Mitsubishi Mr.SLIM PLA-RP-AA User manual

Air-Conditioners
PLA-RP·AA / PUHZ-RP·HA
PU (H)-P·GAA
OPERATION MANUAL
For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit.
FOR USER
English

2
1. Safety Precautions ...................................................................................................................................................................... 2
2. Operation..................................................................................................................................................................................... 3
3. Care and cleaning ....................................................................................................................................................................... 5
4. Troubleshooting ........................................................................................................................................................................... 6
5. Specifications .............................................................................................................................................................................. 7
Contents
sBefore installing the unit, make sure you read all the “Safety precautions”.
sThe “Safety precautions” provide very important points regarding safety. Make sure you follow them.
sThis equipment may not be applicable to EN60555-2:1987/EN61000-3-2:1995+A1:1998+A2:1998 and/or EN60555-
3:1987+A1:1991/EN61000-3-3:1995.
sThis equipment may cause the adverse effect on the same supply system.
sPlease report to or take consent by the supply authority before connection to the system.
Symbols used in the text
Warning:
Describes precautions that should be observed to prevent danger of injury or death to the user.
Caution:
Describes precautions that should be observed to prevent damage to the unit.
Symbols used in the illustrations
: Indicates an action that must be avoided.
: Indicates that important instructions must be followed.
: Indicates a part which must be grounded.
: Indicates that caution should be taken with rotating parts.
: Indicates that the main switch must be turned off before servicing.
: Beware of electric shock.
: Beware of hot surface.
ELV
: At servicing, please shut down the power supply for both of Indoor Unit and Outdoor Unit.
Warning:
Carefully read the labels affixed to the main unit.
Warning:
•The unit should not be installed by the user. Ask the dealer or an authorized company to install the unit. If the unit is installed improperly,
water leakage, electric shock or fire may result.
•Do not stand on, or place any items on the unit.
•Do not splash water over the unit and do not touch the unit with wet hands. An electric shock may result.
•Do not spray combustible gas close to the unit. Fire may result.
•Do not place a gas heater or any other open-flame appliance where it will be exposed to the air discharged from the unit. Incomplete
combustion may result.
•Do not remove the front panel or the fan guard from the outdoor unit when it is running.
•When you notice exceptionally abnormal noise or vibration, stop operation, turn off the power switch, and contact your dealer.
•Never insert fingers, sticks etc. into the intakes or outlets.
•If you detect odd smells, stop using the unit, turn off the power switch and consult your dealer. Otherwise, a breakdown, electric shock or
fire may result.
•This air conditioner is NOT intended for use by children or infirm persons without supervision.
•Young children should be supervised to ensure that they do not play with the air conditioner.
•If the refrigeration gas blows out or leaks, stop the operation of the air conditioner, thoroughly ventilate the room, and contact your dealer.
Caution:
•Do not use any sharp object to push the buttons, as this may damage the remote controller.
•Never block or cover the indoor or outdoor unit’s intakes or outlets.
Disposing of the unit
When you need to dispose of the unit, consult your dealer.
1. Safety Precautions

3
Replacing the Batteries and how to set the current time
If no signal is transmitted and the indoor unit’s lamp does not light up even
if the remote controller is operated, the batteries may have run out, so
replace them with new ones as described below.
1Remove the front lid.
2Replace the batteries with alkali batteries (size AAA). Make sure that
the batteries are installed in the correct direction. (Insert the minus
pole of the batteries first.)
3Reattach the front lid.
4Press the RESET button using a thin stick.
5Press the
h
and
min
button to set the current time.
6Press the CLOCK button using a thin stick and close the front lid.
If you are not going to use the unit for a long period of time, remove the
batteries to prevent damage which may occur due to leakage of electro-
lyte.
1
2
3
4
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
5
6
1
TIMER SET
ON/OFF
˚C
˚C
FILTER
CHECK TEST
TEMP.
