.ALWAYS review this Owner’s Manual for
important safety information.
On-pavement and off-road driving
This vehicle will handle and maneuver
differently from an ordinary passenger car
because it has a higher center of gravity. As
with other vehicles with features of this
type, failure to operate this vehicle correctly
may result in loss of control or an accident.
Be sure to read “Avoiding collision and
rollover” and “Driving safety precautions”
in the “5. Starting and driving” section of
this manual.
MODIFICATION OF YOUR VEHI-
CLE
This vehicle should not be modified. Mod-
ification could affect its performance, safety
or durability, and may even violate govern-
mental regulations. In addition, damage or
performance problems resulting from mod-
ification may not be covered under
Mitsubishi Motors warranties.
WARNING
Installing an aftermarket On-Board Diagnostic
(OBD) plug-in device that uses the port during
normal driving, for example remote insurance
company monitoring, remote vehicle diagnos-
tics, telematics or engine reprogramming, may
cause interference or damage to vehicle sys-
tems. We do not recommend or endorse the use
of any aftermarket OBD plug-in devices, unless
specifically approved by Mitsubishi Motors.
The vehicle warranty may not cover damage
caused by any aftermarket plug-in device.
WHEN READING THE MAN-
UAL MVDGED1-95FC8501-974E-42A5-9BF3-8D0DF8D34DB7
This manual includes information for all
features and equipment available on this
model. Features and equipment in your
vehicle may vary depending on model, trim
level, options selected, order, date of produc-
tion, region or availability. Therefore, you
may find information about features or
equipment that are not included or installed
on your vehicle.
All information, specifications and illustrations
in this manual are those in effect at the time of
printing. Mitsubishi Motors reserves the right to
change specifications, performance, design or
component suppliers without notice and without
obligation. From time to time, Mitsubishi
Motors may update or revise this manual to
provide Owners with the most accurate infor-
mation currently available. Please carefully read
and retain with this manual all revision updates
sent to you by Mitsubishi Motors to ensure you
have access to accurate and up-to-date informa-
tion regarding your vehicle. If you have
questions concerning any information in your
Owner’s Manual, contact a certified Mitsubishi
EV dealer.
IMPORTANT INFORMATION
ABOUT THIS MANUAL
MVDGED1-CC41887D-89CD-4B21-B9F2-EBE20E28E403
You will see various symbols in this manual.
They are used in the following ways:
WARNING
This is used to indicate the presence of a
hazard that could cause death or serious
personal injury. To avoid or reduce the risk,
the procedures must be followed precisely.
CAUTION
This is used to indicate the presence of a
hazard that could cause minor or moderate
personal injury or damage to your vehicle. To
Condition:
CarManuals2.com

(5,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
avoid or reduce the risk, the procedures must
be followed carefully.
SIC0697
If you see the symbol above, it means “Do not
do this” or “Do not let this happen”.
NOS1274
If you see a symbol similar to those above in an
illustration, it means the arrow points to the
front of the vehicle.
NOS1275
Arrows in an illustration that are similar to
those above indicate movement or action.
NOS1276
Arrows in an illustration that are similar to
those above call attention to an item in the
illustration.
CALIFORNIA PERCHLORATE
ADVISORY
MVDGED1-F5F34C01-F9A4-4179-B302-7D5AC3FD83E7
Some vehicle parts, such as lithium batteries,
may contain perchlorate material. The fol-
lowing advisory is provided: “Perchlorate
Material - special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlo-
rate.”
© 2022 Mitsubishi Motors Corporation
All rights reserved. No part of this Owner’s
Manual may be reproduced or stored in a
retrieval system, or transmitted in any form, or
by any means, electronic, mechanical, photo-
copying, recording or otherwise, without the
prior written permission of Mitsubishi Motors
Corporation.
Condition:
CarManuals2.com

