MODOS S5 User manual

instructions
more info and other congurations at
123
www.modos.io
You’re done,
high five!
A x 8
15-3/4” x 12”
B x 20
7-7/8” x 12”
M3 x 24
M1 x 8
M2 x 8
what’s in the box
how to
line connector up with boardfind a friend to help slide connector onto board
assembly instructions
Shelf S5
55 3/4”
52”
Assemble vertical groups (G1, G2, G3, G4)
using only B boards and the illustrated connectors.
Starting with the lowest boards attach all A boards:
Attach (3) A boards to G1/ attach G2/
Attach (2) A boards to G2/ attach G3/
Attach (2) A boards to G3/ attach G4
G1
G2
G3
G4
12”
7-7/8”
G1
G2
G3
G4
