Assembly & OperAting instructiOns
mOdel: 900034495 (4 Burner Flat Top BBQ) Vpn: MG104FT
FOR OUTDOOR USE ONLY
WARNING
• For outdoor use only.
• Improper installation, adjustment, alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this appliance.
• Warning: Accessible parts may be very hot. Keep young children away at all times.
• Do not move the appliance during use.
• Turn off the gas supply at the gas cylinder after use.
• DO NOT modify this appliance.
• Installer to leave instructions with the consumer and consumer to retain them for future reference.
FOR YOUR SAFETY
1. Do not store or use any ammable vapours or liquids in the vicinity of this or any other appliance.
2. A disconnected LPG cylinder shall not be stored in the vicinity of this or any other appliance.
IF YOU SMELL GAS:
1. Turn off all gas valves.
2. Extinguish any remaining open ames.
3. If the odour of gas remains, immediately contact your gas supplier for further advice.
impOrtAnt! reAd these instructiOns cArefully befOre use
This Appliance is designed for use with UNIVERSAL LPG
Certication No: AGA 7771 MFG Model ID: MG104FT
AGA
approval
No: 7771
Australian Gas Association
MG104FT-2014-06-18-V3

impOrtAnt sAfety instructiOns
1. This appliance is for OUTDOOR USE ONLY. Under no circumstances is it to be used indoors.
2. Read all operating instructions and familiarise yourself with the appliance before operating.
3. Do not perform any servicing on this appliance yourself. Servicing must only be conducted by a suitably
qualied and authorised technician.
4. Always check for leaks when the cylinder is replaced or reconnected.
5. Do not store chemicals or ammable materials on or near this appliance.
6. Children should not be left unsupervised near the appliance warming up, during use or while it is cooling
down.
7. Flammable clothing should not be worn near the appliance when it is operating.
8. Do not leave food unattended on the appliance.
9. If a fat re occurs, immediately turn off the gas cylinder.
10. Hot fat can cause serious burns. Care must be taken when removing the grease tray.
11. This appliance must not be positioned under any overhead combustible construction and advised minimum
distances from combustible materials must be maintained at all times.
Minimum clearances to combustibles are:
Overhead – 1000mm
From back – 300mm
From Sides – 100mm
12. When not in use, ensure all gas valves including the cylinder are turned off.
13. Never leave the burners on ‘HIGH’ for more than 10 minutes unless actually cooking. If the burner makes a
“hissing” sound during use the ame may have ashed back inside the burner. If this occurs turn the burner off
allow it to cool and relight it.
14. Do not allow unburnt gas to build up. Always provide sufcient ventilation.
15. Refer to the data label afxed to the appliance for information regarding gas consumption and injector sizes.
16. This appliance shall only be used in an above ground open air situation with natural ventilation, without
stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural
convection.
17. The hose assembly connects to the appliance with a 3/8 SAE compression tting. It must be tightened using a
suitable tool (such as an adjustable wrench) to obtain a gas tight seal. The joint must be tested for leaks using
a soapy water solution after each connection. If a leak is detected the joint must be sealed and the leak sealed
before the appliance is used.
18. Never operate this BBQ with the LPG Cylinder located directly below the burners.
WArning
A strong smell of gas or hissing sound may indicate a serious problem with your appliance
or gas cylinder. Failure to follow these steps could cause serious injury, death or property
damage.
1. Shut off the gas supply to the appliance at the gas cylinder.
2. Turn the control knobs of the appliance to the ‘OFF’ position.
3. If the leak is obvious and easily resolved, seal the leak.
4. If the leak cannot be sealed and it is safe to do so, move the appliance to a safe
location.
Then move away from the gas cylinder and appliance.
If the odour continues or there is a re you cannot control, call your local re department.
Do not use your phone near the appliance.

