MIWA ALV3M Series User manual

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
HOTEL CARD LOCK
ALV3M Series
< Type ALV3MA/ALV3M, V3HTMA/V3HTM >
Operation and maintenance manual
Ver．1.0
June 22, 2021
Miwa Lock Co., Ltd.

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
TABLE OF CONTENTS
1. Functional overview............................................................................................. 3
1.1 Appearance and Names of Parts................................................................................. 4
1.2 Mechanism ................................................................................................................. 5
1.3 Functional overview................................................................................................... 6
2 How to operate............................................................................................................. 8
2.1 General operation ....................................................................................................... 8
2.2 In case of emergency................................................................................................ 10
2.3 When card is lost ...................................................................................................... 10
3 Periodic maintenance.................................................................................................11
3.1 Battery replacement...................................................................................................11
3.2 Confirmation of locking, door lever, and construction status .................................. 12
3.3 Card authentication and operation check.................................................................. 12
3.4 Smartphone authentication and operation Check (V3HTMA/V3HTM only).......... 12
3 Periodic maintenance................................................................................................ 13
3.1 Battery replacement.................................................................................................. 13

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
3
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
1. Functional overview
The separate type hotel card lock ALV3MA/ALV3M, V3HTMA/V3HTM is a Hotel card lock
that allows the card(contactless IC card "Mifare®") issued by the dedicated card issuing system
to be used as keys. The V3HTMA / V3HTM is equipped with a BLE module and can also use a
smartphone (guest mobile) with key data registered as a key.
This equipment mainly consists of a card reader for communicating with a card/smartphone,
LEDs for displaying the authentication result and communication status, an infrared (IrDA)
sensor for communicating with the DTU (Data Transfer Unit) for making various settings
of this equipment, a door lever for opening and closing doors, a lock front section, and an
escutcheon (key seat), thumb turn for double lock operation, and has various functions
corresponding to the key data read from the card and smartphone.
<How to operate smartphone (guest mobile)>
When using a smartphone in V3HTMA/V3HTM, start a dedicated application with BLE
communication enabled, tap the "Unlock" button, and hold the smartphone over it. ※1
The operation method is subject to change without notice for the purpose of improving
convenience and security.
※1:The operation method may differ depending on the smartphone app used.

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
4
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
1.1 Appearance and Names of Parts
■type ALV3MA/V3HTMA
■type ALV3M/V3HTM
Trigger bolt
Inside view
Inside view
Thumb turn
Door lever
Outside view
Handle
seat
Dead bolt
Latch bolt
Door lever
LED
Card Reader/BLE
Communications
Department
Target mark
Infrared (IrDA) sensor
Outside view
Handle
seat
Dead bolt
Latch bolt
Door lever
LED
Card Reader/BLE
Communications
Department
Target mark
Infrared (IrDA) sensor
Trigger bolt
Thumb turn
Door lever

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
5
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
1.2 Mechanism
(1) Lock mechanism
There are two modes. The setting is performed by the DTU (Data Transfer Unit).
・Non-latch mode... Auto lock mode (Nomal use)
When unlocking a lock with the card and smartphone, a lock is
automatically locked up after the specified unlock time
elapsed. The door can be opened/closed freely within
the unlock time. Also, when the door is opened and
then closed, the door is automatically locked up after
the unlock time elapsed.
・Latch mode...........Repeat unlocking mode(Special use)
Continuous unlocking and locking are repeated for each valid card
and smartphone operation.
(2) Double-locked lock mechanism
ForALV3M/V3HTM, use dead bolt to protect customer privacy
・Turn a thumb turn in the room to push out the dead bolt and double lock
the door. Double locked state is not unlocked except for emergency card (emergency
unlocking).
・When non-unlockable card and smartphone is used during the double locked state, the
verification NG lamp (red LED) flashes.
・Even in the double-lock state, you can unlock with the emergency card. (Dead Bolt
Override Function)
Otherwise, you can select the operation mode by setting the card.
For ALV3MA/V3HTMA, the dead bolt will be protruded automatically when the door is
closed, but it will not be in the double-lock state. (Auto Dead Bolt Function)
When the thumb turn is operated, the unit enters the double lock state.
(3) Anti-panic mechanism
・Even in the locked state, unlock from the indoor side only with the door lever
operation.
・Even in the double lock state, the dead bolt is pulled in by operating the door lever to
unlock.

