Mitsubishi Electric LDT462V User manual

46" LCD Display Monitor
MODEL

English-1
English
Index
Features ............................................................................................................................................................................................... English-2
Important Information........................................................................................................................................................................... English-3
Declaration............................................................................................................................................................................................ English-5
Safety Precautions, Maintenance & Recommended Use ................................................................................................................... English-6
Contents ............................................................................................................................................................................................... English-7
Parts Name and Functions................................................................................................................................................................... English-8
Buttons, Switch, and Indicator.............................................................................................................................................. English-8
Connectors and Terminals .................................................................................................................................................... English-9
Wireless Remote Control ...................................................................................................................................................... English-10
How to Use the Wireless Remote Control ............................................................................................................................ English-11
Preparation for use ............................................................................................................................................................................... English-12
Flow of preparation ............................................................................................................................................................... English-12
[P-1] Preparation for installation........................................................................................................................................................ English-13
Determine the installation location........................................................................................................................................ English-13
Ventilation requirements for enclosure mounting................................................................................................................. English-13
To avoid the monitor from falling........................................................................................................................................... English-13
[P-2] Installing the monitor................................................................................................................................................................. English-14
Installing and removing the stands ....................................................................................................................................... English-14
Using the wall mount or ceiling mount.................................................................................................................................. English-14
Installing in the portrait position ........................................................................................................................................... English-15
Installing the main power switch cover................................................................................................................................. English-15
[P-3] Installing the external speakers ................................................................................................................................................ English-16
[P-4] Connection procedure .............................................................................................................................................................. English-17
Wiring diagram ...................................................................................................................................................................... English-17
Prevention of disconnection of HDMI cable ......................................................................................................................... English-17
Connecting with a computer (analog connection)................................................................................................................ English-18
Connecting with a computer (digital connection)................................................................................................................. English-19
Connecting a video device (component video/HDMI device).............................................................................................. English-20
Connecting a video device (composite video/S video device)/stereo amplifier.................................................................. English-21
[P-5] Installing the extension module ................................................................................................................................................ English-22
Installation of the extension module ..................................................................................................................................... English-22
SDI for long-distance connection or multiple-monitor connection ..................................................................................... English-22
Connecting OPS-compliant computer ................................................................................................................................. English-23
[P-6] Connecting RS-232C ................................................................................................................................................................ English-24
Monitor control via RS-232C................................................................................................................................................. English-24
[P-7] Connecting LAN........................................................................................................................................................................ English-25
Monitor connection using LAN ............................................................................................................................................. English-25
[P-8] Connecting the power cord to the monitor .............................................................................................................................. English-26
Connecting the power source............................................................................................................................................... English-26
How to Use............................................................................................................................................................................................ English-27
Flow of How to Using ............................................................................................................................................................ English-27
[U-1] Turning on all the connected devices ....................................................................................................................................... English-28
Turning on external devices .................................................................................................................................................. English-28
Turning on the monitor .......................................................................................................................................................... English-28
Power Management Function ............................................................................................................................................... English-29
[U-2] Selecting the video input .......................................................................................................................................................... English-30
[U-3] Controlling the external devices ............................................................................................................................................... English-31
[U-4] Selecting the OSD language..................................................................................................................................................... English-31
[U-5] Auto-setup................................................................................................................................................................................. English-32
[U-6] Selecting the picture mode....................................................................................................................................................... English-33
[U-7] Screen adjustment .................................................................................................................................................................... English-33
[U-8] Picture adjustment .................................................................................................................................................................... English-34
[U-9] Speaker setting ......................................................................................................................................................................... English-34
[U-10] Volume, balance, and tone control ........................................................................................................................................... English-35
[U-11] Schedule setting ....................................................................................................................................................................... English-36
How to set up schedule......................................................................................................................................................... English-37
[U-12] Remote control.......................................................................................................................................................................... English-38
RS-232C Remote control ...................................................................................................................................................... English-38
LAN Remote control.............................................................................................................................................................. English-40
Configuration and basic operation of OSD screen.............................................................................................................................. English-41
Configuration of OSD screen ................................................................................................................................................ English-41
Basic operation of OSD......................................................................................................................................................... English-42
OSD screen functions........................................................................................................................................................................... English-43
Other functions ..................................................................................................................................................................................... English-53
Picture size ............................................................................................................................................................................ English-53
Picture mode ......................................................................................................................................................................... English-53
Control Lock mode................................................................................................................................................................ English-53
OSD information.................................................................................................................................................................... English-53
Audio input change ............................................................................................................................................................... English-54
PIP, POP function .................................................................................................................................................................. English-55
Remote control numbering function ..................................................................................................................................... English-56
Troubleshooting .................................................................................................................................................................................... English-57
Specifications ....................................................................................................................................................................................... English-58
Pin Assignment..................................................................................................................................................................................... English-59

