MOBILUS C-ZR User manual

User Manual of MOBILUS C-ZR external receiver
www.mobilus.pl

1. GENERAL INFORMATION
Module MOBILUS C-ZR is remotely controllable MOBILUS unit operating in COSMO / COSMO | 2WAY
system, designed for mounting in a wall junction box or wherever there is a need to control blinds.
With it, you can lift and lower the shutters, adjust the angle of the lamellas position, remotely by radio
using dedicated COSMO / COSMO | 2WAY controllers, using the smart home control unit COSMO |
GTW or directly from the connector connected to the module.
2. IMPORTANT INFORMATIONS
• Read the instructions carefully before use.
• When unpacking the unit, make sure that there is no damage in the transport. If so, you
should immediately inform the supplier.
• Read the operating manual carefully before use.
• MOBILUS C-ZR module should be powered by 230 V ~, 50 Hz. Its installation should only
be carried out by persons with electrical qualifications according to the enclosed electrical
diagram in accordance with all applicable regulations.
• The appliance must be installed in place not accessible for children.
• The MOBILUS C-ZR module is designed to work with all COSMO / COSMO | 2WAY series
remote controls, but its full functionality is provided by COSMO | HB, COSMO | HM, COSMO |
HCT and COSMO | GTW smart home control unit.
• The range of the radio control is limited by regulations for maximum power of the remote
control and the conditions of the installation of the equipment. When designing the location
of the remote control, consider limiting the range to about 20m by 2 walls.
• Declaration of Conformity:
We declare under our sole responsibility that the MOBILUS C-ZR complies with the
following European Directives:
1. 2014/53 / EU RED Radio Directive;
2. 2014/30 / EU Electromagnetic Compatibility Directive.
2

3
3. PRODUCT DESCRIPTION
L1
N
PE
230V~ 50Hz
L1
N
PE
230V~ 50Hz
L1
N
PE
230V~ 50Hz
L1
N
PE
230V~ 50Hz
L1
N
PE
230V~ 50Hz
L1
N
PE
230V~ 50Hz
MM
b
a
1. Antenna.
2. Illuminated PROGRAMMING BUTTON P.
3. Connection terminals:
N- Neutral line;
L- phase line;
- UP;
- DOWN;
S1 - switch up;
S2 - switch down;
4. TECHNICAL PARAMETERS
Power supply voltage: 230 V~; 50 Hz.
Radio protocol: COSMO | 2WAY, COSMO.
Frequency:868 MHz.
Signal strength: up to 1 mW.
Range in building: 40 [m]. The range of the radio signal depends on the type of construction,
used materials and placement of units.
Installation location – concealed box �≥ 50 mm.
Working temperature: 0 °C – 40 °C.
Dimensions – 44 x 46 x 19 mm.

5. ENTRY INTO THE MODULE PROGRAMMING MODE
Press and hold a programming button on module MOBILUS C-ZR above 5 sec until the connected
actuator executes one sequence of noticeable and audible micro movements down / up confirming the
entrence of the receiver in the PROGRAMMING MODE. - Fig. 5. In addition, in 1 second intervals the
diode is blinking.
Fig. 2
1 s.
3 x BEP!
WARNING! If within 20 seconds no programming will be performed, the MOBILUS C-ZR radio modu-
le automatically exits from the programming mode. Connected actuator executes one sequence of
noticeable and audible micro movements down / up, blinks are stopped.
6. LOADING THE MASTER-A * CODE TO THE RECEIVER MEMORY
1. Enter the MOBILUS C-ZR PROGRAMMING MODE.
2. Press and hold the STOP and UP buttons simultaneously on the remote control - Fig. 6.
3. The MASTER pilot reads two short beeps from the module.
The MASTER-a code has been loaded into memory and the module goes to the WORK
MODE. Now, with the MASTER remote control, you can operate the units or enter the
PROGRAM MODE to load more remote controls.
4

