This Quick Start Guide will walk you through the steps
of connecting ScreenBeam MoCA Network Adapter
to expand your Internet coverage.
MoCA Network Adapter
Quick Start Guide
Package Contents:
ECB7250
©2021 ScreenBeam Inc.
©2021 ScreenBeam Inc. and the ScreenBeam logo are trademarks or registered
trademarks of ScreenBeam Inc. in the U.S. and/or other countries. All other names
or marks referenced are the names or marks of their respective owners. Product
photo may differ from actual product. However, functionality remains as stated.
Specifications are subject to change without notice.
PN 0530-0858-001
Congratulations! You’ve successfully connected your
device to the Internet.
Additional MoCA Network Adapters may be purchased
and connected to other devices needing an Ethernet
connection and that are near a coaxial port.
Tech Support
For registration or access to user manuals, wall-mount
templates, software updates, etc. visit our webpage:
retailsupport.screenbeam.com
Connect ScreenBeam MoCA
aLocate an available Coax Outlet in the area you would like
to expand your Internet.
NOTE: Use a MoCA splitter (not included) if there is an existing device
using the coax connection (i.e., Set-top box or TV).
bConnect the coaxial cable from the Coax Outlet to the ECB7250
Adapter’s Coax In port.
cConnect the power for the ECB7250 Adapter.
dWait until both the Power and Coax lights turn GREEN.
eECB7250 Adapter is now bridged to your existing network.
fConnect the Ethernet Cable from the Network Adapter
to a Networking Device of your choice.
MoCA-ready network
MoCA Network Adapter2
Power
Ethernet Cable
Coaxial wiring
behind the wall
Coax Ethernet
Power
Power
Coax
Coax In
ECB7250
MPS
Notes: A MoCA splitter is required if there is
an existing device using the coax connection.
IMPORTANT: An existing MoCA-ready network or another ECB7250
Adapter is required. Internet availability should be delivered from your
Internet service provider device (i.e., Cable or Fios modem/router).