(1,1)
Illustrated table of contents 0
Overview 1
Charging
Safety — Seats, seat belts and supplemental restraint system
Instruments and controls
Pre-driving checks and adjustments
Monitor, heater, air conditioner, audio and phone systems
Starting and driving
In case of emergency
Appearance and care
Do-it-yourself
2
3
4
5
6
7
8
9
10
Table of
Contents
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
Condition:
Maintenance and schedules 11
Technical and consumer information/Reporting Safety Defects 12
Index 13
CarManuals2.com

(2,1)
CarManuals2.com

(7,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
0 Illustrated table of contents
Seats, seat belts and Supplemental Restraint
System (SRS) .................................................................... 0-2
Exterior front ..................................................................... 0-3
Exterior rear ....................................................................... 0-4
Passenger compartment ..................................................... 0-5
Cockpit .............................................................................. 0-6
Instrument panel ............................................................... 0-7
Meters and gauges ............................................................ 0-8
Engine compartment ......................................................... 0-9
Warning and indicator lights .......................................... 0-10
Condition:
CarManuals2.com

(8,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
0-2 Illustrated table of contents
MVDGED1-52AF6180-E2C9-4318-AF4E-9DE2FF882623
WAA0188X
1. Front SRS airbags (P.3-49)
2. Front passenger airbag status light (P.3-57)
3. Occupant classification sensors (weight sen-
sors) (P.3-49)
4. Seat belts (P.3-18)
5. Head restraints (P.3-14)
6. Side Curtain SRS airbags (P.3-49)
7. Child restraint anchor point (for top tether
strap) (P.3-33)
8. Third row seats (P.3-11)
9. Driver and passenger SRS knee airbags (P.3-49)
10. Front seats (P.3-3)
11. Front seat-mounted SRS center airbag (P.3-49)
12. Seat belt pretensioner (P.3-70)
13. Front seat-mounted SRS side airbags (P.3-49)
14. Second row seats (P.3-7)
15. LATCH (Lower Anchors and Tethers for
CHildren) system (for second row seats)
(P.3-31)
16. Second-row outboard seat-mounted SRS side
airbags (P.3-49)
SEATS, SEAT BELTS AND SUPPLEMENTAL
RESTRAINT SYSTEM (SRS)
Condition:
CarManuals2.com

(9,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
MVDGED1-CFE71A9F-8404-4B1C-84DD-FF8048FB8B69
WBA0018X
1. Hood (P.5-19)
2. Windshield wiper and washer
— Switch operation (P.4-65)
— Window washer fluid (P.10-8)
— Windshield wiper deicer* (P.4-70)
3. Front camera* (P.7-41, P.7-46, P.7-38, P.7-52,
P.7-91, P.7-127)
4. Power panoramic sunroof* (P.4-100)
5. Power windows (P.4-97)
6. Side turn signal light (P.4-76)
7. Fuel filler door (P.5-28)
— Fuel selection (P.1-16)
8. Front parking sensor* (P.7-165)
9. Front view camera* (P.6-9)
10. Daytime running lights/parking lights and front
turn signal lights (P.4-71)
11. Headlight cleaners* (P.4-76)
12. Fog lights* (P.4-77)
13. Headlights (P.4-71)
14. Tires
— Wheels and tires (P.10-21, P.12-6)
— Flat tire (P.8-4)
— Tire Pressure Monitoring System [TPMS]
(P.4-19, P.7-6)
15. Door mirrors (P.5-37)
16. Side view camera* (P.6-9)
17. Doors
— Keys (P.5-2)
— Door locks (P.5-4)
— Free-hand Advanced Security Transmitter
[F.A.S.T.-key] (P.5-7)
— Security system (P.4-63)
*: if so equipped
Illustrated table of contents 0-3
EXTERIOR FRONT
Condition:
CarManuals2.com

