MOA RF130 User manual

Retro Fridge RF130
Instruction Manual
English / Nederlands / Deutsch / Français
www.moacolors.com

Retro Fridge - English manual 2
EN
BEFORE USE
Before use, please read this manual carefully.
Only connect the appliance to an earthed wall socket.
This appliance is for household use only. When using electrical
appliances, basic safety precautions should always be followed to
avoid res, electric shocks, burns, or other injuries and damage. Read
these operating and safety instructions carefully.
IMPORTANT SAFEGUARDS (1/6)
1. Risk-off child entrapment. Before you throw away your old
appliance:
- Take off the doors.
- Leave the shelves in place so that children may not easily climb inside.
- Cut the connection cable (as close to the appliance as you can.)
- If this appliance you are replacing featured a spring lock (latch) on
the door or lid, be sure to make that spring lock unusable before you
discard the old appliance. This will prevent it from becoming a death
trap for a child.
2. Make sure your outlet voltage and circuit frequency correspond to
the voltage stated on the appliance rating label If this is not the case,
contact the after-sales support line and do not use the refrigerator.
3. Do not use any other appliance at the same time on the same
electrical circuit as it may overload the circuit and blow the fuse or
circuit breaker.
4. To protect against re and electric shock, do not immerse the cord,
plug, power base, or the Retro Under Counter Fridge body itself in
water or other liquid. Do not expose the electrical connections to water.
5. The cord should be run in such a way that there will be no risk of
anyone pulling it inadvertently or tripping over it.

Retro Fridge - English manual 3
EN
IMPORTANT SAFEGUARDS (2/6)
6. Do not kink, bend, squash, strain, or damage the power cord and
protect it from sharp edges and heat.
7. Grip the plug when disconnecting, do not pull the cord.
8. Do not let the cord hang over the edge of a table or benchtop. Do
not let it touch hot surfaces.
9. Do not pick up or operate the appliance if the power supply cord
or plug is damaged, or after it malfunctions or has been dropped or
damaged in any way.
10. In case of damage, contact the after-sales support line for advice.
11. A damaged cord or plug must be replaced by the manufacturer or
a qualied person to avoid a hazard.
12. Make sure all electrical connections are clean and dry before
switching on.
13. Do not use this appliance in conjunction with an extension cord.
14. Unplug the appliance from the power outlet when not in use and
before cleaning, servicing, maintenance, or moving the appliance.
15. This appliance is not intended to be operated by means of an
external timer or separate remote control system.
16. This appliance is intended for domestic use only.
17. This product is not intended for commercial use. Do not use it
outdoors.
18. Only use this refrigerator as described in this manual. Any other
use is not recommended and may cause re, electric shock, or injury.
19. Improper installation and the use of accessories not recommended
by the appliance manufacturer may result in re, electric shock, or
personal injury and will invalidate your warranty.

Retro Fridge - English manual 4
EN
IMPORTANT SAFEGUARDS (3/6)
20. We assume no responsibility for any eventual damages caused by
improper or faulty use.
21. This appliance is not intended for use by persons (including
children) with a reduced physical, sensor, or mental capabilities,
or lack of experience and knowledge unless they have been given
supervision or instruction concerning the use of the appliances by a
person responsible for their safety.
22. Children should be supervised to ensure they do not play with the
appliance.
23. Close supervision is necessary when any appliance is used by or
near children.
24. Do not use chemical, steel wool, or abrasive cleaners to clean the
outside of the unit, as these will scratch the metal surface.
25. Do not operate the unit near liquids (kitchen sink, water basins,
taps, etc).
26. Ensure that all the parts are correctly assembled before operating.
27. Maintain the appliance following the instructions to ensure that it
functions properly.
28. If there is a product malfunction, or if it has been damaged in any
way, call the after-sales support for assistance.
29. Immediately unplug the appliance if re or smoke is emitted.
30. Place the product on a straight, rigid, and stable surface, away
from sources of direct sunlight or excessive heat.
31. Do not place the product near heat sources such as radiators, heat
registers, stoves, or other appliances that produce heat.
32. Do not place the product near other items that may damage it, such
as naked ame sources (lit candles) or objects containing water (a vase
or shbowl).
33.Take care that no objects fall and no liquids are spilled into any
openings.