1
A
1
B
2
TIMER SET
ON/OFF
˚C
˚C
FILTER
CHECK TEST
TEMP.
2
B
1
A
TIMER SET
ON/OFF
˚C
˚C
FILTER
CHECK TEST
TEMP.
A
1
1
A
2. Operation
Check if your remote controller is the wired type or the wireless type before
referring to the illustration and text for operation procedures.
2.1. Switching the unit on/off
•The power supply should not be turned off while the air conditioner is in
use. This can cause the unit to break down.
1Press the ON/OFF button.
AThe ON indicator should light up.
•Even if you press the ON/OFF button immediately after shutting down
the operation in progress, the air conditioner will not start for about three
minutes. This is to prevent the internal components from being dam-
aged.
•If the operation stops due to a power failure, the unit will not automati-
cally restart until the power has been restored. Press the ON/OFF but-
ton to restart.
2.2. Mode select
1If the unit is off, press the ON/OFF button to turn it on.
AThe ON indicator should light up.
2Press the operation mode ( ) button and select the op-
eration mode.
B
Cooling mode
Fan mode
Heating mode
Drying mode
Automatic (cooling/heating) mode
Note:
The heating display and the automatic display does not appear in models that
operate exclusively as cooling only air-conditioner.
2.3. Selecting a temperature
TEMP.
ss
ss
sTo decrease the room temperature:
1Press button to set the desired temperature.
AThe selected temperature is displayed.
•Each time you press the button, the temperature value decreases by 1
°C.
ss
ss
sTo increase the room temperature:
1Press button to set the desired temperature.
AThe selected temperature is displayed.
•Each time you press the button, the temperature value increases by 1
°C.
•Available temperature ranges are as follows:
Cooling & Drying: 19 - 30 °C
Heating: 17 - 28 °C
Automatic: 19 - 28 °C
Circulation: —(Not available)
•The display flashes either 8 °C - 39 °C to inform you if the room tem-
perature is lower or higher than the displayed temperature.
s

4
TIMER SET
ON/OFF
˚C
˚C
1Hr.
FILTER
CHECK TEST
TEMP.
F
1
ON OFF
ON OFF
TIMER SET
ON/OFF
CLOCK
˚C
˚C
FILTER
CHECK TEST
TEMP.
A
21
B
↑
TIMER SET
ON/OFF
CLOCK
ON OFF
˚C
˚C
FILTER
CHECK TEST
TEMP.
1
D
B
2
3
CA
1
A
TIMER SET
ON/OFF
˚C
˚C
FILTER
CHECK TEST
TEMP.
A
1
2.4. Selecting a fan speed
1Press button to select a desired fan speed.
•Each time you press the button, available options change with the dis-
play Aon the remote controller, as shown below.
Fan speed Remote controller display
Low Middle 2 Middle 1 High
4-stage
The display and the fan speed of the unit will differ in the following situa-
tions:
•When STAND BY and DEFROST are displayed.
•Just after the heating mode (while waiting to change to another mode).
•When the temperature of the room is higher than the temperature set-
ting of the unit operating in the heating mode.
•In the dry operation, the indoor fan automatically turns to low-speed
operation. Switching of fan speed is impossible.
▼
▼ ▼ ▼
1
ABCDE
2. Operation
2.5. Adjusting vertical airflow direction
■Except for PSA/PSH series
The vertical air vane helps select the vertical direction of the airflow.
1Press button to select the vertical airflow direction.
•Each time you press the button, the option changes are displayed on
the remote controller, as shown below.
A(swing) →B→C→D→E→A
•If the room temperature is higher than the temperature set on the re-
mote controller while the unit is defrosting or preparing for heating, the
vertical air vane will move to the horizontal airflow position (B).
•In either cooling or dry mode, if you select C, Dor Ewhen the fan
speed is low, middle 2, a display reading “1 Hr”Fwill appear.
After one hour, the air conditioner will switch automatically to horizontal
air mode Band the display “1 Hr”Fwill disappear.
