1. Safety Precautions ...................................................................................................................................................................... 2
2. Operation..................................................................................................................................................................................... 3
3. Care and cleaning ..................................................................................................................................................................... 14
4. Troubleshooting ......................................................................................................................................................................... 15
5. Installation, relocation and inspection ....................................................................................................................................... 16
6. Specifications ............................................................................................................................................................................ 17
Contents
sBefore installing the unit, make sure you read all the “Safety precautions”.
sThe “Safety precautions” provide very important points regarding safety. Make sure you follow them.
sPlease report to or take consent by the supply authority before connection to the system.
Symbols used in the text
Warning:
Describes precautions that should be observed to prevent danger of injury or death to the user.
Caution:
Describes precautions that should be observed to prevent damage to the unit.
Symbols used in the illustrations
: Indicates an action that must be avoided.
: Indicates that important instructions must be followed.
: Indicates a part which must be grounded.
: Indicates that caution should be taken with rotating parts.
: Indicates that the main switch must be turned off before servicing.
: Beware of electric shock.
: Beware of hot surface.
Warning:
Carefully read the labels affixed to the main unit.
Warning:
• The unit should not be installed by the user. Ask the dealer or an authorized company to install the unit. If the unit is installed improperly,
water leakage, electric shock or fire may result.
• Do not stand on, or place any items on the unit.
• Do not splash water over the unit and do not touch the unit with wet hands. An electric shock may result.
• Do not spray combustible gas close to the unit. Fire may result.
• Do not place a gas heater or any other open-flame appliance where it will be exposed to the air discharged from the unit. Incomplete
combustion may result.
• Ventilate the room if refrigerant leaks during operation.
If the refrigerant comes in contact with a flame, poisonous gases will be released.
• Do not remove the front panel or the fan guard from the outdoor unit when it is running.You could be injured if you touch rotating, hot or
high-voltage parts.
• Never insert fingers, sticks etc. into the intakes or outlets, otherwise injury may result, since the fan inside the unit rotates at high speed.
• If you detect odd smells, stop using the unit, turn off the power switch and consult your dealer.
• This air conditioner is NOT intended for use by children or infirm persons without supervision.
• Young children should be supervised to ensure that they do not play with the air conditioner.
Caution:
• Do not use any sharp object to push the buttons, as this may damage the remote controller.
• Never block or cover the indoor or outdoor unit’s intakes or outlets.
Disposing of the unit
When you need to dispose of the unit, consult your dealer. If pipes are removed incorrectly, refrigerant (fluorocarbon gas) may blow out and come into
contact with your skin, causing injury. Releasing refrigerant into the atmosphere also damages the environment.
1. Safety Precautions

3
2.1. Description of “AUTO RESTART FUNCTION”
• This unit is equipped with the auto restart function. When the main power is
turned on, the air conditioner will start operation automatically in the same
mode as set with the remote controller before the shutoff of main power.
• If the unit was set to off with the remote controller before the shutoff of
main power, it will remain stopped even after the main power is turned on.
• If the unit was in the TEST RUN before the shutoff of main power, it will
start operation, at main power on, in the same mode as set with the
remote controller before the TEST RUN.
2.2. Wireless remote controller (How to set the batteries)
1Remove the back lid and insert batteries. Then reattach the back lid.
• Insert the minus pole of the batteries first.
• Check if the polarity of the batteries is correct.
2Press the RESET button.
• If the RESET button is not pressed, the remote controller may not oper-
ate correctly.
• Press using a thin stick.
2.3. Setting the day of the week and time
■Use this screen to change the current day of the week and time setting.
Note:
The day and time will not appear if clock use has been disabled at Function
Selection of remote controller.
2. Operation
AUTO COOL
DRY
HEAT
FAN
VANE
SELECT
TIME
1
2
Day of the Week &
Time display
˚C
˚C
TIME SUN
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
24
9
1
A
Time Setting
TIME SUN
2
3
4
Day of the Week Setting ss
ss
sHow to Set the Day of the Week and Time...
1. Press the or Set Time button Ato show display 2.
2. Press the Timer On/Off (Set Day) button 9to set the day.
* Each press advances the day shown at 3: Sun →Mon →... →Fri
→Sat.
3. Press the appropriate Set Time button Aas necessary to set the
time.
* As you hold the button down, the time (at 4) will increment first in
minute intervals, then in ten-minute intervals, and then in one-hour
intervals.
4. After making the appropriate settings at Steps 2 and 3, press the
Filter button 4to lock in the values.
Note:
Your new entries at Steps 2 and 3 will be cancelled if you press the Mode
(Return) button 2before pressing the Filter button 4.
5. Press the Mode (Return) button 2to complete the setting proce-
dure.This will return the display to the standard control screen, where
1will now show the newly set day and time.
2.4. Switching the unit on/off
•The power supply should not be turned off while the air conditioner is in
use. This can cause the unit to break down.
1Press the ON/OFF button.
BThe ON indicator should light up.
•Even if you press the ON/OFF button immediately after shutting down the
operation in progress, the air conditioner will not start for about three min-
utes. This is to prevent the internal components from being damaged.
AFor the after-mentioned operating functions of the remote controller,
all items are indicated in this illustration.
For wired remote controller
•If the operation stops due to a power failure, the unit will not automati-
cally restart until the power has been restored. Press the ON/OFF but-
ton to restart.
For wireless remote controller
Note:
The signal can travel up to approximately 7 meters (in a straight line) within 45
degrees to both right and left of the center line of the receiver.
In addition, the signal may not be received if there is interference of light of
fluorescent lights or strong sunlight.
For wireless remote controller
ON/OFF
RESET
TOO
WARM
TOO
COOL
MODE
AUTO COOL
DRY HEAT
FAN
VANE
SELECT
TIME
h
1
A
˚C
˚C
SIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
1
B
For wired remote controller

4
ON/OFF
RESET
TOO
WARM
TOO
COOL
MODE
AUTO COOL
DRY HEAT
FAN
VANE
SELECT
TIME
1
A
˚C
˚C
SIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
A
1
For wireless remote controller For wired remote controller
2. Operation
ON/OFF
RESET
TOO
WARM
TOO
COOL
MODE
AUTO COOL
DRY HEAT
FAN
VANE
SELECT
TIME
1
2
A
˚C
˚C
SIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
2
B
1
A
For wireless remote controller For wired remote controller
2.5. Mode select
1If the unit is off, press the ON/OFF button to turn it on.
For wireless remote controller
2Press the operation mode
MODE
button and select the operation mode.
Each time the operation mode
MODE
button is pressed the moves. (A)
Automatic (cooling/heating) mode
Cooling mode
Drying mode
Heating mode
For wired remote controller
2Press the operation mode ( ) button and select the operation
mode.
B
Cooling mode
Drying mode
Fan mode
Heating mode
Automatic (cooling/heating) mode
Information for multi system air conditioner (Outdoor
unit: MXZ series)
ss
ss
sMulti system air conditioner (Outdoor unit: MXZ series) can con-
nect two or more indoor units with one outdoor unit. According to
the capacity, two or more units can operate simultaneously.
•When you try to operate two or more indoor units with one outdoor unit
simultaneously, one for the cooling and the other for heating, the opera-
tion mode of the indoor unit that operates earlier is selected. The other
indoor units that will start the operation later cannot operate, indicating
an operation state.
In this case, please set all the indoor units to the same operation mode.
•There might be a case that the indoor unit, which is operating in
(AUTO) mode. Cannot change over to the operating mode (COOL ↔
HEAT) and becomes a state of standby.
•When indoor unit starts the operation while the defrosting of outdoor
unit is being done, it takes a few minutes (max. about 15 minutes) to
blow out the warm air.
•In the heating operation, though indoor unit that does not operate may
get warm or the sound of refrigerant flowing may be heard, they are not
malfunction. The reason is that the refrigerant continuously flows into it.
2.6. Selecting a temperature
ss
ss
sTo decrease the room temperature:
1Press button to set the desired temperature.
AThe selected temperature is displayed.
•Each time you press the button, the temperature value decreases by 1 °C.
ss
ss
sTo increase the room temperature:
1Press button to set the desired temperature.
AThe selected temperature is displayed.
•Each time you press the button, the temperature value increases by 1 °C.
•Available temperature ranges are as follows:
Cooling/Drying: 19 - 30 °C
Heating: 17 - 28 °C
Automatic: 19 - 28 °C
•The display flashes either 8 °C - 39 °C to inform you if the room tem-
perature is lower or higher than the displayed temperature.
s
s