CONTINUED 6. LOADING THE MASTER-A * CODE TO THE RECEIVER MEMORY
Fig. 6
2 x BEP!
WARNING In the case of a multi-channel remote control
select only one channel to be MASTER.
NOTE For the convenience of programming, it is recom-
mended that each COSMO | C-ZR module had its own
separate MASTER (remote control (separate channel for
multi-channel remotes). Avoid situations where several
COSMO | C-ZR modules remote controls will have com-
mon MASTER (shared channel).
BEEP! BEEP!
MASTER
1 2 3 4 5
5 s.
BEEP! BEEP!
PILOT 2
1 s.
a b
1 2 3 4 5 1 2 3 4 5
*MASTER - remote control or channel (in the case of a multi-channel remotes) loaded first into
the memory of the MOBILUS C-ZR module. Allows you to program further remote controls.
5

7. PROGRAMMING OF THE SECOND AND EVERY OTHER REMOTE CONTROL
1. On the MASTER remote control, simultaneously press and hold the STOP and UP
until the connected actuator performs one sequence of noticeable and audible micro
movements down / up, the module will release three short beeps, confirming entry into the
PROGRAMMING MODE - Fig. 7a.Additionally in this mode every 1 sec. the diode is blinking.
2. On the second remote control (for the multi-channel remote control, select the channel
you want to program), press and hold both STOP and UP buttons simultaneously, until the
connected actuator performs one sequence of noticeable and audible micro movements
down / up, the module will release two short beeps. The remote (channel) was loaded into
the receiver’s memory - Fig. 7b.
Fig. 7
MASTER PILOT 2a b
3x BEP! 2x BEP!
Repeat step 2 to load the next remote control. If, however, no programming operation
is started within 20 seconds, the module automatically returns to operating mode - the
module will output one long beep. Return to operating mode can also be performed
manually using MASTER. In such a situation, press and hold the STOP and UP MASTER
buttons simultaneously at the same time. In both cases, the return to operating mode will
be confirmed by one long beep.
6

8. CHANGING THE DIRECTION OF THE ACTUATOR
1. f you press the UP button on the remote control and the armor goes down, change the
direction of rotation of the drive. At the same time, press and hold:
a ) on the remote control COSMO | HM, | HB buttons STOP and DOWN - Fig. 8b;
b ) on the remote control COSMO | HCT buttons UP and F3 - Fig. 8c;
until the drive executes one sequence of micro down / up moves.
2. Check the UP / DOWN buttons - Fig. 8d.
Fig. 8
a db c
9. C-ZR MODULE RESET - FACTORY SETTINGS
WARNING!!! RESTORATION OF FACTORY SETTINGS erases all programmed remotes from the
MOBILUS C-ZR module.
1. Enter the PROGRAMMING MODE for the MOBILUS C-ZR module - Fig. 9a.
2. In the PROGRAMMING MODE, press and hold the programming key above 5 seconds - Fig.
9b. All previously loaded remote modules have been removed from the memory module
which confirms one sequence of noticeable and audible micro moves down / up of the
connected actuator and three long beeps.
7

CONTINUED 9. C-ZR MODULE RESET - FACTORY SETTINGS
Fig. 9
a b
5 s.
3x BEP! 3 X BEEEP!
10. REMOVAL OF INDIVIDUAL REMOTES (CHANNELS)
It is possible to delete only one of the programmed remotes (not for MASTER remote). To do
this:
1. On the MASTER, press simultaneously and hold the STOP and UP buttons until the connected
actuator executes one sequence of noticeable and audible micro movements down / up, the
module will release two short beeps, confirming the receiver’s entrance into the programming
mode - Fig. 10a.Additionally in this mode every 1 sec. the diode is blinking.
2. On the remote control (channel) that you want to delete, press and hold the STOP and UP
buttons simultaneously until the connected actuator performs one sequence of noticeable
and audible micro movements down / up, MOBILUS C-ZR receives two long beeps
onfirming the removal of the pilot code from the actuator memory - Fig. 10b.
Fig.10
MASTER PILOT 2a b
3x BEP! 2x BEEEP!
8

