MISUMI IP-1614GII Installation and operating instructions

Device manual of IP Cameras
Page 1 of 29
!
!
IP-1614GII
IP Cameras Products Series
User Manual &
Installation Guide
Version: 1.0
Date: March 2, 2006

Device manual of IP Cameras
Page 2 of 29
Table of Contents
TABLE OF CONTENTS..........................................................................................................................2
WHAT IS IP CAMERAS? .......................................................................................................................3
PRODUCT FEATURES............................................................................................................................3
2. PHYSICAL CONNECTIONS..............................................................................................................4
3. INSTALLATION..................................................................................................................................4
CONNECT IP CAM TO NETWORK .........................................................................................................6
CONNECT POWER SUPPLY...................................................................................................................6
HOW TO RESET ....................................................................................................................................6
START YOUR FIRST TIME NETWORK MONITORING .............................................................................7
HOW TO VISIT THE BUILT-IN WEB ........................................................................................................8
ABOUT THE USER INTERFACE OF IP CAM ..........................................................................................9
HOW TO CHECK THE FIRMWARE VERSION ..........................................................................................9
HOW TO CHANGE THE CONFIGURATIONS..........................................................................................10
HOW TO CHANGE USER LOGO ..........................................................................................................12
HOW TO DISABLE AND ENABLE USER LOGO ......................................................................................15
USER MANAGEMENT .........................................................................................................................16
LOG ....................................................................................................................................................17
NETWORK ..........................................................................................................................................18
VIDEO.................................................................................................................................................19
EVENT ................................................................................................................................................20
4. PRODUCT SPECIFICATIONS ......................................................................................................... 23
MODELS .............................................................................................................................................23
SPECIFICATIONS: ...............................................................................................................................23
5. APPENDIX ........................................................................................................................................25
DICTATION .........................................................................................................................................25
USE CGI COMMAND TO SETUP GPIO AND EVENTS .........................................................................27
How to configure GPIO Process? ...............................................................................................27
How to Configure Event Process ................................................................................................27
SCENARIO: USE DI TO TRIGGER EVENT AND SEND IMAGES THROUGH MAIL AND FTP..................28
Turn FTP Service on the server ..................................................................................................28
Enable DI status to “ON”............................................................................................................28
Turn On FTP and Email..............................................................................................................29
Setup Event status........................................................................................................................29
Check DI type status ....................................................................................................................29
Check Event Status ......................................................................................................................29
Click on DI and you can check your mail box and FTP services .............................................29

Device manual of IP Cameras
Page 3 of 29
1. Product Overview
What is IP Cameras?
IP Cameras is designed for intranet & internet use. Users can view image or change
configurations via built-in web server. The two-layer user-validation prevents any
illegal user to monitor or change configuration once user validation is enabled
Product Features
IP Cameras CPU: 32 Bits RISC Processor. 16Mb Flash, 64Mb SDRAM
Linux OS
TCP/IP network remote Video transmission system
High performance JPEG/MJPEG compression
Built-in Web sever
Built-in DHCP Client
Built-in Motion Detection
Frame Rate Control
Administrator / User level password protection
Snapshots
On-line firmware upgrade
Frame Rate: NTSC: 30 frame/sec

Device manual of IP Cameras
Page 4 of 29
2. Physical Connections
W/100cm cable
DC 12V
INPUT
Ethernet
Side Panel Connections Front Panel Connections
IP-R1614GII
3. Installation
Connect Power Supply DC 12V
Ensure your power adapter specification
matchs your power system (ex 110V or 220V)
Connect the adapter to the outlet.
Once the power status is OK.the
LED in red located at the rear panel
of IP cam should light-up.
Connect power jack
Prepare a PC to link your network with Ethernet
W/100cm cable

Device manual of IP Cameras
Page 5 of 29
Network connectivity check
Please check your network connectivity before you start install the product.
Confirm the link status of your LAN is OK. You may try use the following way to
check the network.
Assuming you are under Microsoft Windows 2000 desktop, Click on Start button,
Programs, Accessories, Command Prompt
Δ
Then there will be a blank window
appear to wait command input. Please key in the following command to test the
network status.
C:\>ping 192.168.1.1 [Enter]
*Note: the target IP address given above may be correct in common scenarios, if
your network is not configured by IP segment 192.168.1.x, please change the IP
Address to a valid address in your local network. Any difficulties please contact
your network administrator for assistance.
If your network status is OK, the result of above command should like following
Pinging 192.168.1.1 with 32 bytes of data:
Reply from 192.168.1.1 bytes=32 time=10ms TTL=64
…
If you have confirmed your network connectivity is OK, Please proceed to next part
of installation guide, otherwise, contact your network administrator to recover the
problem.