5
2. Operation
▼
▼ ▼
ON/OFF
RESET
TOO
WARM
TOO
COOL
MODE
AUTO COOL
DRY HEAT
FAN
VANE
SELECT
TIME
1
A
ON/OFF
RESET
TOO
WARM
TOO
COOL
MODE
AUTO COOL
DRY HEAT
FAN
VANE
SELECT
TIME
1
A
s
˚C
˚C
SIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
A
1
For wireless remote controller For wired remote controller
For wireless remote controller For wired remote controller
˚C
˚C
SIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
F
1
2.7. Selecting a fan speed
1Press button to select a desired fan speed.
•Each time you press the button, available options change with the dis-
play Aon the remote controller, as shown below.
Fan speed Remote controller display
Low Medium High
3-stage
•Displays for the wireless remote controller are shown in parentheses.
In the following situations, the display differs from the fan speed of the unit.
•In the case of DEFROST/STAND BY lamp lighting of the unit.
•Just after the heating mode (while waiting to change to another mode).
•When the temperature of the room is higher than the temperature set-
ting of the unit operating in the heating mode.
•In drying mode, the indoor fan sometimes stops.
•When the temperature of the heat exchanger is low in the heating mode
(e.g., immediately after heating operation starts).
2.8. Adjusting vertical airflow direction
The vertical air vane helps select the vertical direction of the airflow.
1Press button to select the vertical airflow direction.
AEach time you press the button, the option changes are displayed on
the remote controller, as shown below.
For wireless remote controller
1→2→3→4→5
For wired remote controller
1Horizontal airfrow 30°4Downword airfrow 70°
2Downword airfrow 45°5Swing
3Downword airfrow 55°
•If the room temperature is higher than the temperature set on the re-
mote controller while the unit is defrosting or preparing for heating, the
vertical air vane will move to the horizontal airflow position (1).
•In either cooling or dry mode, if you select 2, 3or 4when the fan
speed is low, middle 2, a display reading “ONLY 1Hr.”Fwill appear.
After one hour, the air conditioner will switch automatically to horizontal
air mode 1and the display “ONLY 1Hr.”Fwill disappear.
For wireless remote controller
In the following situations, the display differs from the vertical airflow direc-
tion of the unit.
•In the case of DEFROST/STAND BY lamp lighting of the unit.
•When the temperature of the room is higher than the temperature set-
ting of the unit operating in the heating mode.
2.9. Using the timer
For wireless remote controller
It is convenient to set the timer when you go to bed, when you get home,
when you get up, etc.
1Select the timer mode by pressing the
SELECT
button during operation.
AEach time this button is pressed, the timer mode is changed in se-
quence:
(OFF TIMER) (ON TIMER) TIMER RELEASE
2Set the time of the timer using the
TIME
button.
BEach time this button is pressed, the set time increases by 1 hour to
12 hours.
To release the timer:
•Press the
SELECT
button until (OFF TIMER) and (ON TIMER)
are not displayed.
Note:
The OFF TIMER and the ON TIMER cannot be set at the same time.
( ) ( )
( )
51234
ON/OFF
RESET
TOO
WARM
TOO
COOL
MODE
AUTO COOL
DRY HEAT
FAN
VANE
SELECT
TIME
h
1
B
A
2
For wireless remote controller

6
Op No. Sunday Monday ··· Saturday
No. 1
No. 2
···
No. 8
•8:30
•ON
•23 °C
•10:00
•OFF
•10:00
•OFF
•10:00
•OFF
•10:00
•OFF
▲
<Operation 1 settings for
Sunday>
Start the air conditioner at
8:30, with the temperature
set to 23 °C.
<Operation 2 settings for
every day>
Turn off the air conditioner
at 10:00.
▲
˚C
SUN
ON
WEEKLY
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
2
42 3
A9 78
0
4
1
3
B
1
˚C
SUN
ON
WEEKLY
6
7
5
Shows the selected operation (ON or OFF)
* Does not appear if operation is not set.
Shows the temperature setting
* Does not appear if tempera-
ture is not set.
2. Operation
2.10. Using the timer [For wired remote controller]
This section explains how to set and use the timer. You can use Function
Selection of remote controller to select which of three types of timer to use:
1Weekly timer, 2Simple timer, or 3Auto Off timer.
For information about how to set the Function Selection of remote control-
ler, refer to section 2.13. [4]–3 (3).
2.10.1. Using the Weekly Timer
■The weekly timer can be used to set up to eight operations for each day
of the week.
•Each operation may consist of any of the following: ON/OFF time
together with a temperature setting, or ON/OFF time only, or tem-
perature setting only.
•When the current time reaches a time set at this timer, the air condi-
tioner carries out the action set by the timer.
■Time setting resolution for this timer is 1 minute.
Note:
*1. WeeklyTimer/Simple Timer/Auto OffTimer cannot be used at the same time.
*2. The weekly timer will not operate when any of the following conditions is in
effect.
The timer feature is off; the system is in an malfunction state; a test run is
in progress; the remote controller is undergoing self-check or remote con-
troller check; the user is in the process of setting a function ; the user is in
the process of setting the timer; the user is in the process of setting the
current day of the week or time; the system is under central control. (Spe-
cifically, the system will not carry out operations (unit on, unit off, or tem-
perature setting) that are prohibited during these conditions.)
ss
ss
sHow to Set the Weekly Timer
1. Be sure that you are at a standard control screen, and that the weekly
timer indicator 1is shown in the display.
2. Press the Timer Menu button B, so that the “Set Up”appears on the
screen (at 2).
(Note that each press of the button toggles the display between “Set
Up”and “Monitor”.)
3. Press the Timer On/Off (Set Day) button 9to set the day. Each press
advances the display at 3to the next setting, in the following se-
quence: “Sun Mon Tues Wed Thurs Fri Sat”→“Sun”→... →“Fri”→
“Sat”→“Sun Mon Tues Wed Thurs Fri Sat”...
4. Press the or Operation button (7or 8) as necessary to select
the appropriate operation number (1 to 8) 4.
* Your inputs at Steps 3 and 4 will select one of the cells from the
matrix illustrated below. (The remote-controller display at left shows
how the display would appear when setting Operation 1 for Sun-
day to the values indicated below.)
Setup Matrix
Note:
By setting the day to “Sun Mon Tues Wed Thurs Fri Sat”, you can set the same
operation to be carried out at the same time every day.
(Example: Operation 2 above, which is the same for all days of the week.)
ss
ss
sSetting the Weekly Timer
5. Press the appropriate Set Time button Aas necessary to set the
desired time (at 5).
* As you hold the button down, the time first increments in minute inter-
vals, then in ten-minute intervals, and then in one-hour intervals.
6. Press the ON/OFF button 1to select the desired operation (ON or
OFF), at 6.
* Each press changes the next setting, in the following sequence:
No display (no setting) →“ON”→“OFF”
7. Press the appropriate Set Temperature button 3to set the desired
temperature (at 7).
* Each press changes the setting, in the following sequence: No
display (no setting) ⇔24 ⇔25 ⇔... ⇔29 ⇔30 ⇔12 ⇔... ⇔23
⇔No display.
(Available range: The range for the setting is 12 °C to 30 °C. The
actual range over which the temperature can be controlled, how-
ever, will vary according to the type of the connected unit.)
Shows the time
setting
Operation No.
Day Setting