OutdOOr AreAs
This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant
areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection.
Any enclosure in which the appliance is used shall comply with one of the following:
• An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead
cover. See gure 1.
• Within a partial enclosure that includes an overhead cover and no more than two walls. See gure 2 & 3.
Within a partial enclosure that includes an overhead cover and more than two walls, the following shall apply:
1. At least 25% of the total wall area is completely open; and
2. At least 30% of the remaining wall area is open and unrestricted.
In the case of balconies, at least 20% of the total of the side, back and front wall areas shall be open and
unrestricted.
Open side at least
25% of total wall area
Open side at least
25% of total wall area 30 percent or more in total
of the remaining wall area
is open and unrestricted
30 percent or more in total
of the remaining wall area
is open and unrestricted
Figure F4 - Outdoor Area - Example 4
Figure F5 - Outdoor Area - Example 5
Both ends open
Figure F1 - Outdoor Area - Example 1
Figure F2 - Outdoor Area - Example 2
Figure F3 - Outdoor Area - Example 3

generAl infOrmAtiOn
• Minimum size LPG cylinder size - 4kg (POL Valve).
• Strong winds and low ambient temperatures will affect the heating performance of the appliance. You should
consider these factors during use, it is part of cooking outdoors.
• Never use your appliance in a garage, porch, breezeway or any other similar enclosed area.
• Air ow is vital for this appliances safe operation, do not obstruct the ow of ventilation in or around this
appliance.
• This appliance is not intended to be installed in recreational vehicles of marine vessels.
• Gas owing through your regulator can cause a humming sound, this is normal and not a cause for concern.
Purging the gas system of air can assist in reducing this noise and should be done each time a gas cylinder is
connected to the appliance.
• Ensure all transit material has been removed prior to assembly and use.
impOrtAnt
IT MAY BE HAZARDOUS TO ATTEMPT TO FIT OTHER TYPES OF GAS CONTAINERS. ONLY USE IN WELL
VENTILATED AREAS. CARBON MONOXIDE HAZARD - THIS APPLIANCE CAN PRODUCE CARBON MONOXIDE
WHICH HAS NO ODOUR. USING IT IN A CONFINED SPACE (FOR EXAMPLE, CARAVAN, TENT, CAR, MOBILE
HOME) MAY CAUSE DEATH. CAUTION: ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDREN
AWAY. USE OUTDOORS ONLY.
Do not use this appliance if it is leaking, damaged or does not operate properly.
Only use this appliance on a horizontal surface.
The gas cylinder shall be changed in a well-ventilated location, preferably outside, away from people and any
sources of ignition, such as naked ames, pilot ames and electric heaters/ equipment.
This appliance must only be serviced by an authorised person. Avoid twisting or kinking the exible hose. Do not
move the appliance during operation or whilst still hot.
Gas cylinders are to be stored outdoors in a well ventilated area out of reach of children. Any indoor storage shall
comply with AS/NZS 1596.
If there is a leak on your appliance (smell of gas), immediately attempt to turn off the cylinder valve. Remove the
appliance to a well ventilated location away from any ignition source. Check for leaks using soapy water. Do not try
to detect leaks using a ame. Do not modify this appliance.

PARTS LIST
NOTE: To assemble this appliance you will require a minimum of a medium size Phillips head screw driver and a
200mm adjustable wrench.
pArt # descriptiOn Qty pArt # descriptiOn Qty
1Lid Handle 1 16 Cast Iron Grate 1
2Lid 1 17 Hose and Regulator Assy 1
3Lid Bracket 1 18 Bolt Pack 1
4Cast Iron Plate 1
5Flame Diffusers 2 pArt # bOlt pAcK cOmpOnents Qty
6Appliance Chassis 1 19 M6 Cup Nut 4
7Serving Shelf 2 20 M8 Nut 2
8Non Axle Leg 2 21 M6 Flat Washer 6
9Lower Shelf 1 22 M8 Axle/Wheel Bolt 2
10 Spacer 8 23 M6x10mm Bolt 4
11 Wheel 2 24 M6x85mm Bolt 8
12 Wheel Bolts 2 25 M6x60mm 4
13 Axle/Wheel leg 2 26 M6 Nut 6
14 Cylinder Hook 1 27 Spacer 8
15 Grease Tray 1 28 M6x12mm Bolt 2

cOnstructiOn
Step 1: Assemble leg, lower shelf and wheels
Step 2: Fasten serving shelves, cylinder hook & appliance chassis
Step 3: Lid Assembly
M6x4PCS
M10x6PCS
M8x2PCS
M8x2PCS
M6x10x2PCS
M6x85x9PCS
M6x60x4PCS
M6x4PCS
Spacersx8PCS
M6x12x2PCS
M6x10x2PCS
M6x2PCS

Step 4: Final Assembly
Step 5: Completed.