English-2
Features
High-quality LCD panel which provides a wide variety of
contents and messages clearly
Full HD panel Page 58
The LDT462V panel reproduces images from video and computer
signals with precision and clarity, delivering full 1920 x 1080 high-
definition resolution. The high-durability panel reduces the risk of
image persistence in commercial applications.
Enhanced Display Functionality for Various Commercial
Use/Support for System Configuration Suitable for
Diversified Applications
Tiling Capability with Frame compensation Page 52
Up to 25 panels (5 wide x 5 high) can be combined to create a
single large image (i.e., video wall) or other high-impact signage. A
frame compensation function is incorporated to compensate the
width of panel bezels so that images are displayed with the utmost
accuracy.
PiP, PoP and Side-by-side Pages 10, 47, and 55
Picture-in-Picture and Picture-out-of-Picture are available when
you want to display video content from a video input source in the
sub picture and display the PC input source in the main picture,
and vice versa.
The native resolution as high as 1920 x 1080 can display these two
input sources in the Side-by-side mode, ideal for broadcasting and
video-conferencing applications.
Digital Zoom Page 45
Zoom mode for expanding 4:3 image to 16:9.
Various zoom modes are provided and it is possible to expand 4:3
aspect ratio images to 16:9. In addition, you can select the dynamic
display mode to display naturally widened images with different
zooming rates around the screen center and screen edges. You
can also optimally change the image size diagonally, horizontally,
and vertically.
Option slot allowing installation of extension modules
according to applications
Option Slot Page 22
You can mount Intel®OPS-compliant extension modules on the
monitor. With an OPS-compliant extension module, you can extend
the functionality of the monitor according to the purpose of use.
SDI Connection (option) Page 22
The SDI BOX receives SD-SDI, HD-SDI, and 3G-SDI signals at
a maximum speed of 2.970 Gbit/s and displays them on the monitor.
A single image is distributed to multiple monitors that are
daisy-chained via SDI cables (BNC).
Variable Management Functions Supporting Efficient
Operation and Management
Programmable Scheduling Function
Pages 36, 37, and 50
The monitor’s operating schedule can be programmed for up to
seven different scheduled time intervals by time, day of the week
and input port. This allows video content from different inputs
to be displayed on certain monitors within the same installation
according to the schedule, and extends the monitor’s life and saves
the power by turning it off during those hours or days it is not in
use.
Screen-saver Functions Page 48
To reduce image persistence and maximize the panel life in
demanding signage applications, this product is equipped with four
screen-saver functions.
• GAMMA
• COOLING FAN
• BRIGHTNESS
• MOTION
Power-on Delay Page 52
For installations employing numerous monitors, the power-
on delay function can power up the monitors sequentially with
delay between 2-50 seconds after the power is applied. Using
this function can prevent inrush current problems and reduce the
overall electrical load requirements when a single power supply is
used.
LAN Control Pages 25, 40, and 49
You can efficiently and centrally control multiple monitors
for reconfiguration and remote diagnosis by sending control
commands from a computer via a LAN network. Not only
Mitsubishi protocols but only Crestron’s RoomViewTM, being used
widely as software to manage network controllers, and AMX Device
Discovery by AMX.
Others
Built-in Speakers Pages 8 and 34
Speakers inside the display unit create stereo sounds and used to
communicate voice messages. You can connect external speakers
(commercially available) as needed.
Remote Control Pages 10 and 11
Special wireless remote control supports major operations and
settings.
The special wireless remote control is supplied for major controls
such as power-on/off, video source switching, and various settings.
Closed Caption Page 52
You can display captions.
When closed-caption video signals are input, you can select to
display or hide the captions on the screen.
This monitor is compliant with EIA-608-A.

English-3
English
Canadian Department of Communications Compliance Statement
DOC: This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2
No. 60950-1.
FCC Information
1. Use the attached specified cables with the LDT462V (BL109) color monitor so as not to interfere with radio and television
reception.
(1) Please use the supplied power cord or equivalent to ensure FCC compliance.
(2) Please use the supplied shielded video signal cable, 15-pin mini D-SUB to 15-pin mini D-SUB.
2. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
3. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could
void your authority to operate the equipment.
Windows is a registered trademark of Microsoft Corporation.
HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing
LLC in the United States and other countries.
Intel is a trademark of Intel Corporation in the United States and other countries.
Crestron, Crestron RoomView and RoomView are trademarks or registered trademarks of Crestron Electronics, Inc. in the
United States and other countries.
AMX is a trademark or registered trademark of AMX, LLC in the United States and other countries.
All other brands and product names are trademarks or registered trademarks of their respective owners.
Important Information

English-4
Important Information (continued)
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT’S
POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM WALL SOCKET. TO
FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD FROM THE AC OUTLET. DO
NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause electric shock.
Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been
included. Therefore, it should be read carefully in order to avoid any problems.
WARNING
CAUTION
CAUTION:
This LCD Monitor uses a lamp that contains mercury. Disposal of the lamp or the LCD Monitor with the lamp may be
regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or
the Electronic Industries Alliance: www.eiae.org. (For US only).
CAUTION