7
8. After making the appropriate settings at Steps 5, 6 and 7, press the
Filter button 4to lock in the values.
To clear the currently set values for the selected operation, press
and quickly release the Check (Clear) button 1once.
* The displayed time setting will change to “—:—”, and the On/Off
and temperature settings will all disappear.
(To clear all weekly timer settings at once, hold down the Check
(Clear) button 0for two seconds or more. The display will begin
flashing, indicating that all settings have been cleared.)
Note:
Your new entries will be cancelled if you press the Mode (Return) button
2before pressing the Filter button 4.
If you have set two or more different operations for exactly the same
time, only the operation with the highest Operation No. will be carried
out.
9. Repeat Steps 3 to 8 as necessary to fill as many of the available cells
as you wish.
10.Press the mode (Return) button 2to return to the standard control
screen and complete the setting procedure.
11.To activate the timer, press the Timer On/Off button 9, so that the
“Timer Off”indication disappears from the screen. Be sure that the
“Timer Off”indication is no longer displayed.
* If there are no timer settings, the “Timer Off”indication will flash on
the screen.
ss
ss
sHow to View the Weekly Timer Settings
1. Be sure that the weekly timer indicator is visible on the screen (at 1).
2. Press the Timer Menu button Bso that “Monitor”is indicated on the
screen (at 8).
3. Press the Timer On/Off (Set Day) button 9as necessary to select
the day you wish to view.
4. Press the or Operation button (7or 8) as necessary to change
the timer operation shown on the display (at 9).
* Each press will advance to the next timer operation, in order of
time setting.
5. To close the monitor and return to the standard control screen, press
the Mode (Return) button 2.
ss
ss
sTo Turn Off the Weekly Timer
Press the Timer On/Off button 9so that “Timer Off”appears at 0.
2. Operation
˚C
˚C
TIME SUN
WEEKLY
0
˚C
˚C
TIME SUN
WEEKLY
0
ONHr
AFTER
SIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
2A9
0
4
1
B
Timer Settings
˚C
TIMER
SUN
ON
OFF
WEEKLY
1
9
8
ss
ss
sTo Turn On the Weekly Timer
Press the Timer On/Off button 9so that the “Timer Off”indication (at 0)
goes dark.
2.10.2. Using the Simple Timer
■You can set the simple timer in any of three ways.
•Start time only: The air conditioner starts when the set time has
elapsed.
•Stop time only: The air conditioner stops when the set time has
elapsed.
•Start & stop times: The air conditioner starts and stops at the re-
spective elapsed times.
■The simple timer (start and stop) can be set only once within a 72-hour
period.
The time setting is made in hour increments.
Note:
*1. WeeklyTimer/Simple Timer/Auto OffTimer cannot be used at the same time.
*2. The simple timer will not operate when any of the following conditions is in
effect.
The timer is off; the system is in malfunction state; a test run is in progress;
the remote controller is undergoing self-check or remote controller check;
the user is in the process of selecting a function; the user is in the process
of setting the timer; the system is under central control. (Under these con-
ditions, On/Off operation is prohibited.)

8
TIMER ON
OFF
Hr
AFTER
SIMPLE
1
6
5
Timer Setting
˚C
˚C
SIMPLE
7
˚C
˚C
ONHr
AFTER
SIMPLE
7
2. Operation
ss
ss
sHow to Set the Simple Timer
1. Be sure that you are at a standard control screen, and that the sim-
ple timer indicator is visible in the display (at 1).
When something other than the Simple Timer is displayed, set it to
SIMPLE TIMER using the function selection of remote controller (see
2.13. [4]–3 (3)).
2. Press the Timer Menu button B, so that the “Set Up”appears on the
screen (at 2). (Note that each press of the button toggles the display
between “Set Up”and “Monitor”.)
3. Press the ON/OFF button 1to display the current ON or OFF simple
timer setting. Press the button once to display the time remaining to
ON, and then again to display the time remaining to OFF. (The ON/
OFF indication appears at 3).
•“ON”timer: The air conditioner will start operation when the
specified number of hours has elapsed.
•“OFF”timer: The air conditioner will stop operation when the
specified number of hours has elapsed.
4. With “ON”or “OFF”showing at 3: Press the appropriate Set Time
button Aas necessary to set the hours to ON (if “ON”is displayed)
or the hours to OFF (if “OFF”is displayed) at 4.
•Available Range: 1 to 72 hours
5. To set both the ON and OFF times, repeat Steps 3 and 4.
* Note that ON and OFF times cannot be set to the same value.
6. To clear the current ON or OFF setting: Display the ON or OFF set-
ting (see step 3) and then press the Check (Clear) button 0so that
the time setting clears to “—” at 4. (If you want to use only an ON
setting or only an OFF setting, be sure that the setting you do not
wish to use is shown as “—”.)
7. After completing steps 3 to 6 above, press the Filter button 4to
lock in the value.
Note:
Your new settings will be cancelled if you press the Mode (Return) button
2before pressing the Filter button 4.
8. Press the Mode (Return) button 2to return to the standard control screen.
9. Press the Timer On/Off button 9to start the timer countdown.When
the timer is running, the timer value is visible on the display. Be sure
that the timer value is visible and appropriate.
ss
ss
sViewing the Current Simple Timer Settings
1. Be sure that the simple timer indicator is visible on the screen (at 1).
2. Press the Timer Menu button B, so that the “Monitor”appears on the
screen (at 5).
•If the ON or OFF simple timer is running, the current timer value
will appear at 6.
•If ON and OFF values have both been set, the two values appear
alternately.
3. Press the Mode (Return) button 2to close the monitor display and
return to the standard control screen.
ss
ss
sTo Turn Off the Simple Timer...
Press the Timer On/Off button 9so that the timer setting no longer ap-
pears on the screen (at 7).
ss
ss
sTo Turn On the Simple Timer...
Press the Timer On/Off button 9so that the timer setting becomes visible
at 7.
ONHr
AFTER
SIMPLE
4
1
3
2
Action (On or Off)
*“— —” is displayed if there
is no setting.
Timer Setting

9
ONHr
AFTER
SIMPLE
˚C
˚C
OFF
Hr
AFTER
SIMPLE
SIMPLE
▲
▲
At 3 hours after
timer start
At Timer Start Display shows the tim-
er’s ON setting (hours
remaining to ON).
Display changes to
show the timer’s OFF
setting (hours remain-
ing to OFF). The time
displayed is OFF set-
ting (7 hours) –ON set-
ting (3 hours) = 4 hours.
At 7 hours after
timer start
The air conditioner
goes off, and will re-
main off until some-
one restarts it.
˚C
˚C
OFF
Hr
AFTER
SIMPLE
ONHr
AFTER
SIMPLE
˚C
˚C
SIMPLE
▲
▲
At 2 hours after
timer start
At Timer Start
At 5 hours after
timer start
Display shows the tim-
er’s OFF setting (hours
remaining to OFF).
Display changes to
show the timer’s ON
setting (hours remain-
ing to ON). The time
displayed is ON setting
(5 hours) –OFF setting
(2 hours) = 3 hours.
The air conditioner
comes on, and will
continue to run until
someone turns it off.
Examples
If ON and OFF times have both been set at the simple timer, operation and
display are as indicated below.
Example 1:
Start the timer, with ON time set sooner than OFF time
ON Setting: 3 hours
OFF Setting: 7 hours
2. Operation
Example 2:
Start the timer, with OFF time is sooner than ON time
ON Setting: 5 hours
OFF Setting: 2 hours
2.10.3. Using the Auto Off Timer
■This timer begins countdown when the air conditioner starts, and shuts
the air conditioner off when the set time has elapsed.
■Available settings run from 30 minutes to 4 hours, in 30-minute intervals.
Note:
*1. WeeklyTimer/Simple Timer/Auto OffTimer cannot be used at the same time.
*2. The Auto Off timer will not operate when any of the following conditions is
in effect.
The timer is off; the system is in malfunction state; a test run is in progress;
the remote controller is undergoing self-check or remote controller check;
the user is in the process of selecting a function; the user is in the process
of setting the timer; the system is under central control. (Under these con-
ditions, On/Off operation is prohibited.)
AFTER OFF
AUTO OFF
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
2A9
4
B
ss
ss
sHow to Set the Auto Off Timer
1. Be sure that you are at a standard control screen, and that the Auto
Off timer indicator is visible in the display (at 1).
When something other than the Auto Off Timer is displayed, set it to
AUTO OFF TIMER using the function selection of remote controller
(see 2.13. [4]–3 (3)).
2. Hold down the Timer Menu button Bfor 3 seconds, so that the “Set
Up”appears on the screen (at 2).
(Note that each press of the button toggles the display between “Set
Up”and “Monitor”.)
3. Press the appropriate Set Time button Aas necessary to set the
OFF time (at 3).
4. Press the Filter button 4to lock in the setting.
Note:
Your entry will be cancelled if you press the Mode (Return) button 2
before pressing the Filter button 4.
AFTER OFF
AUTO OFF
3
1
2
Timer Setting