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
6
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
1.3 Functional overview
(1) Data verification function
・The card lock is unlocked only when the data (property code, room number, time, etc.)
set in advance by the DTU and the key data (property code, room number, shelf life,
etc.) read from the card and smartphone are verified and determined to be valid.
・When a valid card is holden on the card reader (target mark), the LED on the top of the
card reader lights up in green and unlocks.
If the key data is judged invalid, the LED lights in red and does not unlock.
・When you hold a valid smartphone over the card reader (target mark), the LED on the top
of the card reader flashes orange and then lights green to unlock.
If the key data is determined to be invalid, the LED flashes in orange and then lights in
red and does not unlock.
If the room number is different, the LED flashes in red and verification isn’t performed.
・If reissued and newly issued valid card and smartphones are used, the card and
smartphone that were previously available cannot be used. As a result, prevents
unauthorized use of missing card and smartphones
(2) Usage history function
・Record up to 600 unlock operations using the card and smartphone, and operation history
using the DTU from the new date and time.
When the number exceeds 600, the oldest data is overwritten.
・Up to 100 unlock operations with verification error are recorded in newest to oldest order.
When the history data exceeds 100, it is overwritten in oldest to newest order.
(3)Power sauce
・Uses four AA alkaline batteries, and the battery life is about one and half years (when
used 10 times a day).
・When master card/ sub-master card/ master lock-out card/ housekeeping lock-out card/
cancel card/ daylight saving card/ is used, you can detect low remaining battery level by
using LED and buzzer (low battery detect function).

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
7
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
(4)LED/ buzzer
・Notifies the user of card verification result and lock state with LED and buzzer.
The main states are listed below.
・Buzzer ON/OFF can be changed based on the setting.
Status
LED
Buzzer
Sound
Initial Settings
Card/smartphone verification OK
(other than DTU card)
Lit green
Beep
OFF
Card/smartphone verification NG
Lit Red
Beep beep
DTU card verification OK
Lit orange
Beep
Battery LOW Detection
(When using MS/SMS)
Flashed green
Beep, beep, beep
ON
Battery END detection
Flashed Red
Beep, beep, beep
ON
Non ALV3 card detected
Flashed Red
None
―
Smartphone communication in progress
Flashed orange
None
―
DTU communication in progress
Flashed orange
None
―
※If battery LOW is detected, replace all batteries with identical new ones within approximately 3
days. Continued use will cause the battery to become END, and you will not be able to unlock
with a valid card or smartphone.
※If a battery END is detected, use an external power supply device to unlock with a valid card key.
(5)Other functions
・IrDA communication (infrared communication) function
Uses a portable terminal, known as DTU (Data Transfer Unit), to write/check the card
lock setting data and check the usage history data.
For communicating with DTU, the IrDA communication (infrared communication)
function is used.
※DTU is an abbreviation for Data Transfer Unit.
・Flash memory
Lock data is stored in the flash memory, so the data is held even when the battery runs
out.
・Connection terminal of auxiliary power supply (For no cylinder setting)
Power can be supplied externally when the battery runs out.
・Time hold function
Clock in a lock runs for 5min during a battery exchange.
※Complete battery exchange within 5 minutes.

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
8
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
2 How to operate
2.1 General operation
(1)Card unlock operation
Hold the card over the card reader to unlock.
The usage history is recorded in any of the verification OK/NG.
①Hold the center of the card over the target mark on the card reader until the LED lights.
NOTE)Do not remove the card until the LED lights.
②When the valid card, the LED will light green and unlock.
Operate the door lever while the LED is lit to open the door.
When the preset unlocking time has elapsed, the card lock is automatically activated. (Default:
5 sec.)
③When the invalid card, the LED lights red or flashes red and does not unlock.
※Bringing a hand, metal, or other object that carries electricity close to the card reader part may
cause the LED to flash in red four times.
To the reader and card for detection distance
approx. 22mm at centering
22m
m
Card

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
9
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
(2)Smartphone unlock (V3HTMA/V3HTM only)
Hold your smartphone over the card reader to unlock it.
The usage history is recorded in any of the verification OK/NG.
①Launch the special app and hold the smartphone on the target mark of the card reader until the
LED flashes orange within 30 seconds after tapping the "unlock" button on the accommodation
information display screen.
②If it is a valid smartphone, the LED will flash orange, then turn solid green and unlock.
Operate the door lever while the LED is lit to open the door.
When the preset unlocking time has elapsed, the door is automatically locked. (Default: 5 sec.)
③For invalid smartphone, the LED lights red or flashes red and the card lock does not unlock
after flashing orange.
④For smartphone with an invalid room number, the LED flashes red and the card lock does not
unlock.
※Bringing a hand, metal, or other object that carries electricity close to the card lock reading part
may cause the LED to flash in red four times.
25mm
Smartphone
The detection distance is approximately 25mm
from the center of the reader.
However, it varies depending on the cover and
body material.