usAge instructiOns
Gas Connections
All gas connections must be tested before each use for leaks using a soapy water solution. With the gas cylinder
turned on and the appliance controls off, sponge soapy water onto the gas connection and look for a stream of
bubbles. A stream of bubbles indicates a leak which must be sealed before the appliance is used. NEVER use a
naked ame to test for gas leaks.
Connections at the gas cylinder and appliance must be tested.
Pre Lighting Checks
1. After testing for leaks and being sure that all connections are gas tight, ensure the appliance controls and gas
cylinder are turned off.
2. Make sure there is sufcient gas in the gas cylinder.
3. Ensure the burner is correctly located on the gas control.
4. Remove the lid.
lighting the AppliAnce
Manual Ignition
With the lid removed, place a lit match or long stem gas lighter through the hole in the side of the appliance.
Ensure your hand remains away from the burner when doing this. Turn the control knob nearest the side you are
working from ‘OFF’ to the ‘HIGH’ position. The burner should light.
Automatic Ignition
With the lid open/removed, rotate the desired control from the ‘OFF’ position to the ‘HIGH’ position and hold it
there until you hear the burner light. If it fails to light, return the control to the ‘OFF’ position and try again. It is best
to perform this in a slow deliberate way rather than quick and sudden. If after 5 attempts the burner has not lit, turn
off all controls and allow it to rest for 5 minutes to let any accumulated gas to disperse.
Note that the ignition works by shooting a ame out of the control along the side of the burner. To rotate the
control from ‘OFF’ to ‘HIGH’ you must rst depress and hold the control knob down while you rotate it from ‘OFF’.
Curing the Cooking Surfaces
During manufacture the Cooking Surfaces was coated with a non-toxic paint to protect it from corrosion during
storage and transport. This coating will come completely off in time. However the Cooking Surfaces must be
cured to assist with food not sticking to it. To do this, coat the Cooking Surfaces in a liberal coating of inexpensive
cooking oil. Turn all burners to ‘LOW’ and maintain this for 30 minutes (some paint may start to come off during
this process). Turn the appliance off and allow it to cool. Clean the Cooking Surfaces and the curing process is
complete. This only needs to be done once when the appliance is new and after the cooking surfaces have been
washed as washing removes the oil from the surfaces.

The temperature of the appliance is set by adjusting the controls. Each control adjusts the burner immediately
behind it. There are safety detents at the ‘OFF’ and ‘HIGH’ positions to stop accidentally rotating a control and
placing the appliance in a condition that maybe hazardous. To rotate the control from OFF to ‘HIGH’ you must
depress the knob and hold it depressed while you move the control from the ‘OFF’ position. When moving the
control from ‘HIGH’ to ‘OFF’ you must also depress the control knob whilst passing ‘HIGH’. Movement between
‘HIGH’ and ‘LOW’ is free and you do not have to depress the control knob. Once lit, the temperature is controlled
by adjusting each burner between ‘HIGH’ and ‘LOW’.
Cooking Tips
The following tips will help you to prepare food that is moist and succulent.
Before cooking coat the plate with a liberal coating of cooking oil, which will assist to stop food sticking.
The appliance must be warmed up before use, light the burners and allow them to operate on high for 3 – 5
minutes.
When cooking meat resist the urge to continually turn it over. For moist juicy meat, turn it once only during
cooking. Juices rise to the top of meat during cooking and then settle. Each time meat is turned juices are lost and
the meat becomes drier.
After Cooking
To turn the appliance off, turn off the gas supply at the cylinder rst, and allow the burners to extinguish by
exhausting the remaining gas supply. Once the ames have extinguished, turn the appliance controls to ‘OFF’.
While the hotplate and grill are still hot, using a long handled brush and scraper, remove any remaining food
residue and wipe any excess fat from the cooking surfaces, then coat with fresh cooking oil for continued
protection against corrosion.
cleAning
The appliance will look better and last longer if it is kept clean.
You should check the burners periodically for any sort of blockage. To do this remove each burner individually and
inspect them. Look for any blockages to the ame ports and inside the burner. If any ame ports are blocked, use a
wire brush to unblock them. If there is a blockage inside the burner, use a stiff wire or pipe cleaner to unblock it.
A sign that a blockage is inside the burner is the burner ashing back regularly, if this is occurring, remove the
burner and inspect it for a blockage.
Grease can build up inside the appliance and this can be cleaned with a hot soapy water solution. Do not use a
caustic cleaner as it will irreparably damage the appliances coating.
The grease tray should be emptied regularly. Never touch the grease tray when hot, always allow it to cool
completely before handling.