(10,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
0-4 Illustrated table of contents
MVDGED1-CB027B35-0C4A-475A-B68D-3A7DA1020D00
WBA0019X
1. Electric rear window defroster (P.4-69)
2. Rear window wiper
— Switch operation (P.4-68)
— Window washer fluid (P.10-8)
3. High-mounted stop light (P.10-19)
4. Antenna (P.6-36)
5. Roof rail* (P.4-96)
6. Rear parking sensor
— Parking sensor system* (P.7-165)
— Rear parking sensor System* (P.7-170)
— Rear Automatic Emergency Braking [Rear
AEB]* (P.7-148)
7. Liftgate (P.5-20)
— Free-hand Advanced Security Transmitter
[F.A.S.T.-key] (P.5-7)
8. Rearview camera (P.6-2, P.6-9)
9 EV charging cable* (P.2-6)
10. Tail lights/stop lights/Rear turn signal lights and
Back-up lights (P.10-19)
11. Charging lid (P.2-2)
12. Child safety rear door locks (P.5-6)
*: if so equipped
EXTERIOR REAR
Condition:
CarManuals2.com

(11,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
MVDGED1-7405A9C6-9DB6-43D6-BB85-7D8784BD39F1
WAA0191X
1. Inside mirror (P.5-36)
2. Driver memory settings switch* (driver’s side
door) (P.5-40)
3. Sunglasses holder (P.4-92)
4. Map lights (P.4-102)
— Microphone**
— SOS switch* (P.4-88)
5. Power panoramic sunroof switch* (P.4-100)
6. Sunvisors (P.5-34)
7. Dome light* (P.4-103)
8. Personal light* (P.4-103)
9. Coat hanger (P.4-94)
10. Rear armrest (P.3-10)
— Rear cup holders (P.4-90)
11. Cargo area
— Storage (P.4-91)
— Luggage hooks (P.4-93)
— Tonneau cover* (P.4-95)
— 12V power outlet* (P.4-81)
— 120V AC socket (1500W)* (P.4-84)
— Cargo room light (P.4-104)
— Tire repair kit (P.8-4)
— Auxiliary battery (P.10-8)
12. Door armrest
— Power window switch (P.4-97)
— Power door lock switch (driver’s side door)
(P.5-6)
— Door mirror remote control switch (driver’s
side door) (P.5-37)
13. Front cup holders (P.4-90)
14. Console box (P.4-92)
— USB (Universal Serial Bus) charging out-
let* (P.4-81)
— 120V AC socket (1500W)* (P.4-84)
*: if so equipped
**: Refer to the separate Smartphone-link Display
Audio [SDA] Owner’s Manual.
Illustrated table of contents 0-5
PASSENGER COMPARTMENT
Condition:
CarManuals2.com

(12,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
0-6 Illustrated table of contents
MVDGED1-B18D921D-58BF-4EF2-ABA7-71D7C369DE14
WBA0021X
1. Instrument brightness control (P.4-10)
2. Fuel filler door opener switch (P.5-28)
3. 120V AC socket (1500W) switch (P.4-84)
4. Power liftgate switch* (P.5-20)
5. Headlight and turn signal switch (P.4-71)/Fog-
light switch* (P.4-77)
6. Steering wheel remote control switches (left
side)
— Audio control**
— Multi-information display control (P.4-22)
7. Power switch (P.7-13)
8. Steering wheel remote control switches (right
side)
— Cruise control* (P.7-70)
— Adaptive Cruise Control [ACC]* (P.7-72)
— MI-PILOT Assist* (P.7-91)
— Bluetooth® Hands-Free Phone System**
— Voice Recognition system switch**
9. Wiper and washer switch (P.4-65)
10. Wireless charger* (P.4-82)
11. Shift lever (P.7-19)
12. LDP switch*(P.7-46)
13. Head-Up Display [HUD] switch* (P.4-60)
14. Charge Now switch (P.2-27)
15. Charge connector unlock switch (P.2-20)
16. Steering wheel (P.5-34)
— Horn (P.4-77)
*: if so equipped
**: Refer to the separate Smartphone-link Display
Audio [SDA] Owner’s Manual.
COCKPIT
Condition:
CarManuals2.com