10
˚C
˚C
FUNCTION
1
˚C
˚C
FUNCTION
1
˚C
˚C
1
˚C
˚C
TIME SUN
FUNCTION
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
4
1
1
Lock Indicator
2. Operation
5. Press the Mode (Return) button 2to complete the setting procedure
and return to the standard control screen.
6. If the air conditioner is already running, the timer starts countdown
immediately. Be sure to check that the timer setting appears cor-
rectly on the display.
ss
ss
sChecking the Current Auto Off Timer Setting
1. Be sure that the “Auto Off”is visible on the screen (at 1).
2. Hold down the Timer Menu button Bfor 3 seconds, so that “Moni-
tor”is indicated on the screen (at 4).
•The timer remaining to shutdown appears at 5.
3. To close the monitor and return to the standard control screen, press
the Mode (Return) button 2.
ss
ss
sTo Turn Off the Auto Off Timer...
●Hold down the Timer On/Off button 9for 3 seconds, so that “Timer Off”
appears (at 6) and the timer value (at 7) disappears.
●Alternatively, turn off the air conditioner itself.The timer value (at 7) will
disappear from the screen.
ss
ss
sTo Turn On the Auto Off Timer...
●Hold down the Timer On/Off button 9for 3 seconds. The “Timer Off “
indication disappears (at 6), and the timer setting comes on the display
(at 7).
●Alternatively, turn on the air conditioner. The timer value will appear at
7.
2.11. Locking the remote controller buttons (Opera-
tion function limit controller )
[For wired remote controller]
■If you wish, you can lock the remote controller buttons.You can use the
Function Selection of remote controller to select which type of lock to
use. (For information about selecting the lock type, see section 2.13.
[4]–2 (1)).
Specifically, you can use either of the following two lock types.
1Lock All Buttons:
Locks all of the buttons on the remote controller.
2Lock All Except ON/OFF:
Locks all buttons other than the ON/OFF button.
Note:
The “Locked”indicator appears on the screen to indicate that buttons are cur-
rently locked.
AFTER
TIMER
OFF
AUTO OFF
5
1
4
Timer Setting
˚C
˚C
AUTO OFF
6
7
AUTO OFF
7
˚C
˚C
AFTER OFF
AUTO OFF
6
7
ss
ss
sHow to Lock the Buttons
1. While holding down the Filter button 4, press and hold down the
ON/OFF button 1for 2 seconds.The “Locked”indication appears on
the screen (at 1), indicating that the lock is now engaged.
* If locking has been disabled in Function Selection of remote con-
troller, the screen will display the “Not Available”message when
you press the buttons as described above.
•If you press a locked button, the “Locked”indication (at 1) will blink
on the display.
ss
ss
sHow to Unlock the Buttons
1. While holding down the Filter button 4, press and hold down the
ON/OFF button 1for 2 seconds—so that the “Locked”indication
disappears from the screen (at 1).

11
ON/OFF
TEMP.
˚C
˚C
ON/OFF
TEMP.
˚C
˚C
ON/OFF
TEMP.
˚C
˚C
FILTER
2.12. Other indications [For wired remote controller]
2.12.1. Centrally Controlled
●Displayed when operation is controlled by central controller, etc.
Restricted operations are shown below.
•ON/OFF (including timer operation)
•Operation mode
•Set temperature
Note:
May also be individually restricted.
2.12.2. Flashing Mode Indicator
■When flashes continuously
Displayed when another indoor unit connected to the outdoor unit is
already operating in a different operation mode.
Match with the operation mode of the other indoor unit.
■When mode switched after display flashes
Displayed when operation mode is restricted for each season by central
controller, etc.
Use another operation mode.
2.12.3. Flashing “Filter”
■Indicates that the filter needs cleaning.
Clean the filter.
■When resetting “FILTER”display
When the [FILTER] button is pressed two times successively after clean-
ing the filter, the display goes off and is reset.
Note:
●When two or more different types of indoor unit are controlled, the cleaning
period differs with the type of filter. When the master unit cleaning period
arrives, “FILTER”is displayed. When the filter display goes off, the cumula-
tive time is reset.
●“FILTER”indicates the cleaning period when the air conditioner was used
under general indoor air conditions by criteria time. Since the degree of dirti-
ness depends on the environmental conditions, clean the filter accordingly.
●The filter cleaning period cumulative time differs with the model.
2.12.4. Flashing Error Codes
●If the ON lamp and error code are both flashing: This means that the air
conditioner is out of order and operation has been stopped (and cannot
resume). Take note of the indicated unit number and error code, then
switch off the power to the air conditioner and call your dealer or servicer.
ON/OFF
ERROR CODE
If you have entered contact number to be called in the event of a prob-
lem, the screen displays this number. (You can set this up under Func-
tion Selection of remote controller. For information, refer to section 2.13.)
Indoor Unit’s
Refrigerant
Address
Error Code Indoor Unit No.
Alternating
Display
ON/OFF
˚C
˚C
ERROR CODE
ON/OFF
CALL:XXXX
XXX:XXX
Error Code
When the Check button is pressed:
ON lamp
(Flashing)
●If only the error code is flashing (while the ON lamp remains lit): Opera-
tion is continuing, but there may be a problem with the system. In this
case, you should note down the error code and then call your dealer or
servicer for advice.
* If you have entered contact number to be called in the event of a
problem, push the Check button to display it on the screen. (You can
set this up under Function Selection of remote controller. For infor-
mation, refer to section 2.13.)
2. Operation