Retro Fridge - English manual 5
EN
IMPORTANT SAFEGUARDS (4/6)
34. Prevent overheating: Place the product in a sufciently aerated
place. Ensure that air can circulate freely around the back of the
refrigerator. To ensure best performance, leave a distance of about
100mm to all sides of the fridge.
35. This appliance features a short power cord to reduce the risk
of being entangled, and to reduce the risk of tripping. An extension
cord or longer detachable cord is not recommended for use with this
product.
36. There are no user-serviceable parts inside. Do not attempt to
service this product. Please call our after sales support for instructions.
Danger! Risk of re or explosion. Flammable refrigerant used. To be
repaired only by trained service personnel. Do not puncture refrigerant
tubing.
Caution! Risk of re or explosion. Flammable refrigerant used. Consult
repair manual/owner’s guide before attempting to service this product.
All safety precautions must be followed.
Caution! Risk of re or explosion. Dispose of property in accordance
with federal or local regulations. Flammable refrigerant used.
Caution! Risk of re or explosion due to puncture of refrigerant tubing;
follow handling instructions carefully. Flammable refrigerant used.
37. The refrigerant isobutane (R600a) is contained within the
refrigerant circuit of the appliance, a gas with a high level of
environmental compatibility, which is nevertheless ammable. During
transportation and installation of the appliance, ensure that none of the
components of the refrigerant circuit become damaged.
WARNING: Do not damage the refrigerant circuit! Never use an
appliance with a damaged refrigerant circuit! If the refrigerant circuit
becomes damaged, avoid proximity to open res and all types of
heat and ignition sources. Thoroughly ventilate the room in which the
appliance is located.

Retro Fridge - English manual 6
EN
IMPORTANT SAFEGUARDS (5/6)
38. It is hazardous for anyone other than an authorized service person
to service this appliance.
39. The room for installing the appliance must be at least 1m* per 8g
of refrigerant. The amount and type of refrigerant in the appliance can
be found in the Technical Specications.
40. Do not use other electrical appliances (such as ice cream makers)
inside of refrigerating appliances, unless they are approved for this
purpose by the manufacture.
41. Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
42. During transportation and installation of the appliance, be certain
that none of the components of the refrigerant circuit are damaged.
43. Avoid open ames and sources of ignition.
44. Thoroughly vent late the room in which the appliance is situated.
45. It is dangerous to alter the specications or modify this product in
any way.
46. Any damage to the cord may cause a short circuit, re, and/or
electric shock.
47. This appliance is heavy. Care should be taken when moving it. To
avoid back or other injuries, consider a two-person lift or mechanical
aid when installing it. Failure to do so can result in back or other
injuries.
48. Avoid prolonged exposure of the appliance to direct sunlight.
49. This appliance is intended to be used in a household only.
50. Any electrical components (plug, power cord, compressor and etc.)
must be replaced by a certied service agent or qualied service
personnel.

Retro Fridge - English manual 7
EN
IMPORTANT SAFEGUARDS (6/6)
51. DO NOT USE AN EXTENSION CORD. Use an exclusive wall
outlet. Do not connect your refrigerator to extension cords or in an
outlet used by any other appliance.
52. Make sure that the power plug is not squashed or damaged by
the back of the appliance. A squashed or damaged power plug may
overheat and cause a re.
53. Before rst use, it is advisable to wait at least eight hours
before connecting the appliance to allow the oil to ow back in the
compressor.
54. Adequate air circulation should be around the appliance, lacking
this leads to overheating. To achieve sufcient ventilation follow the
instructions relevant to installation.
55. The appliance must not be located close to radiators or cookers.
56. Make sure that the mains plug is accessible after the installation of
the appliance.
57. Do not put hot food in the appliance.
58. Store pre-packed food in accordance with the food manufactures
instructions.
59. WARNING! Do not use mechanical devices or other means
to accelerate the defrosting process. Never use a sharp or metal
instrument to remove frost or clean the appliance. Use a plastic scraper,
if necessary.
60. Appliance storage recommendations should be strictly adhered to.
Refer to relevant instructions.
61. If the refrigerator is unplugged, turned off, or has lost power, you
must wait for 3 to 5 minutes before restarting the unit. If you attempt to
restart before this time delay, the refrigerator will not start.