(13,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
MVDGED1-E541DB03-EC76-48F2-8AC1-CDA28F389925
WBA0024X
1. Side ventilator (P.6-27)
2. Regenerative braking level selector (paddle
type) (P.7-21)
3. Meters and gauges (P.4-5)/Clock (P.4-59)
4. Head-Up Display [HUD]* (P.4-60)
5. Center ventilator (P.6-26)
6. Audio system** or navigation system**
— Rearview camera* (P.6-2)
— Multi Around Monitor* (P.6-9)
— Bluetooth® Hands-Free Phone System**
7. Fuse box cover (P.10-14)
8. Hood release handle (P.5-19)
9. Steering wheel lock lever (P.5-34)
10. Heater/air conditioner control (P.6-27)
— Defroster switch (P.4-69)
— Windshield deicer switch* (P.4-70)
— Heated seat switch* (P.4-78)
— Heated steering wheel switch* (P.4-78)
11. USB (Universal Serial Bus) input terminal**
12. Drive mode selector (P.7-36)
— Hill Descent Control switch (P.7-162)
13. Innovative Pedal Operation Mode switch (P.7-
32)
14. Brake Auto Hold switch (P.7-26)
15. Parking brake switch (P.7-24)
16. EV mode selector switch (P.7-28)
17. 12V power outlet (P.4-81)
18. Glove box (P.4-91)
19. Hazard warning flasher switch (P.8-2)
*: if so equipped
**: See the separate Smartphone-link Display
Audio [SDA] Owner’s Manual.
Illustrated table of contents 0-7
INSTRUMENT PANEL
Condition:
CarManuals2.com

(14,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
0-8 Illustrated table of contents
MVDGED1-ADD7704B-E089-476F-B602-46E63AF51822
WBA0020X
1. Energy usage indicator (P.4-8)
2. Personal display (P.4-24)
3. Multi-information display (P.4-22)
— Distance to empty/Odometer (P.4-7, P.4-11)
4. Outside air temperature (P.4-60)
5. Clock (P.4-59)
6. Speedometer (P.4-7)
7. Digital speedometer (P.4-7)
8. Drive mode indicator (P. 7-36)
9. Energy level gauge (P.4-9)
10. EV cruising range (P.4-7)
11. EV mode indicator (P.4-11)
12. Shift position indicator (P.4-10 )
13. Total cruising range (P.4-7)
14. Odometer (P.4-11)
15. Fuel gauge (P.4-9)
Warning/indicator lights (P.4-12)
METERS AND GAUGES
Condition:
CarManuals2.com

(15,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
MVDGED1-8EBBE60D-ED28-4099-9931-95512256E0F1
WBA0022X
1. Engine coolant reservoir (P.10-5)
2. Air cleaner (P.10-10)
3. Brake fluid reservoir (P.10-7)
4. Plug-in Hybrid EV system coolant reservoir
(P.10-4)
5. Window washer fluid reservoir (P.10-8)
6. Engine oil dipstick (P.10-6)
7. Engine oil filler cap (P.10-6)
8. Fuse/fusible link box (P.10-13)
Illustrated table of contents 0-9
ENGINE COMPARTMENT
Condition:
CarManuals2.com

