1. Safety Precautions
Symbols used in the text
Warning:
Describes precautions that should be observed to prevent danger of injury
or death to the user.
Caution:
Describes precautions that should be observed to prevent damage to
the unit.
Symbols used in the illustrations
: Indicates a part which must be grounded.
Note:
The phrase “Wired remote controller” in this operation manual refers only to the PAR-41MAA. If you need any information for the other
remote controller, please refer to the instruction book included in this box.
This symbol mark is for EU countries only.
This symbol mark is according to the directive 2012/19/EU Article 14 Information for users and Annex IX, and/or to the direc-
tive 2006/66/EC Article 20 Information for end-users and Annex II.
Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and components which can be
recycled and/or reused. This symbol means that electrical and electronic equipment, batteries and accumulators, at their end-of-life,
should be disposed of separately from your household waste. If a chemical symbol is printed beneath the symbol (Fig. 1), this chemi-
cal symbol means that the battery or accumulator contains a heavy metal at a certain concentration.
This will be indicated as follows: Hg: mercury (0.0005%), Cd: cadmium (0.002%), Pb: lead (0.004%)
In the European Union there are separate collection systems for used electrical and electronic products, batteries and accumulators.
Please, dispose of this equipment, batteries and accumulators correctly at your local community waste collection/recycling centre.
Please, help us to conserve the environment we live in!
Note
Fig. 1
MEANINGS OF SYMBOLS DISPLAYED ON THE UNIT
WARNING
(Risk of re)
This mark is for R32 refrigerant only. Refrigerant type is written on nameplate of outdoor unit.
In case that refrigerant type is R32, this unit uses a ammable refrigerant.
If refrigerant leaks and comes in contact with re or heating part, it will create harmful gas and there is risk of re.
Read the OPERATION MANUAL carefully before operation.
Service personnel are required to carefully read the OPERATION MANUAL and INSTALLATION MANUAL before operation.
Further information is available in the OPERATION MANUAL, INSTALLATION MANUAL, and the like.
►Beforeinstallingtheunit, makesureyou readallthe“SafetyPrecau-
tions”.
►The“SafetyPrecautions”provideveryimportantpointsregardingsafe-
ty. Make sure you follow them.
►Pleasereporttoortakeconsentbythesupplyauthoritybeforeconnec-
tion to the system.
Warning:
• There appliances are not accessible to the general public.
• The unit must not be installed by the user. Ask the dealer or an authorized
company to install the unit. If the unit is installed improperly, water leakage,
electricshockorremayresult.
• Donotaltertheunit.Itmaycausere,electricshock,injuryorwaterleak-
age.
• The unit must be securely installed on a structure that can sustain its
weight.
• Do not stand on, or place any items on the unit.
• Do not splash water over the unit and do not touch the unit with wet hands.
An electric shock may result.
• Do not spray combustible gas close to the unit. Fire may result.
• Donotplaceagasheateroranyotheropen-ameappliancewhereitwill
be exposed to the air discharged from the unit. Incomplete combustion may
result.
• Do not remove the front panel or the fan guard from the outdoor unit when
it is running.
• When you notice exceptionally abnormal noise or vibration, stop operation,
turnothepowerswitch,andcontactyourdealer.
• Neverinsertngers,sticksetc.intotheintakesoroutlets.
• Ifyoudetectoddsmells,stopusingtheunit,turnothepowerswitchand
consultyourdealer.Otherwise,abreakdown,electricshockorremayre-
sult.
• ThisairconditionerisNOTintendedforusebychildrenorinrmpersons
without supervision.
• Young children must be supervised to ensure that they do not play with the
air conditioner.
• If the refrigeration gas blows out or leaks, stop the operation of the air con-
ditioner, thoroughly ventilate the room, and contact your dealer.
• This appliance is intended to be used by expert or trained users in shops, in
light industry and on farms, or for commercial use by lay persons.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruc-
tion concerning use of the appliance in a safe way and understand the haz-
ards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction con-
cerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the air
conditioner.
• When installing or relocating, or servicing the air conditioner, use only the
speciedrefrigerantwrittenonoutdoorunittochargetherefrigerantlines.
Do not mix it with any other refrigerant and do not allow air to remain in the
lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal high
pressure in the refrigerant line, and may result in an explosion and other
hazards.
Theuseofanyrefrigerantotherthanthatspeciedforthesystemwillcause
mechanical failure or system malfunction or unit breakdown. In the worst
case, this could lead to a serious impediment to securing product safety.
1. Safety Precautions ............................................................................. 1
2. Parts Names....................................................................................... 2
3. Operation ........................................................................................... 5
4. Timer................................................................................................. 13
5. Care and Cleaning............................................................................ 13
6. Emergency Operation for Wireless Remote-controller..................... 14
7. Trouble Shooting .............................................................................. 15
8. Installation, relocation and inspection............................................... 16
9. Specications ................................................................................... 18
For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit.
