Micro Joystick
Micro Joystick Omni (P002-51) - Micro Joystick R-net
(P002-52) - Micro Joystick Omni (5gr adapted) (P002-55) -
Micro Joystick LiNX (P002-53)
User manual
Edition D-P002-51-70-M0-1100, August 2023

Contents
Contents About this manual .............................................................................. 2
User manual .............................................................................. 2
mo-vis bv ................................................................................... 2
User manual ....................................................................................... 4
Warning labels .......................................................................... 4
Support, scrapping & recycling ................................................. 7
Limited liability .......................................................................... 8
Intended use ............................................................................. 8
Features .................................................................................... 9
Operation ................................................................................ 12
Parts and accessories .............................................................. 14
Qualifications .......................................................................... 17
First time use ........................................................................... 17
Cleaning .................................................................................. 18
Warnings and limitations ........................................................ 18
Connection options ................................................................. 19
Combinations .......................................................................... 21
Dimensions ............................................................................. 21
1

About this manual
User manual
Thank you for choosing a mo-vis product!
This manual contains useful and important information about your device.
Please read it carefully before use and store safely for future reference.
Our team (or your authorized dealer) will be happy to answer your questions.
mo-vis bv
Biebuyckstraat 15D . 9850 Deinze .
Belgium
http://www.mo-vis.com .
cont[email protected] . [phone]
2
2 Micro Joystick User manual

60
CH-REP: SKS Rehab AG, Im Wyden,
8762 Schwanden GL, Switzerland.
UK Responsible Person: QServe
Group UK, Ltd., 49 Greek Street,
London, WID 4EG, UK.
3
Micro Joystick User manual 3

User manual
Warning labels
Please read this manual, the safety instructions and warning texts carefully,
in order to reduce the risks associated to the device. Our products are safe
under normal and reasonably foreseeable operating conditions.
NOTE: This symbol indicates general notes and information.
CAUTION: This symbol indicates caution for a hazardous situation that,
if not avoided, could result in minor or moderate injury.
WARNING: This symbol indicates a warning for a hazardous situation
that, if not avoided, could result in death or serious injury.
Other labels:
Catalogue number: indicates the
manufacturer's catalogue number
so that the medical device can be
4
4 Micro Joystick User manual

identified.
Batch code: indicates the
manufacturer's batch code so that
the batch or lot can be identified.
Medical device: indicates that the
item is a medical device.
Date of manufacture: indicates the
date when the medical device was
manufactured.
Serial number: indicates the
manufacturer's serial number so
that a specific medical device can be
identified.
Consult instructions for use or con-
sult electronic instructions for use:
indicates the need for the user to
consult the instructions for use.
Keep dry: indicates a medical device
that needs to be protected from
moisture.
Do not use if package is damaged
and consult instructions for use:
5
Micro Joystick User manual 5

indicates that a medical device
should not be used if the package
has been damaged or opened and
that the user should consult the
instructions for use for additional
information.
CE label: indicates that the manufac-
turer or importer affirms the good's
conformity with European health,
safety, and environmental protec-
tion standards.
WEEE: indicates that the product
should not be discarded as unsorted
waste but must be sent to separate
collection facilities for recovery and
recycling.
Manufacturer: indicates the medical
device manufacturer.
6
6 Micro Joystick User manual

Support, scrapping & recycling
Technical support
TROUBLE: In case of technical problems:
• Contact your dealer
• If your dealer is not available or unknown, please contact mo-vis:
cont[email protected] or [phone].
Always state the product code and device serial number when
contacting us. This ensures you are provided with the correct
information.
Spare parts and accessories
Contact mo-vis or your dealer for more information about spare parts and
accessories.
Scrapping & recycling
CAUTION: For scrapping, adhere to your local waste legislation.
Dispose of obsolete electronic parts responsibly in accordance with
local recycling regulations.
7
Micro Joystick User manual 7

Limited liability
mo-vis accepts no liability for personal injury or damage to property
that may arise from the failure of the user or other persons to follow the
recommendations, warnings and instructions in this manual.
CAUTION: This product should only be installed by a qualified service
engineer.
NOTE: All mo-vis user manuals can be found at http://www.mo-vis.com
where they can be consulted in PDF format.
NOTE: In case any serious incident occurs in relation to this device,
this should be reported immediately to mo-vis and the competent
authority of the Member State in which the user is established.
Intended use
The Micro Joystick:
• is a joystick module which can be connected directly to the wheelchair
electronics to control the wheelchair functions.
8
8 Micro Joystick User manual

• is a very small, proportional joystick, specifically designed for people
with very poor or weak muscle strength and/or limited movements.
• can easily be controlled by e.g. finger, chin, tongue, lip ...
• is recommended for people with muscular or neuromuscular diseases.
NOTE: The joystick operates with high sensitivity. A good and
controlled movement coordination and force control is required.
Features
The Micro Joystick:
• is very small and proportional.
• is supplied with two toppers: a small ball and a cup. A third topper is
optionally available, see Parts and accessories on page 14
9
Micro Joystick User manual 9

• is very sensitive due to its low operating force (ca. 8 gr - 0.28 oz) and
movement (3.3 mm - 0.13 in).
• can be controlled by finger, chin, tongue, lip ...
• is designed in ergonomic shape for easy handling.
• has 2 switches that can be linked to the separate interface: (1) on/off
power wheelchair - (2) mode of the power wheelchair.
10
10 Micro Joystick User manual