Device manual of IP Cameras
Page 6 of 29
Connect IP cam to network
Once the power status is OK.the
LED in red located at the rear panel
of IP cam should light-up.
W/100cm cable
Connect IP cam to your hub/switch by using a normal RJ45 cable, plug the RJ45
cable into the Ethernet connector locate at the rear panel of the IP cam, another
side connect to your hub/switch.
Connect Power Supply
Connect power jack
W/100cm cable
Connect Power Supply DC 12V
Ensure your power adapter specification
matchs your power system (ex 110V or 220V)
Connect the adapter to the outlet.
Connect the IP cam and power source with the adapter provided, plug the power
adapter into the DC 12V Connector. Once the power status is OK, the LED in red
located at the rear panel of IP cam should light-up.
How to reset
Load IP Cam Default Settings
DC 12V
INPUT
Ethernet

Device manual of IP Cameras
Page 7 of 29
Start your first time network monitoring
Run the “IPLocator” utility, the newly connected IP cam will be listed in the
application window. Please remember its’ IP address.
Open an Internet Explorer Window input the following address into the address
textbox:
http://[IP cam IP Address provided by IPLocator]
After you press on the enter key, the main working interface and video picked by
the camera should appear after a short period. The installation steps are completed.
You may now start your first network monitoring experience.
Note: when you first time enter the working interface, the browser may ask whether
to install a COMWebSurv component, which is used to communicate with our IP
cam product, PLEASE CHOOSE YES to install, otherwise the monitoring function
may not work.

Device manual of IP Cameras
Page 8 of 29
How to visit the built-in web
Launch your Internet Explorer (I.E. 6.0 or above) first, then type the IP cam’s url. (i.e.
http://192.168.1.100). The user validation is disabled as default, no login is necessary. The
user is same as the system administrator(Default : root/pass).
For the first time user visits the IP Cam, the ActiveX(ATLWebSurvCOM) will be downloaded to
the [Downloaded Program File]. Be sure to click the button [Yes] as below.
Notes: Call your system administrator if you have not enough privilege to download the
ActiveX. (i.e. Users should be the administrator to download the ActiveX for Windows 2000/XP
operation system)
You can find the ActiveX ATLWebSurvCOM will be downloaded to the [Downloaded
Program File] folder. The above dialog will pop automatically once new ActiveX is
available(i.e. after firmware upgrade)

Device manual of IP Cameras
Page 9 of 29
About the User Interface of IP Cam
The upper window is for company logo display (i.e. This is a generic version. The
company logo leaves blank). The left side of the window is the control panel. The
right window is for image display. (Please switch to full screen mode when the
resolution is set to VGA mode)
How to check the firmware version
Click the WebCam icon and you will read the firmware version

Device manual of IP Cameras
Page 10 of 29
How to change the configurations
The system administrator: root is the one who has the privilege to change system
configuration if user validation is enabled. The following window will appear when
you click [Options] icon in the control panel (left side of the window). The follow is
the description & field definition.
[System]:
Server Info: Server Model and Firmware Version
Device Name: the name of hardware device.
Video Mode: Video Mode (NTSC or PAL)
Time Zone: Time Zone Setting
Display Option
Show Camera Name: Show Camera Name on Display
Show Date Time: Show Date Time on display
Traffic Control: Bandwidth Setting
Others
Load default configuration: Load the factory default.
Reboot: Reboot the hardware remotely.
Firmware Upgrade : Upload & upgrade the IP cam firmware.

Device manual of IP Cameras
Page 11 of 29
[Firmware Upgrade]: Please follow the standard procedure to upgrade firmware.
Step 0: Stop all unnecessary running application in your PC.
Step 1: Uncheck the [Browse..] and [Upload] motion images in the Motion Detection Setting
and reboot the hardware. Note: You have to make all event setting to be disable,
before you do this step.
Step 2: Upload the firmware: Be sure to upload the correct firmware. Wrong firmware may
cause your IP cam malfunction. It’s possible to take a few minutes to upload the
firmware into memory depending on the network environment. Since too many
unknown situation may occur in the Internet, we strongly recommend you to upgrade
firmware in the Intranet.
Step 3: Write firmware to your IP cam. It will take a few minutes to write firmware into flash.
The IP cam will reboot automatically when writing firmware is complete. Please DO
NOT reboot the device manually.
Note: Any interrupt during writing will cause the IP cam malfunction. The UPS may
prevent the power failure problem.

