MLT MLT-F120 User manual
Index:
EC Declaration of conformity:...............................................................................................................................................................................2
What is the manual nger cutting MLT-F120 ?.................................................................................................................................................3
Operating instructions :..............................................................................................................................................................................................4
Spare parts:................................................................................................................................................................................................................11
IMPORTANT
Read this user manual and follow the instructions and warnings before operating this device.
Any modication or transformation performed on this machine may cause the loss of the manufacturer’s guarantee and liability.
This manual must always remain near the machine and visible to all operating and maintenance sta in the event that future
consultation is necessary.
«CE» DECLERATION OF CONFORMITY
We, the undersigned,
MLT ZI du Clos Marquet - Rue Michel Rondet - CS 70059 -
42 200 Saint-Chamond, France
The person(s) empowered to carry out the technical documentation :
- Gilles FURNON : product manager, MLT
We declare, under our responsibility, notwithstanding higher authorized criteria, that the machine:
Is in conformance with :
• Design and construction specications of the European Standards on General Machine Safety: 2006/42/CE
• To the following directives / and or standards :
• o EN ISO 12100-1
• o EN ISO 12100-2
• o EN 60204-1
• o EN ISO 13250
• o EN ISO 13857
• o EN ISO 14121-1
Model : F 120
Serial number : 71103
Manufacturer date : 2018
What is the manual nguer
cutting MLT-F120?
Description
Portable die cutter to cut conveyor belts in a zigzag pattern, featuring exchangeable cutting heads for dierent cutting
geometries.
Support bench with material positioning guides.
This die cutter is especially designed to operate onsite for cut thermoplastic materials with interior tissue.
The head is removable to reduce the weight during the transport.
Technical characteristics:
FRAME
Dimensions 481 × 402 × 370 mm (l × w × h)
Weight 12.4 Kg
Max. Thickness 8 mm
HEAD
Dimensions 245 x 205 x 440 (l x w x h)
Weight 30,6 Kg
Operating
Instructions
Portable head assembly
Ensure the cutting handle is positioned completely vertical to keep the down pin inside the body.
Introduce the punching head on top of guides plate until the end.
WARNING
THIS DEVICE INVOLVES THE HAZARD OF HANDS AND ARMS BEING TRAPPED BY THE MOVEMENT OF THE
CUTTING HEAD
GREAT CARE MUST ALSO BE TAKEN BETWEEN THE CUTTING HEAD AND THE SUPPORT PLATE, AS THERE IS A
DANGER OF CUTTING LIMBS.
Fix the head with the knob M-10
Push the down camp to liberate the step pin and move the head until the centre of the frame.
Avoid over-tightening to prevent bending of the clamp in the central part.
Once the belt is in position and complete xed, push the down camp to liberate the step pin and move the head until end of
stroke of GREEN side.
Then we can start to punch acting with handle in all the stork up and down.
Aer each cut operation, position the handle up and push the head to the le side until it locks again. Then the punching head
is in the next position to repeat the operation.
When the rst head of the belt is completely punched, open the clamp and introduce the second head in the YELLOW side,
with coverage on top also.
Once the head is in position to cut the second head of the belt, start to punch until end of stroke in YELLOW side.
NOTE:
This punching head, only works in one direction (green to yellow)
Belt cutting measures for the dierent dies.
80 x 10 90º………………….......................................……100 mm. Longer
When handle is completely up, push the head to YELLOW side until the belt down the blades.
Adjust the pressure stroke.
NOTE
You must adjust the cutting pressure every time that nylon plate is replaced.
Otherwise, excess pressure may cause breakage of the blades, or deterioration of the cutting nylon.
Loosen the 4 screws key 17mm M-10
Up or down the back side of head across the screw pressure like a next picture.
Also, you can move the cutting nylon to prot all the surface because the step always is the same.
17
M-10
Screw regulation pressure
Spare parts
Number Part name Units
F06001 45x90x1850 1
E2101 Inclined handle 2
F06002 Clamping bar 1
F12003 Belt clamp 2
F06004 Rail Franke 2
F12005 Side frame 2
F06006 miniter_20_1033_0_ 2
F061010 Ramp 1
F12007 Ramp tongue 2
F12008 Belt clamp tongue 2
F06009 Poliamide 1
F12010 Nylon support 2
F12011 Tongue plug 2
F12012 vc_192_50_b_m10.par 2
Number Part name Units
E2101 Inclined handle 2
F12026 Base of the device 1
F12027 Cutting base 1
F12028 Spacer upper punch 1
F12029 Spacer inferior pointer 1
F12030 Device side-1.par 1
F12031 Device side-2.par 1
F12032 Pressure regulator 2
SB152015 Rolling bearing 15-20-15 2
SB202615 Rolling bearing 20-26-15 2
Number Part name Units
F12013 Trigger guide bar 2
F12014 Base of the runner 1
F12015 Trigger hinge 1
F12012 Bushing_kh_0824_0.par 2
F12016 Trigger switch 1
F12017 Trigger 1
F12010 i_280_40_p_m6x1.par 1
F12018 Spring 2
F12019 Trigger guide ramp 2 1
F12020 Trigger guide ramp 1
F12021 Hiwin trolley/skid 15 2
F12022 Pin/Bolt 1
F12022
F12021
