Moffat turbofan E32SUBC User manual

© Moffat Ltd, September 2009
Revision 3
E32SUBC OVEN and PROOFER
E32SUBC
Oven and Proofer
Service Manual

© Moffat Ltd, September 2009
Revision 3
E32SUBC OVEN and PROOFER
ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED OUT BY
QUALIFIED PERSONS ONLY.
WARNING:
MAKING ALTERATIONS MAY VOID WARRANTIES AND APPROVALS.
IMPORTANT:

© Moffat Ltd, September 2009
Revision 3
E32SUBC OVEN and PROOFER
This manual is designed to take a more in depth look at the E32SUBC for the purpose of making the units
more understandable to service people.
There are settings explained in this manual that should never require to be adjusted, but for completeness
and those special cases where these settings are required to change, this manual gives a full explanation
as to how, and what effects will result.
Section Page Number
1. Specifications.............................................................................................1
2. Installation ................................................................................................2
3. Operation...................................................................................................3
3.1 Description of Controls
3.2 Operation / Flow Charts
3.3 Field Adjustable Settings
4. Cleaning / Maintenance ..........................................................................19
4.1 Cleaning Oven
4.2 Cleaning Proofer
4.3 Routine Maintenance
5. Trouble-shooting Guide...........................................................................21
5.1 Controller Error Messages
5.2 Trouble Shooting Charts - Oven and Proofer
5.3 Fault Diagnosis - Oven
5.4 Fault Diagnosis - Proofer
6. Service Procedures ..................................................................................30
6.1 Access
6.2 Replacement - Oven
6.3 Replacement - Proofer
6.4 Adjustment / Calibration
7. Accessories ..............................................................................................45
8. Replacement Parts ..................................................................................46
9. Circuit Schematic.....................................................................................55
10. Wiring diagram........................................................................................57
11. Service Contacts ...................................................................................... 59
12. Reference ................................................................................................61
Controller Settings
Fault Codes
Contents

© Moffat Ltd, September 2009
Revision 3
E32SUBC OVEN and PROOFER

Revision 3
© Moffat Ltd, September 2009
E32SUBC OVEN and PROOFER
1
1
Specifications
E
1720 (67.71")
MWS
810 (31.89")
E
ELECTRICAL ENTRY
1000 (39.37")
80 min (3.15")
710 (27.95")
SCAN
50 min (1.97")
DOOR SWING
535mm (21.06")
MINIMUM
INSTALLATION
CLEARANCE
MINIMUM
INSTALLATION
CLEARANCE
E
MWSCOLD WATER CONNECTION
610 (24.02")
117.5 (4.63")
1000 (39.37")
70 (2.76")
645 (25.40")
810 (31.89")
1720 (67.71")
E
355 (13.98")
MWS
MWS
50 (1.97")
Dimensions
Oven internal dimensions
Width 468 mm / 18.5”
Height 533 mm / 21”
Depth 711 mm / 28”
Oven Volume 0.18 m³ / 6.3 ft³
Proofer internal dimensions
Width 460mm / 18”
Height 675mm / 265/8”
Depth 700mm / 275/8”
Proofer Volume 0.22m³ / 7.8ft³
Rack size
Width: 460 mm / 18”
Depth: 660 mm / 26”
No of rack positions: 4
Rack position spacing: 125 mm / 5”
Electrical supply
400-415 VAC, 3P+N+E, 50 Hz, 7.0 kW
Water supply
Max Pressure 550 kPa / 5.5 bar / 80 psi
Min Pressure 100 kPa / 1.0 bar / 15 psi

2
2
Installation
Revision 3
© Moffat Ltd, September 2009
E32SUBC OVEN and PROOFER
2.4 Water connection
ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED OUT BY
QUALIFIED PERSONS ONLY.
WARNING:
2.3 Electrical connection
2.1 Installation requirements
2.2 Location clearances
2.5 Before use
It is most important that this oven /
proofer is installed correctly and that the
operation is correct before use.
Installation shall comply with local
electrical, health and safety requirements.
Before Connection to Power Supply:
• Remove all packing.
• Check equipment and parts for damage.
Report any damage immediately to the carrier
and
distributor.
• Remove protective plastic coating from the
side panels.
Check that the available power supply is correct
to that shown on the rating plate located on the
right-hand side panel.
To ensure correct ventilation for the motor and
controls the following minimum installation
clearances are to be adhered to:
• Use a spirit level to ensure oven / proofer is
level from side to side and front to back. (If
this is not carried out, uneven baking could
occur).
Important:
THE VENT LOCATED ON THE OVEN TOP MUST
NEVER BE OBSTRUCTED.
• E32SUBC oven / proofers are supplied fitted
with power cords. Ensure unit is fitted with
correct cord and plug.
• To access the electrical connection terminal
block, grounding lug and strain relief, remove
the right hand side panel.
WARNING - THIS APPLIANCE MUST BE
EARTHED / GROUNDED
• A cold water supply should be fitted to the
water inlet hose (connection size R¾).
• Max inlet pressure 550kPa / 80psi.
• Turn on water supply to check for leaks.
• Operate the oven for about 1 hour at 200°C
(400°F) to remove any fumes or odours which
may be present.
Top 200 mm / 8”
Rear 50 mm / 2”
Left-hand side 0 mm / 0”
Right-hand side 80 mm / 3”
380-415 Vac, 50/60 Hz, 3P+N+E, 7.0 kW @ 415V.
208 Vac, 50/60 Hz, 3P+E, 7.0 kW @ 208V.
220-240 Vac, 50/60 Hz, 3P+E, 7.0 kW @ 240V.