12
→
Item 1
1. Change Language
(“CHANGE LANGUAGE”)
2. Function limit
(“FUNCTION SELEC-
TION”)
3. Mode selection
(“MODE SELECTION”)
4. Display change
(“DISP MODE SETTING”)
Item 2
Language setting to display
(1) Operation function limit setting (operation lock)
(“LOCKING FUNCTION”)
(2) Use of automatic mode setting (“SELECT AUTO
MODE”)
(3) Temperature range limit setting (“LIMIT TEMP
FUNCTION”)
(1) Remote controller main/sub setting (“CON-
TROLLER MAIN/SUB”)
(2) Use of clock setting (“CLOCK”)
(3) Timer function setting (“WEEKLY TIMER”)
(4) Contact number setting for error situation
(“CALL.”)
(1) Temperature display °C/°F setting (“TEMP
MODE °C/°F”)
(2) Suction air temperature display setting (“ROOM
TEMP DISP SELECT”)
(3) Automatic cooling/heating display setting
(“AUTO MODE DISP C/H”)
Item 3 (Setting content)
•Display in multiple languages is possible.
•Setting the range of operation limit (operation lock)
•Setting the use or non-use of “automatic”operation mode
•Setting the temperature adjustable range (maximum, minimum)
•Selecting main or sub remote controller
* When two remote controllers are connected to one group, one
controller must be set to sub.
•Setting the use or non-use of clock function
•Setting the timer type
•Contact number display in case of error
•Setting the telephone number
•Setting the temperature unit (°C or °F) to display
•Setting the use or non-use of the display of indoor (suction) air
temperature
•Setting the use or non-use of the display of “Cooling”or “Heat-
ing”display during operation with automatic mode
2. Operation
2.13. Function selection of remote controller [For wired remote controller]
The setting of the following remote controller functions can be changed using the remote controller function selection mode. Change the setting when
needed.
2.13.1. Function selection flowchart
[1] Stop the air conditioner to start remote controller function selection mode. → [2] Select from item 1. → [3] Select from item 2. → [4] Make the setting. (Details are specified
in item 3) → [5] Setting completed. → [6] Change the display to the normal one. (End)
(Hold down the Ebutton and press the Dbutton for two
seconds.)
* The display cannot be changed during the unit function
selection, the test run and the self diagnosis.
(Hold down the Ebutton and press
the Dbutton for two seconds.)
* The remote controller records the
setting that is made in this way.
Press the
Gbutton.
See [4]–1
Item 3
(Setting content)
See [4]–2. (1)
See [4]–2. (2)
See [4]–2. (3)
See [4]–3. (1)
See [4]–3. (2)
See [4]–3. (3)
See [4]–3. (4)
See [4]–4. (1)
See [4]–4. (2)
See [4]–4. (3)
Item 1 Remote Controller Function Se-
lection Mode
Item 2
Mode selection
(“MODE
SELECTION”)
Normal display (Display when
the air condition is not running)
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
F
G
CD
B
I
A
H
E
Change Language
(“CHANGE LANGUAGE”)
Function limit
(“FUNCTION
SELECTION”)
Display change
(“DISP MODE
SETTING”)
NOTE
Timer operation stops when the display for
remote controller function selection is
changed to the normal one.
Press the Gbutton.
Press the
Ebutton.
Press the
Ebutton.
Press the
Ebutton.
Press the
Ebutton.
Press the
Gbutton.
Press the
Gbutton.
Press the
Dbutton.
Press the
Dbutton.
Press the
Dbutton.
→→→→→
→
→
Operation function limit setting (“LOCKING FUNCTION”)
Press the Gbutton.
Temperature range limit setting (“LIMIT TEMP FUNCTION”)
Use of automatic mode setting (“SELECT AUTO MODE”)
→
Temperature display °C/°F setting (“TEMP MODE °C/°F”)
Press the Gbutton.
Automatic cooling/heating display setting (“AUTO MODE DISP C/H”)
Suction air temperature display setting (“ROOM TEMP DISP SELECT”)
→
Remote controller main/sub setting (“CONTROLLER MAIN/SUB”)
Press the Gbutton.
Timer function setting (“WEEKLY TIMER”)
Use of clock setting (“CLOCK”)
Contact number setting for error situation (“CALL.”)
Dot display
The language that is selected in
CHANGE LANGUAGE mode ap-
pears on this display. English is
set in this manual.

13
2. Operation
2.13.2. Detailed setting
[4]–1. CHANGE LANGUAGE setting
The language that appears on the dot display can be selected.
•Press the [ MENU] button G to change the language.
1Japanese (JP), 2English (GB), 3German (D), 4Spanish (E), 5Russian (RU), 6Italian (I), 7Chinese (CH), 8French (F)
[4]–2. Function limit
(1) Operation function limit setting (operation lock)
•To switch the setting, press the [ ON/OFF] button D.
1no1 : Operation lock setting is made on all buttons other than the [ ON/OFF] button.
2no2 : Operation lock setting is made on all buttons.
3OFF (Initial setting value) : Operation lock setting is not made.
* To make the operation lock setting valid on the normal screen, it is necessary to press buttons (Press and hold down the [FILTER] and [ ON/
OFF] buttons at the same time for two seconds.) on the normal screen after the above setting is made.
(2) Use of automatic mode setting
When the remote controller is connected to the unit that has automatic operation mode, the following settings can be made.
•To switch the setting, press the [ ON/OFF] button D.
1ON (Initial setting value) : The automatic mode is displayed when the operation mode is selected.
2OFF : The automatic mode is not displayed when the operation mode is selected.
(3) Temperature range limit setting
After this setting is made, the temperature can be changed within the set range.
•To switch the setting, press the [ ON/OFF] button D.
1LIMIT TEMP COOL MODE :
The temperature range can be changed on cooling/dry mode.
2LIMIT TEMP HEAT MODE :
The temperature range can be changed on heating mode.
3LIMIT TEMP AUTO MODE :
The temperature range can be changed on automatic mode.
4OFF (initial setting) : The temperature range limit is not active.
* When the setting, other than OFF, is made, the temperature range limit setting on cooling, heating and automatic mode is made at the same time.
However, the range cannot be limited when the set temperature range has not changed.
•To increase or decrease the temperature, press the [ TEMP. ( ) or ( )] button F.
•To switch the upper limit setting and the lower limit setting, press the [ ] button H. The selected setting will flash and the temperature can be
set.
•Settable range
Cooling/Dry mode: Lower limit: 19°C ~ 30°C Upper limit: 30°C ~ 19°C
Heating mode: Lower limit: 17°C ~ 28°C Upper limit: 28°C ~ 17°C
Automatic mode: Lower limit: 19°C ~ 28°C Upper limit: 28°C ~ 19°C
* The settable range varies depending on the unit to connect (Mr. Slim units, CITY MULTI units, and intermediate temperature units)
[4]–3. Mode selection setting
(1) Remote controller main/sub setting
•To switch the setting, press the [ ON/OFF] button D.
1Main : The controller will be the main controller.
2Sub : The controller will be the sub controller.
(2) Use of clock setting
•To switch the setting, press the [ ON/OFF] button D.
1ON : The clock function can be used.
2OFF : The clock function cannot be used.
(3) Timer function setting
•To switch the setting, press the [ ON/OFF] button D(Choose one of the followings.).
1WEEKLY TIMER (initial setting on MA deluxe) : The weekly timer can be used.
2AUTO OFF TIMER : The auto off timer can be used.
3SIMPLE TIMER (Default setting on MA smooth) : The simple timer can be used.
4TIMER MODE OFF : The timer mode cannot be used.
* When the use of clock setting is OFF, the “WEEKLY TIMER”cannot be used.
(4) Contact number setting for error situation
•To switch the setting, press the [ ON/OFF] button D.
1CALL OFF : The set contact numbers are not displayed in case of error D.
2CALL **** *** ****: The set contact numbers are displayed in case of error.
CALL_ : The contact number can be set when the display is as shown on the left.
•Setting the contact numbers
To set the contact numbers, follow the following procedures.
Move the flashing cursor to set numbers. Press the [ TEMP. ( ) and ( )] button Fto move the cursor to the right (left). Press the [ CLOCK
() and ( )] button Cto set the numbers.