(16,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
0-10 Illustrated table of contents
MVDGED1-56F49709-8C97-4624-BC9E-EFFB2D8B65F4
Red
light Name Page
Auxiliary battery charge
warning light 4-14
Brake warning light 4-14
Electric shift control system
warning light 4-15
Electric parking brake
warning light 4-15
Engine oil pressure warning
light 4-15
Hands OFF warning light
(if so equipped) 4-15
Master warning light (red) 4-16
Seat belt warning light 4-16
SRS airbag warning light 4-16
Yellow
light Name Page
Active stability control
[ASC] warning light 4-16
Active stability control
[ASC] off indicator light 4-17
Acoustic Vehicle Alerting
System [AVAS] warning
light
4-17
Anti-lock Braking System
[ABS] warning light 4-17
Brake system warning light 4-17
Check engine warning light 4-17
Electric power steering
warning light 4-18
Forward Collision Mitiga-
tion System [FCM] OFF
warning light (if so
equipped)
4-18
Hill Descent Control sys-
tem ON indicator light 4-18
Low tire pressure warning
light 4-19
Master warning light (yel-
low) 4-20
Yellow
light Name Page
Plug-in Hybrid EV System
warning light 4-20
Rear Automatic Emergency
Braking [Rear AEB] system
OFF warning light (if so
equipped)
4-20
WARNING AND INDICATOR LIGHTS
Condition:
CarManuals2.com

(17,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
Other
light Name Page
Automatic High Beam
[AHB] indicator light (if so
equipped)
4-20
Brake Auto Hold indicator
light (orange) 4-20
Brake Auto Hold indicator
light (green) 4-20
Charging indicator 4-21
Drive battery temperature
warning light 4-21
Exterior light indicator 4-21
Front fog light indicator
light (if so equipped) 4-21
High beam indicator light 4-21
Innovative Pedal Operation
Mode indicator 4-21
READY indicator 4-21
Turn signal/hazard indicator
lights 4-21
Illustrated table of contents 0-11
Condition:
CarManuals2.com

(18,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
0-12 Illustrated table of contents
MEMO
Condition:
CarManuals2.com

(19,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
1 Overview
Plug-in Hybrid EV System ............................................... 1-2
Main features ................................................................ 1-2
Operation of gasoline engine ....................................... 1-4
Refueling (gasoline) ..................................................... 1-5
Drive battery ...................................................................... 1-5
Characteristics .............................................................. 1-6
Precautions for operation ............................................. 1-6
EV cruising range ............................................................. 1-6
Acoustic Vehicle Alerting System [AVAS] ...................... 1-7
Operating sound under charging ....................................... 1-7
In case of a collision ......................................................... 1-7
Inspection and maintenance .............................................. 1-9
High-voltage components .......................................... 1-10
For persons with electro-medical apparatus ................. 1-11
Cautions and actions to deal with intense heat .............. 1-12
Cautions and actions to deal with intense cold ............. 1-14
Fuel selection ................................................................... 1-16
Gasoline detergent additives ...................................... 1-16
Octane requirement .................................................... 1-16
Oxygenated gasoline ................................................ 1-16
Ethanol (Gasohol) ..................................................... 1-16
Methanol ................................................................... 1-16
Reformulated gasoline .............................................. 1-16
MMT (methylcyclopentadienyl
manganese tricarbonyl) ............................................ 1-16
Sulfur in gasoline ..................................................... 1-17
Filling the fuel tank ........................................................ 1-17
Installation of accessories ............................................... 1-17
Important points! ...................................................... 1-18
Modification/alterations to the electrical or
fuel systems .................................................................... 1-18
Genuine Parts .................................................................. 1-18
Safety and disposal information for used engine oil ....... 1-19
Protect the environment ........................................... 1-19
Do not carry fuel-filled containers or spray cans
inside your vehicle ......................................................... 1-19
Event Data Recorders (EDR) ......................................... 1-19
Additional data recording ......................................... 1-20
Condition:
CarManuals2.com