•When the heating thermostat is OFF, the louver automatically turns hori-
zontally during defrosting or preparation for heating.
2.6. Using the timer
1) Set the current time
1Press button to display the “CLOCK”B.
Remote CLOCK →
CLOCK
ON
→
CLOCK
OFF
→ No Display
controller display A
2Each time you press button, the time increases in increments of
one minute. Each time you press button, the time decreases in
increments of one minute.
•Press and hold the button to rapidly change the time.
•The time changes in increments of one minute → ten minutes → in units
of hour; in this order.
•Approximately ten seconds after pressing the button, the display on the
remote controller will turn off.
The example shows a timer set for operation start at 8:00 and end at 17:00.
2) Set the mode to continuous as follows
1Press button to display D .
3) Set the time to start the unit as follows
2Press button to display B
ON
.
3Press
TIMER SET
button to set the time that you want the unit to start.
The start time is displayed at A.
4) Set the time to stop the unit as follows
2Press button to display C
OFF
.
3Press
TIMER SET
button to set the time that you want the unit to stop.
The stop time is displayed at A.
5) Set the mode to timer as follows
1Press button to display D .

5
A
13
2
For wireless remote controller
1Press the
AUTO STOP
or
AUTO START
button (TIMER SET).
•Time can be set while the following symbol is blinking.
OFF timer : Ais blinking.
ON timer : Ais blinking.
2Use the
h
and
min
buttons to set the desired time.
3Canceling the timer.
To cancel the OFF timer, press the
AUTO STOP
button.
To cancel the ON timer, press the
AUTO START
button.
•It is possible to combine both OFF and ON timers.
•Pressing the ON/OFF button of the remote controller during timer
mode to stop the unit will cancel the timers.
•If the current time has not been set, the timer operation cannot be used.
B
A
D
C
■PLA-RP·AA
TIMER SET
ON/OFF
˚C
FILTER
˚C
FILTER
CHECK TEST
TEMP.
1
A
3. Care and cleaning
2. Operation
3.1. Cleaning the filters and the indoor unit
Cleaning the filters
•Clean the filters using a vacuum cleaner. If you do not have a vacuum
cleaner, tap the filters against a solid object to knock off dirt and dust.
•If the filters are especially dirty, wash them in lukewarm water. Take care
to rinse off any detergent thoroughly and allow the filters to dry com-
pletely before putting them back into the unit.
Caution:
•Do not dry the filters in direct sunlight or by using a heat source,
such as an electric heater: this may warp them.
•Do not wash the filters in hot water (above 50°C), as this may warp
them.
•Make sure that the air filters are always installed. Operating the
unit without air filters can cause malfunction.
Caution:
•Before you start cleaning, stop operation and turn OFF the power
supply.
•Indoor units are equipped with filters to remove the dust of sucked-
in air. Clean the filters using the methods shown in the following
sketches.
■PLA-RP·AA
1Pull the knob on the intake grille in the direction indicated by the
arrow and it should open.
2Open the intake grille.
3Release the knob on the center edge of the intake grille and pull the
filter forward to remove the filter.
A Knob B Grille C Intake grille D Filter
3.2. Care and cleaning
Clean the filter
When the A“FILTER”indicator blinks on the remote controller to alert you
to the necessity of cleaning of the filter.
∗As a guideline for typical office environment, the long-life filter must be
cleaned every 2,500 operating hours.
Reset the FILTER indicator
1Press the FILTER button twice after cleaning.
sWhen you press the FILTER button twice, the “FILTER”indicator A
will be turned off and reset.
sThe FILTER indicator provides you with a guideline for the neces-
sity of filter cleaning based on total operating hours in typical in-
door air conditions. Depending on different operating environments,
more or less frequent cleaning may be necessary.

6
Problem
Unit does not cool or heat very well.
The unit stops operating before ar-
riving at the set temperature in the
heating mode.
