Module Electronic KNX LC-S.1 User manual

KNX LINE COUPLER
LC-S.1
BASIC INFORMATION
The KNX line coupler provides a bi-directional data connection between two KNX TP lines or areas and works as
a KNX network. KNX TP main line and KNX TP subline are coupled having a galvanic isolation in between.
• Various routing filter for group and individual telegrams
• Temporary disabling of routing filter via button
• Long telegrams with up to 240 bytes APDU length are supported
• LED status indication
• Galvanic isolation of connected lines
• Integrated ACK generator
• Power supply via KNX bus
• Low power consumption
• DIN rail 35mm mounting
A. Function button B. Programming button C. KNX TP main line connector D. KNX TP subline connector
1. LED bus state KNX TP (main line) 2. LED bus state KNX TP (subline) 3. LED telegram traffic KNX TP (main line)
4. LED telegram traffic KNX TP (subline) 5. LED group address routing 6. LED physical address routing
7. Programming LED
page 1
B
7
D
A
4
2
1
3
C
56
PASSPORT
МГРЛ-27.12.1931-007.01 ПС
Module Electronic LLC
module-electronic.ru, [email protected]
phone: [phone]

1. Bus state KNX TP (main line)
Green: Main line OK
Orange: Manual function active
2. Bus state KNX TP (subline)
Green: Subline OK
OFF: Subline not connected
3. Telegram traffic KNX TP (main line)
Green (blinking): Telegram traffic
Red (blinking): Transmission error
OFF: No telegram traffic
4. Telegram traffic KNX TP (subline)
Green (blinking): Telegram traffic
Red (blinking): Transmission error
OFF: No telegram traffic
5. Group address routing*
Green: Filter table active
Orange: Route all
Red: Block all
OFF: Routing of group telegrams is different on main line and
subline
6. Physical address routing
Green: Filter table active
Orange: Route all
Red: Block all
OFF: Routing of physical telegrams is different on main line
and subline
7. Programming
Red: Programming mode active
OFF: Programming mode not active
Device model
LC-S.1
KNX interfaces (Main, Sub)
Specification
TP-256
Available application soware
ETS 4 and later
KNX connector
4-wire EIB connector (PUSH WIRE spring clips) for standard
cable TP1 0,8мм Ø
KNX physical address by default
15.15.0
Power supply
via KNX bus: 21...30В DC
Consumption on the KNX bus (29V DC)
< 10mA
< 300mW
Operation temperature
-5°C ... + 45°C
Operation humidity
5 ... 95% (no condensation)
Degree of protection
IP 20, clean environment
Mounting type
DIN rail 35mm
Dimensions
36 х 90 х 71mm (2TE)
Weight
62g
page 2
LED INDICATION
SPECIFICATIONS
* only group telegrams with main groups 0...13

page 3
LC-S.1
+
-
KNX bus (Sub)
MAIN SUB
+
-
KNX bus (Main)
PASSPORT
МГРЛ-27.12.1931-007.01 ПС
INSTALLATION
Attaching to DIN rail
Removing from DIN rail
WIRING DIAGRAMS

page 4
SAFETY INSTRUCTIONS
ATTENTION! Installation and connection of the device to the mains must only be carried out by
qualified personnel! Be sure to turn off the power before installing or removing the device! The design
of the device meets the requirements of electrical safety according to GOST 12.2.007.0-75.
SETTING INSTRUCTIONS
The device is set up in accordance with the instruction manual. (The full manual and application program can be
downloaded at https://module-electronic.ru/documents or by scanning the QR code at the bottom of the
document).
TRANSPORTATION, STORAGE AND DISPOSAL
The conditions for the transportation of devices must comply with conditions 5 of GOST 15150-69.
Storage of devices in packaging at the warehouses of the manufacturer and consumer must comply with storage
conditions 1 in accordance with GOST 15150-69. Aer transportation or storage at low temperatures, it is
necessary to withstand the device at room temperature for at least 2 hours before turning it on. Do not dispose
of the device with household waste.
WARRANTY
Warranty period - 12 months from the date of sale to the consumer. The manufacturer is not liable and does not
indemnify for damage caused by the fault of the consumer in case of non-compliance with the conditions of
transportation, storage, installation and operation, as well as in case of violation of the seal when trying to repair
the device yourself.
All the necessary information on the warranty can be obtained by the consumer by calling Module Electronics or
on the website: www.module-electronic.ru.
Serial number
Made in Russia
Name, address of the trading organization
Date of sale
Seller Signature
seller's stamp
