Moffat Waldorf GP8600G-LS Instruction Manual

Technical data sheet for
GAS GRIDDLE 600mm
GP8600G-B, GP8600G-CB, GP8600G-LS
Heavy-duty thermostatic gas griddle
20mm thick griddle plate
Ribbed plate options
Chromed mirror plate options
Top weld sealed plates
53MJ thermostatic burner system
3 models of base unit
Stainless steel exterior
Easy clean
Easy service
Fully modular
Controls
• 90-300˚C thermostat
• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob
• Flame failure pilot burner
• Piezo ignition to pilot burner
Cleaning and Servicing
• All models with easy clean stainless steel external finish
• Plate is finished front and rear with overlap construction to remove
cleaning traps
• Control service and gas conversion through front of unit
• Burner service requires plate removal
Overall Construction
Griddle
• 20mm thick machined top plates standard
• Optional ribbed plate sections
• Optional mirror finish hard chrome plates
• 2.5mm thick 304 stainless steel splash guards sides and rear
• 2.0mm thick grease channel
• 53MJ single 4 bar even heat burner with single thermostatic control
• Full pilot and flame failure protection with piezo ignition
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Splashback and side panels 1.2mm 304 stainless steel
• Front panels 0.9mm 304 stainless steel
• Stainless steel grease drawer
• Overlapping finish at front and rear of plate for easy clean
Bench mount (supplied as –B model)
• Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs
with adjustable feet.
• Adjustable height 80mm – 105mm
Cabinet base (supplied as –CB model)
• Fully modular for match suite finish
• Double skin 0.9mm 304 stainless steel interior and exterior
• Optional GN 1/1 4 position racking kit (1 or 2 cabinet bays)
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
Leg stand (supplied as –LS model)
• Fully modular for matched suite finish
• Framed top for connection to Griddle
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
• Fully modular framed stand shelf with 0.9mm 304 stainless steel finish
• Suitable for rear or through shelf gas connection to Griddle
• Quick assembly design (no tools required)
GP8600G-LS

Australia
Moffat Pty Limited
Victoria/Tasmania
740 Springvale Road
Mulgrave, Victoria 3170
Telephone 03-951 3
Facsimile 03-951 3 33
[email protected]
New South Wales
Telephone [phone]
[email protected]
South Australia
Telephone 03-951 3
[email protected]
Queensland
Telephone [phone]
[email protected]
Western Australia
Telephone [phone]
[email protected]
New Zealand
Moffat Limited
Christchurch
Telephone [phone]
[email protected]
Auckland
Telephone [phone]
[email protected]
Australia
www.moffat.com.au
New Zealand
www.moffat.co.nz
ISO9001
All Waldorf products are designed and
manufactured by Moffat using the
internationally recognised ISO9001 quality
management system covering design
manufacture and final inspection ensuring
consistent high quality at all times.
ISO9001
Quality
Management
Standard
Designed and manufactured by
In line with policy to continually develop and
improve its products Moffat Limited reserves
the right to change specifications and design
without notice.
Specifications
Burner
4 bar chromed steel burner with pilot, flame
failure and piezo ignition
Gas power
53MJ/hr, 14.7kW
Plate
Cooking surface 592mm x 530mm, 3138cm2
Gas connection
R 3/4(BSP) male
130mm from RH side, 35mm from rear,
and 655mm from floor
All units supplied with Natural and LP gas regulator
Dimensions
Bench models
Width 600mm
Depth 805mm
Height 315mm
Incl. splashback 530mm
All models (excluding Bench model)
Width 600mm
Depth 805mm
Height 915mm
Incl. splashback 1130mm
Packing data
Bench and Leg Stand models
0.37m3
Width 640mm
Depth 865mm
Height 665mm
Cabinet Base models
0.70m3
Width 640mm
Depth 865mm
Height 1255mm
Gas types
Available in Natural gas and LP gas
Please specify when ordering
Units supplied complete with gas type
conversion kits
Other gas types on request
Options at extra cost
Joining caps
Castors
Plinth mounting
Ribbed plate options
Chrome plate options
GP8600G-B
Bench Model
GP8600G-CB
Cabinet Base
GP8600G-LS
Leg Stand
Printed in New Zealand
© Copyright Moffat Limited
Moffat/4639/BH/1M/8.05
Technical data sheet for
GAS GRIDDLE 600mm
Plan