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
10
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
2.2 In case of emergency
・Unlock using an emergency card.
The card lock can be unlocked even when the unit is in the double-lock state.
・When unlocked with the emergency card, it is continuously unlocked. During this time, the LED
lights in green continuously.
・The continuous unlocking state of the emergency card is released by the dead bolt operation with
the thumb turn or release operation with DTU, and the normal state is restored.
※During continuous unlocking of Emergency Card batteries, the batteries will be severely
depleted, and should be released promptly after use.
After the release operation, confirm that the LED turns off and locks (the indoor handle is
fixed).
2.3 When card is lost
In the unlikely event that the card is lost, take the following actions:
Card type
Action
Emergency card
Master card
Housekeeping lockout card
Master lockout card
Cancel card
Daylight Saving Card
Hold the newly issued valid card of the same type over all card
locks in the hotel.
Holding the Emergency Card will result in continuous unlocking
state. Be sure to perform thumb turn operation or DTU operation
to cancel continuous unlocking state.
Submaster card
Hold a newly issued valid card over all card locks at the
applicable level.
Guest Card
Multi-guest card
One-shot card
Standby Card
Guest Mobile (Smartphone)
Passage card (continuous unlock card)
Hold a newly issued valid card over the card lock in the applicable
room.
When a second room is set for the guest card and the
smartphone, hold the card over the lock in the appropriate
second room as well.

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
11
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
3 Periodic maintenance
3.1 Battery replacement
（１） Use a Phillips screwdriver to remove the front panel of the control case side.
（２） Raise the shutter and remove the battery box.
（３） Open the cover of the battery box, remove all batteries, and replace them with new batteries
of the same type.At that time, be sure to check the polarity (+/-) of the battery.
（４） Close the cover of the battery box, raise the shutter and push the battery box into the control
case after the contact terminal side of the battery box is turned toward the control case.
（５） Confirm that the shutter has fallen and use a Phillips screwdriver to attach the front panel.
※ Precautions
・Complete battery replacement within 5 minutes.
・Do not mix old and new batteries or mix batteries of different manufacturers as this may cause
leakage or ignition.
・Be careful not to reverse-insert the battery.
Incorrect orientation of the battery may cause operation failure, battery leakage, symptom battery
depletion, etc.
(Check the direction of + and-thoroughly.)
・Dispose of used batteries according to local regulations.
Battery box
Control case
Phillips screwdriver
Battery box
Front
Front panel screws
Shutter
Contact
terminal
panel
Contact
terminal
Front panel side
the cover of the battery box

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
12
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
3.2 Confirmation of locking, door lever, and construction status
※Check the operation with the door opened first to prevent the lockout from the room.
(1)Check with the door open
(a)Is the outdoor handle fixed and locked.
(b)Can the dead bolt be moved in and out by the thumb-turn operation.
(V3MA and V3HTMA with auto specifications of dead bolt function are excluded)
(c)Is the latch bolt retracted by the indoor handle operation.
(d)Is it possible to carry out indoor handle operation with dead bolt protruding and pull in dead
bolt and latch bolt at the same time.
(2)Operation check when closing the door
(A) Is latching (the latch bolt enters the strike while sliding in, and protrudes in the strike)
possible.
(3)Operation check with door closed
(i)Does it not open even if the door is pressed in a locked state.
(ii)Is the same operation as checks (a) to (d) with the door open.
3.3 Card authentication and operation check
※Check the operation with the door opened first to prevent the lockout from the room.
(1) Is it possible to unlock by holding the construction card or the master card when it is in operation
and the LED lights up in green.
(2)After unlocking, does the LED turn off and lock after the set time elapse.
(3)Does the LED of the card lock light up in green and is it in a continuous unlocking state by
holding the emergency card over the card lock during management of the hotel card lock system.
If the LED lights in red or flashes in red, start over the procedure.
3.4 Smartphone authentication and operation Check (V3HTMA/V3HTM only)
※Check the operation with the door opened first to prevent the lockout from the room.
(1) Does the card lock light up in green on the LED and unlock after the smartphone is held over
the card lock and the LED flashes yellow.
(2)After unlocking, does the LED turn off and lock after the set time elapse.
If the LED lights in red or flashes in red, start over the procedure.

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
13
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
4 Compliance statement
4.1 USA-Federal Communications Commission (FCC)
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
This unit complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This unit may not cause harmful interference, and
(2) This unit must accept any interference received, including interference that may cause undesired
operation.
FCC Caution:
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
14
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines as this equipment has
very low levels of RF energy.
・Responsible Party –U.S. Contact Information
MIWA LOCK CO.,LTD. USA Office
9272 Jeronimo Road, Suite 119, Irvine, CA 92618
Telephone：[phone] / FAX：[phone]

Hotel Card Lock System ALV3 Series
Card lock operation and maintenance manual
15
Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
4.2 Innovation, Science and Economic Development Canada （ISED）
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following
two conditions:
(1)This device may not cause interference.
(2)This device must accept any interference, including interference that may cause undesired
operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1)L’appareil ne doit pas produire de brouillage;
(2)L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled
environment and meets RSS-102 of the ISED radio frequency (RF) Exposure rules as this equipment
has very low levels of RF energy.
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un
environnement non contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF)
CNR-102 de l’ISDE puisque cet appareil a une niveau tres bas d'energie RF.