CONTINUED 10. REMOVAL OF INDIVIDUAL REMOTES (CHANNELS)
WARNING! Repeat step 2 to proceed to remove the next remote control. However, if within
20 sec. no programming operation is started, the receiver automatically returns to operating
mode. Return to operating mode can also be performed manually using the MASTER. In such
a situation, simultaneously press and hold the STOP and MASTER buttons until the connected
actuator executes one sequence of noticeable and audible micro movements down / up. In
both cases, the return to operating mode will be through one sequence of micro down / top
moves of the connected actuator.
11. CONNECTING THE ADDITIONAL SWITCH / DRIVER
It is possible to connect an external keyboard connector (without support) - Fig. 11. They must be
connected according to the attached diagram.
Fig. 11
L1
N
PE
N
PE
230V~ 50Hz
a
b
L1
N
PE
N
PE
230V~ 50Hz
a c
b
L1
N
PE
N
PE
230V~ 50Hz
a
b
L1
N
PE
N
PE
230V~ 50Hz
a c
b
c
9

12. CONTROL OF THE POSITION OF THE SHUTTER AND SLOPE OF THE LAMELLAS - CONNECTOR
Control of the position of the shutter up / down. Briefly pressing the key corresponding to the
direction will lower or raise the louver to the appropriate end positions. The operation stops
after a short press of the opposite key to the current shutter motion.
Lamella’s slope control. Long holding down one of the connector keys will cause the lamella to
rotate slowly. If the lamella is in the required position, release the key.
13. CONTROL OF THE POSITION OF THE SHUTTER AND SLOPE OF THE LAMELLA
- REMOTE CONTROL
You can control the position (up / down) of the shutter with all COSMO | 2WAY remotes.
Full control, along with the possibility to set the slope of the lamella is provided only by the
following remote controls: COSMO | HM, COSMO | HB, COSMO | HCT.
Appropriate operating mode should be setted.
For remotes COSMO | HM, COSMO | HB.
1. Press / to activate the remote control.
2. Press the P2 function key located on the rear of the controller - Fig. 10.
3. Set II operating mode - two blue LEDs will light up.
Fig. 10
P2P1
I II III
For remotes COSMO | HCT (for software from 2.4.0-4.0)
1. Go to the SETTINGS tab -> OTHER -> OPERATION MODE.
2. Select II OPERATION MODE.
3. Save settings.
10

11
CONTINUED 13. CONTROL OF THE POSITION OF THE SHUTTER AND SLOPE OF
THE LAMELLA - REMOTE CONTROL
Control of the up / down position of the shutter. Briefly pressing the button corresponding to
the direction / UP / DOWN will lower or raise the shutter to the appropriate end positions.
The operation is stopped after a short press of the STOP button .
Lamellas slope control. Long pressing of one of the remote control / UP / DOWN buttons will
cause the lamella to rotate slowly. If the lamella is in the required position, release the button.
14. REPEATER FUNCTION
SIGNAL REPEATER - This feature allows you to expand the radio control area. The MOBILUS C-ZR mo-
dule with the repeater function enabled receives signals from the controller or actuators and passes
them forward. Thanks to the furthest located receivers which are not within the controller can receive
and transmit information through modules located indirectly. Turn on the repeater function:
1. Press the STOP and UP buttons simultaneously on the MASTER until the connected actuator executes
one sequence of noticeable and audible micro movements down / up, the MOBILUS C-ZR module will
issue three short beeps confirming entry into the PROGRAMMING MODE. Additionally in this mode
every 1 sec. the diode is blinking.
2. On the remote control, press the button sequence: UP, STOP, DOWN, UP, STOP, DOWN. Activation of
the repeater function will cause three sequences of DOWN-UP micro-movements by the actuator, in
addition, it will output the sequence of audio signals from the module: 3 short, 3 short, 1 long. - Fig. 14c.
3. Repeat step 1 to deactivate the repeater function. Then press the button sequence: UP, STOP,
DOWN, UP, STOP, DOWN -confirmation of deactivation is the execution of two sequences of
micro-DOWN-UP movements by connected actuator and release of sequence of sound signals
from the module: 3 short, 1 long - Fig.14d.
WARNING! Turn on the repeater function only on devices that are within range of the signal
range. Because of the efficient work, we recommend that you enable the signal repeater
function on up to three devices in the facility. Unreasonable inclusion of signal repeater on
many devices may cause interference in all radio equipment.