English-5
English
We hereby certify that the color monitor LDT462V (BL109)
is in compliance with
Council Directive 2006/95/EC:
— EN 60950-1
Council Directive 2004/108/EC:
— EN 55022
— EN 61000-3-2
— EN 61000-3-3
— EN 55024
and marked with
Mitsubishi Electric Corporation
2-7-3, Marunouchi,
Chiyoda-Ku
Tokyo 100-8310, Japan
Declaration
Declaration of the Manufacturer
Declaration of the Manufacturer
Note: This symbol mark is for EU countries only.
This symbol mark is according to the directive 2002/96/EC Article 10 Information for users and
Annex IV, and/or to the directive 2006/66/EC Article 20 Information for end-users and Annex II.
Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and
components which can be recycled and/or reused.
This symbol means that electrical and electronic equipment, batteries and accumulators, at their end-of-life,
should be disposed of separately from your household waste.
If a chemical symbol is printed beneath the symbol shown above, this chemical symbol means that the
battery or accumulator contains a heavy metal at a certain concentration. This will be indicated as follows:
Hg: mercury (0,0005%), Cd: cadmium (0,002%), Pb: lead (0,004%)
In the European Union there are separate collection systems for used electrical and electronic products,
batteries and accumulators.
Please, dispose of this equipment, batteries and accumulators correctly at your local community waste
collection/recycling centre.
Please, help us to conserve the environment we live in!
Warning
This is a Class A product. In a domestic environment this product may cause radio interference, in which case the
user may be required to take adequate measures.

English-6
FOR OPTIMUM PERFORMANCE, PLEASE NOTE
THE FOLLOWING WHEN SETTING UP AND USING
THE LCD COLOR MONITOR:
• DO NOT REMOVE MONITOR BACK COVER. There are
no user serviceable parts inside and opening or removing
covers may expose you to dangerous shock hazards or
other risks.
Refer all servicing to qualified service personnel.
• Do not spill any liquids into the cabinet or use your monitor
near water.
• Do not insert objects of any kind into the cabinet slots,
as they may touch dangerous voltage points, which can
be harmful or fatal or may cause electric shock, fire or
equipment failure.
• Do not place any heavy objects on the power cord.
Damage to the cord may cause shock or fire.
• Do not place this product on a sloping or unstable cart,
stand or table, as the monitor may fall, causing serious
damage to the monitor.
• When operating the LCD monitor with its AC 100-120 V
power supply in North America, use a power supply cord
provided with the monitor.
If a power cord is not supplied with this monitor, please
contact your supplier.
• When operating the LCD monitor with its AC 220-240 V
power supply in Europe, use a power supply cord provided
with the monitor.
If a power cord is not supplied with this monitor, please
contact your supplier.
• In UK, use a BS-approved power cord with molded plug
having a black (10 A) fuse installed for use with this monitor.
• When operating the LCD Monitor with a 220-240 V AC
power supply in Australia, use the power cord provided with
the monitor.
If a power cord is not supplied with this equipment, please
contact your supplier.
• For all other cases, use a power cord that matches the AC
voltage of the power outlet and has been approved by and
complies with the safety standard of your particular country.
• Do not place any objects onto the monitor and do not use
the monitor outdoors.
• The inside of the fluorescent tube located within the LCD
monitor contains mercury. Please follow the bylaws or rules
of your municipality to dispose of the tube properly.
• Do not bend power cord.
• Do not use monitor in high temperature, humid, dusty, or
oily areas.
• If monitor or glass is broken, do not come in contact with
the liquid crystal and handle with care.
• If the LCD monitor is damaged and the liquid crystal leaks
out, do not inhale or swallow it.
• Allow adequate ventilation around the monitor, so that heat
can properly dissipate. Do not block ventilated openings or
place the monitor near a radiator or other heat sources.
Do not put anything on top of the monitor.
• The power cable connector is the primary means of
detaching the system from the power supply. The monitor
should be installed close to a power outlet, which is easily
accessible.
• Handle with care when transporting. Save packaging for
transporting.
• Please clean the holes of back cabinet to reject dirt and
dust at least once a year because of set reliability.
• If using the cooling fan continuously, it’s recommended to
wipe holes a minimum of once a month.
• When installing the remote control batteries;
- Align the batteries according to the (+) and (-) indications
inside the case.
- Align the (-) indication of the batteries first inside the
case.
CAUTION:
Immediately unplug your monitor from the wall outlet and refer
servicing to qualified service personnel under the following
conditions:
• When the power supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen inside the
monitor.
• If the monitor has been exposed to rain or water.
• If the monitor has been dropped or the cabinet damaged.
• If the monitor does not operate normally by following
operating instructions.
Recommend Use
CAUTION:
• For optimum performance, allow 20 minutes for warm-up.
• Rest your eyes periodically by focusing on an object at least
5 feet away. Blink often.
• Position the monitor at a 90° angle to windows and other
light sources to minimize glare and reflections.
• Clean the LCD monitor surface with a lint-free, non-abrasive
cloth. Avoid using any cleaning solution or glass cleaner!
• Adjust the monitor’s brightness, contrast, and sharpness
controls to enhance readability.
• Avoid displaying fixed patterns on the monitor for long
periods of time to avoid image persistence (after image
effects).
• Get regular eye checkups.
Ergonomics
To realize the maximum ergonomic benefits, we recommend
the following:
• Use the preset Size and Position controls with standard
signals.
• Use the preset Color Setting.
• Use non-interlaced signals.
• Do not use primary color blue on a dark background, as
it is difficult to see and may produce eye fatigue due to
insufficient contrast.
Safety Precautions, Maintenance & Recommended Use