The airflow direction suddenly
changes.
A white mist is expelled from the in-
door unit.
The indicators of the remote control-
ler do not light up when operated.
Problem
CENTRALLY CONTROLLED is dis-
played in the remote controller.
The start and stop functions are not
available just after restarting the unit.
“H0”is displayed in the remote con-
troller.
An error code is displayed in the re-
mote controller.
The operating display of the wireless
remote controller’s receiver is flash-
ing.
Solution
The start and stop functions of the
remote controller are not available
when the CENTRALLY CONTROL-
LED message is lit.
Wait about three minutes (operation
has stopped to prevent damage to
the air conditioner).
An automatic startup test is being
performed (will last for about two min-
utes).
A self-diagnostic function is being
performed to preserve the air condi-
tioner.
* Do not attempt to make repairs
yourself. Turn the main switch off
and contact the dealer from whom
you bought the air conditioner. Pro-
vide him or her with the name of the
unit and the information displayed
in the remote controller.
Solution
Clean the filter.
Frost forms when the outdoor tem-
perature is low and humidity is high.
Wait for about 10 minutes for the frost
to melt.
After one hour of cooling-mode op-
eration with the airflow in a down-
ward direction, the unit will automati-
cally change to the “Horizontal air-
flow”mode.
When the unit is in the heating or de-
frosting mode, it will automatically
change to the “Horizontal airflow
mode”.
This may occur just after the unit is
turned on when a high level of hu-
midity is present in the room.
Turn on the power switch. “·”will be
displayed.
Before you call out a repair man, check the following table to see whether there is a simple solution to your problem.
[for wireless remote controller]
[for wired remote controller]
NOTE: After a power cut, the unit will not restart automatically. You will have to restart it by pressing the POWER - ON/OFF button on the remote controller.
If none of the above apply, turn the main switch off and contact the dealer from whom you bought the air-conditioner, telling him the model name and the
nature of the problem. Do not try to fix the unit yourself.
In any of the following cases, turn off the main power switch
and contact your local dealer for service:
•The operation lamp (on the main unit) flashes.
•The switches do not work properly.
•The circuit breaker trips frequently (or the fuse blows frequently).
•Water has accidentally been splashed into the unit.
•Water leaks from the unit.
•Something is accidentally dropped into the air-conditioner.
•An unusual noise is heard during operation.
The following do not indicate any malfunction:
Odours: smells such as tobacco or cosmetic odours may persist after they have been sucked into the unit.
Sound of liquid flowing inside indoor unit: this can occur during or after operation and is simply the sound of refrigerant being circulated inside the unit.
Ticking sound coming from indoor unit: this can occur when cooling or heating has just begun or has just stopped. It is caused by the indoor unit shrinking
or expanding slightly due to the change in temperature.
The message “CENTRALLY CONTROLLED”appearing on the LCD panel: from time to time, this message may come up on the LCD panel.This does not
indicate any malfunction.
Remote Controller Settings for Installing/Replacing Batteries and Restarting Operation (for wireless remote con-
troller)
•Always press the reset button after installing or replacing batteries.
•The initial settings are used when installing or replacing batteries after which the settings for restarting are used.
Initial Settings Restarting
Operating mode Fan Previous operating mode
Temperature setting —Previous temperature setting
Fan speed High Previous fan speed setting
Airflow direction Level Operating mode
Cooling - Dry Level
Heating Previous setting
Fan Level
NOTE: The refrigerant charged in the air conditioner is safe. Refrigerant normally does not leak, however, if refrigerant gas leaks indoors, and comes into contact
with the fire of a fan heater, space heater, stove, etc., harmful substances will be generated.
Be sure to ask the service representative whether there is refrigerant leakage or not when repairs are carried out.
Problem
Unit does not operate at all.
Problem
Unit does not start immediately.
Solution
Wait until the unit restarts automati-
cally. The compressor may hesitate
resuming because a three-minute
resume prevention circuit is incorpo-
rated in the outdoor unit for protec-
tion of the compressor.
