LDT521V
LDT651L
LDT651P
1. PC/AV Output Terminal
(DVI-D)
2. PC1 Input Terminal
(DVI-D)
AV1 Input Terminal
(DVI-D)
3. PC2 Input Terminal (HDMI)
AV2 Input Terminal (HDMI)
4. PC3 Input Terminal (mini
D-Sub 15 pin)
5. PC4 Input Terminals
(BNC)
6. AV3 Input Terminals
(BNC)
7. AV5 Input Terminal (BNC)
8. AV4 Input Terminal (S)
9. LAN Terminal
10. RS-232C Output Terminal
(D-Sub 9 pin)
11. RS-232C Input Terminal
(D-Sub 9 pin)
12. PC/AV Audio Output
Terminals
13. AV Audio Input Terminals
14. PC Audio Input Terminal
15. External Speaker
Terminals
16. Main Power Switch
17. AC Input Terminal
2
4
7
10
11
12
9
8
6
5
3
1
17 1 2 3 4 6 8 9 12 13 1514
10 1116 5 7
1 2 3 4 6 8 9 12 13 1514
10 11
5 7
RS-232C Output1.
Terminal (D-Sub 9 pin)
RS-232C Input Terminal2.
(D-Sub 9 pin)
AV3 Input Terminal3.
(BNC)
AV2 Input Terminals4.
(BNC)
PC3 Input Terminals5.
(BNC)
PC Audio Input6.
Terminal
PC2 Input Terminal7.
(mini D-Sub 15 pin)
AV Audio Input8.
Terminals
PC/AV Audio Output9.
Terminals
PC1 Input Terminal10.
(DVI-D)
AV1 Input Terminal
(DVI-D)
PC/AV Output Terminal11.
(DVI-D)
External Speaker12.
Terminals
LDT521V LDT651L LDT651P
Unit: mm
1254
742
1156
652
149
92
581
13
Unit: mm
126
860
58
1572
923
1432
807
133
Unit: mm
807
1572
923
1002
440
1514
150
156
1432
58
ORIENTATION Landscape/Portrait Landscape Portrait
VIEWABLE IMAGE SIZE 52.04” 64.53” 64.53”
RESOLUTION 1920 x 1080 (FHD) 1920 x 1080 (FHD) 1920 x 1080 (FHD)
BRIGHTNESS 450 cd/m2420 cd/m2450 cd/m2
VIEWING ANGLE Vertical:176oHorizontal: 176oVertical:176oHorizontal: 176oVertical:176oHorizontal: 176o
CONTRAST RATIO 1800:1 2000:1 2000:1
WEIGHT
(WITHOUT BASE) 86 lbs. 137 lbs. 145 lbs.
DIMENSION
(W x H x D in) WITHOUT BASE) 49.4” x 29.2” 5.9” 61.9” x 36.3” x 5.0” 36.3” x 61.9” x 5.9”
RESPONSE TIME 6ms (Gray to Gray) 6ms (Gray to Gray) 6ms (Gray to Gray)
COLOR 16.7 Million 16.7 Million 16.7 Million
PC ANALOG INPUT
CONNECTORS BNC (R,G,B,H,V) (PC/AV Common), RGB (Mini D-sub 15pin),
PC DIGITAL INPUT
CONNECTORS DVI-D, HDMI DVI-D, HDMI DVI-D
PC OUTPUT
CONNECTORS DVI-D (PC/AV common) DVI-D (PC/AV common) DVI-D (PC/AV common)
SYNC INPUT/OUTPUT Separate (TTL), Composite (TTL), Sync on green,
AV INPUT CONNECTORS Composite BNC, Separate (Y/C), <S-TERMINAL>, Component (Y/Pb/
Pr<BNC> (PC/AV common)
Composite BNC, Component (Y/Pb/
Pr<BNC> (PC/AV common)
AUDIO INPUT
CONNECTORS
RCA pin-jack L/R, Stereo mini jack
(Analog), HDMI (Digital)
RCA pin-jack L/R, Stereo mini jack
(Analog), HDMI (Digital)
RCA pin-jack L/R, Stereo mini jack
(Analog)
AUDIO OUTPUT RCA pin-jack L/R RCA pin-jack L/R RCA pin-jack L/R
CONTROL OUTPUT RS-232C <Mini D-Sub 9 pin> RS-232C <Mini D-Sub 9 pin> RS-232C <Mini D-Sub 9 pin>
OPERATING POWER
CONSUMPTION 275W 480W 560W
REMOTE CONTROL Yes Yes Yes
PLUG AND PLAY Yes Yes Yes
VESA COMPATIBLE Yes Yes Yes
POWER SUPPLY AC100-240, 50/60 Hz AC100-240, 50/60 Hz AC100-240, 50/60 Hz
ACCESSORIES VESA Compliant wall mount or floor stands available upon request
WARRANTY 3-Year Parts and Labor, toll-free 24 x 7 technical support, available on-site warranty repairs and service
MITSUBISHI
ELECTRIC
PRESENTATION PRODUCTS
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.
Presentation Products Division
Toll Free: 888.307.0349
www.mitsubishi-presentations.com
Canada
Mitsubishi Electric Sales Canada Inc.
Information Technologies Group
Phone: 905.475.7728
www.mitsubishielectric.ca
©2008 Mitsubishi Digital Electronics America, Inc. Standard features,
options and specications subject to change without notice. Microsoft,
Windows, and the Windows logo are registered trademarks of Microsoft
Corporation. Mac and the Mac logo are trademarks of Apple Computer, Inc,
registered in the U.S. and other countries. All other trademarks or registered
trademarks are the property of their respective holders.
LITLDT521V651L651P
LDT521V | LDT651L | LDT651P