English-7
English
46" LCD Display Monitor
MODEL
Contents
Power Cord
For EU
Video Signal Cable
(Mini D-SUB 15-pin to
Mini D-SUB 15-pin Cable)
Main Power Switch Cover
Screw (3)
(To fix Main power switch cover) Wireless Remote
Control and AAA
Batteries
Your LCD monitor (LDT462V) comes with the following:
* For the use in the other regions, use a power cord that
matches the AC voltage of the power outlet and has been
approved by and complies with the safety standard of those
regions or countries.
The following components are supplied as option.
• Stands
• SDI BOX
Clamper x 2
(To prevent from falling)
Screw for Clamper
(M4) x 2
Clamper x 3
(For preventing disconnection of
the power cord and HDMI cable,
and for securing the cables)
LCD Monitor
Power Cord
For North America
* The supplied power cord varies depending on destination.
User’s Manual

English-8
6PLUS (+) button
Acts as (+) button to increase the adjustment in the OSD menu.
Increases the audio output level when the OSD menu is off.
7MINUS (-) button
Acts as (-) button to decrease the adjustment in the OSD menu.
Decreases the audio output level when the OSD menu is off.
8UP ( ) button
Acts as button to move the highlighted area up to select an
adjustment item in the OSD menu.
9DOWN ( ) button
Acts as button to move the highlighted area down to select
an adjustment item in the OSD menu.
10 EXIT button
Activates the OSD menu when the OSD menu is off.
Acts as EXIT button to go back to the previous OSD menu.
11 Speakers
Audio sound is output from the built-in speakers.
(Reference) Control Lock mode
You can lock the operation buttons. See page 53.
1Main Power Switch
Switches the main power on/off.
2Remote control sensor and Power indicator
Remote control sensor: Receives the signal from the wireless
remote control.
Power indicator: Indicates the state of the LCD monitor.
• Steady green: The power is on.
• Steady red: The power is off.
Some operations such as power-on
are possible.
• Steady green and red: The LCD monitor is in the sleep
mode.
• Off: The main power is off.
• Steady red and blinking green: The LCD monitor is in the
schedule standby mode.
• Blinking red: The LCD monitor has an error
(detected by the self-diagnostic
function).
3POWER button ( )
Switches the power on/off.
This button doesn’t work when the power indicator is off. Turn
on the main power. (See page 28.)
4MUTE button
Switches the audio mute on/off.
5INPUT button
Displays the OSD menu to switch the video input.
You can select [HDMI], [DVI-D], [D-SUB], [OPTION]*, [YPbPr],
[S-VIDEO], or [VIDEO] using the UP ( ) or DOWN ( ) button.
* OPTION can be used when an extension module is
mounted on the option slot.
Buttons, Switch, and Indicator
ON
OFF
Parts Name and Functions
NOTE:
For details about the OSD menu operation using the buttons, see “Basic operation of OSD.” (See page 42.)
Front
Control buttons
Rear

English-9
English
1AC IN (3-pin, with earth terminal)
Connects with the supplied power cord.
2RS-232C connector (D-SUB 9-pin)
IN connector:
Connects with the RS-232C OUT connector of a computer or
other connected LDT462V.
OUT connector:
Connects with the RS-232C IN connector of other connected
LDT462V.
3LAN connector
Connects with a LAN cord.
4D-SUB OUT
Outputs the signal that is supplied to the D-SUB IN or YPbPr IN
connector.
5DVI-D IN
Connects with the digital video output of a computer, etc.
6D-SUB IN
Connects with the analog video output of a computer, etc.
7HDMI IN
Connects with the digital video output of a computer, DVD
player, etc.
8YPbPr IN
Connects with the component video output of a DVD player,
etc.
9AUDIO IN
Connects with the audio output connector of external
equipment such as a computer, VCR, and DVD player.
(a) AUDIO IN1: ø3.5 stereo mini-jack connector
(b) AUDIO IN2: RCA connector
(c) AUDIO IN3: RCA connector
Connectors and Terminals
Pr Pb Y
IN IN
OUT ROUT L
10 VIDEO INPUT/OUTPUT (S connector/BNC)
Connects with video equipment.
S-VIDEO IN: S-video input connector (MINI DIN 4-pin)
VIDEO IN: BNC connector
VIDEO OUT: BNC connector
11 AUDIO OUT (RCA)
Outputs the signal that is supplied to the selected AUDIO IN
connector. Connects with an external audio amplifier, etc.
12
EXTERNAL SPEAKER TERMINAL
Connects with external speakers (commercially available)
(stereo, 8 Ω 10 W each).
13 Speaker switch
Switches the built-in speakers and external speakers
(commercially available).
14 Option slot
Insert an OPS-compliant module (option or commercially
available).
CAUTION:
Damage to the product may result or monitor may not function
properly if an incompatible device is installed in this slot. See
page 22.
When mounting an OPS-compliant computer (commercially
available), turn on the cooling fan.
Parts Name and Functions (continued)
Anti-theft lock slot
You can insert a
Kensington anti-theft
lock key.
Rear Left side
Main Power Switch