Retro Fridge - English manual 8
EN
PARTS & PLACEMENT
1. LED light 2.Wine Rack
3. Glass shelf 4. Salad Box
5. Door/Bottle Shelf 6. Door/Bottle Shelf
1
2
3
4
5
6

Retro Fridge - English manual 9
EN
SETTING UP APPLIANCE
Unpacking:
- This product has been packaged to protect it against transportation
damage. Remove all packaging materials from around and inside the
appliance, but do not remove any foam insulation surrounding the
pipes at the back. Keep the original packaging carton and materials
in a safe place; it will help prevent any damage if the product needs to
be transported in the future, and you can use it to store the appliance
when it is not in use. If the carton is to be disposed of, please recycle
all packaging materials where possible.
- Plastic wrapping can be a suffocation hazard for babies and young
children, so ensure all packaging materials are out of their reach and
disposed of safely.
- Parts: Check to ensure you have all the parts pictured on the previous
page spread.
- Unwind the power cord to its full length and inspect it for damage. Do
not use the appliance if the appliance or its cord has been damaged
or is not working properly. In case of damage, contact our after-
sales support line for advice on examination, repair, or return of the
damaged product.
- Make sure the refrigerator is disconnected from the power supply
before cleaning the interior surfaces and all internal accessories with
lukewarm water, a soft cloth, and a neutral/mild soap/detergent. This
will remove any dust from transit and storage and help remove the
typical smell of a brand new product. Then dry thoroughly. Important:
do not use harsh or abrasive detergents or powders as these will
damage the nish.

Retro Fridge - English manual 10
EN
DOOR HANDLE INSTALLATION
The door handle comes unattached due to packaging restrictions. It is
easlity attached by following the instructions below.
1. Handle accessories
#1 Screw #2 Screw #3 Door handle
Qty. 2 Qty. 2 Qty. 1
2. To install the handle, follow the instrcutions below:
Remove teh original screws from door.
- Fix the two screws (1) on the door.
- Put the metal handle (3) into the two xed screws, match the two holes
on the handle.
- Intall screw (2) at the bottom of handle and fasten it tightly.

Retro Fridge - English manual 11
EN
Installing the refrigerator:
- Before installing your new fridge, read all safety instructions in this
manual, then follow the instructions below:
- Place the fridge on a sturdy, level oor for quieter operation. Ensure
that the oor is strong enough to support the fridge when it is fully
loaded.
- If the refrigerator is to be placed on a carpet, support it with a
wooden board underneath. Be aware that placing the refrigerator on
the carpet may mean that heat from the compressor may cause the
carpet to fade.
- This appliance is designed to be freestanding only and should not be
recessed or built-in.
- Do not tilt the fridge more than 45° from upright when moving it.
- Avoid areas where the appliance would be exposed to direct sunlight,
sources of heat (stove, heater, radiator, etc.), extreme cold ambient
temperatures, or excessive moisture and high humidity. Installing it in
the coolest area of the room will save energy consumption and running
costs.
- Handle with care! Do not apply force to any part such as the
condenser or door. The metal rails on the bottom underneath of this
refrigerator may have sharp edges, so always unpack and handle
with care. Do not drag the unit: place it carefully in position to avoid
scratching the oor.
Space requirements:
- Place the unit so there is enough space for the door to open.
- Ensure that air can circulate freely around the back of the cabinet,
which is necessary to cool the
compressor and condenser. Allow at least 100mm clear space at the
back and 50mm at the sides of the unit.
Leveling:
- The appliance must be installed level in order to work properly. If the
unit is not level, the doors and magnetic seal alignments will not be
covered properly.
- To level the unit, adjust one or both leveling feet at the base of the unit.

