MITSUBISHI
ELECTRIC
PRESENTATION PRODUCTS
Leading the evoLution of
HIGH-DEFINITION
digital signage
Slim eye-catching bezel design•
Advanced high-definition digital signage display•
Full 1920 x 1080 native resolution•
Built-in CAT5 transmitter and receiver•
Front and rear ambient light sensors•
www.mitsubishi-presentations.com
888.307.0349
MDT521S
52” LCD Monitor

CLASS 52” (Diagonal) LCD Monitor
VIEWABLE IMAGE SIZE 45.4” x 25.5”
ORIENTATION Landscape / Portrait / Face Up
BRIGHTNESS/LUMENS 700 cd/m2
PIXEL PITCH 0.600 mm
CONTRAST RATIO 2000:1
DIMENSIONS
(W x H x D in.)
47.3 x 27.5 x 4.8
WEIGHT
(WITHOUT STAND
AND SPEAKERS)
88 lbs. (Net)
BEZEL WIDTH 0.77”
RESPONSE TIME 8 ms (gray to gray)
VIEWING ANGLE Horizontal and vertical: 178O
VIDEO/AUDIO
INPUTS AND OUTPUTS
mini D-Sub 15 pin In/Out, HDMI, DVI-D, CAT5 In/Out, BNC (R,G,B,H,V) In/out, S-Video, Composite (BNC, RCA), Audio LR (RCA), Audio Stereo mini jack
SPEAKER OUTPUT External speaker jack
CONTROL INPUT/OUTPUT RS232C (mini D-Sub 9 In/Out)
POWER CONSUMPTION
(WITHOUT SPEAKERS)
360 W
ESTIMATED BACKLIGHT LIFE Up to 50,000 hours*
AUDIO SPEAKER Optional: SP-521S
TABLE STAND Optional: ST-521S
WALL MOUNT
COMPATABILITY
Optional: CTM-MS2
WARRANTY 3-years parts and labor, Express
Replacement Assistance, toll-free 24x7 technical support
*Results may vary depending on usage and operating environment
MITSUBISHI ELECTRIC
PRESENTATION PRODUCTS
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. Presentation Products Division Toll Free: Email: [email protected] www.mitsubishi-presentations.com Canada Mitsubishi Electric Sales Canada Inc. Information Technologies Group Phone: [phone] www.mitsubishielectric.ca
LITMDT521S
Optional Stand:
ST-521S
MDT521S
52” LCD Monitor
Slot for optional CAT5 input/output connectors (modular connector 8pin) EXTERNAL CONTROL (mini D-Sub 9 pin)
VIDEO IN/OUT VIDEO IN CONNECTOR (BNC and RCA) VIDEO OUT CONNECTOR (BNC) S-VIDEO IN CONNECTOR (Mini DIN 4 pin)
RGB 4 IN/ DVD/HD IN (BNC) AC IN connector EXTERNAL SPEAKER TERMINAL AUDIO OUT AUDIO IN 1,2,3
RGB 1 IN (HDMI) RGB 2 in (DVI-D) RGB 3 IN (mini D-Sub 15 pin) RGB out (mini D-Sub 15 pin)
multiple standard input and output connectors
Out OutIn In In In
Side Connector
Panel
Rear Connector
Panel