English-10
1POWER button
Switches the power on/off.
* When the Power indicator is not glowing, no controls will
work.
2INPUT buttons
Select the input signal from [HDMI], [DVI-D], [D-SUB], [OPTION]*,
[YPbPr], [S-VIDEO], and [VIDEO].
* OPTION can be used when an extension module is
mounted on the option slot.
NOTE:
The [BNC] and [DISPLAY PORT] buttons don’t work.
3PICTURE MODE button
Selects the picture mode from [HIGHBRIGHT], [STANDARD],
[sRGB], and [CINEMA]. See page 33.
HIGHBRIGHT: The brightness is maximized.
STANDARD: Factory default setting.
sRGB: Suitable for color matching with sRGB-
compliant devices.
CINEMA: Suitable for viewing movies.
4DISPLAY button
Displays the screen information. See page 53. When the remote
control mode is LOCK, you can set it back to NORMAL by
holding down the DISPLAY button for at least 5 seconds (see
page 52).
5SET button
Accepts the settings made in the OSD menu.
6MINUS button (-)
Acts as (-) button to decrease the adjustment in the OSD menu.
When the PIP mode is active, this button moves the sub picture
to the left.
7AUTO SETUP button
Displays the auto setup menu. See pages 32 and 48.
8AUDIO INPUT buttons
Selects the audio input according to the video input.
9PIP (Picture-in-Picture) buttons
ON/OFF button: Switches the PIP or POP mode on/off.
INPUT button: Selects video to be displayed in the sub
picture.
CHANGE button: Changes the main picture with the sub
picture.
[Description]
PIP: Picture-in-Picture
The sub picture is displayed within the main picture.
POP: Picture-out-Picture
The sub picture is displayed to the bottom right of the main
picture.
SIDE BY SIDE
The main picture and the sub picture are displayed side by
side.
NOTE:
When the screen size is [CUSTOM] or [REAL], the PIP and POP
modes don’t work.
10 STILL button
ON/OFF button: Switches the still picture mode on/off.
CAPTURE button: Captures the new picture.
11 SIZE button
Selects the picture size from [FULL], [NORMAL], [CUSTOM],
[DYNAMIC], and [REAL]. See page 53.
12 MENU button
Switches the OSD menu mode on/off.
13 UP button ( )
Acts as button to move the highlighted area up to select
an adjustment item in the OSD menu. When the PIP mode is
active, this button moves the sub picture up.
14 PLUS button (+)
Acts as (+) button to increase the adjustment in the OSD menu.
When the PIP mode is active, this button moves the sub picture
to the right.
15 EXIT button
Displays the previous OSD menu.
16 DOWN button ( )
Acts as button to move the highlighted area down to select
an adjustment item in the OSD menu. When the PIP mode is
active, this button moves the sub picture down.
17 MUTE button
Switches the mute function on/off.
18 VOLUME buttons (VOL)
Pressing the plus (+) side increases the audio output level.
Pressing the minus (-) side decreases the audio output level.
Parts Name and Functions (continued)
Wireless Remote Control

English-11
English
Operating Range of the Wireless Remote Control
Point the wireless remote control toward the LCD monitor’s
remote control sensor during button operation.
Use the wireless remote control within a distance of about 7 m
from the front of the LCD monitor’s remote control sensor and
at a horizontal and vertical angle of within 30° within a distance
of about 3.5 m.
CAUTION:
The remote control system may not function when direct
sunlight or strong illumination strikes the remote control sensor
of the LCD monitor, or when there is an object in the path.
Handling the wireless remote control
* Do not subject to strong shock.
* Do not allow water or other liquid to splash on the wireless
remote control. If the wireless remote control gets wet, wipe
it dry immediately.
* Avoid exposure to heat and steam.
* Other than to install the batteries, do not open the wireless
remote control.
Parts Name and Functions (continued)
Installing and removing the wireless remote
control batteries
The wireless remote control is powered by 1.5 V AAA batteries.
How to install the batteries
1. Unlock and pull up the cover in the arrow’s direction.
2. Align the batteries according to the (+) and (-) indications
inside the case.
3. Replace the cover.
How to remove the batteries
1. Unlock and pull up the cover in the arrow’s direction.
2. Remove the batteries.
CAUTION:
Incorrect use of batteries can result in leaks or explosion.
Be careful especially about the following points.
• Place “AAA” batteries matching the (+) and (-) signs on each
battery to the (+) and (-) signs of battery compartment.
• Do not mix battery types.
• Do not combine new batteries with used ones. It causes
shorter battery life or leakage of batteries.
• Remove dead batteries immediately to prevent battery
liquid from leaking into the battery compartment. Don’t
touch exposed battery acid because it causes damage to
your skin.
NOTE:
If you do not use the wireless remote control for a long period,
remove the batteries.
How to Use the Wireless Remote Control