CONTINUED 14. REPEATER FUNCTION
Fig. 14
b
MASTER
a
2X
3 x BEP
c d
3x BEP, 3x BEP,
1x BEEEEP
3x BEP, 1x BEEEEP
15. BIDIRECTIONALITY
MOBILUS C-ZR with two-way communication with the remote control allows control of the
state of shutter position ( eg. open, closed, intermediate level ).
Proper operation of bidirectional communication requires the use of pilots with bidirectional
communication.
Remote controls supporting two-way communication: MOBILUS COSMO | HCT, COSMO | G3+,
COSMO | HM, COSMO | HB, COSMO | WT9, COSMO | WT.
12

13
16. BI-DIRECTIONAL - INFORMATION ABOUT THE POSITION OF THE SHUTTER
The MOBILUS C-ZR transmits information to the remote control about the shutter position and
the intermediate position, as well as the angle of the lamellas (for the COSMO | GTW). Mode is
automatically turned on - there is no deactivation.
17. BI-DIRECTIONAL - OVERLOAD INFORMATION
MOBILUS C-ZR transmits information to remotes about overload - for example, it may be
related to a housing lock occurring at the time of raising or lowering. Mode is factory-setted - it
is possible to turn off.
Enable / disable of overload detection:
1. At the MASTER remote control press and hold the STOP and UP buttons simultaneously
until the connected actuator performs one sequence of noticeable and audible micro
movements down / up confirming the receiver input into the programming mode - Fig. 17a.
Additionally in this mode every 1 sec. the diode is blinking.
2. On the MASTER, press the STOP button and hold until the actuator connected to the
MOBILUS C-MR module will perform two sequences of noticeable and audible micro
movements down / up. Overload detection active - Fig. 17b.
3. To stop the overload detection, repeat step 1. Then press the STOP button on the MASTER
control and hold until the actuator connected to the MOBILUS C-ZR module will perform 1
sequence of noticeable and audible micro moves down / up - Fig. 17c.
Fig. 14
b
MASTER
a
2x
c

18. SETTING OF THE SWITCHING TIME OF RELAYS
MOBILUS C-ZR allows you to change the relay switching time. This operation is necessary, for
example, for very high shutters. By default this time is 120 seconds.
1. Press MASTER at the same time and hold the STOP and UP buttons until the connected
actuator performs one sequence of noticeable and audible micro movements down / up,
confirming the receiver entry into the programming mode - Fig. 18a.Additionally in this mode
every 1 sec. the LED flashes.
2. On the MASTER, press the UP button - Fig. 18b.The blind will begin to rise.
3. At the moment when the user presses the STOP key, the new relay operating time is
saved - Fig. 18c.
Fig.18
b
MASTER
a
c
14

15
19. CHANGING THE MODULE OPERATING MODE
The COSMO C-ZR module allows you to work in 3 modes. Set the appropriate operating mode
depending on which tubular motor the module is connected to. By default, the module works in
I mode. In order to change the operating mode, you must:
1. Enter the MOBILUS C-ZR PROGRAMMING MODE.
2. In PROGRAMMING MODE, press the programming button 3 times.
3. The module will make an audible signal, and the connected tubular motor will perform
a sequence of up / down movements. Repeating the above operation will change the
module’s operating mode.
I operating mode (1x beep - 1x sequence of movements) - for actuators with mechanical
limiters
II operating mode (2x beeps - 2x movement sequences) - for actuators with electronic limiters
- 90 degrees
III operating mode (3x beeps - 3x movement sequences) - for actuators with electronic limiters
- 180 degrees
20. ENVIRONMENTAL PROTECTION
This appliance is marked according to the European Directive on Waste Electrical and Electro-
nic Equipment (2002/96/EC) and further amendments. By ensuring this product is disposed
of correctly, you will help to prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of this
product. The symbol on the product, or the documents accompanying the product, indicates
that this appliance may not be treated as household waste. It shall be handed over to the ap-
plicable collection point for the waste electrical and electronic equipment for recycling purpose.
For more information about recycling of this product, please contact your local authorities,
your household waste disposal service or the shop where you purchased the product.

MOBILUS MOTOR Spółka z o.o.
ul. Miętowa 37, 61-680 Poznań, PL
tel. [phone], fax [phone]
VAT NO. PL9721078008 www.mobilus.pl
Wersja 1.1ENG, 170714