Retro Fridge - English manual 12
EN
REVERSIBLE DOOR
The door can be opened from left to right and vice versa. Should you
wish to change the opening direction, please follow these instructions.
Note: All parts removed should be kept safely. You will require these for
the reinstallation of the door.
Support the door from the bottom
Remove the six screws that afx the hinges and two spacers to the
cabinet frame
- Place the door at on a padded surface to prevent scratching
Remove the six hinge screws that afx the hinges to the Retro door
Remove the blanking plugs from the opposite side and use to plug the
holes exposed by the removal of the hinge Screw the hinges onto the
opposite side of the door Pick the door up and carefully align with the
cabinet holes Screw the remaining six screws into both hinges and the
two spacers into the cabinet to secure the door.

Retro Fridge - English manual 13
EN
MECHANICAL CONTROLLER
The mechanical thermostat temperature control and the LIGHT on/off
switch is located at below places:
Temperature settings:
The settings 0(OFF) - 7(MAX) regulate the interior temperature of the
refrigerator.
Setting 0(OFF) = not operating (Please press the knob and turn to get
the “0” position)
Setting 1(MIN) = lowest setting (warmest internal temperature) Setting
7(MAX) = highest setting (coldest internal temperature)
NOTE: The refrigerator temperature will vary depending on the number
of cans/ bottles stored and on the frequency with which the door
is opened. The internal temperature varies in different parts of the
refrigerator. The back of the refrigerators is the coldest. Please keep the
cans/bottles away from the rear wall to avoid freezing the bottles and
to allow the circulation of cold air.
NOTE: Thermostat 0(OFF) position indicates the refrigerator is turned
off although power is still being supplied. By turning the thermostat
dial to the left, the refrigerator will turn on automatically. When the
refrigerator is not to be used for a long period of time, disconnect the
plug and leave the door partially open.

Retro Fridge - English manual 14
EN
FOODSTORAGE
- The refrigerator compartment is suitable for the short-term storage of
fresh food. The temperature inside varies depending on the amount
of food stored, the ambient temperature, and the frequency of door
opening. Adjust the thermostat accordingly.
- In order to maintain good cooling efciency and save energy, we
recommend you do not open the door for too long or too often. Do
not overload the fridge, and keep enough space around items for cold
airow. Do not block ventilation openings.
- The walls of the fridge are equipped with a series of runners so that
the shelves can be positioned to suit individual storage requirements.
- In order to keep fruit and vegetables fresh in the salad drawer, make
sure they are properly packaged and the cover sits rmly on top of the
salad drawer(applicable model).
- Two wine bottles can be stored conveniently in the shelf-hanging wine
rack. If you do not require this wine rack, or to remove it for cleaning,
pull the shelf that holds the rack completely out of the fridge, then slide
the wine rack off the side of the shelf (applicable model).
ENERGY SAVING TIPS
- Place the fridge in the coolest area of the room, away from heat-
producing appliances and out of direct sunlight.
- Let heated food and beverages cool to room temperature before
placing them into the fridge.
- Do not overload the fridge as it forces the compressor to run longer.
- Wrap foods properly and wipe containers dry before placing them in
the fridge. This cuts down on frost build-up inside the fridge.
- Do not line any fridge storage bin with aluminum foil, wax paper, or
paper towels. Liners interfere with cold air circulation, reducing cooling
efciency.
- Position food so that air can circulate freely around it.
- Do not leave the fridge door open for longer than required.
- Make sure no food touches the back of the compartment.
- Don’t set the thermostat on exceeding cold temperatures.