English-12
Flow of preparation
P-1 Preparation for installation
- Determine the installation location
- Ventilation requirements for enclosure mounting
- To avoid the monitor from falling
Page 13
Carry out as necessary
P-2
P-3
P-5
P-6
P-7
P-4
P-8
Carry out as necessary
Carry out as necessary
Carry out as necessary
Carry out as necessary
Installing the external speakers (commercially available)
Installing the extension module
- Installation of the extension module
- SDI for long-distance connection or multiple-monitor connection
- Connecting OPS-compliant computer
Connecting RS-232C
- Monitor control via RS-232C
Connecting LAN
- Monitor connection using LAN
Installing the monitor
- Installing and removing the stands (The stands are optionally available.)
- Using the wall mount or ceiling mount
- Installing in the portrait position
- Installing the main power switch cover
Pages 14 to 15
Page 16
Page 24
Page 25
Pages 17 to 21
Pages 22 to 23
Page 26
Page 27
Connection procedure
- Wiring diagram
- Prevention of disconnection of HDMI cable
- Connecting with a computer (analog connection)
- Connecting with a computer (digital connection)
- Connecting a video device (component video/HDMI device)
- Connecting a video device (composite video/S video device)/stereo amplifier
Connecting the power cord to the monitor
- Connecting the power source
The monitor is ready for use.
How to Use
Preparation for use

English-13
English
P-1 Preparation for installation
This LCD has a temperature sensor and cooling fan. If the LCD
becomes hot, the cooling fan will turn on automatically. If the
LCD becomes overheated, the “Caution” menu will appear.
If the “Caution” menu appears, stop using the monitor and
allow it to cool. When the LCD monitor is used in an enclosure
or with protection on LCD surface, please check the inside
temperature of the monitor by “HEAT STATUS” (See page 52). If
the temperature is higher than the normal level, set “COOLING
FAN” to ON using the SCREEN SAVER function (See page 48).
When mounting an OPS-compliant computer (commercially
available), turn on the cooling fan.
To avoid the monitor from falling
When installing the monitor using the tabletop stands (option),
take measures to prevent the monitor from falling over in case
of an earthquake or other disaster to lessen the probability of
injury and damage resulting from the fall.
As shown in the figure, secure the monitor to a solid wall or
pillar using rope (commercially available) strong enough to bear
the weight of the monitor. [LDT462V: approximately 26.5 kg (with
the optional stands)]
When using screw hooks (commercially available), use ring
hooks, not C-hooks (with opening).
CAUTION:
• The effect of the fall prevention substantially depends
on the strength of brackets and base to which the fall
prevention devices is attached. When you cannot ensure
sufficient strength, provide adequate reinforcement.
• Though the recommended fall prevention is intended to
lessen the probability of injury and damage, it doesn’t
assure its effectiveness against any kind of earthquake or
disaster.
• Do not sleep where the monitor may topple over or fall in
case of an earthquake or other disaster.
• Before moving the monitor, remove the rope that is
securing the monitor. Failure to do so may result in injury or
breakdown of the monitor.
Determine the installation location
CAUTION:
DO NOT ATTEMPT TO INSTALL THE LCD MONITOR BY
YOURSELF.
Installing your LCD monitor must be done by a qualified
technician. Contact your dealer for more information.
CAUTION:
MOVING OR INSTALLING THE LCD MONITOR MUST BE
DONE BY TWO OR MORE PEOPLE.
Failure to follow this caution may result in injury if the LCD
monitor falls.
CAUTION:
Proper operation of the monitor is not guaranteed when it is
mounted upside down, face up, or face down.
IMPORTANT:
Lay the protective sheet, which was wrapped around the LCD
monitor when it was packaged, beneath the LCD monitor so as
not to scratch the panel.
Ventilation requirements for enclosure mounting
To allow heat to disperse, leave space around the monitor as
shown in the figure below.
CAUTION:
Don’t block the holes in the rear of the monitor shown in the
figure above. If they are blocked, heat accumulates inside the
monitor, causing breakdown. The upper limit of the operation-
guaranteed ambient temperature when the monitor is installed
in the landscape position is 40˚C. When installing the monitor
in a case or an enclosure, ensure adequate ventilation to keep
the temperature inside the case 40˚C or lower by providing
a cooling fan or ventilation holes in the case. The upper limit
when the monitor is in the portrait position is 35˚C.
Screw holes
Screw hook, etc.
(commercially available)
Clamper Screw
Rope, etc.
(commercially available)
204 mm
Don’t block these holes.
Wall

