Mo-vis Micro Joystick LiNX User manual

moving forward together
Micro Joystick
Micro Joystick Omni (P002-51) - Micro Joystick R-net
(P002-52) - Micro Joystick Omni (5gr adapted) (P002-55) -
Micro Joystick LiNX (P002-53)
Installation manual
Edition D-P002-51-70-M1-1200, August 2023

Contents
Contents About this manual .............................................................................. 4
Installation manual ................................................................... 4
mo-vis bv ................................................................................... 4
Important information ........................................................................ 5
Warranty ............................................................................................ 6
Repair and replacement ............................................................ 6
Amendments ............................................................................. 6
Disclaimer and limitations of remedies .................................... 7
Voiding of warranties ................................................................ 7
Technical support ................................................................................ 8
Warning labels .................................................................................... 9
Limited liability ................................................................................. 12
Preparations ..................................................................................... 13
Qualified service engineer ...................................................... 13
Tools ........................................................................................ 13
Installation plan ...................................................................... 14
1

Installation ....................................................................................... 15
Operation ......................................................................................... 17
LED status ................................................................................ 17
Configuration .................................................................................... 19
Software download ................................................................. 19
Defining parameter settings ................................................... 20
Parameter settings .................................................................. 20
Testing .............................................................................................. 35
Check the device for intactness .............................................. 35
Operational test ...................................................................... 35
Test drive ................................................................................. 36
Stop test .................................................................................. 37
First time use .................................................................................... 38
Maintenance .................................................................................... 40
Monthly inspection ................................................................. 40
Yearly inspection ..................................................................... 40
Error codes ....................................................................................... 41
Omni Joystick Connection ................................................................. 45
Purpose ................................................................................... 45
Connectivity ............................................................................ 45
2

Features .................................................................................. 46
Other information ................................................................... 46
R-net Joystick Connection ................................................................. 47
Purpose ................................................................................... 47
Connecting the R-net communication cable ........................... 47
R-net parameters .................................................................... 48
R-net trip codes ....................................................................... 49
Supported R-net parameters .................................................. 49
Other information ................................................................... 52
LiNX Joystick Connection .................................................................. 54
Purpose ................................................................................... 54
Connectivity ............................................................................ 54
LiNX parameters ...................................................................... 54
P002-55 Micro Joystick Omni (5gr adapted) ...................................... 55
Technical data ................................................................................... 57
Product description & code .................................................... 57
Interface connectors ............................................................... 57
Dimensions ............................................................................. 57
Required force ......................................................................... 58
3

About this manual
Installation manual
This manual contains useful and important information about your device.
Please read it carefully before use and store safely for future reference.
Our team will be happy to answer your questions.
mo-vis bv
Biebuyckstraat 15D . 9850 Deinze .
Belgium
http://www.mo-vis.com .
cont[email protected] . [phone]
60
CH-REP: SKS Rehab AG, Im Wyden,
8762 Schwanden GL, Switzerland.
UK Responsible Person: QServe
Group UK, Ltd., 49 Greek Street,
London, WID 4EG, UK.
4
4 Micro Joystick Installation manual

Important information
CAUTION: Incorrect use or installation may lead to risk of injury to
the user and damage to the wheelchair or other property. In order
to reduce these risks, you should carefully read this manual, paying
particular attention to the safety instructions and warning texts.
NOTICE: Only install this product on a wheelchair where the wheelchair
manufacturer allows the installation of third party parts.
5
Micro Joystick Installation manual 5

Warranty
mo-vis bv warrants the product to be free from defects in material and
workmanship for a period of 2 years under proper use, care and service. The
dealer should never keep mo-vis products in stock for a period more than 6
months prior to delivery to the end-user. mo-vis' warranty will never exceed a
period of 2 years and 6 months after shipment.
All warranties do not extend beyond the initial purchaser from an authorized
mo-vis dealer or mo-vis itself.
Repair and replacement
For warranty service, contact your dealer (or us if bought directly). In the
event of a defect in material or workmanship, the dealer or customer must
obtain a Return Merchandise Authorization (RMA) number from us. The
product must be shipped to a service centre designated by mo-vis. mo-vis will
repair or, at mo-vis’ option, replace any product covered by the warranty.
Amendments
No person is authorized to alter, extend or waive the warranties of mo-vis.
6
6 Micro Joystick Installation manual

