MIW KWP-3076 User manual

3 SPEED OSCILLATING WALL FAN
MODEL: KWP-3076
READ AND SAVE THESE INSTRUCTIONS
1 - Guard screw
2 - Guard ring
3 - Front guard
4 - Screw blade
5 - Fan blade
6 - Screw motor
7 - Rear guard
8 - Motor shaft
9 - Motor assembly
10 - Wall bracket
11 - Screw base.
a. Fix the wall bracket (No.10) firmly with screw base (No.11).
b. Hang motor assembly (No.9) wall bracket (No.10).
c. Fix the rear guard (No.7) on the motor assembly (No.9) with the screw of
motor (No.6).
d. Insert fan blade (No.5) to motor shaft (No.8), lock fan blade with screw
(No.4).
e. Hold the front guard (No.3) with logo in an upright position. Fix guard
ring (No.2) on rear guard. Secure the tow guards properly with guard
screw (no.1) to avoid front guard from falling down.
Watts (W) Amps (A)
Volts
Low Low
108
94
1.04
0.42
Medium Medium
118
105
1.16
0.48
High High
152
135
1.57
0.60
240V / 50Hz
110V / 50Hz
SPECIFICATION

OSCILLATING WALL FAN
ASSEMBLY AND OPERATING INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
CAUTION:
Read and follow all intructions before operating fan. Do not use fan if any parts
are damaged or missing.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE TO WATER
OR RAIN.
TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT USE THIS FAN
WITH ANY SOLID STATE SPEED CONTROL DEVICE.
RULES FOR SAFE OPERATION :
1. Never insert fingers or any other objects through the grill guard when fan is in
operation.
2. Unplug power cord when moving from one location to another.
3. Unplug power cord when removing grill for cleaning.
4. Be sure fan is on a stable, flat surface when in operation.
5. Do not use fan in windows. Rain and moisture may create electrical hazard.
CAUTION: Do not alter the fan's assembly in any way.
WARNING:
BE SURE FRONT AND REAR GRILL SCREWS ARE TIGHTENED BEFORE OPERATING.
CAUTION:
The knob must be fully tightened before assembling the FAN HEAD TO THE
INNER TUBE.
Do not alter the blade’s angle, securely tighten the blade securing screw.
COLUMN/MOTOR ASSEMBLY INSTRUCTIONS:
Insert the motor at top hole of the inner Tube.
Then firmly tighten the screw at the two holes or the fan neck.
TOOLS REQUIRED Wrench
OPERATING INSTRUCTIONS
TO ADJUST AIRFLOW UPWARD OR DOWNWARD:
Tilt fan head to the desired angle.
Loosen THE POSITION SCREW first and then loosen the knob. Tilt fan head to the
desired angle then firmly tighten THE POSITION SCREW first and then tighten the
knob.
TO MAKE THE FAN OSCILLATE:
Press down the knob at the top of the fan head.
TO STOP THE FAN OSCILLATE:
Pull up the knob at the fan head.
SPEED CONTROL:
Rotate THE SWITCH to 0, 1, 2 and 3 designates OFF, LOW, MEDIUM, and HIGH
speeds respectively.
WARNING:
Unplug from electrical supply source before cleaning:
Use soft damp cloth to clean. Then wipe with dry cloth.
Do not use cleaning solution that is harmful to paints or plastics.
Do not bend the blades.
The motor bearings are permanently sealed and do not require additional
lubrication.