English-14
P-2 Installing the monitor Carry out as necessary
Using the wall mount or ceiling mount
Lay the screen face down
Lay the protective sheet on a table, which was wrapped around
the monitor when it was packaged, beneath the screen surface
so as not to scratch the screen surface.
This device cannot be used or installed without the Tabletop
Stand or other mounting accessory. Failure to follow the correct
mounting procedures can result in damage to the equipment or
injury to the user or installer. Product warranty does not cover
damage caused by improper installation.
Failure to follow these recommendations can void your
warranty.
For installation, use M6 screws (with a loose-proof spring
washer and having a length 10 mm longer than the thickness of
the mounting bracket) and tighten them securely. MITSUBISHI
ELECTRIC recommends using mounting interface that comply
with TÜV-GS and UL1678 standard in North America.
100 100 100 100
545.5 545.5
200
323323
CAUTION:
For preventing the monitor from falling.
• Install the monitor with metal brackets for wall or
ceiling installation (commercially available) on your own
responsibility. For detailed procedures of installation, refer
to the instructions of the metal brackets.
• To lessen the probability of injury and damage resulting
from fall of the monitor in case of earthquake or other
disaster, be sure to consult the bracket manufacturer for
installation location.
• To lessen the risk of falling of the monitor, thread
commercially available rope through the handles at the
right and left of the monitor and secure the rope to the
wall mount brackets or ceiling mount brackets. Use rope
that can bear a load 6 times the weight of the monitor
(approximately 150 kg).
• Do not sleep where the monitor may topple over or fall in
case of an earthquake or other disaster.
• Use screws having enough strength to support the LCD
display monitor (made of stainless steel etc.).
Handles
Protective Sheet
(mm)
Table
Installing and removing the stands
The stands are available as option.
Refer to the user’s manual of the stand for more information.
How to install the stands
1. Turn the monitor off.
2. Insert the option stands in the guide frames on both sides
to the end.
Secure the option stands on both sides firmly using the
screws supplied with the option stands.
3. Install the monitor on a flat and stable surface.
NOTE:
• Install the stands so that their longer portions come to the
front.
How to remove the stands
1. Spread the protective sheet on a flat surface, such as a
desk.
2. Place the monitor on the protective sheet.
3. Remove the screws to remove the option stands.
Option stand x 2
(Longer portion comes to the front.)
Screw x 2
(Accessories of
the option stand)

English-15
English
P-2 Installing the monitor (continued) Carry out as necessary
Installing in the portrait position
The monitor can be installed in the portrait position.
Ensure that the monitor is oriented as shown below.
CAUTION:
• The operating environmental condition (temperature) when
the monitor is in the portrait position is 5˚C to 35˚C.
• Proper operation of the monitor is not guaranteed when it is
not mounted as shown below (upside down, face up, face
down, etc.).
• When mounting an OPS-compliant computer (commercially
available), be sure to set COOLING FAN to ON using
SCREEN SAVER in the CONFIGURATION1 menu of the
OSD screen function. If it is set to AUTO, the life of the
computer may become shorter than that with it set to ON or
the computer may have trouble.
• In the portrait position, the lifetime of the fluorescent tube
(backlight) is shorter than that when the monitor is in the
landscape position.
Installation in the portrait position
The “ ” logo should be on the LEFT side when
viewed from the front of the monitor.
Operation environment for portrait installation
When the monitor is installed in the portrait position, the
following conditions should be satisfied.
Temperature 5 - 35°C / 41 - 95°F
Humidity 20 - 80% (without condensation)
Face-up
Face-down
90° Clockwise
Portrait
Portrait
logo
Landscape
Installing the main power switch cover
Attach the main power switch cover (accessory) and secure
it using a screw as needed, to prevent the main power switch
from being operated.
NOTE:
Once you attach the main power switch cover, you cannot turn
on or off the main power switch.
Screw for securing the
main power switch cover
(accessory)
Main power switch
cover (accessory)

English-16
To speaker terminal (L)To speaker terminal (R)
Red(+)/Black(-)Red(+)/Black(-)
SPEAKER (S)(L)
SPEAKER (S)(R)
Black(-)
Red(+)
Black(-)
Red(+)
Left speaker
(commercially
available)
Right speaker
(commercially
available)
How to install the external speakers
1. Connect the speaker output connectors on the monitor and external speakers (commercially available) using speaker cables.
Insert the left speaker cable into the SPEAKER (S) terminal (L) on the monitor, and insert the right speaker cable into the
SPEAKER (S) terminal (R).
NOTE:
Match the polarity of the speaker cables and that of the terminals (+ (red)/- (black)).
Unmatched polarity may cause problems with audio output.
Specifications of the recommended speaker:
Rated input: 10 W
Impedance: 8 Ω (left), 8 Ω (right)
CAUTION:
Use speakers that meet the specifications. Otherwise, the monitor or the speakers may have trouble.
P-3 Installing the external speakers Carry out as necessary

