monitoring and routing solution. As
a multi-image processor, it offers the highest level of signal flexibility. Each chassis can display 32 HD, SD
or Analog inputs any number of times, in any size, across 4 displays of any resolution and orientation.

Kaleido-X (7RU)
11
Kaleido-X (4RU) system overview
Kaleido-X (7RU)
The Kaleido-X (7RU) is a multi-room, multi-image display processor and router in a single, expandable
chassis. Its unique mix of capabilities represents the most integrated monitoring and routing solution. As
a multi-image processor, it offers the highest level of signal flexibility. Each chassis can display 96 HD, SD
or Analog inputs any number of times, in any size, across 8 displays of any resolution and orientation. As a
router, it offers switching of 96 unprocessed inputs to 48 HD/SD outputs for feeding monitors, test
equipment and master control or production switchers.

12
Getting Started
2
Kaleido-X (7RU) system overview
Kaleido-X (7RU) x 2 Expansion
Since version 3.00 of Miranda’s Kaleido-X Software, it is possible to expand the input connectivity of one
Kaleido-X (7RU) frame to include that of a second. The two frames, each with its own expansion (KXO-EXP)
card, are connected by a high bandwidth cable, such that all the output (KXO) modules on each frame (up
to 6 in total) have access to all inputs (KXI) on each frame (up to 192 in total) without any blocking or
bandwidth limitations.
Using XEdit, the two frames can be configured as a single system, allowing rooms to share input modules
from either frame. The expansion card allows seamless sharing of video, audio monitoring output, time