Disclaimer and limitations of remedies
The express warranties set forth in this agreement are in lieu of all other
warranties of merchantability or fitness of purpose. In no event shall mo-
vis be liable for any direct, indirect, incidental or consequential damages
resulting from any defect in this product.
Warranty of parts subject to “normal wear and tear” (e.g. joystick handles,
pads, …) are not covered in the warranty except as it applies to defects in
material or construction.
Voiding of warranties
The foregoing warranties are contingent upon the proper installation, use,
maintenance and care of the product. The warranty will be void if the product
has been installed or used improperly, or if it has been repaired or any part
replaced by persons other than mo-vis or an authorized dealer. This product
is considered as a non-serviceable part.
The addition of equipment or features that are not manufactured or
recommended by mo-vis could affect the intended function of the mo-vis
product and may invalidate the warranty.
7
Micro Joystick Installation manual 7

Technical support
TROUBLE:
In case of technical problems:
1 Contact mo-vis at [e-mail] or [phone].
2 Always state the device serial number when contacting us. This
ensures you are provided with the correct information.
8
8 Micro Joystick Installation manual

Warning labels
Please read this manual, the safety instructions and warning texts carefully,
in order to reduce the risks associated to the device. Our products are safe
under normal and reasonably foreseeable operating conditions.
NOTE: This symbol indicates general notes and information.
CAUTION: This symbol indicates caution for a hazardous situation that,
if not avoided, could result in minor or moderate injury.
WARNING: This symbol indicates a warning for a hazardous situation
that, if not avoided, could result in death or serious injury.
Other labels:
Catalogue number: indicates the
manufacturer's catalogue number
so that the medical device can be
9
Micro Joystick Installation manual 9

identified.
Batch code: indicates the
manufacturer's batch code so that
the batch or lot can be identified.
Medical device: indicates that the
item is a medical device.
Date of manufacture: indicates the
date when the medical device was
manufactured.
Serial number: indicates the
manufacturer's serial number so
that a specific medical device can be
identified.
Consult instructions for use or con-
sult electronic instructions for use:
indicates the need for the user to
consult the instructions for use.
Keep dry: indicates a medical device
that needs to be protected from
moisture.
Do not use if package is damaged
and consult instructions for use:
10
10 Micro Joystick Installation manual

indicates that a medical device
should not be used if the package
has been damaged or opened and
that the user should consult the
instructions for use for additional
information.
CE label: indicates that the manufac-
turer or importer affirms the good's
conformity with European health,
safety, and environmental protec-
tion standards.
WEEE: indicates that the product
should not be discarded as unsorted
waste but must be sent to separate
collection facilities for recovery and
recycling.
Manufacturer: indicates the medical
device manufacturer.
11
Micro Joystick Installation manual 11

Limited liability
mo-vis accepts no liability for personal injury or damage to property
that may arise from the failure of the user or other persons to follow the
recommendations, warnings and instructions in this manual.
CAUTION: Carry out only the service and maintenance activities
specified in this manual, as long as you comply with the demands
stated in this manual for a specific action. In case of doubt, contact mo-
vis.
WARNING: The device should always be tested without any person
sitting in the wheelchair after every alteration of the physical
installation or adjustment of the parameters.
12
12 Micro Joystick Installation manual

Preparations
CAUTION: Before you start with the installation:
• Please check the packaging and verify that all items are included.
• Make sure that you have all the necessary documentation and
knowledge to install this device.
• Check the condition of the device.
Qualified service engineer
Only a qualified service engineer may install the device.
CAUTION: An incorrect programming of the wheelchair electronics may
cause damage to the devices, or injury to the user.
Tools
Use an Allen wrench to install the device.
CAUTION: Use proper tools to install and adjust the device. The use of
improper tools may cause damage to the device.
13
Micro Joystick Installation manual 13