English-17
English
Prevention of disconnection of HDMI cable
When you connect the HDMI cable to the connector on the monitor, in order to prevent accidental disconnection of the cable, you
are recommended to secure it using the supplied clamper as shown in the figure.
Personal computer
(DVI-D, HDMI)
Personal
computer
(Analog RGB)
LCD monitor (rear)
LCD monitor (second monitor)
DVD player or HD disk
player (HDMI, BNC)
VCR (RCA)
Stereo amplifier
External speakers
Clamper
Before making connections
• First turn off the power of all the connected equipment before making connections.
• Refer to the user manual of each piece of equipment.
NOTE:
Please use the audio cable without resistance when the audio output terminal of the audio device and PC is stereo mini-Jack.
When the audio cable with resistance is used, the audio level may not be increased or no audio may be output.
Wiring diagram
P-4 Connection procedure
LCD monitor
(first monitor)

English-18
Signal cable
(Mini D-SUB 15-pin to Mini D-SUB 15-pin)
To audio output
D-SUB IN
D-SUB OUT
AUDIO IN1
(mini)
AUDIO OUT (RCA)
Audio cable
(ø 3.5 mm stereo mini)
D-SUB IN
AUDIO IN2 (RCA)
Signal cable
(Mini D-SUB 15-pin to Mini D-SUB 15-pin)
Audio cable (RCA)
To D-SUB output
LCD monitor (first monitor)
LCD monitor (second monitor)
Personal computer
(Analog RGB)
Connecting with a computer (analog connection)
Analog connection:
(1) Connect a signal cable (mini D-SUB 15-pin – mini D-SUB 15-pin) (accessory) to the D-SUB IN connector.
(2) Select [D-SUB] using the INPUT button on the monitor or the D-SUB button on the wireless remote control.
Second monitor connection:
• Connect the D-SUB OUT connector (mini D-SUB 15-pin) on the first monitor and the D-SUB IN connector (mini D-SUB 15-pin)
on the second monitor using a signal cable (mini D-SUB 15-pin – mini D-SUB 15-pin) (an accessory of the second monitor or
commercially available).
(The analog input signal of D-SUB selected by the first monitor is output. The digital input signal of HDMI or DVI-D is not output.)
NOTE:
When different monitors need to be adjusted so that their tint can be identical, such as when using multiple screens, it is
recommended to use a signal distributor (commercially available).
Audio connection:
• Connect an audio cable (ø3.5 mm stereo mini) (commercially available) to the AUDIO IN1 connector.
Select [AUDIO1] using the AUDIO INPUT buttons on the wireless remote control.
• To output audio to the second monitor:
Connect the AUDIO OUT connector on the first monitor and the AUDIO IN2 connector or AUDIO IN3 connector on the second
monitor using an audio cable (RCA) (commercially available).
P-4 Connection procedure (continued)

English-19
English
DVI-D IN
HDMI IN
AUDIO IN1 (mini)
HDMI cable
DVI-D cableTo DVI-D output
To HDMI output
To audio output
Audio cable
(ø3.5 mm stereo mini)
Personal computer
(DVI-D, HDMI)
Connecting with a computer (digital connection)
Digital connection:
• Connection via the HDMI IN connector
(1) Connect an HDMI cable (commercially available) to the HDMI IN connector.
(2) Select [HDMI] using the INPUT button on the monitor or the HDMI button on the wireless remote control.
• Connection via the DVI-D IN connector
(1) Connect a DVI-D cable (commercially available) to the DVI-D IN connector.
(2) Select [DVI-D] using the INPUT button on the monitor or the DVI-D button on the wireless remote control.
Audio connection:
• Connect an audio cable (ø3.5 mm stereo mini) (commercially available) to the AUDIO IN1 connector.
Select [AUDIO1] using the AUDIO INPUT buttons on the wireless remote control.
When an HDMI cable is connected, select HDMI audio.
(You can select HDMI only when the video input is [HDMI].)
LCD monitor (rear)
P-4 Connection procedure (continued)
The monitor automatically distinguishes the timings shown in the table below and sets the screen information. When a PC or other
device is connected, it automatically displays images properly. See the page describing AUTO SETUP/AUTO ADJUST.
<Factory preset timing>
Resolution Frequency Remarks Resolution Frequency Remarks
Horizontal Vertical Horizontal Vertical
1 640 x 480 31.5 kHz 60 Hz 9 1280 x 1024 64.0 kHz 60 Hz
2 800 x 600 37.9 kHz 60 Hz 10 1400 x 1050 65.3 kHz 60 Hz
3 1024 x 768 48.4 kHz 60 Hz 11 1680 x 1050 65.3 kHz 60 Hz
4 1280 x 720 45.0 kHz 60 Hz 12 1600 x 1200 75.0 kHz 60 Hz
5 1280 x 768 47.8 kHz 60 Hz 13 1920 x 1080 56.2 kHz 50 Hz
6 1280 x 800 49.7 kHz 60 Hz 14 1920 x 1080 67.5 kHz 60 Hz Recommend timing
7 1360 x 768 47.7 kHz 60 Hz 15 1920 x 1200 74.0 kHz 60 Hz
CVT Reduced Blanking
8 1440 x 900 55.9 kHz 60 Hz
NOTE:
When a signal other than 1920 x 1080 is input, characters may be blurred and figures and objects may be distorted.
Images may not be displayed correctly depending on the video card or driver being used.