Solution
Turn main power on. Then press the
POWER ON/OFF button to turn the
unit on.
Wait until power is restored, then
press the POWER ON/OFF button
to turn the unit on.
Operating range
Indoor air intake temperature Outdoor air intake temperature
Cooling Maximum 35 °C DB, 22.5 °C WB 46 °C DB
Minimum 19 °C DB, 15 °C WB –5 °C DB
Heating Maximum 28 °C DB 21 °C DB, 15 °C WB
Minimum 17 °C DB –11 °C DB, –12 °C WB
4. Troubleshooting

7
RP3 RP4 RP5 RP6
V:~/N 220-230-240/50
943 1350
950
330+30
55 100
75 121
Model
Capacity (Cooling/Heating) <kW>*1
Total Input (Cooling/Heating) <kW>*1
Power source (voltage <V>/Frequency <Hz>)
Dimension (Height) <mm>*2
Dimension (Width) <mm>*2
Dimension (Depth) <mm>*2
Fan Airflow rate (Low-Middle2-Middle1-High) <m
3
/min>
Noise level (Low-Middle2-Middle1-High) <dB>
Net weight <kg>*2
■PLA-RP·AA+PU(H)-P·GAA
■PU(H)-P·GAA
Model
Power source (voltage <V>/Frequency <Hz>)
Dimension (Height) <mm>
Dimension (Width) <mm>
Dimension (Depth) <mm>
Fan Airflow rate <m3/min>
Net weight <kg>
RP3 RP4 RP5 RP6
7.70/9.20 9.60/10.50 13.30/15.60 14.20/17.00
3.42/3.48 3.68/3.91 5.09/5.54 5.90/6.35
–
258 (30) 298 (30)
840 (950)
840 (950)
15-16-18-20 20-23-26-28 22-25-28-30
28-30-32-34 33-36-39-41 37-40-43-45
24 (5) 30 (5) 32 (5)
P3V P4V
P3Y P4Y P5Y P6Y
V:~/N220-230-240/50, Y:3N~380-400-415/50 3N~ 380-400-415/50
855 1260
900 1050
330+20
50 85 95 100
79 97 112 113
Model
Capacity (Cooling/Heating) <kW>*1
Total Input (Cooling/Heating) <kW>*1
Power source (voltage <V>/Frequency <Hz>)
Dimension (Height) <mm>*2
Dimension (Width) <mm>*2
Dimension (Depth) <mm>*2
Fan Airflow rate (Low-Middle2-Middle1-High) <m
3
/min>
Noise level (Low-Middle2-Middle1-High) <dB>
Net weight <kg>*2
■PLA-RP·AA+PUHZ-RP·VHA
RP3 RP4 RP5 RP6
7.10/8.00 10.00/11.20 12.50/14.00 14.00/16.00
1.97/2.34 3.03/3.39 3.89/4.27 4.99/4.91
–
258 (30) 298 (30)
840 (950)
840 (950)
15-16-18-20 20-23-26-28 22-25-28-30
28-30-32-34 33-36-39-41 37-40-43-45
24 (5) 30 (5) 32 (5)
■PUHZ-RP·VHA
Model
Power source (voltage <V>/Frequency <Hz>)
Dimension (Height) <mm>
Dimension (Width) <mm>
Dimension (Depth) <mm>
Fan Airflow rate <m3/min>
Net weight <kg>
*1 Cooling: Indoor 27 °CDB/19 °CWB, Outdoor 35 °CDB
Heating: Indoor 20 °CDB, Outdoor 7 °CDB/6 °CWB
*2 This figure in ( ) indicates panel’s.
5. Specifications

Please be sure to put the contact address/telephone number on
this manual before handing it to the customer.
HEAD OFFICE: MITSUBISHI DENKI BLDG., 2-2-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN
Printed in Japan
BG79U016H02