Installation plan
Set up an installation plan before beginning the installation. Based on the
users' needs and capabilities, this plan should take into account:
• Where which part of the device should be placed.
• How the device will be operated.
• A robust and reliable positioning. Hard or sudden movements of the
wheelchair may not disorganize the installation.
WARNING: Protect the device against bumps. Mind damaging the
unit and wiring. Make sure that cabling is mounted in such a way that
excessive wear and tear is avoided.
WARNING: Do not use the control as only support for hands or limbs.
Movements and shocks may disrupt controls.
14
14 Micro Joystick Installation manual

Installation
1 Define the position of the joystick.
When the arrow at the bottom of the joystick points to the front, a
forward movement of the joystick will result in an according forward
movement of the wheelchair.
If needed, you can change this positioning in steps of 90° with the
Configurator Software.
2 Place the mounting ring around the joystick housing.
3 Secure the Q2M half clamp to the mounting ring.
Use an Allen wrench to mount the 20 mm bolt.
NOTE: It is not advised, but you may mount the joystick without
using the Q2M half clamp.
CAUTION: Tighten the screws firmly, but not excessively. Excessive
force may damage the unit.
4 Slide the unit over a Q2M Rod, or any other 6 mm rod, to position the
Micro Joystick on the wheelchair.
A Q2M Rod D6 50 mm is included in your package, but you can use any
other Q2M Rod (e.g. a C- or S-Rod from the Multi Swing).
5 Place and secure the interface unit and all cabling on the wheelchair.
15
Micro Joystick Installation manual 15

WARNING: Place the Interface unit with the connectors facing
downwards. This is to prevent water from entering the Interface
unit.
6 Place a power on/off (pwr) and/or mode (in) switch, secure their cabling
and insert their connections. You can use the connections on the
Interface unit.
CAUTION: Before inserting a connector, remove the protective
cover. If the connections are not used, always put or keep the
protective covers in.
CAUTION: This is Class I Medical Device (MDR 2017/745). All
accessories, including switches, must also comply with the MDR
2017/745 regulations (e.g. the mo-vis Twister, tested according to
EN12184 standards).
7 Connect the cabling to the wheelchair electronics.
CAUTION: All wheelchair electronics must be switched off during
installation.
16
16 Micro Joystick Installation manual

Operation
The movements of the control are translated into according movements of
the wheelchair, e.g. driving or menu navigation.
Common practice to navigate the wheelchair with the joystick is as follows:
•Direction: point the control into the direction you want the wheelchair
to move. The wheelchair then moves in that direction.
•Speed: the further you move the control from the default (center)
position, the faster the wheelchair moves.
•Stop: whenever you release the control, the control moves back to the
default (center) position and the wheelchair stops.
CAUTION: Avoid hitting obstacles during driving.
WARNING: When the LED light flashes and/or after every incident with
the wheelchair or the mo-vis device, contact your dealer immediately
to perform a functional test.
LED status
The illumination of the LED on the joystick interface indicates the operational
status of the joystick.
17
Micro Joystick Installation manual 17

JOYSTICK
STATUS
COLOUR LED
TIMING
COUNT STATE DESCRIPTION
Configur-
ing
Orange Fast Wheelchair is configur-
ing
Powercy-
cle
Orange Heartbeat Wheelchair waits for
power cycle
Focus Green Always on System is in focus
Out of
focus
Green Heartbeat System is out of focus
Out of
neutral
Green Medium
Not
applicable
Joystick is out of neu-
tral
Error Red Errors See Error
codes
on page
41
Something went wrong
18
18 Micro Joystick Installation manual

Configuration
WARNING: Changes in parameter settings may cause damage to the
device or power chair, or may cause injury to people.
CAUTION: Always change parameters and test the outcome without
anyone sitting in the power chair.
Software download
• You can download the Configurator Software on our website http://
www.mo-vis.com
• Software requirement: Windows version 10 or 11, 64 bit
• For all details on how to install and use the software, we refer you to the
Configurator Software manual.
• To configure the parameters of the device, you need dealer level access.
This level is password-protected. Contact mo-vis to obtain the password.
NOTE: Never share your password with anyone and keep access to the
Configurator Software strictly personal.
19