14
B
A
D
C
Caution:
•Always turn off the power, first on the remote controller and then
the main switch, before cleaning or servicing the unit.
•When installing or removing the filter or the intake grille, do not
stand on an unsteady surface.You may fall and injure yourself. Be
also careful not to let dust fall into your eyes.
Dirty or clogged filters block the airflow and reduce efficiency. Very dirty
filters can damage the air-conditioner itself.
Intake grille removal
1Pull the catch on the intake grille in the direction indicated by the arrow
and it should open.
2Unhook the hinges to remove the intake grille from the grille.
Filter removal
1Open the intake grille.
2Release the catch on the center edge of the intake grille and pull the
filter forward to remove the filter.
ACatch BGrille CIntake grille DFilter
2. Operation
[4]–4. Display change setting
(1) Temperature display °C/°F setting
•To switch the setting, press the [ ON/OFF] button D.
1°C : The temperature unit °C is used.
2°F : The temperature unit °F is used.
(2) Suction air temperature display setting
•To switch the setting, press the [ ON/OFF] button D.
1ON : The suction air temperature is displayed.
2OFF : The suction air temperature is not displayed.
(3) Automatic cooling/heating display setting
•To switch the setting, press the [ ON/OFF] button D.
1ON : One of “Automatic cooling”and “Automatic heating”is displayed under the automatic mode is running.
2OFF : Only “Automatic”is displayed under the automatic mode.
2.14. Emergency operation
[For wireless remote controller]
When the remote controller cannot be used
When the batteries of the remote controller run out or the remote controller
malfunctions, the emergency operation can be done using the emergency
buttons on the grille.
ADEFROST/STAND BY lamp
BOperation lamp
CEmergency operation switch (heating)
DEmergency operation switch (cooling)
EReceiver
Starting operation
•To operate the cooling mode, press the button D.
•To operate the heating mode, press the button C.
Note:
•Details of emergency mode are as shown below.
Details of EMERGENCY MODE are as shown below.
Operation mode COOL HEAT
Set temperature 24°C24°C
Fan speed High High
Airflow direction Horizontal 30°Downward 70°
Stopping operation
•To stop operation, press the button Dor the button C.
A B C D E
SLP-2AL (For SLZ-KA25/KA35/KA50VAL)
3. Care and cleaning

15
3.1. Cleaning the filters and the indoor unit
Cleaning the filter
•Clean the filter using a vacuum cleaner. If you do not have a vacuum
cleaner, tap the filter against a solid object to knock off dirt and dust.
•If the filter is especially dirty, wash it in lukewarm water. Take care to
rinse off any detergent thoroughly and allow the filter to dry completely
before putting it back into the unit.
Caution:
•Do not dry the filter in direct sunlight or by using a heat source,
such as an electric heater: this may warp it.
•Do not wash the filter in hot water (above 50°C), as this may warp
them.
•Make sure that the air filter is always installed. Operating the unit
without air filter can cause malfunction.
Cleaning the indoor unit
•Wipe the outside of the unit with a clean, dry, soft cloth.
•Clean off any oil stains or finger marks using a neutral household deter-
gent (such as dishwashing liquid or laundry detergent).
Caution:
Never use gasoline, benzene, thinner, scouring powder or any type of
non-neutral detergent, as these substances may damage the unit’s
case.
Before you call out a repair man, check the following table to see whether there is a simple solution to your problem.
[for wireless remote controller]
Problem
Unit does not operate at all.
No indication of wireless remote con-
troller, indication is dim, or signal
transmission cannot reach remote
controller sensor.
Problem
Unit does not start immediately.
The operating display of the wireless
remote controller’s receiver is flash-
ing.
Solution
Wait until the unit restarts automati-
cally. The compressor may hesitate
resuming because a three-minute
resume prevention circuit is incorpo-
rated in the outdoor unit for protec-
tion of the compressor.
A self-diagnostic function is being
performed to preserve the air condi-
tioner.
* Do not attempt to make repairs
yourself. Turn the main switch off
and contact the dealer from whom
you bought the air conditioner. Pro-
vide him or her with the name of
the unit and the information dis-
played in the remote controller.
Solution
Turn main power on. Then press the
POWER ON/OFF button to turn the
unit on.
Wait until power is restored, then
press the POWER ON/OFF button
to turn the unit on.
The batteries have run out.
Replace the batteries with new ones
(size AAA), and then press the reset
button. Though both alkaline batter-
ies and manganese batteries can be
used, alkaline batteries are recom-
mended because their service life is
longer than that of manganese bat-
teries.
* If indication is not detected even
when new batteries have been re-
placed, check that the batteries
have been installed properly.
4. Troubleshooting
3. Care and cleaning

16
Installation place
Avoid installing the air conditioner in the following places.
•Where flammable gas could leak.
Caution:
Do not install the unit where flammable gas could leak.
If gas leaks and collects around the unit, it may cause an explosion.
•Where there is much machine oil.
•Salty place such as the seaside.
•Where sulfide gas is generated such as a hot spring.
•Where there is oil splashing or much oily smoke.
Warning:
If the air conditioner operates but does not cool or heat (depending
on model) the room, consult your dealer since there may be a refrig-
erant leak. Be sure to ask the service representative whether there is
refrigerant leakage or not when repairs are carried out.
The refrigerant charged in the air conditioner is safe. Refrigerant nor-
mally does not leak, however, if refrigerant gas leaks indoors, and
comes into contact with the fire of a fan heater, space heater, stove,
etc., harmful substances will be generated.
Inverter type
fluorescent lamp
To prevent the effect
of a fluorescent lamp,
keep it away as far
apart as possible.
To prevent picture
distortion or
noise, keep 1 m
or more apart.
TV
Radio
100 mm or more
400 mm or more
Well-
ventilated dry
place
Wall, etc.
5. Installation, relocation and inspection
Problem
Unit does not cool or heat very well.
The unit stops operating before ar-
riving at the set temperature in the
heating mode.
The airflow direction suddenly
changes.
A white mist is expelled from the in-
door unit.
The indicators of the remote control-
ler do not light up when operated.
Problem
CENTRALLY CONTROLLED is dis-
played in the remote controller.
The start and stop functions are not
available just after restarting the unit.
“PLEASE WAIT”is displayed in the
remote controller.
An error code is displayed in the re-
mote controller.
Solution
The start and stop functions of the
remote controller are not available
when the CENTRALLY CONTROL-
LED message is lit.
Wait about three minutes (operation
has stopped to prevent damage to
the air conditioner).
An automatic startup test is being
performed (will last for about two min-
utes).
A self-diagnostic function is being
performed to preserve the air condi-
tioner.
* Do not attempt to make repairs
yourself. Turn the main switch off
and contact the dealer from whom
you bought the air conditioner. Pro-
vide him or her with the name of
the unit and the information dis-
played in the remote controller.
Solution
Clean the filter.
Frost forms when the outdoor tem-
perature is low and humidity is high.
Wait for about 10 minutes for the
frost to melt.
After one hour of cooling-mode op-
eration with the airflow in a down-
ward direction, the unit will automati-
cally change to the “Horizontal air-
flow”mode.
When the unit is in the heating or de-
frosting mode, it will automatically
change to the “Horizontal airflow
mode”.
This may occur just after the unit is
turned on when a high level of hu-
midity is present in the room.
Turn on the power switch. “”will
be displayed.
[for wired remote controller]
If none of the above apply, turn the main switch off and contact the dealer from whom you bought the air-conditioner, telling him the model name and the
nature of the problem. Do not try to fix the unit yourself.
In any of the following cases, turn off the main power switch and contact your local dealer for service:
•The operation lamp (on the main unit or the remote controller) flashes.
•The switches do not work properly.
•The circuit breaker trips frequently (or the fuse blows frequently).
•Water has accidentally been splashed into the unit.
•Water leaks from the unit.
•Something is accidentally dropped into the air-conditioner.
•An unusual noise is heard during operation.
The following do not indicate any malfunction:
Odours: smells such as tobacco or cosmetic odours may persist after they have been sucked into the unit.
Sound of liquid flowing inside indoor unit: this can occur during or after operation and is simply the sound of refrigerant being circulated inside the unit.
Ticking sound coming from indoor unit: this can occur when cooling or heating has just begun or has just stopped. It is caused by the indoor unit shrinking
or expanding slightly due to the change in temperature.
The message “CENTRALLY CONTROLLED”appearing on the LCD panel: from time to time, this message may come up on the LCD panel. This does
not indicate any malfunction.
4. Troubleshooting