Retro Fridge - English manual 15
EN
MAINTENANCE & CLEANING
Disconnect the appliance from the power supply before cleaning.
Internal Cleaning
- Do not pour water over the appliance.
- The cavity should be cleaned periodically using a solution of
bicarbonate of soda and lukewarm water (5mI to 0.5 litre of water)
- Clean the accessories separately with soap and water. Do not put
them in the dishwasher.
- Do not use abrasive products, detergents, or soaps.
- After washing, rinse with clean water and dry carefully.
- When you have nished cleaning reconnect the plug with dry hands.
External Cleaning
- Wash the outer cabinet with warm soapy water. Do NOT use abrasive
products.
- There are sharp edges on the underside of the product so care should
be taken when cleaning.
- Once or twice a year dust the rear of the appliance and the
compressor at the back of the appliance, with a brush or vacuum
cleaner, as an accumulation of dust will affect the performance of the
appliance and cause increased energy consumption.
Warning:
- Never clean the unit with an abrasive, acid, oil, or solvent-based
cleaning agent, or with abrasive pads or scourers. Never use
ammable uids or sprays for cleaning as the fumes from these
substances can create a re hazard or explosion.
- Never clean the appliance with a steam cleaner. Moisture could
accumulate in the electrical components, the danger of electric shock!
Hot vapors can lead to the damage of plastic parts.
- The appliance must be completely dry before it is placed back into
service.
- Ethereal oils and organic solvents can attack plastic parts, e.g. lemon
juice or the juice from orange peel, or cleansers that contain acetic
acid. Do not allow such substances to come into contact with the
appliance parts.

Retro Fridge - English manual 16
EN
TROUBLESHOOTING
Problem: The fridge doesn’t work.
Solution:
- Check that the appliance is switched on.
- Check that there has not been a power cut.
- Check that the plug is not faulty .
- Check that the fuse has not blown.
- Check that the voltage is correct for the appliance.
- Are there any faults with the socket? For this purpose, try the plug
of your appliance by connecting it to a socket which you are sure is
working.
Problem: The temperature inside the appliance is not cold enough.
Solution:
- Check that there is not too much food in the appliance.
- Check that the thermostat is set to a suitable temperature.
- Check that the appliance is not placed in direct sunlight, or too near to
a heating source.
- Check that the ambient temperature is within the operation limits of the
appliance.
- Are the doors of the appliance opened frequently? Once the door is
opened, the humidity found in the air in the room enters the appliance,
especially if the humidity levels in the room are very high. The more
frequently the
door is opened in humid conditions the more chance of the build up of
moisture.
- The door is not closed completely.
- The door gasket does not seal properly.
- The cooler does not have the correct clearances at the sides/back.
Problem: The temperature within the appliance is too cold.
Solution:
- Increase the working temperature by adjusting the thermostat to
a lower setting. The highest setting should only be used as a rapid
cool setting and should only be set 2 hours before a large amount of
food is placed in the fridge. If this is not done the temperature in the
fridge compartment could fall below 0°C as the compressor will run
continuously.

Retro Fridge - English manual 17
EN
Problem: Moisture forms on the inside or outside walls of the fridge.
Solution:
- Hot and humid weather increases the internal rate of frost build—up.
This is normal.
- Open the door less often and make sure it is always properly closed.
Problem:The outer surfaces of the appliance are wet.
Solution:
- Condensation will from on the outside of the cooler if it operates in
moist areas, simply wipe it dry.
Problem: Smell/odour.
Solution:
- Check all the food and drink that is in the fridge is in date and
correctly packaged. If it isn’t then it should be removed immediately or
repackaged. Check for spillages on each shelf, rack and drawer. You
may need to remove the drawers to check that no spillages have settled
underneath them. Spillages that have not been cleaned and have been
left can cause smells and unwanted odours.
Problem: The doors do not close properly.
Solution:
- Ensure there are no obstructions preventing door closure.
- Check the door compartments and shelves are correctly in place.
- Check the door seal is not warped or torn.
- Check the appliance is level.
Problem: Unusual noises.
Solution:
- Check that the appliance is on a at, level surface and is stable.
- Check the spacing’s around the appliance and ensure it is not
touching other items.
- Bubbling and gurgling sound:• This noise is emitted as the
coolant uid ows through the pipes within the system. This is normal.
-Water owing sound: • This is the normal sound of water
owing into the drain trough during the defrosting process.
- If the appliance is operating noisily (compressor noise): This is normal.
This noise indicates that the compressor is operating normally. As the
compressor is being energized, it might run a bit more noisily for a
short period of time.
- Contraction and expansion of the inside walls may cause popping
and cracking noises.