Device manual of IP Cameras
Page 12 of 29
How to change User Logo
We allow you to use your own logo from version v3.0. User logo will not be erased
when you upgrade firmware in the future. The detailed procedures are as follows:
Step1: Type http://Video ServerIP/LogoUpload.htm
Step 2: Browser the logo file to use and upload to upload it.
Note: The file format must be gif and the max size is 30 K bytes.

Device manual of IP Cameras
Page 13 of 29
Step 3: Click [Change] button to write logo file into flash memory.
Step 4: Reboot Video Server once ChangeLogo is complete.

Device manual of IP Cameras
Page 14 of 29
Step 5: You have to clear the [Temporary Internet files] to take changes effect since
there is always some catch in the I.E. Please click [Tools] [Internet Options..] on the
top bar.
Step 6: Clear [Temporary Internet files] as follows.

Device manual of IP Cameras
Page 15 of 29
Step 7: Refresh I.E. (Click F5) to take changes effect. You will see you new logo
below.
How to disable and enable user logo
Type: http://Video ServerIP/SetOEM.cgi?LOGO=0 to turn off the user logo
or http://Video ServerIP/SetOEM.cgi?LOGO=1 to turn on the user logo

Device manual of IP Cameras
Page 16 of 29
User Management
The administrator(root) has the privilege to manage users if User Validation is enabled. Here
are the configurations available & field definition.
[User]:
User validation
Yes : Enable user check
No : Disable user check
Add/Modify User: To create new user or modify existing user password
Username : user name
Password: user password
Confirm : user password confirmation
Delete user: To delete existing user
Current User List: The users in the IP cam

Device manual of IP Cameras
Page 17 of 29
Log
The system log will be listed in the window when you click [Log] icon.
Operation: The operation which user operates
Value: The value to change
Client IP: The IP address of client PC
Client MAC: The mac address of client PC
Datetime: date-time which operation occurs

Device manual of IP Cameras
Page 18 of 29
Network
Allows administrator(root) to change network setting when you click [Network] icon.
IP Setting: Please consult you networking manager for the following values
Manual: To set network setting manually.
DHCP: To let IP cam get network setting from DHCP server automatically.
IP Address: IP address of IP cam
Subnet mask: Subnet mask of IP cam
Default Gateway: Default gateway of IP cam
DNS 1/2/3: DNS Server IP if necessary
Http Port: Change the http port of built-in web server (default 80).
(i.e. range 80, 1025 ~ 65535)

Device manual of IP Cameras
Page 19 of 29
Video
Allows administrator(root) to change Image Setting, Traffic Control or Motion Detection.
Image Setting
Quality: Image Quality (Low/Normal/Good/Fine/Excellent)
Images Size: 160x120/176x144/320x240/352x288/640x480/704x576
Rotation: Nomal/180 degree (Upside down)
Advanced: Image preference adjustment
Brightness: Adjust image brightness
Contrast: Adjust image contrast
Hue: Adjust image hue
Saturation: Adjust image saturation
Traffic Control
Unlimited: To send out image at full speed. (up to 30 frames per second)
Frame per second: Delay to send image every x second(mini-second)

Device manual of IP Cameras
Page 20 of 29
Event
This Option contains three major functions: Server Configuration, GPIO
Configuration and Event Configuration
Server Configuration: User can setup Ftp and Mail services that provides the
actions in Event setting.
See figure below:
Allows administrator(root) to configure the mail & ftp setting once motion detected
Mail Setting: if check on Mail motion images, Device will send motion images
Mail Server: Name or IP of Mail server
Username: User name
Password: User password (Password will be validated if checked)
Mail From: Mail sender
Mail To: Mail receiver
Mail Subject: Mail subject
FTP Setting: if check on Mail motion images, Web DVR will upload motion images
FTP Server: FTP Server
Username: User name
Password: User password
Upload Path: Images upload path