17
Electrical work
•Provide an exclusive circuit for power supply of the air conditioner.
•Be sure to observe the breaker capacity.
Warning:
•The customer should not install this unit. If the unit is installed incorrectly, fire, electric shock, injury due to a falling unit, water leakage, etc.
may result.
•Do not connect using branched outlet or an extension cord, and do not attach many loads to one electric outlet.
A fire or electric shock may result from poor contact, poor insulation, exceeding the permissible current, etc.
Consult your dealer.
Caution:
•Apply grounding
Do not connect a grounding wire to a gas pipe, water pipe, lightning rod or ground wire of a telephone.
If a grounding is incorrect, it may cause an electric shock.
•Install an earth leakage breaker depending on the place where the air conditioner is to be installed (humid place, etc.).
If the earth leakage breaker is not installed, it may cause an electric shock.
Inspection and maintenance
•When the air conditioner is used for several seasons, the capacity may be lowered due to dirt inside the unit.
•Depending upon the conditions of use, an odor may be generated or dirt, dust, etc. may prevent proper drainage.
•It is recommended to apply inspection and maintenance (charged) by a specialist in addition to normal maintenance. Consult your dealer.
Also consider operation sound
•Do not put an object around the air outlet of the outdoor unit. It may cause lowering of capacity or increase operating sound.
•If abnormal sound is heard during operation, consult your dealer.
Relocation
•When the air conditioner is to be removed or reinstalled because of rebuilding, moving, etc., special techniques and work are required.
Warning:
Repair or relocation should not be done by the customer.
If this is done incorrectly, it may cause a fire, electric shock, injury by dropping of the unit, water leakage, etc. Consult your dealer.
Disposal
•To dispose of this product, consult your dealer.
If you have any question, consult your dealer.
Model
Function
Power supply
Capacity kW
BTU/h
Input kW
Indoor unit
Airflow (Lo-Me-Hi) CMM
Noise level (Lo-Me-Hi) dB
Weight kg
Outdoor unit
Noise level dB
Refrigerant R410A kg
Weight kg
SLZ-KA25VA (L)
Cooling Heating
2.5 3.0
8,500 10,200
0.69 0.83
SLZ-KA25VA (L)
8-9-10
28-31-37
16.5 + Grille 3
SUZ-KA25VA
46
0.90
33
SLZ-KA35VA (L)
Cooling Heating
~/N, 230V, 50Hz
3.5 4.0
11,900 13,600
1.06 1.10
SLZ-KA35VA (L)
8-9-11
29-33-38
16.5 + Grille 3
SUZ-KA35VA
48
1.05
35
SLZ-KA50VA (L)
Cooling Heating
4.6 5.0
15,700 17,100
1.63 1.55
SLZ-KA50VA (L)
8-9-11
30-34-39
16.5 + Grille 3
SUZ-KA50VA
55
1.6
53
Notes: 1. Rating conditions (cooling) Indoor : 27°C DB, 19°C WB Outdoor : 35°C DB
2. Rating conditions (heating) Indoor : 20°C DB Outdoor : 7°C DB, 6°C WB
3. Specifications subject to change without notice.
Guaranteed operating range
Indoor Outdoor
KA25, KA35 KA50
Cooling Upper limit 32°C DB, 23°C WB 46°C DB, –43°C DB, –
Lower limit 21°C DB, 15°C WB -10°C DB, –
Heating Upper limit 27°C DB 24°C DB, 18°C WB
Lower limit 20°C DB -10°C DB, -11°C WB
Units should be installed by licensed electric contractor accordingly to local code requirement.
6. Specifications
5. Installation, relocation and inspection

82
1. Misure di sicurezza ................................................................................................................................................................... 82
2. Funzionamento ......................................................................................................................................................................... 83
3. Cura e pulizia ............................................................................................................................................................................ 94
4. Ricerca dei guasti ..................................................................................................................................................................... 95
5. Installazione, spostamento e controllo ...................................................................................................................................... 96
6. Specifiche tecniche ................................................................................................................................................................... 97
Indice
sLeggere attentamente la sezione “Misure di sicurezza” prima di far funzionare l’unità.
sLa sezione “Misure di sicurezza” contiene informazioni importanti sulla sicurezza di funzionamento dell’unità. Accertarsi che vengano seguite perfetta-
mente.
sPrima di collegare l’equipaggiamento alla rete di alimentazione, contattare o chiedere l’autorizzazione dell’autorità competente.
Simboli utilizzati nel testo
Avvertenza:
Descrive le precauzioni da prendere per evitare il rischio di lesioni, anche mortali, per l’utente.
Cautela:
Descrive le precauzioni da prendere per evitare il danneggiamento dell’unità.
Simboli utilizzati nelle illustrazioni
: Indica un’azione da evitare.
: Indica la necessità di rispettare un’istruzione importante.
: Indica la necessità di collegare un componente a massa.
: Indica che occorre operare con grande cautela con le parti rotanti.
: Indica che l’interruttore principale deve essere disattivato prima di effettuare la manutenzione.
: Attenzione alle scosse elettriche.
: Attenzione alle superfici roventi.
Avvertenza:
Leggere attentamente le etichette attaccate all’unità principale.
Avvertenza:
• L’unità non deve essere installata dall’utente. Richiedere al distributore o ad una società autorizzata di installare l’unità. Se l’unità non è installata correttamen-
te, vi è il rischio di perdite d’acqua, di scosse elettriche o di incendio.
• Non salire e non appoggiare alcun oggetto sull’unità.
• Non spruzzare acqua sull’unità e non toccarla con le mani bagnate. Ciò può provocare una scossa elettrica.
• Non spruzzare gas combustibile nei pressi dell’unità, per evitare il rischio di un incendio.
• Non piazzare un riscaldatore a gas o qualsiasi altro apparecchio a fiamma aperta in un luogo esposto all’aria scaricata dall’unità. Ciò può essere alla base di
una combustione incompleta.
• In caso di perdite di refrigerante durante il funzionamento, ventilare la stanza.
Se il refrigerante viene a contatto con fiamme vengono esalati gas tossici.
• Non rimuovere il pannello anteriore o la griglia di protezione del ventilatore dalla sezione esterna durante il funzionamento dell’unità. Un eventuale contatto con
le parti rotanti, roventi o ad alta tensione può infatti causare conseguenze gravi.
• Non inserire le dita, oggetti appuntiti, ecc..., nei fori di entrata o di uscita dell’unità per evitare di ferirsi, in quanto il ventilatore all’interno dell’unità ruota ad alta
velocità.
• In presenza di odori particolari, arrestare il funzionamento dell’unità, spegnere l’interruttore di alimentazione e contattare il proprio distributore.
• Il climatizzatore NON può essere usato da bambini o persone inferme senza la sorveglianza appropriata.
• È opportuno sorvegliare i bambini piccoli affinché non giochino con il climatizzatore.
Cautela:
• Non usare alcun oggetto appuntito per premere i pulsanti, in modo da non danneggiare il comando a distanza.
• Non bloccare o coprire gli ingressi o le uscite interni od esterni dell’unità.
Eliminazione dell’unità
Se occorre eliminare l’unità, contattare il proprio distributore. Nel caso in cui i tubi siano rimossi in modo non corretto, il refrigerante (gas fluorocarburo) può infatti fuoruscire
e venire a contatto della pelle, con conseguenze gravi. Il rilascio di refrigerante nell’atmosfera è inoltre dannoso per l’ambiente.
1. Misure di sicurezza