stOrAge
Do not store the appliance until it has completely cooled.
• Storage of the appliance in doors is permissible only if the gas cylinder has been disconnected, removed from
the appliance and remains outdoors.
• Store the appliance in a cool dry location.
• Always disconnect the gas cylinder and store it in a safe suitable location away from naked ames and sources
of ignition. The gas cylinder must be stored vertically, never lay it on its side.
• Never store the gas cylinder in a building such as a garage.
• If storing the appliance outdoors it is recommended to cover it with a heavy duty cover that will protect it from
the elements.
• Keep the cooking area free from combustible materials such as fuel, ammable vapours and liquids.
AdditiOnAl impOrtAnt infOrmAtiOn
• This appliance is for domestic outdoor use ONLY. Do not use it indoors. Do not use for commercial purposes
including club or similar events.
• Do not store gas cylinders below ground level. LP Gas is heavier than air and if there is a leak the gas will
accumulate creating a dangerous condition.
• Do not store or rest gas cylinders on their side. This may cause liquid to be expelled from the cylinder which
can lead to a dangerous condition.
• Ensure you have tested every gas connection for leaks before each use. This includes inspecting the condition
of the hose and regulator assembly and making certain it is in a suitable condition for use.
• Always turn the cylinder valve off when not in use.
Abnormal Operation
Due to unseen circumstances the appliance may not operate as designed. Indications of this are ashing back in
the burner, large soft yellow ames, ames lifting extensively away from the burner and the appliance not igniting
or remaining alight. If any of these conditions occur you should rstly check your gas supply to ensure there is
sufcient gas, no leaks and the valves are opened sufciently for use. If this is the case and the problem/s is still
persisting you will need to contact a suitably qualied authorized person to service your appliance.
Care and Maintenance
In addition to the regular cleaning of your appliance, there is some other minor maintenance that can be
performed to ensure its longevity. Before conducting any maintenance ensure the gas cylinder is turned off and
disconnected.
• If there are any rubber seals as part of the gas connection, check them regularly for wear or cracking and
replace as necessary.
• It is recommended that a suitably authorised and qualied person should perform a thorough examination of
the appliance at least every 5 years.
• The service life for a gas cylinder is 10 years from the date stamped on it protection collar. You should ensure
that any cylinder you use with this appliance is within it service life.
• It is recommended to keep the cooking surfaces covered with cooking oil at all times.

12 mOnth WArrAnty
1. Our goods come with guarantees that cannot be excluded under the Consumer Guarantees Act (NZ). You
are entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to a major failure. Where a failure does not amount to
a major failure, MITRE10 (New Zealand) is entitled to choose between providing you with a repair, replacement
of refund. To obtain compensation, you would need to provide documentary evidence of the loss or damage
suffered, and documentary evidence that such loss or damage was a reasonably foreseeable consequence of a
failure by MITRE10 (New Zealand) to comply with a consumer guarantee under the Consumer Guarantees Act
(NZ). Such evidence may include photographs, statutory declarations, receipts, reports (e.g. from your doctor),
depending on the loss or damage.
2. In addition to all rights and remedies to which you may be entitled under Consumer Guarantees Act (NZ)
and any other relevant legislation, the manufacture warrants this product free from defects in materials or
workmanship for a period of 12 months from the date of purchase.
3. In order to claim under this warranty you will need to bring the product to any MITRE10 (New Zealand) store,
along with proof of purchase (typically this will be a receipt). Any cost incurred by you in bringing the product
to the service desk will be borne by you. We will then, at our option, either repair or replace the product, or
refund your money and take back the product in accordance with our returns policy, a copy of which is available
at any MITRE10 (New Zealand) store.
4. Our liability under this manufacturer’s warranty is subject to us being satised that a defect was caused be
defective workmanship or materials, and was not contributed to by factors, or circumstances beyond our
control, including (but not limited to) defective installation, maintenance or repair, alteration or modication of
the product in a manner not recommended by the manufacturers or any neglect, misuse or excessive use.
5. The benets conferred by this manufactures warranty are in addition to all rights and remedies conveyed by the
Consumer Guarantees Act (NZ), and any other statutory rights to which you may already be entitled, and this
warranty does not exclude, restrict or modify any such rights or remedies that are implied by law.
THIS WARRANTY IS PROVIDED BY: MITRE10 (NEW ZEALAND)
46-48 View Road
Gleneld
Auckland 0627
09 4439900