3
3
Operation
Revision 3
© Moffat Ltd, September 2009
E32SUBC OVEN and PROOFER
3.1 Description of Controls
NOTE: A full user’s operation manual is supplied with the product and can be used for further
referencing of installation and operation.
Display Screen
A full graphical display screen which will display all relevant
information relating to both oven and proofer during operation:-
The left hand Screen - Oven:-
Will display all information relating to the oven during
programming and operation.
Navigation Keys
Used to change the parameters during the
Programming Mode only.
Used to scan through the Oven programmes
selected, during the Cooking Mode and to
change menu’s during the Programming Mode..
Programming Key
Press for 3 seconds to access programming
mode for Oven Program Keys.
Programme Indicator:
Illuminates when in program mode.
Oven Keys
Oven Temp Check Key:
Press to check oven set and actual temperature
at any time.
Oven Programme Keys (Keys 1 to 5):
Press once to call up program (LED ON).
Press again to start program (LED flashes).
Press and hold for 2 seconds to cancel program.
Oven + 1 Minute Key:
Press to increase the cooking time in one
minute increments.
Oven On / Off Key:
Turns the Oven only On / Off.
3.1.1 E32SUBC oven

4
3
Operation
Revision 3
© Moffat Ltd, September 2009
E32SUBC OVEN and PROOFER
Display Screen
A full graphical display screen which will display all
relevant information relating to both oven and proofer
during operation:-
The right hand Screen - Proofer:-
Will display all information relating to the
proofer during programming and
operation.
Navigation Keys
Used to change the parameters during the
Programming Mode only.
Used to scan through the Proofer
programmes selected, during the Proofing
Mode and to change menu’s during the
Programming Mode.
Programming Key
Press for 3 seconds to access change of
Proofer temperature and humidity settings.
Also accesses Programming Mode for Proofer
Timer Keys.
Programme Indicator:
Illuminates when in program mode.
Proofer Keys
Proofer Temp / Humidity Check Key:
Press to check proofer set and actual
temperature and humidity at any time.
Proofer Timer Keys:
Press once to call up timer (LED ON).
Press again to start timer (LED flashes).
Press and hold for 2 seconds to cancel timer.
Proofer + 1 Minute Key:
Press to increase the proofing time in one
minute increments.
Proofer On / Off Key:
Turns the Proofer only On / Off.
3.1.2 E32SUBC proofer

5
3
Operation
Revision 3
© Moffat Ltd, September 2009
E32SUBC OVEN and PROOFER
TURN ON / PREHEAT
Press ON / OFF key.
PROOFER READY
LOAD PROOFER
START TIMER
– Press Proofer key
NEXT LOAD
START TIMER
– Press Proofer key
TIMER DONE
UNLOAD PROOFER
CANCEL ALARM
– Press timer key
TIMER DONE
UNLOAD PROOFER
CANCEL ALARM
– Press timer key
20 MINS
NEXT LOAD
START TIMER
– Press Proofer key
TIMER DONE
UNLOAD PROOFER
CANCEL ALARM
– Press timer key
20 MINS
20 MINS
20 MINS
20 MINS
3.2 Operation / Flow Charts
3.2.1 Proofer
NOTE: Proofer display will always show timer status of the timer with the least remaining
time.
20MINS TIME-UP
Load Proofer with next load.
20MINS TIME-UP
Load Proofer with next load.
20MINS TIME-UP
Load Proofer with next load.

6
3
Operation
Revision 3
© Moffat Ltd, September 2009
E32SUBC OVEN and PROOFER
3.2.2 Oven
TURN ON / PREHEAT
Press ON / OFF key
OVEN READY
LOAD OVEN
START
– Press program key
BAKE PROGRAM DONE
UNLOAD OVEN
CANCEL ALARM
– Press program key
SELECT DIFFERENT PROGRAM
Press program key
TEMP STATUS
OR
OVEN READY