83
AUTO COOL
DRY
HEAT
FAN
VANE
SELECT
TIME
ON/OFF
RESET
TOO
WARM
TOO
COOL
MODE
AUTO COOL
DRY HEAT
FAN
VANE
SELECT
TIME
h
1
A
˚C
˚CSIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
1
B
Per il regolatore a distanza senza fili Per il regolatore a distanza con fili
1
2
2.1. Descrizione della“FUNZIONE DI RIAVVIO AUTOMATICO”
•Questa unitàèdotata della funzione di riavvio automatico. Quando l’interruttore
generale dell’unitàèstato acceso, il condizionatore d’aria cominceràa funzionare
nella stessa modalitàdi funzionamento impostata con il telecomando prima del-
l’interruzione di corrente.
•Se l’unitàèstata disattivata con il telecomando prima dell’interruzione di corrente,
non riprenderàa funzionare automaticamente con il ritorno della corrente.
•Se l’unitàera in mode di prova di funzionamento prima dell’interruzione di corren-
te, riprenderàa funzionare nella stessa modalitàdi funzionamento impostata con
il telecomando prima del mode di prova di funzionamento.
2.2. Regolatore a distanza senza fili (Installazione delle batterie)
1Rimuovere lo sportellino posteriore e inserire le batterie. Ricollocare quindi lo
sportellino.
•Inserire per prima l’estremitàcon il polo negativo.
•Controllare se la polaritàdelle batterie ècorretta.
2Premere il tasto RESET.
•Se esso non viene premuto, il telecomando puònon funzionare correttamente.
•Premerlo con un oggetto appuntito.
2.3. Impostazione del giorno della settimana e dell’ora
■Usare questa schermata per modificare il giorno corrente della settimana e
l’impostazione dell’ora.
Nota:
Il giorno e l’ora non saranno visualizzati se in Selezione funzioni èstato
disattivato l’uso dell’orologio.
2. Funzionamento
ss
ss
sCome impostare il giorno della settimana e l’ora…
1. Premere il pulsante “Set Time”o Aper visualizzare il display 2.
2. Premere il pulsante “Timer On/Off”(Set Day) 9per impostare il giorno.
* Ad ogni pressione del pulsante si passa al giorno successivo a quello vi-
sualizzato in 3: Dom →Lun →... →Ven →Sab
3. Premere il pulsante “Set Time”appropriato Aper regolare l’ora nel modo de-
siderato.
* Tenendo premuto il pulsante, l’ora (v. 4) aumenteràprima ad intervalli di un
minuto, poi ad intervalli di dieci minuti, e quindi ad intervalli di un’ora.
4. Dopo aver effettuato le impostazioni appropriate ai passaggi 2 e 3 premere il
pulsante 4“Filter”per confermare i valori.
Nota:
I nuovi valori immessi nei passaggi 2 e 3 saranno cancellati se si preme
il pulsante “Mode”(Return) 2prima di premere il pulsante 4“Filter”.
5. Premere il pulsante 2“Mode”(Return) per completare la procedura di
impostazione. Premendo questo pulsante il display visualizzerànuovamente
la schermata di controllo standard; in 1saranno visualizzati il giorno e l’ora
appena impostati.
2.4. Accensione/spegnimento dell’unità
•Evitare di interrompere l’alimentazione del condizionatore quando questo sta fun-
zionando, per non danneggiarlo.
1Premere il pulsante ON/OFF.
BLa spia di accensione si illumina.
•Anche se viene premuto il pulsante ON/OFF immediatamente dopo lo spegni-
mento dell’unità, il condizionatore non si avvieràdurante tre minuti. Ciòserve ad
evitare che i componenti interni rimangano danneggiati.
APer le funzioni operative del telecomando menzionate qui di seguito, tutti gli
elementi sono indicati in questa illustrazione.
Per il regolatore a distanza con fili
•Se il funzionamento del condizionatore viene arrestato a seguito di un’interruzio-
ne di corrente, l’unitàverràriavviata automaticamente solo al ripristino della cor-
rente. Premere il pulsante ON/OFF per riavviare l’unità.
Per il regolatore a distanza senza fili
Nota:
Il segnale puòpercorrere circa 7 metri al massimo (in linea retta) entro 45 gradi
a destra e a sinistra dell’asse del ricevitore.
Inoltre non èpossibile ricevere il segnale se vi èun’interferenza luminosa da
parte di luci fluorescenti o luce solare intensa.
Display Giorno della
settimana e ora
˚C
˚C
TIME SUN
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
24
9
1
A
Impostazione dell’ora
TIME SUN
2
3
4
Impostazione del giorno della
settimana

84
ON/OFF
RESET
TOO
WARM
TOO
COOL
MODE
AUTO COOL
DRY HEAT
FAN
VANE
SELECT
TIME
1
A
˚C
˚CSIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
A
1
Per il regolatore a distanza senza fili Per il regolatore a distanza con fili
2. Funzionamento
s
s
2.5. Selezione della modalità
1Se l’unitàèspenta, premere il pulsante ON/OFF per accenderla.
Per il regolatore a distanza senza fili
2Premere il pulsante della modalitàdi funzionamento
MODE
e selezionare la modalità
desiderata.
Ogni volta che si preme il
MODE
tasto modalitàoperativa, si sposta. (A)
Modalitàautomatica (raffreddamento/riscaldamento)
Modalitàdi raffreddamento
Modalitàdi deumidificazione
Modalitàdi riscaldamento
Per il regolatore a distanza con fili
2Premere il pulsante della modalitàdi funzionamento ( ) e selezionare
la modalitàdesiderata.
B
Modalitàdi raffreddamento
Modalitàdi deumidificazione
Modalitàdi ventilazione
Modalitàdi riscaldamento
Modalitàautomatica (raffreddamento/riscaldamento)
Informazioni relative al condizionatore dell’aria multi system
(Sezione esterna: serie MXZ)
ss
ss
sCondizionatore dell’aria Multi System (sezione esterna: serie MXZ) puòcol-
legare piùdi due unitàad una singola sezione esterna. Conformemente alla
capacità, èpossibile far funzionare simultaneamente piùdi due sezioni in-
terne.
•Quando si cerca di far funzionare piùdi due sezioni interne simultaneamente ad
una singola sezione esterna, una per il raffreddamento e l’altra per il riscaldamen-
to, viene selezionata la modalitàdi funzionamento della sezione interna che fun-
ziona per prima. L’altra sezione interna che inizieràa funzionare successivamen-
te, arresteràil suo funzionamento e verràindicato il messaggio.
In questo caso, si prega di impostare tutte le sezioni interne nella stessa modalità
di funzionamento.
•Quando l’unitàinterna funziona in modalità(AUTO), puòaccadere che non
riesca a passare alla modalitàdi funzionamento (RAFFREDDAMENTO ↔RISCAL-
DAMENTO); in questo caso l’unitàentreràin stato di attesa (standby).
•Quando la sezione interna inizia a funzionare una volta completata la fase di
sbrinamento della sezione esterna, ci vorranno alcuni minuti (max.circa 15 minuti)
prima che venga soffiata aria calda.
•In modalitàriscaldamento, se la parte superiore della sezione interna diventa cal-
da o viene percepito il rumore causato dal flusso di gas, non si èin presenza, nei
due casi, di un malfunzionamento. Il motivo èda ricercarsi nel fatto che il gas
refrigerante scorre continuamente all’interno della sezione interna anche questa
non sta funzionando.
2.6. Impostazione della temperatura
ss
ss
sPer abbassare la temperatura della stanza:
1Premere il pulsante per impostare la temperatura desiderata.
AVerràvisualizzata la temperatura selezionata.
•Ogni volta che si preme il pulsante, la temperatura diminuisce di 1 °C.
ss
ss
sPer aumentare la temperatura della stanza:
1Premere il pulsante per impostare la temperatura desiderata.
AVerràvisualizzata la temperatura selezionata.
•Ogni volta che si preme il pulsante, la temperatura aumenta di 1 °C.
•I campi di valori della temperatura disponibili sono:
Raffreddamento/Deumidificazione: 19 - 30 °C
Riscaldamento: 17 - 28 °C
Automatico: 19 - 28 °C
•Sul display lampeggia sia 8 °C - 39 °C per informarvi se la temperatura della
stanza èinferiore o superiore a quella visualizzata.
ON/OFF
RESET
TOO
WARM
TOO
COOL
MODE
AUTO COOL
DRY HEAT
FAN
VANE
SELECT
TIME
1
2
A
˚C
˚CSIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
2
B
1
A
Per il regolatore a distanza senza fili Per il regolatore a distanza con fili