• is fully adjustable to individual possibilities and needs with well-thought-
out electronics (USB-C connection).
• is compatible with multiple types of wheelchair electronics.
• has a LED light on the interface which will start to flash green in case of
an error or orange in case of active tilt (see Installation manual) .
11
Micro Joystick User manual 11

Special adaptation
There is now also another version available of the Micro Joystick: the P002-55
Micro Joystick Omni (5gr adapted). The movement is still 3.3 mm - 0.13 in,
but the operating force is now 5 gr - 0.18 oz.
NOTE: Before mo-vis can deliver this product to you, the user and/
or the dealer will have to declare that they have read and agreed to
specific risk mitigations. Please refer to the Micro Joystick Installation
manual for more information.
Operation
The movements of the control are translated into according movements of
the wheelchair, e.g. driving or menu navigation.
Common practice to navigate the wheelchair with the joystick is as follows:
•Direction: point the control into the direction you want the wheelchair
to move. The wheelchair then moves in that direction.
•Speed: the further you move the control from the default (center)
position, the faster the wheelchair moves.
•Stop: whenever you release the control, the control moves back to the
default (center) position and the wheelchair stops.
CAUTION: Avoid hitting obstacles during driving.
12
12 Micro Joystick User manual

WARNING: When the LED light flashes and/or after every incident with
the wheelchair or the mo-vis device, contact your dealer immediately
to perform a functional test.
LED status
The illumination of the LED on the joystick interface indicates the operational
status of the joystick.
JOYSTICK
STATUS
COLOUR LED
TIMING
COUNT STATE DESCRIPTION
Configur-
ing
Orange Fast Wheelchair is configur-
ing
Powercy-
cle
Orange Heartbeat Wheelchair waits for
power cycle
Focus Green Always on System is in focus
Out of
focus
Green Heartbeat System is out of focus
Out of
neutral
Green Medium
Not
applicable
Joystick is out of neu-
tral
Error Red Errors See Something went wrong
13
Micro Joystick User manual 13

Parts and accessories
A Micro Joystick package consists of the following parts:
EXAMPLE P002-51 -
MICRO JOYSTICK
OMNI / P002-55
MICRO JOYSTICK
OMNI (5 GR
ADAPTED)
P002-52
- MICRO
JOYSTICK R-NET
P002-53
- MICRO
JOYSTICK LINX
P002-50 - Micro Joystick sensor
NOTE: In the case of the P002-55, the P002-50
will be adapted for lower force
M006-08 - Micro Joystick ball
M006-09 - Micro Joystick cup (10.1 mm)
14
14 Micro Joystick User manual

EXAMPLE P002-51 -
MICRO JOYSTICK
OMNI / P002-55
MICRO JOYSTICK
OMNI (5 GR
ADAPTED)
P002-52
- MICRO
JOYSTICK R-NET
P002-53
- MICRO
JOYSTICK LINX
M006-20 - Micro Joystick mounting set
See Installation
Manual
SUB D9 cable
and Joystick
Omni Interface
R-net cable and
Joystick R-net
Interface
LiNX cable and
Joystick LiNX
Interface
D-P002-51-70-MX Micro Joystick User manual
D-P002-51-70-M9 Micro Joystick Installation manual
15
Micro Joystick User manual 15

Optional
A third topper is optionally available: M006-27 Micro Joystick Cup (15.5 mm).
Unit detail
The connections of the interface unit have protective covers to avoid the
intrusion of dust or moist during usage.
16
16 Micro Joystick User manual

Spare parts
Spare parts and accessories must be ordered by the dealer at mo-vis bv.
Always mention the product code of the desired item.
Qualifications
CAUTION: Only a qualified service engineer may install the device.
CAUTION: An incorrect programming of the wheelchair or device
electronics, may cause damage to the devices or injury to the user.
First time use
CAUTION: A qualified service engineer should assist during first time
use of the device and make sure that all functions are clear to the user,
including what to do in case of problems or doubt.
17
Micro Joystick User manual 17

Cleaning
WARNING: As dust and dirt could lead to reduced functionality, all
parts of the device should be cleaned on a regular basis (monthly) or
whenever needed.
• Gently remove dust and dirt with a damp cloth.
• Use only non-aggressive disinfectant cleaning agents.
CAUTION: Do not immerse in water or use excessive amounts of liquid.
CAUTION: Do not apply additional lubricants to the moving parts.
The handles of the joystick can be removed to clean them.
• You may shortly immerse the handle in warm water with a gentle
cleaning agent. Let the handle dry before putting it back on.
• If the handle is damaged, worn out or remains dirty, please contact your
authorized dealer or mo-vis to replace it.
Warnings and limitations
NOTE: This product complies with the limit values for Electromagnetic
Compatibility (EMC) with respect to power wheelchairs, as set out in
18
18 Micro Joystick User manual

the harmonized standards for the EU in the Medical Device Regulation,
No. 2017/745.
WARNING: Do not cover or block the device to avoid uncontrolled
behavior of the device or the wheelchair.
CAUTION: If an output inhibit is programmed, then it should be
checked monthly if this is still operational. Please see the Installation
Manual for more information.
Connection options
The connection interface depends on the control version. Please see the
Installation Manual for more information.
19
Micro Joystick User manual 19
