MistKing Seconds Timer User manual

Timer is ON and connected MistKing® system is misting
Timer is OFF and idle
Current time clock
Program : P0-P9
Start time of the program
Stop after set duration
Program repeats every day
LCD Display
WEEK
Setup Instructions:
1. Set current time and day of the week (picture A):
In normal status screen, press “
O
” key once to enter time setup.
Press “
O
” key to switch between week date, hour, minute and second. Use up arrow or down
arrow to adjust the value when ashing.
2. Set Timer Programs:
a.a. Set the “MODE” (picture B): In normal status, press “SET” key once, the current mode
ashes, press up arrow or down arrow key to switch between “AUTO, ON and OFF”; choose
the desired mode, then press “SET” key once.
Remember: Timer only executes the P0-P9 program in AUTO mode.
b
b. Set “P0” (picture C): When ”WEEK” of “P0” ashes, press “
O
” key to switch between day of
the week, or whole week (Mon, Tue, Wed, Thu, Fri, Sat, Sun, & Week), start time (hour, minute
and second) and stop duration (hour, minute and second). Use up arrow or down arrow key
to adjust the values when ashing.
START: Requires exact time when program is set to start. ie 10:54:00 am
STOP: Length of time specifying how long the misting system should engage. For example
00:00:40 would indicate 40 sec.
WEEK:
WEEK: Default setting for each program. Instead of executing the program any specic day,
it will repeat every day of the week
L
L
L
MistKing® Seconds Timer (ST-24) can be set to mist at user specified times. In addition, the misting duration of each program can also
be customized. ST-24 has 10 programs (P0-P9), giving you total control. No need to use all programs if not required. Each program can
be repeated daily or on a specific day only.
Example: P0: Start at 8:30 am and mist for 25 sec, every day of the week.
P1: Start at 2:30 pm, and mist for 1 min 20 sec, Wednesdays only.
Model: ST-24
Seconds Timer
Modes:
ON:
Always ON ---
OFF:
Always OFF ---
AUTO:
Uses any of the congured programs (P0-P9)
c. Set “P1”:
When done setting “P0”, press “SET” key once. Display will show “P1”, which can now be congured using same method from above (2b).
Continue pressing "SET" to set up programs for P2-P9 if need. Keep pressing SET until you cycle through all Programs and exit into main
screen.
Seconds Timer Connection
1.
Connect the BLUE lead on the seconds controller to the
power adapter of your MistKing misting system.
2.
Connect the BLACK lead to your pump and ZipDrip (if
available). DO NOT plug ZipDrip to blue lead.
NOTE: Seconds controller works only with MistKing
systems and therefore requires additional Mistking
components to work properly.
Using the seconds timer with non-MistKing
equipment voids warranty.

Go to
MistKing
.com for more information on systems and parts
Mistking
®
is a Registered Trade Mark of © All Rights Reserved
Tips:
a) RAPID ADJUST: While setting individual values, press and hold “up arrow” or “down arrow” for faster advancement of settings
b) SAVE & EXIT: When done modifying values press and hold “SET” key for 3 seconds to Save & Exit. Alternatively don't input anything
for 15 seconds and timer will exit automatically saving and displaying the main screen.
c) RESET: In normal status press UP and DOWN arrows together for 5 seconds. Timer will reset to factory settings. Since no programs
will be set the right part of the screen will show OFF.
Q
Quick-ON Function:
In normal status, press and hold up arrow key for 5 seconds to active the quick-on function. While pressed the timer will activate
allowing you to quickly bypass any timer settings and manually activate the misting system. Quick ON, does not affect any settings.
When up arrow is released, timer resumes normal operation and misting stops.
Energy-saving:
If there is no key activity on the ST-24 for approximately 10 minutes the LCD backlight automatically turns off. Pressing any key will
reactivate the back light again.
Display:
When the system is idle, the left part of the screen displays current time. Right part of the screen shows the next programmed time to
be executed (only hour and minute). If the next program start time is the same day as current clock it will display the start time with A or
P( A=AM, P=PM, see picture E, F)
I
If the next program start time is not the same day as the current time shows, the display will show A or P like above but in addition will
specify in how many days the program is scheduled, ie A1~A7 or P1~P7; for example: Current time is 4am, the next program starts 05:00
AM tomorrow, the display will indicate 5:00A1 (am, in 1 day, see picture G). If the next program starts tomorrow at 05:00PM, display will
show 05:00P1 (pm, in 1 day, see picture H) A1 means AM of next day, P1 means PM of next day. A2, means AM in 2 days, etc.
MENU ITEM
MODE
PROGRAM
WEEK
START
STOP
WEEK
WEEK DATE
CLOCK
Description
Species if timer is permanently ON, OFF or in AUTO. Only AUTO
mode will follow set P0-P9 programs
Selected Program
Selected Day or the week in the conguration of the program or
whole WEEK, repeated daily
Specic time when a pSpecic time when a program should start
Duration misting system should be ON
Clock's day of the week
Internal Timer Clock. Based on current time precise DAY and NIGHT
operation is possible
Settings Range
AUTO / ON / OFF
P0, P1, P2, P3, P4, P5, P6, P7, P8, P9
Mon, Tue, Wed, Thu, Fri, Sat, Sun, Week
00:00:00 - 23:59:59
Max Cycle length 12:59:59
M
Mon, Tue, Wed, Thu, Fri, Sat, Sun
00:00:00 - 23:59:59