Retro Fridge - English manual 18
EN
Problem: The fridge door will not open.
Solution:
- If the door has just been opened, leave it for a few minutes to allow
the air pressure to equalise before trying again.
Problem: The compressor runs continuously.
Solution:
- The temperature is set too cold: select a lower(warmer) setting.
- The door is open, or something is obstructing proper door closure.
- The door gaskets are wom, dirty or damaged.
- Large quantities of food have been added to the fridge.
- The room temperature is hotter than usual.
Problem: The external fridge surface is warm.
Solution:
- The exterior walls can be warmer than room temperature. This is
normal while the compressor works to transfer heat from inside
the fridge cabinet.
GOING AWAY?
- Short vacation: Leave the fridge operating during vacations of less
than a month.
- Long vacation: If you are not going to use the fridge for longer
periods, remove all food and unplug the power cord. Clean and dry
the interior thoroughly. To prevent odor and mold growth, leave the
door open slightly, blocking it open, if necessary. (Restrict children’s
access to the room with the open fridge to avoid creating a child
entrapment risk.)
MOVING THE FRIDGE
- Unplug the fridge and remove all food from the inside. Securely tape
down the drawer and shelves and tape the door shut. Turn the leveling
feet up to the base to avoid damage.
- CAUTION: Never pick up the refrigerator by the door.
- Protect the outside of the unit with a blanket or similar soft material
and make sure the fridge stays secure in the upright position during
transportation.

Retro Fridge - English manual 19
EN
DISPOSAL
Do not dispose of the device in normal domestic waste.
Dispose of the device over a registered waste disposal rm or through
your communal waste disposal facility.
Observe the currently valid regulations. In case of doubt, consult your
waste disposal facility.
WARRANTY
Dear Valued Customer ,
Thank you very much for purchasing a MOA product.
We wish you to inform you that this product is covered by a warranty
which complies with all legal provisions concerning existing warranty
and consumer rights in the country where the product was purchased.
Should you nd any defect or malfunction of your MOA product,
please contact the appropriate Customer Care Center.
Sincerely yours,
The MOA Team

Retro Koelkast - Nederlandse handleiding 20
NL
VOOR HET GEBRUIK
Lees deze handleiding voor gebruik met aandacht.
Sluit het apparaat alleen aan op een geaard stopcontact.
Dit apparaat is alleen voor huishoudelijk gebruik. Bij gebruik van
elektrische apparaten, moeten algemene veiligheidsmaatregelen altijd
opgevolgd worden om brand, elektrische schokken, brandwonden en
andere verwondingen en vormen van schade te voorkomen. Lees deze
gebruiksaanwijzing en veiligheidsmaatregelen zorgvuldig.
BELANGRIJKE
VEILIGHEIDSVOORSCHRIFTEN (1/6)
1. Pas op: kinderen kunnen vast komen te zitten. Voordat u uw oude
apparaat weggooit:
- Verwijder de deuren.
- Laat de planken zitten, zodat kinderen niet in het apparaat kunnen
klimmen.
- Snijd de stroomkabel af (zo dicht mogelijk aan de kant van het
apparaat).
- Heeft het apparaat dat u vervangt een veerslot op de deur of deksel,
maak deze dan onbruikbaar voordat u het apparaat weggooit. Zo kan
het apparaat geen dodelijke val vormen voor kinderen.
2. Zorg dat uw stopcontact en stroomspanning overeenkomen met de
voltage op het label van het apparaat. Verschilt de voltage, neem dan
contact op met de klantenservice en gebruik de koelkast niet.
3. Gebruik geen andere apparaten tegelijkertijd op dezelfde
stroomgroep. Dit kan de groep overbelasten en de zekering of
veiligheidsschakelaar doen springen.
4. Om vuur en elektrische schokken te voorkomen, mag de kabel,
stekker, voeding of de behuizing van de Retro Koelkast voor onder
het keukenblad niet worden ondergedompeld in water of een andere
vloeistof. Stel de elektrische verbindingen niet bloot aan water.
5. Plaats de stroomkabel zo, dat niemand er per ongeluk aan kan
trekken of over kan struikelen.