(20,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
1-2 Overview
MVDGED1-C3B31910-7FC6-489A-B344-CBAC949D5111
MAIN FEATURES
MVDGED1-44F3BC48-528A-4370-AA2E-EA62C6FC8C91
It is operated as electric vehicle in the EV drive
mode using the electrical power stored in the
drive battery*1, according to the remaining
amount of the drive battery. It is also automatic
control*2 for driving in series hybrid mode or
parallel hybrid mode using engine power from
EV drive mode according to the driving
condition or if the charging level of the drive
battery is decreased.
*1: If there is a remaining amount in the drive
battery, it is actively driven in the EV drive
mode. The cruising range varies depending on
the remaining charge in the drive battery,
vehicle speed, and air conditioner operating
conditions.
*2: You can adjust the timing to switch to the EV
drive mode by using the SAVE mode.
Refer to “EV mode selector switch” (P.7-28).
.With the high performance motor, noise and
vibration during driving is minimized
limited and powerful acceleration can also
be obtained.
.With the regenerative brake, the drive
battery is automatically charged when the
accelerator is released.
.Your vehicle comes standard with a charge
port and charging cable (EV charging cable)
that uses a household outlet (AC 120 V) as
a charging source.
.You may also charge your vehicle using an
OUTLANDER compatible 240 V charging
device (EVSE:Electric Vehicle Supply
Equipment).
.As an optional feature, your vehicle may
come equipped with an additional quick
charge port to be used with a CHAdeMO
quick charger.
EV drive mode
MVDGED1-B3030083-ACA5-4E55-AA0C-3B36B5448D58
.The vehicle is driven by the motors only
using electrical power stored in the drive
battery. However, EV drive mode is can-
celed depending on the drive battery level,
vehicle speed, and air conditioner operating
conditions. Pay attention to the following
points:
— Check the EV cruising range in the
information screen. Refer to “EV cruis-
ing range display/Total cruising range
display” (P.4-7).
— Drive your vehicle at moderate speeds
avoiding quick acceleration/deceleration.
Repeated quick acceleration/deceleration
causes the drive battery level to decrease
quickly, which extremely reduces the EV
cruising range.
.If you want to drive the vehicle without
starting the engine as much as possible,
make the switch to the EV priority mode by
pressing the EV mode switch. Refer to “EV
mode selector switch” (P.7-28).
Series hybrid mode
MVDGED1-B47B7260-8B1E-4F2D-8DE1-F47F1979C979
.The vehicle is driven by the motors only
using the electricity generated by the
engine. This mode is used when the drive
battery level is low, at quick acceleration, or
when power is required like climbing uphill.
Parallel hybrid mode
MVDGED1-E97E4954-4257-4404-B9F7-90572384DB8B
.The vehicle is driven by the power of the
engine, assisted by motors. This mode is
used during high-speed driving with better
engine efficiency.
PLUG-IN HYBRID EV SYSTEM
Condition:
CarManuals2.com

(21,1)
[ Edit: 2022/ 4/ 12 Model: DGE-D ]
The roles of the motors and engine in each drive mode
MVDGED1-FAC12C9C-84FA-49F8-99B9-D4AA8C40DE39
Motor Engine
EV Drive Mode Drives the vehicle OFF
Series Hybrid Mode Drives the vehicle Generates electricity
Parallel Hybrid Mode Drives the vehicle Drives front wheels and generates electricity
Regenerative braking
MVDGED1-D907F01F-123A-4293-A711-68037DF0D0EC
Motion energy is converted into electric energy
using the motor as a power generator.
Then a braking force generates and converted
electric energy will be charged to the drive
battery.
.If you lift your foot off the accelerator pedal
during driving, a braking force that is
designed equivalent to engine braking of a
combustion engine vehicle will be gener-
ated. Also, if you shift the select position
into “B” (Regenerative Brake) from “D”
(Drive), effectiveness of the regenerative
braking is getting strong. Shift the shift
lever into “B” (Regenerative Brake) posi-
tion according to the driving condition.
.When you depress the brake pedal, the
regenerative braking force may be in-
creased.
.If a problem occurs in the Plug-in hybrid
EV system, or if the ABS and/or the ASC
have been activated, the regenerative brak-
ing will be restricted. The foot brake will
still operate.
.When stronger regenerative braking is
generated, the stop lights will illuminate
even when the brake pedal is not depressed.
.With regenerative braking, the closer the
drive battery is to a full charge and the
Overview 1-3
Condition:
CarManuals2.com
